- Page 1 ADA-6081 Analog Audio Distribution Amplifier User Manual 175-000040-00 Edition B...
- Page 2 Top View Figure 1 shows the position of the switches, links, and controls on the top of the ADA-6081(V). Those components that are only available on the ADA-6081V models are noted. It also displays the configurations for the CN link pins.
- Page 3 ADA-6081V Analog Audio Distribution Amplifier User Manual Side View Figure 2 shows the side view of the ADA-6081(V) module. Components that are only available on the ADA-6081V models are noted in the diagram. The following features had been named incorrectly in previous manuals: •...
- Page 4 Digital Glue, DigiWorks, DTV Glue, Engineering The Big Picture, EventWORKS, EZ HD, Focused on the Future, Genesis, HDTV Glue, HEDCO, Innovision, ISIS, JUNO, LeFont, Leitch, Leitch Network Systems, LNS, LogoMAX, LogoMotion, MediaFile, MediaPort, MIX BOX, Monarch, Motion File, OPUS, PanelMAPPER, Pilot, Portal, PROM-Slide, RouterWORKS,...
- Page 5 ADA-6081 Analog Audio Distribution Amplifier User Manual Edition B July 2002...
- Page 7 Preface Purpose This manual details the features, installation procedures, operational procedures, and specifications of the ADA-6081 Analog Audio Distribution Amplifier. Audience This manual is written for technicians and operators responsible for installation, setup, and/or operation of ADA-6081Analog Audio Distribution Amplifier.
- Page 8 Preface Revision History Edition Date Revision History Issue 1 (A) February 1999 Initial release • Part number revision July 2002 • Formatting changes ADA-6081 User Manual...
-
Page 9: Installation Information
It is suggested that you keep at least one set of original Leitch packaging, in the event that a product needs to be returned for service. If the... -
Page 10: Important Safety Instructions
WARNING: Indicates a personal injury hazard not immediately accessible as one reads the marking. CAUTION: Indicates a hazard to property including the product or to take attention and refer to the manual. ADA-6081 User Manual... - Page 11 Power should not be applied to the frame while the top is open, unless properly trained personnel are servicing the unit. [PL Poland] Przod zdjeciem pokrywy wyciagnac wtyczke z gniazda sieciowego. [French] AVIS: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR. INSTALLER SUR SUPPORT DE MONTAGE SEULEMENT. ADA-6081 User Manual...
- Page 12 SOLO PARA INSTALAR EN RACK MONO SE KATALLHLO ‘HPOSTHRIGMAF‹C P ATENÇÃO: UWAGA: PERIGO DE CHOQUE SO PARA GROZI PORAZENIEM NIE MONTAGEM EM BASTIDOR OTWIERAC MONTOWAC TYLKO W RAMIE AVIS - Risque de choc electrique. Ne pas ouvrir. viii ADA-6081 User Manual...
- Page 13 To avoid injury or fire hazard, do not operate this product in an explosive atmosphere. Avoid Exposed Circuitry To avoid injury, remove jewelry such as rings, watches, and other metallic objects. Do not touch exposed connections and components when power is present. ADA-6081 User Manual...
- Page 14 Samtliga nätkablar måste bortkopplas för att göra de interna kretsarna spänningsfria. Do not use this apparatus near water Do not expose this apparatus to dripping or splashing water. Ensure that no objects filled with liquid, such as vases or cups, are placed on the apparatus. ADA-6081 User Manual...
- Page 15 Observe precautions for handling electrostatic-sensitive devices.See “Preventing Electrostatic Discharge” below for details. Fuse Replacement: CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH THE SAME TYPE OF FUSE. [French]ATTENTION: REMPLACER UNIQUEMENT PAR UN FUSIBLE DE MEME TYPE. ADA-6081 User Manual...
- Page 16 Anvand samma batterityp eller en eller en ekvivalent typ som rekommenderas av tillverkaren. Kassera anvant batteri enligt fabrikantens instruktion. [D Denmark] Advarsel! Lithiumbatteri. Eksplosionsfare ved fejlagtig handtering. Udskiftning ma kun ske med batteri af samme fabrikat oq [KO Korean] ADA-6081 User Manual...
- Page 17 • Handle Components Carefully. Do not slide sensitive components over any surface. Do not touch exposed connector pins. Handle sensitive components as little as possible. • Transport and Store Carefully. Transport and store sensitive components in a static-protected bag or container. ADA-6081 User Manual xiii...
-
Page 18: Certifications And Compliances
EN61000-4-11 Voltage dips, short interruptions and voltage variations- immunity tests. per the provision of the Electromagnetic Compatibility Directive 89/ 336/EEC of 3 May 1989 as amended by 92/31EEC of 28 April 1992 and 93/68/EEC, Article 5 of 22 July 1993. ADA-6081 User Manual... - Page 19 Directive 73/23/EEC of February 19, 1973, as amended by 93/68/EEC. UL 6500-98 Audio/Video and Musical Instrument Apparatus for Household, Commercial and Similar General Use. CAN/CSA Safety Requirements for Mains Operated Electronic and E65-94 Related Apparatus for Household and Similar General Use. ADA-6081 User Manual...
- Page 20 Preface ADA-6081 User Manual...
-
Page 21: Table Of Contents
Inputs ......................16 Analog Audio Input ................16 Gain Adjustment Range ..............16 Outputs ..................... 17 Analog Audio Output ............... 17 Audio Output Drive Capability ............17 GPI Outputs ..................17 Monitoring Audio Output ..............18 ADA-6081 User Manual xvii... - Page 22 Contents xviii ADA-6081 User Manual...
-
Page 23: Chapter 1: Overview
Chapter 1 Overview General Description The Genesis ADA-6081 and ADA-6081V are dual stereo analog audio distribution amplifiers fully configured with links on each channel. The modules can be configured as single channel stereo analog audio distribution amplifiers with six outputs on each channel, or dual channel stereo amplifiers with three outputs on each channel, through various combinations to a single mono-channel with 12 outputs. - Page 24 GPO2 low indicates an error condition in either the audio signals in stereo DA2, or the video/sync signals in video DA2. The ADA-6081(V) has a serial diagnostics port that allows it to report to Leitch’s CCS Pilot application. CCS allows access to error status, set-up information and control of the module by a remote PC.
-
Page 25: Side View
Side View Chapter 1: Overview Side View Figure 1-1 shows the side view of the ADA-6081(V). Components that are only available on the ADA-6081V models are noted. 6081 6081(V) ADA-6081V only Channel 1 Local/Remote Channel 2 Local/Remote Channel 3 Local/Remote... -
Page 26: Top View
Chapter 1: Overview Top View Top View Figure 1-2 shows the position of the switches, links and controls on the top of the ADA-6081(V). Those components that are only available on the ADA-6081V models are noted. VR10 VR12 VR13 CN11... -
Page 27: Chapter 2: Installation
ESD Both the A10 and the AV12 rear connectors may be used with the induced damage. FR-6002 and the FR-6004 frames. The ADA-6081(V) is hot-swappable. Power may remain on during the installation of the module. ADA-6081 User Manual... -
Page 28: Back Panel Connections
GPI Outputs Figure 2-1. A10 and AV12 Rear Connections The AV12 rear connector is used with the ADA-6081 and VDA-6001 mounted side by side. The ten BNC connectors for the VDA-6001 are to the right of the two D-connectors shown above. See the VDA-6001 User Manual for the BNC connections, which are the same as V10 RCM. -
Page 29: Cable Requirements
Audio 3 +ve Output 3 Audio 4 -ve Output 1 Audio 4 +ve Output 1 Audio 4 -ve Output 2 Audio 4 +ve Output 2 Audio 4 -ve Output 3 Audio 4 +ve Output 3 Shield - Frame Ground ADA-6081 User Manual... -
Page 30: Installation And Setup
In order to access the preset controls of this module when it is installed in a FR-6004 rack frame, insert the 6070ME Extender PCB into the rack This equipment may be first, so that the ADA-6081 PCB may be installed clear of the rack frame damaged by electrostatic and other PCBs. -
Page 31: Configuration Links
+6 dB Gain -6 dB Attenuation VR10 fully clockwise VR10 fully counter-clockwise The factory setting is 0 dB. VR11 fully clockwise VR11 fully counter-clockwise VR12 fully clockwise VR12 fully counter- clockwise VR13 fully clockwise VR13 fully counter-clockwise ADA-6081 User Manual... - Page 32 Pins A and B linked (factory setting = 0 dB) Pins B and C linked (factory setting = 0 dB) +5 dB No pins linked, park on one pin Pins A and B linked +12 dB Pins A and B linked Pins A and B linked ADA-6081 User Manual...
- Page 33 Pins A and B linked (factory setting = 0 dB) Pins B and C linked (factory setting = 0 dB) +5 dB No pins linked, park on one pin Pins A and B linked +12 dB Pins A and B linked Pins A and B linked ADA-6081 User Manual...
-
Page 34: Ada-6081V Only
The variable resister VR5 can be adjusted to change the time taken for a sustained silence error to be reported. This effects all four audio channels, error LEDs, and their respective GPI outputs. Fastest Response Slowest Response Control (under 5 seconds) (over 20 seconds) Fully clockwise Fully counter-clockwise ADA-6081 User Manual... - Page 35 3 and 4. The position of the jumper link on CN14 defines the nature of the third GPO connection, GPO_GLO: CN14 Pins A and B Linked Pins B and C Linked Function +5 V output (normal) Global GPI output connection ADA-6081 User Manual...
- Page 36 Chapter 2: Installation Installation and Setup ADA-6081 User Manual...
-
Page 37: Chapter 3: Specifications
The following table lists mechanical specifications: Item Specification Length 8.66 in. (220 mm) Width 3.94 in. (100 mm) Height 0.71 in. (18 mm) Weight 5.30 oz (150 g) Electrical The following table lists power specifications: Item Specification Power Consumption ADA-6081 User Manul... -
Page 38: Inputs
Input Level Max +28 dBu Gain Adjustment Range The following table lists gain adjustment range specifications: Item Specification Standard (local) 18 dB to -18 dB Remote Gain Option +12 dB to -66 dB for local setting/mute (ADA-6081V) ADA-6081 User Manul... -
Page 39: Outputs
4x2 into High Impedance 4x2 Outputs into 600R and +18 dBu 4x1 into High Impedance GPI Outputs The GPI is active on low and can drive high intensity LEDs directly. Item Specification Quantity ADA-6081V only) Connector D-type connector ADA-6081 User Manul... -
Page 40: Monitoring Audio Output
Specification Quantity 2 stereo (or 4 mono) Connector 3.5 mm stereo Care should be taken if using 600 Ω Impedance headphones to monitor the audio due the possible presence Output Level +10 dBu of high audio levels. ADA-6081 User Manul... - Page 41 (each, a "Customer") of hardware or software products manufactured by Leitch (each, a "Product"), or of non-warranty repair or other services provided by Leitch ("Services"), that each such Product and all such Services will be free from defects in materials and workmanship that adversely affect the Product's performance or the Services' intended purpose for a period (the "Warranty Period")
