For Your Safety Product Safety Information Read the Safety Information Do not use while section of this user re-fuelling guide on this page Do not use This device may hand-held while produce a bright driving or flashing light For body-worn Do not dispose of operation maintain a separation of 15...
Switch off when instructed in Do not attempt to hospitals and disassemble medical facilities Switch off when Do not rely on this instructed in device for aircrafts and emergency airports communications Switch off in Only use approved explosive accessories environments RF Exposure General Statement on RF Energy Your phone contains a transmitter and a receiver.
Page 5
to assure the protection of all persons, regardless of age and health. The guidelines use a unit of measurement known as Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg and the highest SAR value for this device when tested at the ear was 1.35 W/kg*.
Page 6
Limiting Exposure to Radio Frequency (RF) Fields For individuals concerned about limiting their exposure to RF fields, the World Health Organization (WHO) provides the following advice: Precautionary measures: Present scientific information does not indicate the need for any special precautions for the use of mobile phones.
Operating Machinery Full attention must be given to operating the machinery in order to reduce the risk of an accident. Product Handling General Statement on Handling and Use You alone are responsible for how you use your phone and any consequences of its use. You must always switch off your phone wherever the use of a phone is prohibited.
• Do not paint your phone or its accessories. • Do not attempt to disassemble your phone or its accessories, only authorized personnel should do so. • Do not expose your phone or its accessories to extreme temperatures, minimum - [5] and maximum + [50] degrees Celsius.
Electrostatic Discharge (ESD) Do not touch the SIM card’s metal connectors. Antenna GPS antenna Bluetooth antenna Antenna Do not touch the antenna unnecessarily. Normal Use Position When placing or receiving a phone call, hold your phone to your ear, with the bottom towards your mouth.
Air Bags Do not place a phone in the area over an air bag or in the air bag deployment area. Store the phone safely before driving your vehicle. Seizures/Blackouts The phone can produce a bright or flashing light. Repetitive Motion Injuries To minimize the risk of RSI when texting or playing games with your phone: •...
• Take lots of breaks to stretch and relax. Emergency Calls This phone, like any wireless phone, operates using radio signals, which cannot guarantee connection in all conditions. Therefore, you must never rely solely on any wireless phone for emergency communications. Loud Noise This phone is capable of producing loud noises, which may damage your hearing.
Connection to a Car Seek professional advice when connecting a phone interface to the vehicle electrical system. Faulty and Damaged Products Do not attempt to disassemble the phone or its accessory. Only qualified personnel should service or repair the phone or its accessory.
Hearing Aids People with hearing aids or other cochlear implants may experience interfering noises when using wireless devices or when one is nearby. The level of interference will depend on the type of hearing device and the distance from the interference source, increasing the separation between them may reduce the interference.
Consult the airline staff about the use of wireless devices on board the aircraft, if your device offers a ‘flight mode’ this must be enabled prior to boarding an aircraft. Interference in Cars Please note that because of possible interference to electronic equipment, some vehicle manufacturers forbid the use of mobile phones in their vehicles unless a hands-free kit with an external antenna is included in the installation.
Contents Quick Start ............21 Phone Overview............21 Before Getting Started..........22 Powering On/Off Your Phone ......25 1.3.1 Setting Up Your Phone for the First Time ...25 1.3.2 Waking Up Your Phone from Sleep Mode..26 Your Home Screen ..........27 Widgets and Google Services .......
Page 16
2.2.2 Rejecting an Incoming Call .......36 2.2.3 Muting a Call..........36 2.2.4 Putting a Call on Hold ........36 2.2.5 Turning the Speaker On/Off .....36 Call Settings .............. 37 Entering Text ............39 Using the On-screen Keyboards ......39 Touch Input Settings..........41 Contacts ............... 43 Managing Contacts ..........43 4.1.1 Creating a Contact........43 4.1.2 Searching for a Contact ......43...
Page 17
Getting Connected..........57 Connecting to the Internet........57 6.1.1 Ways of Connecting to the Internet..57 6.1.2 GPRS/EDGE/3G ........... 57 6.1.3 Wi-Fi ...............58 Using the Phone as a Modem .......60 6.2.1 Enabling the Phone as a Modem .....60 6.2.2 Disabling the Modem Function ....61 Using the Phone as a Wi-Fi Hotspot....
Page 18
7.1.4 Camera Settings..........71 7.1.5 Camcorder Settings ........71 FM Radio ..............71 7.2.1 Opening FM Radio........72 7.2.2 Listening to FM Radio ......... 72 Playing Your Music ..........73 7.3.1 Creating Playlists.......... 74 7.3.2 Managing Your Playlists ......74 7.3.3 Adding a Song to a Playlist ......74 7.3.4 Setting a Song as Ringtone .......
Page 19
8.4.2 Adding a New Friend ........80 8.4.3 Changing Your Online Status ....81 8.4.4 Starting a Chat ..........81 Places ................. 81 Latitude ..............82 Phone Settings ............ 84 Basic Settings............84 9.1.1 Setting Time and Date ........84 9.1.2 Display Settings..........85 9.1.3 Sound Settings ..........86 9.1.4 Language Settings ........89 9.1.5 Mobile Network Services ......89 Security Settings............
Page 20
9.4.2 Allowing the Installation of Non-Market Applications ..........95 9.4.3 Installing an Application......96 9.4.4 Removing an Application......96 Other Settings............97 9.5.1 Search Settings..........97 9.5.2 Resetting the Phone ........98 10 Other Applications ..........99 10.1 Calculator ..............99 10.2 Note pad ..............99 10.3 Stopwatch ..............99 10.4 Task Manager............99 10.5 SIM Toolkit ..............100...
3. To switch your phone to sleep mode, press Power Key. 1.3.1 Setting Up Your Phone for the First Time When you first power on your XCD35 after you purchase it Phone Settings- Other or reset it to factory (see...
Settings—Resetting the Phone ), you need to do some settings before using it. Tap Change language to change the language you want to use, if needed. Tap the Android robot on the screen to start the tutorial. Tap Skip to skip the tutorial, or tap Begin to continue. View the on-screen instructions and tap Next.
Your Home Screen Widgets and Google Services Widgets A widget works as a shortcut to let you preview or use an application. You can stick widgets on your desktop as icons or preview windows. Besides the default widgets installed on your phone, you can also download more from Android Market.
Page 28
Google Services Google provides you various excellent services, such as Talk, Gmail, Market, Maps, etc.
Using Finger Gestures You can use finger gestures to control your phone. The controls on your touch screen change dynamically depending on the tasks you are performing. 1. Tap the buttons, icons, or applications to select items or to open applications. 2.
Calls Select Dialer from Home screen, you can open the dial pad. Tips: • During a call, you can tap Home Key or Back Key to hide the active call display and use other apps. To reopen it, tap Dialer from Home Screen and select Return to call in progress.
Contacts Select > Contacts from Home Screen, you can view, search, or use contacts as you like. Tips: Contacts For detailed information, please see the chapter. 1.10 Messages You can use messages at your fingertips - text, multimedia, IM, email, and Gmail.
• SMS/MMS: Tap Home Key > > Messages. • IM: Tap Home Key > > Talk. • Email: Tap Home Key > > Email. • Gmail: Tap Home Key > > Gmail. 1.11 Media See it, listen to it, share it! You can even have time to relax to some music.
Phone Calls Making a Call 2.1.1 Making a Call from Dialer 1. Tap Home Key > > Dialer. 2. Enter the phone number or the contact name you want to call. to erase wrong entry; hold this key to clear all digits.
2.1.3 Making a Call from Call History 1. Tap Home Key > > Call log. You can also open Call log by tapping the Call log tab from the Contacts Screen, or by tapping from Dialer. 2. Tap next to the number you want to call. 2.1.4 Making a Call from a Text Message If a message text contains a phone number that you want...
3. Call the number of someone else you want to join in. 4. While you are connected to the second number, tap Merge calls. 5. To add another party, tap Add call. 6. Dial the number, and when connected, tap Merge calls.
2.2.2 Rejecting an Incoming Call Drag to the left to reject the call. 2.2.3 Muting a Call During a call, you can mute your microphone so that the person with whom you are speaking cannot hear you, but you can still hear him or her. Tap Mute to turn your microphone off.
Call Settings You can adjust the call settings of your phone. To open the call settings menu, press Menu Key > Settings > Call settings from Home Screen. Fixed Restrict outgoing calls to a fixed set of Dialing numbers. To enable this feature you must Numbers know your SIM card’s PIN2 code.
Page 38
Additional Caller If your network supports, settings choose whether to display your number in outgoing calls. Call Choose whether to be waiting notified of new incoming calls while you are already on a call. Call barring Forbid certain types of calls. settings...
Entering Text Using the On-screen Keyboards When you enter a field that needs text or numbers, an on-screen keyboard appears automatically. Tap and hold the input box and select Input method from the pop-up menu to change input method. Android Keyboard The Android Keyboard provides a layout similar to a desktop computer keyboard.
Page 40
TouchPal Keyboard Flick left or right to select one of the three TouchPal keyboard layouts. Full QWERTY CooTek T+: Tap to enter the left letter on the key; tap and flick right to enter the right letter/symbol on the key. 12–Key PhonePad: Tap a key repeatedly until the desired letter appears.
• Tap to delete text before the cursor. • Tap to switch between uppercase and lowercase. Tap twice to lock uppercase. • Tap to use word prediction. • Tap to change language. • Tap to enter a period. Hold to open text editing options.
Page 42
TouchPal You can tick the check boxes to enable the following. • Word prediction • Key press sound • Key press vibration • Mixed language input • Swipe to switch layout • Next word prediction • Mistyping correction • Slide-down symbol input, and •...
4 Contacts You can save contacts to your phone memory or your SIM. More information can be saved on the phone memory for a contact than on the SIM. For instance, IM, postal addresses, organization, etc. Tap Home Key > >...
Import contacts from the SIM card or export to the card 1. Tap Menu Key > Import/Export from Contacts. 2. Select to import or export contacts. Your XCD35 will automatically read the contacts. 3. Tap the contacts you want to import/export. Or, just tap Menu Key > Select all.
4.2 Creating a Group and Adding Contacts Tap Groups tab from the Contacts Screen. Tap Menu Key > New Group. Input the group name and tap OK. Tap the group just created from the group list to open it. Tap Menu Key > Add. Select the contacts you want to add to this group.
Messaging Messages Your SMS (text message) and MMS (multimedia messaging service) files are located in Messages (Home Key > > Messages). When you receive a new message, you can open it from the Notification Panel, or from the Messages Screen. Simply tap on the new message to read it.
5.1.2 Sending an MMS 1. Tap Home Key > > Messages. 2. Tap New message. 3. Enter the recipient’s number and, if necessary, message text, just like you do with a text message. 4. Tap Menu Key > Add subject to enter the subject of your MMS.
5.1.3 Managing Messages and Their ‘Threads’ Reply to a Message 1. Tap the message thread you want to reply to from the Messages Screen. 2. Tap Type to compose and type your message. 3. Tap Send. Delete a Message (Thread) 1.
Page 49
Text message (SMS) settings • Delivery reports: Request a delivery report for each SMS message you send. • Manage SIM card messages: Manage the messages saved in your SIM card. • SMS vailidity: Set the validity time limit for outgoing text messages.
Notification settings • Notifications: Select to display message notifications in status bar. • Select ringtone: Select a ringtone for your incoming messages. • Vibrate: Select to make your phone vibrate when receiving a new message. Signature settings • Edit signature: Edit your signature, which can be added automatically to outgoing messages.
Page 51
2. Select the type of your account (POP3/IMAP/Exchange). Edit the incoming server settings, and then tap Next/Next[Check]. If you select Next[Check], your phone will check the incoming server settings and finish the setup automatically..
Page 52
If you are notified that setup could not be finished, you might need to correct some settings to finish it. 3. Edit the outgoing server settings and tap Next/Next[Check]. If you select Next[Check], your phone will check the outgoing server settings and finish the setup automatically.
Page 53
4. Set the Email checking frequency; select whether to use this account by default or be notified when Email arrives, and then tap Next. 5. Give your account a name and set a name displayed on outgoing message, and then tap Done.
5.2.2 Composing an Email After creating an Email account, you can compose and send Email messages. 1. Tap Menu Key > Compose from Email Screen. 2. Tap the To field and enter the recipient’s address. You can also tap Menu Key > Add Cc/Bcc to add recipients.
5.2.3 Replying to or forwarding an Email 1. Tap the Email account from Email Screen to open the Email inbox. 2. Tap the Email you want. 3. Tap Reply /Reply all to reply to the Email, or tap Menu Key > Forward to forward the Email. 5.2.4 Email Settings Tap the account you want to set in Email and tap Menu...
Page 56
• Sync deleted message: Delete an Email on the phone and the Email will be deleted on the server, too. Notification settings • Email notifications: Select to be notified in status bar when Email arrives. • Select ringtone: Select the ringtone for incoming Email notification.
Getting Connected Connecting to the Internet 6.1.1 Ways of Connecting to the Internet Your phone’s networking capabilities allow you to access the Internet or your corporate network via the mobile network’s GPRS/EDGE/3G connection or Wi-Fi. 6.1.2 GPRS/EDGE/3G You will need a data plan to use your wireless service operator’s GPRS/EDGES/3G network.
Point Names. 2. Tap Menu Key > New APN. 3. Tap Name to enter you APN name displayed in the APN list (You can name it as you like). 4. Tap APN to enter the APN obtained from your operator. 5.
Page 59
If you selected an open network, you will be automatically connected to the network. If you selected a secured network, you will need to input the correct password. Checking the Connection Status You can check the Wi-Fi network status from the status bar and wireless controls.
Using the Phone as a Modem You can access the Internet on your PC via your phone as a modem. Note the function may result in data charges from your mobile phone carrier. Please contact them for detail. 6.2.1 Enabling the Phone as a Modem TIPS: Make sure that USB storage is turned off before enabling the modem function.
6.2.2 Disabling the Modem Function Tap Home Key > Menu Key > Settings > Wireless & networks > Tethering & portable hotspot and clear the USB tethering check box. You can also just pull out the USB cable. Using the Phone as a Wi-Fi Hotspot You can use the phone as a portable WLAN router, providing Wi-Fi connection for one or multiple PC or other...
the Portable Wi-Fi hotspot check box. Tap Portable Wi-Fi hotspot settings > Configure Wi-Fi hotspot. Change the name of the hotspot and its security setting, if necessary. The default hotspot is set as an open one. You can tap Open and choose WPA/WPA2 PSK to set up a password.
• Tap beside the address bar or tap Menu Key > Bookmarks. Select a bookmark to open. • Tap beside the address bar or tap Menu Key > Bookmarks. Choose an item from the Most visited tab or History tab. 6.4.1 Browsing Options •...
• Open new browser window: Menu Key > New window. Then tap the address bar to enter the website you want to browse. • Switch browser windows: If you have more than one browser windows opened, you can switch between these windows by tapping Menu Key >...
TIPS: You can press Menu Key > List view/Thumbnail view to change how you view bookmarks on your phone screen. Edit a Bookmark Open a Browser window. or Menu Key > Bookmarks. Select an item you want to edit and hold on it until the shortcut menu pops up.
Page 66
• Open pages in overview: Select to show overview of newly opened pages. • Text encoding: Select a text encoding type. • Block pop-up windows: Select the check box to block pop-up windows. • Load images: Select the check box to show the images on web pages.
• Remember form data: Select the check box to remember the data you type in forms for later use. • Clear form data: Clear the saved form data. • Enable location: Select to allow sites to request access to your location. •...
3. Select the Discoverable check box to make your phone visible. 6.5.3 Changing Your Phone’s Name When your phone is visible to other Bluetooth devices it will be seen by its name, and you can make that anything you want – like ‘Dave’s XCD35’.
1. Tap Home Key > > Settings > Wireless & networks > Bluetooth settings. 2. Select the Bluetooth check box if needed. 3. Tap Device name. 4. Enter the name and tap OK. 6.5.4 Pairing with Another Bluetooth Device You can pair your phone with another device that has Bluetooth capabilities.
Experiencing Multimedia Camera and Camcorder Your phone comes with a 3.2-megapixel camera that lets you capture sharp pictures and videos. Use Camera or Camcorder to take pictures and videos. 7.1.1 Opening Camera or Camcorder Tap Home Key > > Camera/Camcorder. Notes: You can switch between camera and camcorder quickly by dragging the switch.
7.1.4 Camera Settings From the Camera Screen tap to set up focus mode, exposure, picture size/quality, color effect, ISO, anti-banding, saturation, contrast, sharpness, and camera reset. to enable or disable saving of pictures’ locations. to change white balance. Tap Zoom to zoom in or out. 7.1.5 Camcorder Settings From the Camcorder Screen, tap...
7.2.1 Opening FM Radio Tap Home Key > > FMRadio to open the application. The radio is turned on automatically, and you will see the icon in the status bar. 7.2.2 Listening to FM Radio to scan for the previous or next channel.
Tap Menu Key > Sleep to set the FM radio sleep timer. to turn off the FM radio. Playing Your Music You can play digital audio files from your phone’s memory card in Music. 1. Tap Home Key > > Music to open the Music Screen. 2.
7.3.1 Creating Playlists Playlists help you organize your music files: 1. Select a music file you want to add to a new playlist. 2. Tap and hold on the file until a shortcut menu pops up. 3. Tap Add to playlist. 4.
3. Select Use as phone ringtone. Tips: You can also set a song as ringtone when it is being played back. Tap Menu Key > Use as ringtone. Playing Your Videos To play a video file, tap Home Key > >...
Gallery Galley helps you view pictures and play back videos. For pictures, you can do some basic editing, such as cropping and rotation. You can also set them as your wallpaper or contact icon, and share with your friends. Sound Recorder Sound Recorder enables you to record your voice memos that you can set as ringtone.
7.6.1 Opening Sound Recorder Tap Home Key > > Sound Recorder. Notes: You need to install a memory card to use Sound Recorder. 7.6.2 Recording a Voice Memo 1. Get the microphone near the speaker. 2. Tap to start recording. 3.
Using Gmail™ Gmail is Google’s web-based Email service. When you sign in to your Google account on your XCD35, the Gmail is automatically configured and ready for use. Depending on your synchronization settings, Gmail on your phone can automatically synchronize with your Gmail account on the web.
8.2.2 Creating and Sending a Gmail Message 1. In the Inbox, press Menu Key > Compose. 2. Enter the message recipient’s Email address in the To field. If you are sending the Email to several recipients, separate each Email address with a comma. 3.
Tips: Tap and hold an empty time slot in Calendar’s Day, Week, or Month view to quickly add a new event scheduled in that time slot. 8.3.3 Viewing Calendar Events You can check your schedules in Day, Week, Month, or Agenda view.
2. Press Menu Key > Add friend. 3. Enter the Google Talk ID or Email address of the friend you want to add. 4. Tap Send invitation. Your friend will receive an invitation from Google. Press Menu Key > More > Invites to see pending invitation. 8.4.3 Changing Your Online Status 1.
2. Tap Home Key > > Places. Wait while you are being located. Your location, when found, is shown at the bottom of the screen. 3. Select a business category and the information of that type of business near you will be displayed. You can also use the Find places search box on the top to find the business you need.
Page 83
In Latitude, tap Menu Key to refresh friends status, see them on Maps, add new friends, or change privacy settings. You can also turn off Latitude service by tapping Sign out of Latitude in Privacy settings.
Phone Settings Basic Settings 9.1.1 Setting Time and Date 1. Tap Home Key > Menu Key > Settings > Date & time. 2. Clear the Automatic tick box if you want to set the time and date by yourself. 3. Tap Set date. Adjust the date, and tap Set to save it. 4.
9.1.2 Display Settings By tapping Menu Key > Settings > Display from Home Screen, you can configure the display settings, such as screen rotation, animation, brightness, and screen timeout. Adjusting Screen Brightness 1. Select Brightness. 2. Adjust the brightness and tap OK. Adjusting Delay before the Screen Turns off 1.
9.1.3 Sound Settings By tapping Menu Key > Settings > Sound from Home Screen, you can configure the sound settings, such as ringtones and notifications. Setting the Ringtone 1. Tap Phone ringtone. 2. Select the ringtone you want to use from the pop-up list. Tips: You can also set an audio file as the ringtone while Experiencing Multimedia —...
Page 87
Tips: By default, vibration is enabled in silent mode, and appears in the status bar when you switch the phone to silent mode. If vibration is disabled, will be replaced by the silent icon in the status bar. Switching to Vibration Mode Select Vibrate and choose the condition for vibration from the Sound settings.
Page 88
Flipping to Turn off Ringtone In Sound settings tick the Turn to forbid phone ring box. Then you can flip your phone over to mute the ringtone when there is an incoming call. Adjust Volumes If you want to set the volumes, make sure your phone is not in silent mode.
Screen Selection Tones You can set your phone to play tones when touching the screen to make a selection. Select the Audible selection check box from Sound settings. Screen Lock Sound Tick the Screen lock sounds box in Sound settings. When you lock or unlock the screen, sound will be played as a notification.
Page 90
Data Roaming Data roaming allows you to use data services when you are on a roaming network. 1. Tap Home Key > > Settings > Wireless & networks > Mobile networks. 2. Check the Data roaming check box to allow data services when roaming.
Security Settings You can protect your phone and the SIM card from unauthorized use. 9.2.1 Protecting Your Phone with a Screen Unlock Pattern Setting a Screen Unlock Pattern You can protect your phone from unauthorized use by creating a personal screen unlock pattern. 1.
5. Draw your pattern again and tap Confirm. Locking the Screen Press Power Key to lock the screen. To unlock the screen, press Power Key and draw the pattern. 9.2.2 Protecting Your Phone with a PIN or Password Creating a PIN or Password 1.
1. Tap Home Key > > Settings > Location & security > Set up SIM/USIM card lock. 2. Select the Lock SIM/USIM card check box. 3. Enter the PIN and tap OK. Changing the SIM PIN Before changing the PIN, you need to enable it. 1.
Enabling Secure Credentials 1. Tap Home Key > > Settings > Location & security. 2. Tap Set password and create a password for the credential storage. 3. Select the Use secure credentials check box. Deleting Credentials 1. Tap Home Key > >...
9.3.3 Formatting Your Memory Card 1. Unmount your memory card. 2. Tap Format SD card > Format SD card > Erase everything. 9.4 Application Settings 9.4.1 Viewing Applications Installed on Your Phone Tap Home Key > > Settings > Applications > Manage applications.
9.4.3 Installing an Application You can install an application from the Android Market by selecting the item you want to download and tap Install. You can also install a non-Marketing application if you have allowed the installation of it. Make sure that you select an application developed for your phone and processor type before installing it.
Other Settings 9.5.1 Search Settings You can manage search settings and history by tapping Home Key > > Settings > Search. Google Search Settings • Show web suggestions: Select to show suggestions from Google as you type. • Use My Location: Tick the check box to allow Google to access your location data.
10 Other Applications 10.1 Calculator Tap Home Key > > Calculator. Tips: Tap Menu Key > Advanced panel to use scientific calculation. 10.2 Note pad Note pad is used to write text memos. Press Menu Key to add or delete notes. Hold an existing note to edit it, delete it or change its title.
10.5 SIM Toolkit SIM Toolkit appears in the main menu only if your SIM card provides this function. To use the SIM card services, insert your SIM card into the phone first. Tap Home Key > > SIM Toolkit.
11 Appendix 11.1 Specifications Approx. 114 mm × 56.5 mm × Dimensions 11.8 mm Weight Approx. 130g (with battery) Bearer GSM/WCDMA support Main display dimension, 3.5 inches 800*480 resolution Sensor type CMOS Back Still image Camera capture 3.2M Pixels with auto focus resolution Internal memory ROM: 512MB, RAM: 512MB...
To minimize the environmental impacts and take more responsibilities to the earth we live on, this document shall serve as a formal declaration that the XCD35 manufactured by DELL CORPORATION is in compliance with the Directive 2002/95/EC of the European Parliament - RoHS (Restriction...
• The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health. For this product’s Recycling Manual based on WEEE directive, please visit the website below to download the document: http:// www.euro.dell.com/recycling...
