- Page 1 LP4 Integrative Laser Pointer User Manual...
-
Page 2: Laser Pointer
It’s a versatile tool for use with PowerPoint presentations. It enables you to walk around the room and still control the presentation. The LP4 includes a transmitter and USB receiver. The receiver nests into the transmitter when not in use. Features: 1. - Page 3 I. Operating System Windows 2000 and above, Windows XP, Vista, Win 7, Win 8 II. Operating Tips 1. For optimal performance and RF reception, place the receiver at least 6” away from all electrical devices, including monitors, speakers or external storage devices. 2.
- Page 4 Functions Instruction: Power switch Power on or power off —————————————————————————————— Power Indicator Turn on the power switch, the light above light the switch will be on; If entering into the sleep mode or turning off the power switch, the light will go out ——————————————————————————————...
- Page 5 IV. Battery installation • The product is powered by 1x AAA battery. • Open the battery cover, and insert 1x AAA battery into the battery holder. • Battery negative(-) is left and positive (+) is right as below • Put the battery cover back into position. Note 1.
- Page 6 V. Technical parameters RF Frequency 2.437GHz —————————————————————————————— RF Output power 0dBm —————————————————————————————— Sensitivity -90dBm —————————————————————————————— Control distance Up to 10 meters —————————————————————————————— Laser wavelength 650nm —————————————————————————————— Laser distance >200m —————————————————————————————— Max output <5mW —————————————————————————————— Battery 1 x AAA —————————————————————————————— Working voltage 1.2~1.5V ——————————————————————————————...
- Page 7 VI. Safety Measures • To avoid possible eye damage, never point the LP4 at people especially their faces, or look directly into the LP4 laser beam. • Avoid pointing the presenter’s laser beam at a mirror or other highly reflective surface.
- Page 8 Note: The LP4 uses RF technology. The USB receiver will identify the first transmitter currently in use. If you want to use different transmitters with the same receiver, pull the receiver out and after waiting six seconds, plug it back in again. Then press any key on the transmitter and it will then operate.
