JAI Spark SP-5000M-GE2 User Manual

Jai spark series 5m digital progressive scan monochrome and color camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Spark Series
User Manual
SP-5000M-GE2
SP-5000C-GE2
5M Digital Progressive Scan
Monochrome and Color Camera
Document Version: Ver.1.3
SP-5000-GE2_Ver.1.3_Oct2014
1050E-1404

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spark SP-5000M-GE2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for JAI Spark SP-5000M-GE2

  • Page 1 Spark Series User Manual SP-5000M-GE2 SP-5000C-GE2 5M Digital Progressive Scan Monochrome and Color Camera Document Version: Ver.1.3 SP-5000-GE2_Ver.1.3_Oct2014 1050E-1404...
  • Page 2 JAI Ltd., Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.
  • Page 3 SP-5000M-GE2 Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera. mark shows that the environment-friendly use period of contained Hazardous Substances is 15 years.
  • Page 4 SP-5000C-GE2 Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera. mark shows that the environment-friendly use period of contained Hazardous Substances is 15 years.

  • Page 5: Table Of Contents

    Introduction ..................- 7 - ® Before using GigE Vision camera ............- 7 - JAI GigE Vision ® camera operation manuals ............- 7 - Software installation ................... - 7 - About GigE Vision Ver2.0 ................- 7 - Recommended PC to be used .................
  • Page 6 SP-5000M-GE2 / SP-5000C-GE2 5.5.5 Pulse Generator End Point ..............- 40 - 5.5.6 Pulse Generator Repeat Count .............. - 40 - 5.5.7 Pulse Generator Clear Activation ............- 40 - 5.5.8 Pulse Generator Clear Sync Mode ............- 40 - 5.5.9 Pulse Generator Clear Source ...............
  • Page 7 SP-5000M-GE2 / SP-5000C-GE2 7.3.2 Trigger Mode ..................- 66 - 7.3.3 Trigger Source ..................- 66 - 7.3.4 Trigger activation ................- 67 - 7.3.5 Trigger Overlap .................- 67 - 7.4. Normal continuous operation (Timed Exposure Mode/Trigger Mode OFF) ....- 68 - 7.5. Timed mode ..................- 68 - 7.5.1 If the overlap setting is “OFF”...
  • Page 8 SP-5000M-GE2 / SP-5000C-GE2 8.10 HDR (High Dynamic Range) (SP-5000M-GE2 only) ..........- 88 - Camera setting ................. - 89 - Camera Control Tool ................- 89 - Camera Default Setting ................- 89 - External appearance and dimensions .......... - 90 - Specifications .................

  • Page 9: Introduction

    Software installation The JAI GigE Vision SDK & Control Tool can be downloaded from the JAI web site at www.jai.com. The JAI SDK is available for Windows XP, Vista, and Windows 7, 32-bit and 64-bit. For the details of software installation, please refer to the “Getting Started Guide” supplied on the JAI SDK download page.

  • Page 10: Recommended Pc To Be Used

    SP-5000M-GE2 / SP-5000C-GE2 Recommended PC to be used The PC used should have the following performance or better 1) Recommended CPU : Core i3 or better, 2) Recommended memory: DDR3, 4GB fully equipped (Windows 7 32-bit) DDR3, 8GB fully equipped (Windows 7 64-bit) 3) Graphics card : Should apply with PCI Express Generation 3.0 or better 4) NIC : Use Intel NIC PCI-Express Bus to install Intel NIC should be better than Generation 2.0.

  • Page 11: Camera Operation Manual

    DC iris systems, as well as provide a video iris output signal, or to provide additional TTL IN and OUT lines. The latest version of this manual can be downloaded from: www.jai.com The latest version of the Camera Control Tool for the SP-5000M-GE2 and SP-5000C-GE2 can be downloaded from: www.jai.com...

  • Page 12: Main Features

    SP-5000M-GE2 / SP-5000C-GE2 Main features  New Spark Series, 1” progressive scan camera  Intelligent body design for easy and flexible installation  Utilizes new GigE Vision ver.2.0  Aspect ratio 5:4, 2560(H) x 2048(V) - 5.2 million effective pixels ...

  • Page 13: Locations And Functions

    SP-5000M-GE2 / SP-5000C-GE2 Locations and functions Locations and functions  Lens mount C-mount (Note *1)  10-pin connector AUX Connector for lens control (Standard)  LED Indicator for power and trigger input  12-pin connector DC and trigger input  LED (LINK) GigE network indication (LINK for GigE 1) ...

  • Page 14: Rear Panel

    SP-5000M-GE2 / SP-5000C-GE2 Rear panel The rear panel mounted LEDs provide the following information: POWER/TRIG Amber: Power connected – initiating  This light goes OFF after initiating. Steady green: Camera is operating in Continuous mode  Flashing green: The camera is receiving external triggering ...

  • Page 15: Input And Output

    SP-5000M-GE2 / SP-5000C-GE2 5. Input and output GigE interface 5.1.1 GigEVision 2.0 interface extension SP-5000-GE2 complies with GigE Vision 2.0. Its extension functions are described below. 5.1.1.1 Link Aggregation By handling two ports as one port, the maximum transfer rate can be achieved at 2Gbps. This function is based on IEEE 802.3ad, IEEE 802.1AX Link Aggregation and GigE Vision 2.0.
  • Page 16 SP-5000M-GE2 / SP-5000C-GE2 Connecting configuration 1. If only 1 port is linked up, the connecting configuration is SL (Single Link). 2. If Port 1 and Port 2 are linked up, and if dLAG is enabled, the operation is determined by LACP or if sLAG is enabled, the operation is sLAG connecting configuration.

  • Page 17: Ptp

    SP-5000M-GE2 / SP-5000C-GE2 5.1.1.2 PTP (IEEE 1588-2008: Precision Time Protocol） Table 3. Specifications Equipped functions Only slave Master function is not equipped Used Transport Multicast UDP datagram In IEEE 1588, various transports But, Delay_Req and including Ether Frame are defined. In Delay_Resp are Unicast UDP GigE Vision 2.0, it is defined to use datagram...

  • Page 18: Notes For Connecting 100Base-Tx

    SP-5000M-GE2 / SP-5000C-GE2 5.1.1.4 Notes for connecting 100BASE-TX  In order to use 100 Mbps network, 100BASE-TX and Full Duplex are available. Half Duplex cannot be used.  In the case of connecting on 100BASE-TX, the maximum packet size should be 1500 bytes. ...
  • Page 19 SP-5000M-GE2 / SP-5000C-GE2 On the Search Downloads page, select your operating system -- in this case Windows 7. Select either 32-bit or 64-bit version. After downloading the driver, double-click PROWin32.exe or PROWin64.exe to install the driver. - 17 -...
  • Page 20 SP-5000M-GE2 / SP-5000C-GE2 After installing the driver, it is possible to confirm version information about the driver in the listing on the “Programs and Features” page. 2. Setting of NIC properties Settings of each port. Open the “Device Manager” and find the network adapter, Intel PRO 1000 PT Dual Port Server Adapter.
  • Page 21 SP-5000M-GE2 / SP-5000C-GE2 Set Jumbo Frame (Jumbo Packet) to 9014 Bytes. Select “Performance Options” and click the “Properties” button. - 19 -...
  • Page 22 SP-5000M-GE2 / SP-5000C-GE2 In setting(s) box, set “Interrupt Moderation Rate” to “Extreme.” Set “Receive Buffers” at 2048. Settings of “Teaming” Open “Teaming” tab. Check “Team this adapter with other adapters” and click “New Team” button. - 20 -...
  • Page 23 SP-5000M-GE2 / SP-5000C-GE2 Input “Team” name, if necessary, otherwise leave it as is. Then click “Next”. The “Select adapters to include in this team” dialog will open. The adapter with its properties dialog currently open will already be checked. Check the other adapter, in this case, Intel PRO 1000 PT Dual Port Server Adapter #4.
  • Page 24 SP-5000M-GE2 / SP-5000C-GE2 “Team Type Selection” will open. In the SP-5000-GE2, only “Static Link Aggregation” and “IEEE 802.3ad Dynamic Link Aggregation” are available. In this example, “Static Link Aggregation” is selected. Then click “Next”. The confirmation message for creating new team will be displayed. In this example, it is Static Link Aggregation.
  • Page 25 SP-5000M-GE2 / SP-5000C-GE2 The following are the “Team 0” properties. JAI SDK Install After “Teaming” of NIC is completed, the JAI SDK must be installed. - 23 -...
  • Page 26 Accept license and click “Next” 」 Fill in the fields if needed. Then click “Next”. This screen confirms whether or not the JAI GigE Vision Filter Driver is to be installed. When GigE Vision cameras are used, this must be checked. - 24 -...
  • Page 27 SP-5000M-GE2 / SP-5000C-GE2 Set the folder to install. If the default setting is OK, just click “Next”. Select a setup type. If “Complete” is OK, then click “Next”. Click the “Install” button to start installation. - 25 -...
  • Page 28 SP-5000M-GE2 / SP-5000C-GE2 Click “Yes” to restart the PC. After restarting, check to see that the filter driver is in the local area network. In the following example, two port names of the Intel PRO 1000 PT Dual Port Server Adapter are re-named.
  • Page 29 SP-5000M-GE2 / SP-5000C-GE2 In the Properties window of the Local Area Network which is to be Teamed, the JAI GigE Vision Filter Driver is initially checked. After “Teaming,” JAI GigE Vision Filter Drivers are not checked in the Properties of Port 1 and Port 2 of the Intel PRO 1000 PT Dual Port Server Adapter Local Area Network.
  • Page 30 SP-5000M-GE2 / SP-5000C-GE2 In JAI SDK 2.0.x, the Settings window is updated with the applicable camera interface settings. Settings button - 28 -...
  • Page 31 In JAI SDK 2.0.x, “Buffer Count” and “Enable Packet Resend” are found under the GenICam (GenTL) settings as a Device Layer property, while they are found in the Settings dialog in the JAI SDK 1.4.1 camera control tool. These settings can be set every time the camera is connected.

  • Page 32: Connectors And Pin Assignment

    SP-5000M-GE2 / SP-5000C-GE2 Connectors and pin assignment 5.2.1 Output connector for Gigabit Ethernet Type： RJ-45 Fig.3 RJ-45 connector The digital output signals follow the Gigabit Ethernet interface using an RJ-45 conforming connector. The following table shows pin configuration. Table 4. RJ-45 pin configuration Pin No.

  • Page 33: Aux Standard Hirose 10-Pin Connector

    SP-5000M-GE2 / SP-5000C-GE2 5.2.3 AUX Standard Hirose 10-Pin connector 5.2.3.1 Figure and pin configuration Type : HIROSE 10-Pin Connector 3260-10S3(55) Fig.5 Hirose 10-pin connector Table 6. Hirose 10P pin assignment (Standard) Name Note DRIVE IRIS+ Motorized Lens DRIVE FOCUS+ Motorized Lens DRIVE ZOOM+ Motorized Lens COMMON...

  • Page 34: Aux Type 3 Hirose 10-Pin Connector (Factory Option)

    SP-5000M-GE2 / SP-5000C-GE2 5.2.5 AUX Type 3 HIROSE 10-Pin connector (factory option) Type: HIROSE 10-Pin Connector 3260-10S3(55) Table 8. HIROSE 10P pin assignment Name Note TTL OUT2 Line8 TTL OUT3 Line9 TTL_IN2 Line10 LVDS_IN1+ Line11 LVDS_IN1- Digital IN/OUT interface In the SP-5000M-GE2 and SP-5000C-GE2, the digital IN/OUT capability in the software control tool can assign the necessary signals needed for the system.
  • Page 35 SP-5000M-GE2 / SP-5000C-GE2 Table 10. Line Source Line Source item Description Connect Low Level signal to line item selected in Line Selector, Default setting High Connect High Level signal to line item selected in Line Selector Frame Trigger Wait Connect Frame Trigger Wait signal to line item selected in Line Selector Frame Active Connect Frame Active signal to line item selected in Line Selector Acquisition Trigger Wait...

  • Page 36: Line Mode

    SP-5000M-GE2 / SP-5000C-GE2 5.3.3 Line Mode Indicates the status of the interface, input or output. 5.3.4 Line Inverter Sets the polarity of the selected input or output. 5.3.5 Line Status Indicates the status of the selected signal, input or output (True=High or False=Low) 5.3.6 Line Format Controls the format of the line item selected in Line Selector.
  • Page 37 SP-5000M-GE2 / SP-5000C-GE2 Sel Bit (5,0) Sel Bit (7) Soft Trigger Trigger 0 (Acquisition Start) LVAL IN Trigger 1 (Acquisition Stop) FVAL IN Trigger 2 (Frame Start) Exposure Active Trigger 3 (Transfer Start) Acquisition Trigger Wait Sel Bit (7) Acquisition Active GPIO 2 (OPT OUT 1) Frame Trigger Wait OPT 3 (OPT OUT 2)

  • Page 38: In And Out Matrix Table

    SP-5000M-GE2 / SP-5000C-GE2 5.3.7.2 IN and OUT matrix table The following table shows the input and output matrix table. Table 11. GPIO IN and OUT matrix table Selector (Cross Trigger Pulse Generator Line Selector point switch output) Selector Selector Source signal (Cross point switch input) ...

  • Page 39: 5.4 Optical Interface

    SP-5000M-GE2 / SP-5000C-GE2 5.4 Optical Interface SP-5000-GE2 is equipped with opto-isolated inputs and outputs, providing galvanic separation between the camera’s inputs/outputs and peripheral equipment. In addition to galvanic separation, the opto-isolated inputs and outputs can cope with a wide range of voltages;...

  • Page 40: Characteristics Of Optical Interface

    SP-5000M-GE2 / SP-5000C-GE2 5.4.3 Characteristics of optical interface The relationship of the input signal to the output signal through the optical interface is as follows. User Power（VCC） SP-5000-GE2 270Ω 3.3V User Power Output line Time Delay Rise TDR (us) 0.54 0.54 0.62 0.68...

  • Page 41: Clock Pre-Scaler

    SP-5000M-GE2 / SP-5000C-GE2 5.5.1 Clock Pre-scaler Clock pre-scaler (Divide Value) can set the dividing value of the frequency divider (12-bit length) and the pixel clock is used for this. Four built-in pulse generators work by the same clock. In the SP-5000-GE2, the pixel clock is set at 48 MHz. 5.5.2 Pulse Generator Selector This is where you select one of the 4 pulse generators in order to set or modify its...

  • Page 42: Pulse Generator Start Point

    SP-5000M-GE2 / SP-5000C-GE2 5.5.4 Pulse Generator Start Point Set the active output start count value for the selected pulse generator. However, please note that a maximum 1 clock jitter for the clock which is divided in the clock pre-scaler can occur. 5.5.5 Pulse Generator End Point Set the active output ending count value for the selected pulse generator.

  • Page 43: Pulse Generator Clear Source

    SP-5000M-GE2 / SP-5000C-GE2 5.5.9 Pulse Generator Clear Source The following clear source can be selected as the pulse generator clear signal. Table14. Pulse generator clear source Pulse Generator Clear Source Description item Connect Low level signal to Clear Source for the selected pulse generator. Default setting Connect High level signal to Clear Source for the selected pulse High...

  • Page 44: Pulse Generator Inverter

    SP-5000M-GE2 / SP-5000C-GE2 5.5.10 Pulse Generator Inverter Clear Source Signal can have polarity inverted. 5.5.11 Pulse Generator Setting Parameters Table15. Pulse Generator setting parameters Display Name Value Clock Pre-scaler 1 to 4096 Pulse Generator Clock (MHz) [Pixel Clock:48 MHz]÷[Clock Pre-scaler] Pulse Generator Selector - Pulse Generator 0 - Pulse Generator 1...

  • Page 45: Sensor Layout, Output Format And Timing

    SP-5000M-GE2 / SP-5000C-GE2 Sensor layout, output format and timing Sensor layout CMOS sensors used in the SP-5000M-GE2 and SP-5000C-GE2 have the following tap and pixel layout. 6.1.1 Monochrome sensor 2560 Pixels Fig.14 Monochrome sensor layout 6.1.2 Bayer color sensor Adress(0,0) 2560 Pixels Fig.15 Bayer color sensor layout...

  • Page 46: Camera Output Format

    SP-5000M-GE2 / SP-5000C-GE2 6.2. Camera output format The following table shows the relationship between camera output and sensor readout system. Camera output format Sensor readout system Reference figure 1X–1Y 1-tap readout 6.2.1 Note: The description of camera output format is based on GenICam SFNC Ver.1.5.1. 6.2.1 1X-1Y 1X–1Y is defined in GenICam SFNC Ver.1.5.1 for 1-tap readout and the readout system is the...

  • Page 47: Sp-5000M-Ge2 Pixel Type

    SP-5000M-GE2 / SP-5000C-GE2 6.2.2 SP-5000M-GE2 Pixel Type 6.2.2.1 GVSP_PIX_MONO8 8-bit output 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 6.2.2.2 GVSP_PIX_MONO10 16-bit output 0 1 2 3 4 5 6 7 8 9 X X X X X X 0 1 2 3 4 5 6 7 X X X X X X 6.2.2.3 GVSP_PIX_MONO10PACKED 12-bit output...

  • Page 48: Gvsp_Pix_Baygr10Packed 12-Bit Output

    SP-5000M-GE2 / SP-5000C-GE2 6.2.3.3 GVSP_PIX_BAYGR10PACKED 12-bit output Odd Line 2 3 4 5 6 7 8 9 0 1 X X 2 3 4 5 6 7 8 9 Even Line 2 3 4 5 6 7 8 9 0 1 X X 2 3 4 5 6 7 8 9 6.2.3.4 GVSP_PIX_RGB8_PACKED (24-bit)

  • Page 49: Pixelsize

    SP-5000M-GE2 / SP-5000C-GE2 6.2.4 PixelSize Table16. Pixel size Bit per Pixel Pixel Format SP-5000M-GE2 SP-5000C-GE2 Bpp8 Mono8 BayerGR8 Bpp12 Mono10Packed BayerGR10Packed YUV411Packed Bpp16 Mono10 BayerGR10 YUV422Packed Bpp24 RGB8Packed YUV444Packed Output timing 6.3.1 Horizontal timing 6.3.1.1 Output format: 1X–1Y, Vertical Binning OFF 1 clock = 20.833 ns LVAL DVAL...

  • Page 50: Vertical Timing

    SP-5000M-GE2 / SP-5000C-GE2 6.3.2 Vertical timing 6.3.2.1 Output format: 1X–1Y, Vertical Binning OFF 1L = 165 clocks FVAL 2048L 47 ～48L(Min) DVAL Exposure 9 ～10L Video Exposure Active Frame Active Fig.19 Vertical Timing (Vertical binning OFF) 6.3.2.2 Output format: 1X–1Y, Vertical Binning ON FVAL 1024L 47 ～48L(Min)

  • Page 51: Roi (Region Of Interest) Setting

    SP-5000M-GE2 / SP-5000C-GE2 6.3.3 ROI (Region Of Interest) setting In the SP-5000-GE2, a subset of the image can be output by setting Width, Height, Offset-X, and Offset-Y. If the height is decreased, the number of lines read out is decreased and as the result, the frame rate is increased.

  • Page 52: Operating Modes

    SP-5000M-GE2 / SP-5000C-GE2 Operating modes 7.1. Acquisition control (change the frame rate) 7.1.1 Acquisition Mode In the SP-5000-GE2, the following three acquisition modes are available. Single frame : One frame can be output by AcqusitionStart command Multi frames : The number of frames which is specified in Acquistion Frame Count, are output by AcquisitionStart command Continuous : Images are continuously output by AcquisitionStart command until...
  • Page 53 SP-5000M-GE2 / SP-5000C-GE2 Setting condition 1 Acquisition Mode： Single Trigger Selector： Acquisition Start Trigger Mode： OFF Acquisition Start command Output Signals Acquisition Active Exposure Active (Sensor Exposure) Frame Active FVAL(Sensor Read out) (Stream Active) Acquisition Trigger Wait = Frame Trigger Wait = L Acquisition Status Acquisition Active FALSE...
  • Page 54 SP-5000M-GE2 / SP-5000C-GE2 Setting condition 2 Acquisition Mode： Single Trigger Selector： Acquisition Start Trigger Mode： ON Acquisition Start command Output Signals Trigger Acquisition Trigger Wait Acquisition Active Exposure Active (Sensor Exposure) Frame Active FVAL(Sensor Read out) (Stream Active) Frame Trigger Wait = L Acquisition Status Acquisition Active FALSE...
  • Page 55 SP-5000M-GE2 / SP-5000C-GE2 Setting condition 3 Acquisition Mode： Single Trigger Selector： Frame Start Trigger Mode： ON Acquisition Start command Output Signals Trigger Frame Trigger Wait Acquisition Active Exposure Active Sensor Exposure Frame Active FVAL(Sensor Read out) Stream Active Acquisition Trigger Wait Acquisition Status Acquisition Active FALSE...

  • Page 56: Multi Frame Operation

    SP-5000M-GE2 / SP-5000C-GE2 7.1.1.2 Multi Frame operation In this mode, the AcquisitionStart command captures the number of frames which are specified by AcquisitionFrameCount. ◆ Normal multi-frame operation 1) AcquisitionStart command is input 2) AcquisitionTriggerWait becomes effective 3) AcquisitionActive becomes “TRUE”(accepts capture) 4) Output N frames as specified by AcquisitionFrameCount 5) AcquisitionActive becomes “FALSE”.
  • Page 57 SP-5000M-GE2 / SP-5000C-GE2 Setting condition 1 Acquisition Mode： Multi Trigger Selector： Acquisition Start Acquisition Frame Count ： 2 Trigger Mode： OFF Acquisition Start command Output Signals Acquisition Active Exposure Active (Sensor Exposure) Frame Active FVAL(Sensor Read out) (Stream Active) Acquisition Trigger Wait = Frame Trigger Wait = L Acquisition Status Acquisition Active...
  • Page 58 SP-5000M-GE2 / SP-5000C-GE2 Setting operation 2 Acquisition Mode： Multi Trigger Selector： Acquisition Start Acquisition Frame Count： 2 Trigger Mode： ON Acquisition Start command Output Signals Trigger Acquisition Trigger Wait Acquisition Active Exposure Active (Sensor Exposure) Frame Active FVAL(Sensor Read out) (Stream Active) Frame Trigger Wait = L Acquisition Status...
  • Page 59 SP-5000M-GE2 / SP-5000C-GE2 Setting operation 3 Acquisition Mode： Multi Trigger Selector： Frame Start Acquisition Frame Count： 2 Trigger Mode： ON Acquisition Start command Output Signals Trigger Frame Trigger Wait Acquisition Active Exposure Active (Sensor Exposure) Frame Active FVAL(Sensor Read out) (Stream Active) Acuisition Trigger Wait Acquisition Status...

  • Page 60: Continuous

    SP-5000M-GE2 / SP-5000C-GE2 7.1.1.3 Continuous In this mode, when the AcquisitionStart command is set, the image is continuously output at the current frame rate. This is the default setting for the SP-5000M-GE2 and SP-5000C-GE2. 1) AcquisitionStart command is input 2) AcquisitionTriggerWait becomes effective 3) AcquisitionActive becomes “TRUE”...
  • Page 61 SP-5000M-GE2 / SP-5000C-GE2 Setting operation 1 Acquisition Mode： Continuous Trigger Selector： Acquisition Start Trigger Mode： OFF Acquisition Start Acquisition Stop command command Output Signals Acquisition Active Exposure Active (Sensor Exposure) Frame Active FVAL(Sensor Read out) (Stream Active) Acquisition Trigger Wait Frame Trigger Wait Acquisition Status Acquisition Active...
  • Page 62 SP-5000M-GE2 / SP-5000C-GE2 Setting condition 2 Acquisition Mode： Continuous Trigger Selector： Acquisition Start Trigger Mode： ON Acquisition Start Acquisition Stop command command Output Signals Trigger Acquisition Trigger Wait Acquisition Active Exposure Active (Sensor Exposure) Frame Active FVAL(Sensor Read out) (Stream Active) Frame Trigger Wait Acquisition Status Acquisition Active...
  • Page 63 SP-5000M-GE2 / SP-5000C-GE2 Setting condition 3 Acquisition Mode： Continuous Trigger Selector： Frame Start Trigger Mode： ON Acquisition Start Acquisition Stop command command Output Signals Trigger Frame Trigger Wait Acquisition Active Exposure Active (Sensor Exposure) Frame Active FVAL(Sensor Read out) (Stream Active) Acuisition Trigger Wait Acquisition Status Acquisition Active...

  • Page 64: Acquisition Frame Rate

    SP-5000M-GE2 / SP-5000C-GE2 7.1.2 Acquisition frame rate With Trigger OFF (free running mode – see section 7.2.1), the default frame rate of the camera is based on the specified ROI. The smaller the ROI, the faster the default frame rate. However, it is possible to specify a free-running frame rate (i.e., no trigger needed) that is slower than the default rate.

  • Page 65: Calculation Of Frame Rate Of Network Bandwidth

    SP-5000M-GE2 / SP-5000C-GE2 Clock number of 1 line ValidClocksOfLine = (ClocksOfLine - AddtionalClocks) x (Width + 127) / 128 x 128 / 2560 + 1 + AddtionalClocks If the result is less than 165, ValidClocksOfLine = 165; Clock number of 1 frame ClocksOfFrame = (ValidClocksOfLine + (BinningHorizontal - 1) x 4 ) x (Height + 7) + 858 The maximum frame that sensor can operate SensorFrameRate (Hz) = 48000000 / ClocksOfFrame...

  • Page 66: Exposure Settings

    SP-5000M-GE2 / SP-5000C-GE2 7.2. Exposure settings This section describes how to set the exposure settings. 7.2.1 Exposure Mode The exposure mode can be selected from the following three ways. Table18. Exposure mode Exposure Mode setting Exposure operation No exposure control (free-running operation) Exposure operation at the value set in Exposure Time.

  • Page 67: Exposure Time

    8 seconds (Note – noise may make image unusuable after 2 seconds) 7.2.3 Exposure Auto This is a function to control the exposure automatically. It is effective only for Timed. JAI ALC Reference controls the brightness. There are three modes, OFF, Once and Continuous. OFF: No exposure control...

  • Page 68: Trigger Control

    SP-5000M-GE2 / SP-5000C-GE2 7.3. Trigger Control The following 6 types of Trigger Control are available by the combination of Trigger Selector, Trigger Mode, Exposure Mode and Trigger Option. Table21. Trigger control Camera Settings JAI Custom Description Trigger Mode Trigger Trigger Name Selector...

  • Page 69: Trigger Activation

    SP-5000M-GE2 / SP-5000C-GE2 Table23. Trigger source Trigger Source Description item Connect LOW level signal to the selected trigger operation Default setting High Connect HIGH level signal to the selected trigger operation Connect Soft Trigger signal to the selected trigger operation Soft Trigger Trigger can be input manually by the execution of the software trigger Trigger software is available on each trigger source.

  • Page 70: Normal Continuous Operation (Timed Exposure Mode/Trigger Mode Off)

    SP-5000M-GE2 / SP-5000C-GE2 7.4. Normal continuous operation (Timed Exposure Mode/Trigger Mode OFF) This is used for applications which do not require triggering. In this mode, the video signal for the auto-iris lens is available if AUX connector is configured with option Type 2. For the video timing, refer to chapter 6.3.

  • Page 71: If The Overlap Setting Is "Readout

    SP-5000M-GE2 / SP-5000C-GE2 7.5.2 If the overlap setting is “Readout” Trigger Exposure Exposure Active Exposure Period XEEN FVAL 30 µs 10.13 µs 2.51 µs 8L to 9L (18.142 µs) Fig.35 Readout 7.6. Trigger width mode In this mode, the exposure time is equal to the trigger pulse width. Accordingly, longer exposure times are supported.

  • Page 72: If The Overlap Setting Is "Readout

    SP-5000M-GE2 / SP-5000C-GE2 7.6.2 If the overlap setting is “Readout” Trigger Exposure Exposure Active Exposure Period XEEN FVAL 2L(min) 30 µs 10.158 µs 2.75 µs 226 ns 7L to 8L Fig.37 Readout Note: Timing at the end of the trigger if the trigger overlap is set to READOUT As for the timing for the end of the exposure by the external trigger pulse, its input-prohibited end time from the previous frame varies based on the pixel format used.

  • Page 73: Rct Mode

    SP-5000M-GE2 / SP-5000C-GE2 7.7. RCT mode Until the trigger is input, the camera operates continuously and the video signal for the auto-iris lens is output, provided the AUX connector has been ordered with a Type 2 configuration option. At this moment, the video signal, FVAL and LVAL are output but DVAL is not output. When the trigger is input, the fast dump is activated to read out the electronic charge very quickly, after which the accumulation and the readout are performed.

  • Page 74: Piv (Particle Image Velocimetry)

    SP-5000M-GE2 / SP-5000C-GE2 7.8. PIV (Particle Image Velocimetry) The Particle Image Velocimetry mode can be used in applications where 2 images need to be taken with a very short time interval. It can only be used with strobe flash as illumination. The first accumulation time is 10 sec to 2 sec.

  • Page 75: Sequence Roi Trigger

    SP-5000M-GE2 / SP-5000C-GE2 7.9. Sequence ROI Trigger This mode allows the user to define a preset sequence of up to 10 images, each with its own ROI, exposure time and gain values. Primary settings to use this mode Exposure Mode: Timed Trigger Mode: ON Video Send Mode: Trigger Sequence or Command Sequence 7.9.1...

  • Page 76: Trigger Sequence Mode Basic Timing

    SP-5000M-GE2 / SP-5000C-GE2 7.9.2 Trigger Sequence mode basic timing In this mode, as each trigger input is received, the image data associated with the next index within the preset sequence is output. Frame Start Trigger In Sequence Index 0 Index 1 Index 2 Index 3 Index 4...
  • Page 77 SP-5000M-GE2 / SP-5000C-GE2 Set Offset X of sequence ROI. Sequence ROI Binning Horizontal = 1 (Off): Setting range is 0 to (2544 - [Sequence ROI Width]) for Monochrome Setting range is 0 to (2552 - [Sequence ROI Width]) for Color Sequence ROI Binning Horizontal = 2 (On): Setting range is 0 to (1272 - [Sequence ROI Width]) The limitations of step number and other factors are the same as the normal ROI mode...

  • Page 78: Multi Roi Function

    SP-5000M-GE2 / SP-5000C-GE2 (14) Sequence ROI Reset Command This command resets the current index pointer and reverts to index 0 in the table. Frame Count is also re-initialized. 7.10 Multi ROI function This function divides one frame image into a maximum of 5 images vertically and reads out all areas in one frame.

  • Page 79: Multi Roi Setting Parameters

    SP-5000M-GE2 / SP-5000C-GE2 7.10.1 Multi ROI setting parameters (1) Multi ROI Index Max：Setting value = 0 ～ 4 Maximum 5 ROI settings are possible in a frame. Set Index 0 through 4 in Multi ROI Index table as an application requires. (2) Multi ROI Width Multi ROI Width can be set individually for Multi ROI Index 0 to 4.

  • Page 80: Operation And Function Matrix

    SP-5000M-GE2 / SP-5000C-GE2 7.11. Operation and function matrix Table27. Operation and function matrix Video Send Mode Auto Trigger Exposure Trigger Trigger V-Binning H-Binning Exposu Auto Iris Auto Exposur Over Multi Sequ Operation mode Option Note1 Note1 re Time Note2 Output Gain Note1 ence...

  • Page 81: Other Functions

    SP-5000M-GE2 / SP-5000C-GE2 Other functions Black level control This function adjusts the setup level. The adjusting level is -64 to +63LSB at 10-bit output. 8.1.1 Black Level Selector The following factors can be set. SP-5000M-GE2: DigitalAll SP-5000C-GE2: DigitalAll/DigitalRed/ DigitalBlue 8.1.2 Black Level The black level can be set in the following range.

  • Page 82: Gain Selector

    Digital Red All：0.4466～5.643 Digital Blue All：0.4466～5.643 8.2.4 Gain Auto This function automatically controls the gain level. This is controlled by the command JAI ALC Reference. There are three modes. OFF: Adjust manually. Once: Operate only one time when this command is set...

  • Page 83: Balance White Auto

    SP-5000M-GE2 / SP-5000C-GE2 Gain Auto Max: The maximum value of GainAuto control range can be set Gain Auto Min: The minimum value of GainAuto control range can be set ALC Reference: The reference level of Gain Auto control can be set (Common with ExposureAuto) ALC Area Type：...

  • Page 84: Lut Index

    SP-5000M-GE2 / SP-5000C-GE2 8.3.2 LUT Index This represents the “starting” or “input” pixel value to be modified by the Lookup Table. The SP-5000-GE2 has a 256-point Lookup Table, meaning the index points are treated like an 8-bit image with 0 representing a full black pixel and 255 representing a full white pixel. The index points are automatically scaled to fit the internal pixel format of the camera.

  • Page 85: Shading Correction

    SP-5000M-GE2 / SP-5000C-GE2 Dark Compression 0: Dark Compression 1: Linear (Default) Dark Compression Function Linear(Factory default) No compression, Gamma=1.0 Compress the signal level in the dark portion. It can improve the signal to Dark Compression noise ratio, but on the other hand, the linearity will be deteriorated. 8.5.

  • Page 86: Blemish Compensation

    SP-5000M-GE2 / SP-5000C-GE2 Note: Under the following conditions, the shading correction circuit may not work properly. If there is some area in the image with a video level less than 70%  If part of the image or the entire image is saturated ...

  • Page 87: Lens Control

    SP-5000M-GE2 / SP-5000C-GE2 The RAW data contains only luminance information for each color and outputs as a monochrome signal. The Bayer color interpolation function can complement lacking color information on each pixel and output RGB or YUV color data as the result. Color interpolation compensates for the lack of color information by using information from adjacent pixels.

  • Page 88: Setting For P-Iris Lens Being Used

    SP-5000M-GE2 / SP-5000C-GE2 8.8.2 Setting for P-iris lens being used P-iris lenses use an absolute setting value control system and therefore, if the following parameters are input, precise iris position control is possible. 8.8.2.1 P-Iris lens select Select the lens used from the P-iris select list. At this moment, there are no 1-inch P-Iris lenses available in the list.

  • Page 89: Zoom

    SP-5000M-GE2 / SP-5000C-GE2 8.8.3.2 Zoom Wide: While this command is supplied, the zoom will continue to move towards wide angle. Tele: While this command is supplied, the zoom will continue to move towards telephoto. Stop: When this command is supplied, the zoom operation stops. 8.8.3.3 Focus+ Near: While this command is supplied, the focus will continue to shift closer to the...

  • Page 90: Hdr (High Dynamic Range) (Sp-5000M-Ge2 Only)

    SP-5000M-GE2 / SP-5000C-GE2 8.10 HDR (High Dynamic Range) (SP-5000M-GE2 only) HDR sensing mode can be set when HDR Mode is set to ON while Exposure Mode is Timed. The parameters to configure dynamic range are HDR_SLOPE Level 1, Level 2, Level 3 and Level 4.

  • Page 91: Camera Setting

    The JAI SDK and Control Tool software can be downloaded from www.jai.com. Camera Default Setting When the camera is connected to PC and JAI SDK 2.0 is started up, XML file which stores default settings of the camera is downloaded to JAI_SDK camera control tool.

  • Page 92: External Appearance And Dimensions

    SP-5000M-GE2 / SP-5000C-GE2 External appearance and dimensions Dimensions tolerance: ± 0.3mm Unit: mm Fig.56 Outside dimensions - 90 -...

  • Page 93: Specifications

    SP-5000M-GE2 / SP-5000C-GE2 Specifications 11.1 Spectral response Fig.57 Spectral response (SP-5000M-GE2) Fig.58 Spectral response (SP-5000C-GE2) (With IR Cut Filter) Note: Full sensor response. IR-cut filter not shown. - 91 -...

  • Page 94: Specifications Table

    SP-5000M-GE2 / SP-5000C-GE2 11.2 Specifications table Specifications SP-5000M-GE2 SP-5000C-GE2 Scanning system Progressive scan, 1-tap Synchronization Internal 1000Base-T Ethernet (GigE Vision 2.0) x 2Ports (100Base-T can be used) Interface Complies with Single, sLAG (Static Link Aggregation) and dLAG (Dynamic Link Aggregation) Image sensor 1 inch Monochrome CMOS 1 inch Bayer color CMOS...
  • Page 95 SP-5000M-GE2 / SP-5000C-GE2 Acquisition Frame Rate 44 fps (Max) ～ 0.125 fps (Min), at 8-bit output Acquisition Acquisition Start/ Acquisition Stop Trigger Selector Exposure Frame Start Transfer Acquisition Start/ Acquisition Stop / Frame Transfer Exposure mode OFF, Continuous, Timed (EPS), Trigger Width Trigger option OFF / PIV / RCT (with ALC function) Trigger Overlap...
  • Page 96 SP-5000M-GE2 / SP-5000C-GE2 Operating temperature/Humidity -10C to +50C / 20 – 80% (No-condensing) Performance guaranteed Operating Temperature / Humidity -45C to +70C/20% to 80% (No-condensing) Storage Temp. / Humidity -45C to +70C/20% to 80 % (no-condensing) Regulation CE (EN61000-6-2 and EN61000-6-3), FCC part 15 class B, RoHS, WEEE Housing Dimensions 62 x 62 x 55.5 mm (W x H x D) (excluding protrusion) Weight...

  • Page 97: Appendix

    SP-5000M-GE2 / SP-5000C-GE2 Appendix 1. Precautions Personnel not trained in dealing with similar electronic devices should not service this camera. The camera contains components sensitive to electrostatic discharge. The handling of these devices should follow the requirements of electrostatic sensitive components. Do not attempt to disassemble this camera.

  • Page 98: Caution When Mounting The Camera

    When exporting this product, please follow the export regulation of your own country. 6. References 1. This manual can and datasheet for SP-5000M-GE2 / SP-5000C-GE2 can be downloaded from www.jai.com 2. Camera control software can be downloaded from www.jai.com - 96 -...

  • Page 99: Manual Change History

    SP-5000M-GE2 / SP-5000C-GE2 Manual change history Date Revision Changes April 2014 Preliminary New Release July 2014 New release Aug. 2014 Revise LAG settings information Sept. 201 Revise Spectral response Oct. 2014 Revised B/W Spectral response with wider wave length, Add the description of the dark compression - 97 -...

  • Page 100: User's Record

    Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners. JAI A-S cannot be held responsible for any technical or typographical errors and reserves the right to make changes to products and documentation without prior notification.
