Summary of Contents for Hybrid Systems J.S.C. HybSys 5000
- Page 1 HybSys User Manual User Manual IP Phone HybSys 5000 Version 1.0...
-
Page 2: Table Of Contents
HybSys User Manual 1. Introduction ....................... 3 Components ......................3 Flexible Function ....................4 Key Function ......................5 Product Installation ....................6 Installation ........................ 6 Typical Product network connecting Diagrams ............ 6 IP Phone Configuration ..................7 Memory key ......................7 Screen display setting .................... -
Page 3: Introduction
HybSys User Manual 1. Introduction Welcome to select our IP Phone and thanks for your trust and support to our company. We sincerely hope you can enjoy the convenience and capabilities brought forward by our products. IP Phone provides more value-added functions than normal phone. Our IP phone guarantees rich functions and crystal voice quality at mass-affordable price, which is fully compatible with SIP industry standard and able to interoperate with most SIP compliant devices and software on the market. -
Page 4: Flexible Function
HybSys User Manual 1.2 Flexible Function Key button introduction 1．Callers 2.Redial 3. Hands free 4.Memory key 5.Volume+ 6．Volume- 7.Transfer 8.Mute 9.Hold 10.Phonenumber 11．Network 12.Esc 13. Earphone 14. Directory 15．Soft1 16.Soft2 17.Soft3 18.Left 19．Up 20.Right 21.Down 22.Menu... -
Page 5: Key Function
HybSys User Manual 1.3 Key Function There are 38 keys on the phone. Definitions of each is stated as below Key Button Mode Definitions 0 -9 In the dial-up mode Decimal digit number 0-9 In the keypad configure mode Swiftly press to display the digit number 0-9 first, then swiftly press to display the English character or others In the dial-up mode As one part of phone number when call out... -
Page 6: Product Installation
HybSys User Manual 2 Product Installation 2.1 Installation Insert handset cord into the handset jack and the other end to the jack on the left side of the phone Insert the power adapter plug into the phone Power jack and the 2-prong plug end of which into grounded power outlet Connect one end of the network cable to the WAN port, which is indicated as on LCD,... -
Page 7: Ip Phone Configuration
Hereinabove the manual has defined the keypad function. It is easy to config IP phone thru the keypads. HybSys 5000 can be configured without PC, With keypad configuration, it is available to set Network parameter, SIP, Ring tone, and so on. There are ten function items in Menu. Including... -
Page 8: Screen Display Setting
HybSys User Manual Choose one from Memory 1 ~ Memory 5 Enter the phone number for speed dial. Select Save Finished. Dial Speed Dial Memory Key 3.1.2 Press Memory 1~5 key in idle mode Press Hand free or pick up the handset 3.2 Screen display setting Screen display setting is the second item in the menu, press Soft key2 to access set mode, including contrast adjustment by left and right button. -
Page 9: Volume Setting
HybSys User Manual Finished. 3.3 Volume Setting Ring tone and microphone input/output volume can be adjusted in this menu. Pressing Menu Key in Idle mode Press the Down Key twice. The LCD displays 03 Volume Setting Ringer Volume Setting 3.3.1 Select Enter. -
Page 10: Language Setting
The LCD displays 06 SIP Setting SIP server setting Synchronously, HybSys 5000 support two SIP service providers (SP) which are called SIP1 and SIP2. User can set his SIP account by keypad. NOTE: If the register port is not 5060 .You must set it in WEB. -
Page 11: Network Setting
Network setting including WAN port network mode, static DHCP, PPPOE. Selecting static to modify the static IP, DNS, gateway IP. When selecting DHCP, WAN port will get IP from DHCP server automatically. When selecting PPPOE, HybSys 5000 can connect with ADSL modem. -
Page 12: Ring Type Setting
Finished. Ring Type Setting HybSys 5000 has 12 types of incoming ring tones for user selecting. Include 4 types of MP3 ring. Using LEFT and RIGHT key to choose the ring tone you like Press Menu Key in Idle mode Press the Up Key . -
Page 13: Check The Callers Record
You can check the incoming calls, outgoing calls and missed calls by pressing Callers 5 Voice Record HybSys 5000 phone makes amelioration on voice record. 5.1 Voice Memo In idle state, SOFT KEY 3 is for recording. Pick up the handset and press soft key 3 (record) to select voice memo, then record your defined voice to change the voice memo to user–defined,... -
Page 14: Multi-Line Calling Out
6.1 Multi-line calling out HybSys 5000 phone support the maximum 5 line calling out. That is to say the phone can register to 5 different SIP VoIP system synchronously. User can set the memory key from 1 to 5 according to the SIP account for calling out. - Page 15 HybSys User Manual Picture: Wizard 01 Network Mode Select have three mode for choosing. Take DHCP as example. Stick DHCP mode check box , then click NEXT. It will enter into another config windows that it is for SIP setting Picture: Wizard 02 Set display name Set SIP register server IP address...
-
Page 16: Network Setting
HybSys User Manual Set SIP register server account username（Usually it is the same with the config port number） Set password of SIP register server account Set assigned phone number Enable /disable register function. That is to say to use or do not use SIP 1 service After finishing setting SIP1 account, then click NEXT to go into the following picture. - Page 17 HybSys User Manual Picture: Wizard 04 Three models (Static /DHCP/PPPoE) are paratactic. Users can set the right model according to actual requirements. Static : user need to set IP, NETMSK, Gateway IP by manually DHCP: WAN Port will get IP from DHCP server (like your router ) PPPOE: It is for ADSL internet mode.
- Page 18 HybSys User Manual IP Address WAN IP address Netmask Network mask Gateway Default gateway IP address DNS Domain Option configuration Primary DNS IP address for primary Domain Name Server Alter DNS Option configuration Server If ISP no special requirements, remains default setting User Provided by ADSL ISP...
-
Page 19: Lan Configuration
HybSys User Manual LAN configuration 7.2.2 Click LAN Config, it will enter into Picture: Wizard 05 Picture: Wizard 05 Config LAN: generally config one private IP address LAN IP address Netmask Network Mask Start LAN DHCP Service and NAT or do not: default setting is start Start Bridge Mode or do not（transparent mode）: Once start Bridge Mode, some parts of LAN config will be disabled, and the phone will no longer set IP address for LAN physical port，LAN and WAN will join in the same network；... -
Page 20: Sip Setting
HybSys User Manual 7.3 SIP Setting Click SIP Setting, then the page will show as the below picture (Picture: Wizard 06) Picture: Wizard 06 Regist status SIP register state；if register successfully, show “Registered”(marked red in the pic) in the square bracket，otherwise show Unregistered Display name the called display the name... - Page 21 Register Password Set password of SIP register server account Proxy Password Set password of SIP register account HybSys 5000 Domain Realm Set the sip domain if you have it, otherwise will use the proxy server address as sip domain. (Usually it is same with registered server and proxy server IP address).
- Page 22 RFC2543. Default config is RFC3261 Enable /disable phone support SIP prack function. Enable /disable to send register into with authentication HybSys 5000 Select this function, will not send authentication request to server each time. Server receive authentication HybSys...
- Page 23 HybSys User Manual Set SIP STUN server port STUN detect NAT type and interval time Set SIP phone local port 23 -...
