Summary of Contents for Blata Minibike 2.5
- Page 1 MINIBIKE...
-
Page 3: Safety Warning
SAFETY WARNING Always pay attention to the instructions and safety warnings below This manual contains important safety information and instructions which should be read carefully before operating the vehicle. For your own safety and the safety of others follow these rules. Neither manufacturer nor distributor is responsible for injuries caused by unsafe and improper use of the vehicle. -
Page 4: Table Of Contents
M I N I B I K E 2,5 SERVICE MANUAL FOR USE AND MAINTENANCE OF MINIBIKE Before starting the operation of your Minibike, read thoroughly these directions. CONTENTS PAGE INTRODUCTION ......................2 BASIC TECHNICAL DATA ....................2 UNPACKING AND BASIC CONTROLS - FIG. 1 ............3 SAFETY..........................3 BEFORE STARTING ....................... -
Page 5: Introduction
Children only under the supervision of a grown - up and responsible person. If the terms of a track are fulfilled, the Minibikes can be used for races. Minibike Blata should not be used during winter season and under bad weather conditions. Usage under these conditions leads to abnormal mechanical wear and corrosion of most minibike parts - especially those directly exposed to climatic influences. -
Page 6: Unpacking And Basic Controls - Fig. 1
UNPACKING AND BASIC CONTROLS: The Minibike is packed and delivered with folded handlebars and levers mounted on them. After unpacking, set up the handlebars in such a function position that will suit you best. However at maximum handlebars turning, the brake levers must not bump into the lining. -
Page 7: Starting The Engine - Fig. 2
STARTING THE ENGINE To be done only on the starting stand - Fig. 2. After opening the tank filling hole, fill the tank with fuel and close it by screwing - in cap.Open the petrol supply cock by turning the small lever into position “ON”, Fig.3. Set the choke lever into position “C”... -
Page 8: Ride
RIDE After mounting the Minibike and slow turning the acceleration handle, you are starting your ride. Before braking, turn back the acceleration handle and depress slightly the front brake lever and then the rear brake lever. Beware of the wheels not to get them in skid. The Minibike engine will be switched off by pusching the red pusch - buttom of the stop switch on handlerods. -
Page 11: Parts List
MINIBIKE - 2,5 110.000.00 MINIBIKE 2,5 510.002.00 STARTER COMPLETE ENGINE 510.003.00 STARTER ROPE 110.001.00 ENGINE COMPLETE 510.004.00 HOLDER 110.001.01 510.005.00 ENGINE PROPER HOLDER 110.002.00 CARBURETTER SHA 1412L 510.006.00 GUIDE BUSH 110.004.00 PISTON COMPLETE - A 510.007.00 STARTER CASE 110.004.01 PISTON COMPLETE - B 510.008.00 STARTER SPRING 110.004.02... - Page 12 LINING 119.009.00 TANK 114.001.01 LINING COMPLETE, NON VARNISHED 119.010.00 SCREW CAP 114.002.30 LINING COMPLETE, VARNISHED 119.011.00 RUBBER FOR FRAME 114.003.01 FRONT LINING, NON VARNISHED 119.012.00 GAS TUBE 114.004.00 SADDLE, NON VARNISHED 119.013.00 HOSE CLAMP 114.005.00 FRONT FENDER, NON VARNISHED 119.020.00 STAND 114.006.30 FRONT LINING, VARNISHED...
-
Page 13: Front And Rear Brakes - Fig. 7
916.072.02 916.072.02... -
Page 14: Adjusting The Brakes - Fig. 4
ADJUSTING THE BRAKES Small incremental brake adjustment : Free play at the handlebar lever is effected by turning the knurled end on the cable adjustor. This will allow the lever to be set at the nominal to ¼ inch of free lever movement. -
Page 15: Dismanteling And Mounting The Rear Wheel - Fig. 5
DISMANTLING AND MOUNTING THE REAR WHEEL, FIG. 5 Unscrew the rear axle nut 920.011.01 and loosen the nuts 920.009.01 on chain tighteners. Shift the wheel forward and remove the chain. At pulling out the wheel axle, secure the rear wheel two distance rollers fall out. The wheel mounting to be carried out in reverse sequence. -
Page 16: Non Use And Storage Procedure
Date, stamp and signature of the dealer: The entire construction solution for minibike and used disc brakes are protected by industrial design. No part of this publication may be reproduced without an explicit consent of BLATA COMPANY ! COPYRIGHT © BLATA 2006...
