HighEasy HY-8004HT User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Embedded Hard Disk DVR
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HY-8004HT and is the answer not in the manual?

Questions and answers

Summary of Contents for HighEasy HY-8004HT

  • Page 1 Embedded Hard Disk DVR User’s Manual...

  • Page 2: Table Of Contents

    CONTENTS CONTENTS..........................2 CHAPTER 1 ................... 6 INTRODUCTION ................6 RODUCT MODEL SUPPORTED ....................6 ECHNICAL INDEX ....................8 AJOR FUNCTIONS 1.3.1 FUNCTION.................. 8 OMPRESSION 1.3.2 ............8 IDEO RECORDING AND STORAGE BACKUP 1.3.3 ..................8 REVIEW AND PLAYBACK 1.3.4 ................
  • Page 3 ................24 RIEF OF PERATING MENU 5.2.1 ............... 24 ENU ITEM SWITCH AND SETTING 5.2.2 .................... 25 ENU ITEM LISTING ....................28 ENU OPERATION 5.3.1 ..................28 ECORDING OPERATION 5.3.2 ..................28 LAYBACK OPERATION 5.3.3 ..................... 31 ILT CONTROL 5.3.4 ....................
  • Page 4 ......................67 UPDATE ....................... 67 UPDATE Page 4 of total 94 pages...
  • Page 5 The user manual is applicable to HY-8004HT HY-8008HT HY-8016HT HY-8004HF HY-8008HF HY-8004HC HY-8008HC HY-8012HC HY-8016HC HY-8012HS HY-8016HS Hard Disk DVR. The user manual may contain inaccurate information, or incompatible with product function and operation, or misprint. The contents of this manual will be updated along with the increasing of product function.

  • Page 6: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 Product model supported Compression format Product model Power consumption HY-8004HF <30W HY-8008HF <31W D1 with audio HY-8004HT <16W HY-8008HT <32W HY-8016HT <32W HY-8004HC <15W HY-8008HC <22W CIF with audio HY-8012HC <30W HY-8016HC <37W HY-8012HS <30W CIF without audio HY-8016HS <37W...
  • Page 7 Hard disk Support 4 built-in IDE figures and 8 hard disks Length * width * height mm 439 X 445 X 96 2U black Cabinet dimension computer case Page 7 of total 94 pages...

  • Page 8: Major Functions

    1.3 Major functions 1.3.1 Compression Support 16- channel PAL/NTSC system video signal, use H.264 technology for video compression, and support variable bit rate and variable frame rate Support 16-channel audio signal with independent real-time compression for each channel of audio signal, use G.726 technology for audio compression standard, and maintain steady synchronization for sound and images 1.3.2 Video recording and storage/backup Multiple record modes: manual recording, timing recording, alarm integration recording and...

  • Page 9: Alarm Integration Function

    Support files playback modes, such as fast motion play item 2 times/4 times/8 times/16 times , slow motion play item 1/2times, 1/4 times, 1/8 times, 1/16 times , single frame, previous file, next file, etc. Display accurate event time during the video playback 1.3.4 Alarm integration function Have 8-channel external switch Alarm in, and video loss alarm, motion detection alarm Support 4-channel alarm out...
  • Page 10 Remote end can carry out local recording and playback playback quality has relations with network situation Remote Capture image Support TCP/IP protocol;, it can access directly via Windows IE browser Page 10 of total 94 pages...

  • Page 11: Chapter 2 Installation Description

    Chapter 2 Installation description 2.1 Unpacking and accessories check One host machine, one power cable, one remote controller, a sheet of warranty card, one user manual book, one compact disk, a pair of No.7 battery, four hard disk data line, one USB mouse 2.2 Installation environment Far from high temperature heat resources and places Avoid direct radiation of sunlight...

  • Page 12: Hard Disk Installation

    Hard disk installation Installing steps are as follows: Open the computer case If two hard disks are connected on a ATA hard disk data line, master and slave of hard disk should be set up Take down the fixed shelf for the hard disks Put hard disk into the fixed shelf, and fix left and right sides of hard disk with screw Install the fixed shelf back to the device, and fix it on the device with screw Connect data line of ATA hard disk.
  • Page 13 GND DIN8 … DIN1 8-channel normal open/normal close type switch quantity, share the same earth connection line ○ 2 . 4-channel alarm out: -4 +4 -3 +3 -2 +2 -1 +1 Normal open, relay closed output, 4-channel relay contact type switch quantity ○...
  • Page 14 audio preview and playback, RCA figure ○ 6 . TV output: 1 TV output, BNC figure ○ 7 . Side slide switch: Select TV output or VGA output. When switch slides to VGA side, output VGA signal When switch slides to TV side, output TV signal ○...

  • Page 15: Chapter 3 Operation Instruction

    Chapter 3 Operation instruction 3.1 Key description of front panel Type Name Description Remote control infrared figure Figure Connect with USB storage device, USB mouse, USB burning USB figure CD-ROM Power Power indicator Record Recording indicator Alarm Alarm out indicator State Hard disk presents orange and flicking during read writing.

  • Page 16: Key Description Of Remote Controller

    different window sizes during the playback Auxiliary key Auxiliary function key Canceling alarm Cancel alarm Slow motion Select slow motion play key 1/2 times, 1/4 times, 1/8 times, play 1/16 times during the playback Select fast motion play key 2 times, 4 times, 8 times, 16 times fast motion play during playback Switch key...

  • Page 17: Mouse Operation

    otherwise, the remote control cannot control the device. Mouse operation Click mouse left key on a certain function menu icon and enter the content of the menu Carry out the operation indicated on the control Change state of check box or motion detection module Click left mouse Click figure box or pop up digital panel in password field, click directly on figure...

  • Page 18: Chapter 4 System Operation

    Chapter 4 System operation Startup and shut down 4.1.1 Startup Connect to the power cable, press the power switch on back panel, power indicator is on. When press power key or switch key of remote controller, video recorder starts up. Video output default after startup is multi window output mode, if startup time is within the setting time of timing recording, system will start automatically timing recording function, recording indicator of corresponding channel will be on, system works normally.

  • Page 19: Shut Down

    Input correct password, click OK key, login in successsingley, and then can carry out operation on DVR. 4.1.2 Shut down Method 1: press on/off key on panel for 3 seconds or more, and then can shut down the system Method 2: press directly on/off key on the remote control and then , can shut down the system Method 3: shut down the system from desktop menu main menu→...

  • Page 20: Recording Operation

    Recording operation Users can select different recording mode according to their demands, recording operation description of different modes are as follows: 4.2.1 Manual recording Two ways to operate manual recording Method 1: press recording key of front panel or remote controller Method 2: select manual recording on the desktop menu When operate on manual recording, means non-recording state, ■...

  • Page 21: Alarm Distribution Operation

    must cancel the timing recording The time period of motion detection is required to set in timing setting. when implementing motion detection setting, detecting area should be set Motion detection may connect with alarm out, see Chapter 5 main menu→ Common setting →...
  • Page 22 Confirm computer host is connected correctly with DVR through net cable Set IP address, subnet mask and gateway of DVR on main menu→ Common setting → network setting Check whether network is connected well with “ping” command Open IE browser to access DVR Connect DVR with client on computer host, see Chapter 6 for details Page 22 of total 94 pages...

  • Page 23: System Menu Structure

    Chapter 5 System menu structure System menu structure single window 4 Windows Windows QuickSearch 16 windows Video Search CommonlSettin List Search Pan Control coding setting Video Color Diisk information System information Timer Quick search Version Information Network Manual Recording Common setting Alarm in Lock Screen...

  • Page 24: Menu Item Switch Ing And Setting

    5.2 Description of operation menu Mouse operation is simple, which has been introduced previously; the contents in this chapter are mainly operation in remote control and panel 5.2.1 Menu item switch and setting Enter main menu and submenu a) After logining in successsingley, appear multi window preview mode, press ok key, graphic user figure(later abbreviate it as GUI)figure like the right figure appeared: b) Press direction key ▲▼, it can switch circularly system menu item to main menu, dark...
  • Page 25 Press direction key ▲ ▼, it can switch to select submenu Press ok key to enter class one sub sub-menu Enter class two sub-menu Direction key ▲ ▼ can switch to select class one sub-menu Press ok key to enter selected class two sub-menu Set menu contents Press direction key ▲...
  • Page 26 Display information, such as number of channels, Alarm in and output port quantities, hardware version, software version, issuing date Version information and serial number and etc. Basic parameter setting, system time, date, video storage parameter, serial number, signal mode, window saver, language selection and System settings Common setting self-start when power supply is on...
  • Page 27 Set time period for alarm output and delay time when alarm output ends Property alarm output Add and delete new user, modify user’s password, set local operation right and remote operation right and etc. User management Search system logs according to different query conditions Log information Manually clear alarm, including...

  • Page 28: Menu Operation

    Menu operation 5.3.1 Recording operation On preview window, press recording key , pop up the following recording control dialogue figu Press direction key to switch to recording channel means non- recording state, ■ means recording state, press ok key to change the recording channel state d) Press ▼...
  • Page 29 Page 29 of total 94 pages...
  • Page 30 Press play key control the play and pause of playback Press previous paragraph and next paragraph keys, it will jump to the previous or next recording files in this channel Press single frame key to control files single frame play, play frame one by Press stop key, it will stop playing files, and the figure display area closed and present black color figure.

  • Page 31: Pan /Tilt Control

    5.3.3 Pan/Tilt/Zoom control In class two submenu PTZ, show as the following figure, select corresponding channel and protocol, set baud rate and address in consistent with the decoder, press direction key to select save, and then pressok key to save and become effective Enter PTZ control from desktop menu, figure is as follows, when in multi-window preview, default to enter first channel Pan/Tilt control figure when in single window preview, enter Pan/Tilt control figure of this figure (figure displays on the left upper corner of the window)
  • Page 32 Key name Function description Carry out up, down, left and right direction control on Direction key Pan/Tilt Slip key Show or hide extensible function menu figure Close key Exit from Pan/Tilt control figure Focus Adjust the focus of the camera through these two keys Magnification Adjust the magnification change size of the camera through change...
  • Page 33 can make the camera to rotate according to cruise point line Page 33 of total 94 pages...

  • Page 34: System Menu

    5.3.4 System menu 5.3.4.1 Desktop menu Desktop menu shows as the right figure: Single Window : select single window ,press ok key , it will pop up a sub-menu including 16 channels item , press up and down direction key to select a channel, press ok key , it can jump from preview window to selected single window Press left key, it can hide right sub menu.
  • Page 35 Press direction key ▲ ▼, it can switch among tone, brightness, contrast and saturation Press direction key , it can adjust the selected parameter, and adjustment will go into effect at once Select default, press OK key , it can restore the channel video color parameters to default value.
  • Page 36 time Select channel, press direction key ▲ ▼ to switch the selected channel Select play, press ok key to play Select cancel, press ok key will cancel the operation and return NOTE When search files are more and more, time required for quick searching will be longer and longer.
  • Page 37 Select user, press direction key ▲ ▼ to select different users, and press direction key to select password edit, press number key to input correct password, press direction key to select confirm, press ok key , then it can release the lock window Select cancel, press ok key to exit from the figure, it is still in lock window state.

  • Page 38: Search File

    5.3.4.2 Search File Select Search File on main menu figure, press ok key , it will enter the following figure : Select Quick Search, press ok key to enter the dialog of quick search figure 5.3.4.1, see section 5.3.4.1 for detailed operation Select List Search , press ok key , it will enter the following figure : Page 38 of total 94 pages...
  • Page 39 Search search files according to video types (common recording, manual recording, alarm recording, motion detection recording , channel, time and other conditions, the result will be displayed in list form, select displayed files to play back . Press left and right direction key to select channel, press direction key ▲ ▼ to change channel Press left and right direction key to select recording time, press directly number key to change recording time Press left and right direction key to select search, press ok key , it will display video files in the...

  • Page 40: System Information

    5.3.4.3 System information Select system information on main menu figure, press ok key , it will enter the following figure: Select disk information, press ok key , it will enter the following figure: Page 40 of total 94 pages...
  • Page 41 Display IDE figure state, type, total capacity of each hard disk, total capacity, residual capacity and state, according to this information, can judge whether it is a good hard disk or not; otherwise, and then shut down first and then change a good hard disk. Update Dir: it is used in the previous version of video files on storage path of hard disk to change to storage path of new version, so as for the convenience of old version video file playing normally.

  • Page 42: Common Setting

    Display number of channels, Alarm in and output numbers, hardware version, software version, publishing date and serial number information, and the user cannot change the information. 5.3.4.4 Common Settings Select common Settings on main menu figure, press ok key , it will enter the following figure: 5.3.4.4.1 Common Common is to set basic parameter on system time, date, disk overlay parameter, serial number, video signal mode, window saver and language selected.
  • Page 43 Select Common, press ok key , it will enter the following figure: System time: it is used to modify current system date and time of DVR, when finish modifying system time, click the button Save and save it. Select system time, press left and right direction key can switch to select year, month, day, hour, minute and seconds, and then press directly number key to modify.
  • Page 44 number range is 0-99. Signal Mode: three kind of modes PAL, NTSC and SECAMA. Press up and down direction key can modify the signal mode. Window saver: it is used to set window saver and saver time, including 5 minutes, 10 minutes, 15 minutes and without window saver.
  • Page 45 Channel: it is used to select the corresponding channel. Select channel, press up and down direction key to select channel. Encode mode: H.264. Encode format: there are three kinds of coding format, including CIF ,D1and SD. Select coding format, press up and down direction key can select different coding format. 8004HF, 8008HF, 8004HT, 8008HT, 8016HT has three coding formats, such as CIF, D1,SD Stream type: show corresponding stream type according as the changing of encode...
  • Page 46 qualities, grade 1 image quality is the best, grade 2 is the second, grade 6 is the worst. Select image quality, press up and down direction key can select different grade image quality. Video lost: when there is video loss, it will link with alarm out. Select video loss alarm, press ok key can select or cancel selection.
  • Page 47 Sound alarm: when setting motion detection, whether it starts sound alarm. Press ok key to enable or cancel sound alarm. Screen alarm: when setting motion detection, whether it starts window alarm. Press ok key to enable or cancel window alarm. Upload to center: when setting motion detection, whether it uploads to alarm center.
  • Page 48 Mosaic: it is used to hide privacy area, select to start using mosaic, press ok key can enable or cancel selection. When setting mosaic, can select Mosaic Set, press ok key , and then enter mosaic setting figure, see the following figure: Setting area is divided into 192 16*12 zones, white border block represent current cursor position, blue area is a mosaic defended area, the normal color one is non- defended area.
  • Page 49 Selected Duration, press ok key to enable the edit, and then can press directly number key to input the delay time. Every channel may have different prerecord time. 5.3.4.4.3 Timer Timing is to set timing period for four recording types, including timing recording, external alarm, motion detection and motion detection |external alarm, two timing periods can be set every day for each type.

  • Page 50: Network Setting

    Timing module mainly starts different type recording in a setted period of time by setting record type, period of time and the corresponding channel number.It contains two periods of time. By operating the state of the checkbox ,you can set the time period. means to enable the time period.
  • Page 51 Page 51 of total 94 pages...
  • Page 52 IP address: set IP address of DVR. Press up and down direction key and press number key can change value of IP address. Subnet mask: set subnet mask of the IP address. Press up and down direction key and press number key can change value of subnet mask.
  • Page 53 figure: 5.3.4.4.5 Alarm In Alarm In is to set the linkage treatment for Alarm in, device type and Alarm in. Select alarm in, press ok key , it will enter the following figure: Alarm in: it is used to select corresponding alarm channel number. Press up and down direction key to select.
  • Page 54 not start using time set, alarm out will be handled in the whole day. Press ok key to select or cancel reverse display start using. time set Week: it is used to select the day. It is effective while starts using, time set press up and down direction key to select.

  • Page 55: Motion Detection

    If selecting sound alarm, window alarm and upload to alarm center, in case to cancel these three alarm treatments, in addition to cancel setting, must select clear alarm in advanced item as well and then press ok key. 5.3.4.4.6 Motion detection Motion detection means that it may trigger linkage device of corresponding channel recording while object in detection area generates movement.
  • Page 56 Channel: select channel number required motion detection. Press up and down direction key to select. Channel number: select recording channel number for motion detection check is permitted . Press ok key to select or cancel reverse display recording channel. Alarm out: it is used to start external device of linkage alarm out port while motion detection occurs. Press ok key to select or cancel reverse display alarm out port.
  • Page 57 Sensitivity: can set the move in the detecting range as three grades of sensitivity. Press up and down direction key to select different grades of sensitivity. Enable motion: it is used to set defense area of motion detection. Press left and right direction key to move cursor to the setting, press ok key to enter Enable motion area setting figure, see the following figure: Page 57 of total 94 pages...

  • Page 58: Pan /Tilt Setting

    Setting area is divided into 192 16*12 zones, blue border block represent current cursor position, gray area is a motion detection defended area, the normal color one is undefended area. Press auxiliary key to switch to defended state and non-defended state. During the defended state, press direction key to move blue border grid to set motion detection area, when it is in non-defended state, press direction key to move blue border grid can cancel defended state area, press exit key to save setting after the completion of setting and exit.

  • Page 59: Display Mode

    Channel: it is used to select corresponding channel number. Press up and down direction key to select. Protocol: it is used to select corresponding decoder protocol. Press up and down direction key to select. Address: it is used to set corresponding Pan/Tilt/Zoom decoder address. Press number key directly to input address value, range is 0-100.
  • Page 60 channel. Cycled output: it is used to set whether starts using cycled output. Press ok key to select or cancel reverse display cycled output. Setting: it is used to carry out relative settings for loop output while starts using cycled output. Press ok key, it will enter the following figure: Spot: it is used to select corresponding spot port.

  • Page 61: Restore Default

    Disable/Enable: it is used to set whether starts using corresponding spot port. Press up and down direction key to select. Cycled time: it is used to set corresponding spot port output time. Press directly number key to input with a time range of 5-300 sec. OK: it is used to save figure settings.
  • Page 62 Alarm out: It is used to select alarm out channel. Press up and down direction key to select. Time Table: It is used to select whether start using time table. If linking with alarm out, when starts without using time table, alarm out will be default in whole day.. Press ok key to select or cancel reverse display start using time table.

  • Page 63: Advanced Setting

    5.3.4.5 Advanced Setting Select advanced Setting on main menu figure, press ok key, it will enter the following figure: 5.3.4.5.1 User manage Select user manage, press ok key, it will enter the following figure: Page 63 of total 94 pages...
  • Page 64 Modify admin password: Firstly select the user whose password need be modified in the users list, then press left and right direction key to select change password, press ok key to enter password figure, see the following figure: Select new password item, press directly number key to input password, the same as confirm password item.
  • Page 65 Input user name (may be numbers or alphabet characters),user password(only be numbers) and confirm password in turn according to the corresponding item. , press ok key to complete to add user. Delete user: select firstly a user, then press left and right direction key to select delete user, press ok key to delete user.

  • Page 66: Log Information

    Note If the logined user is Admin,, Admin can set the right of other users. 5.3.4.5.2 Log information Log information is used to search and view operating logs on DVR Select log information, press ok key, it will enter the following figure: Page 66 of total 94 pages...

  • Page 67: C Oding Setting

    Channel: The corresponding channel for searching logs Select All to search the logs of all channels. Press up and down direction key to select. Search type: Including All Allow time Allow type and Allow time & type.. Press up and down direction key to select.

  • Page 68: Clear Alarm

    When search selects all, main type, sub-type, starting time and terminal time are all of no effect. When search selects time, main type and sub-type are of no effect. When search selects type, starting time and terminal time are of no effect. 5.3.4.5.3 Clear alarm Clear alarm is manual clear motion dynamic detection, Alarm in, video loss linkage alarm sound alarm, window prompt, upload to alarm center .

  • Page 69: R Estart System

    Exception type: select hard disk single, IP conflict, illegal access, hard disk error and input signal loss. Press up and down direction key to set. Alarm out: it is used to start external device at linkage alarm out port while motion detection occurs. Press ok key to enable or cancel reverse display alarm out port.

  • Page 70: Device Detection

    5.3.4.6.1 Device Device detection means to inspect the backup device, and list the detected device type, name, total capacity and space available and etc. Select backup file ,press ok key, it will enter the following figure: Backup devices can be CD-RW, USB and so on, when it is connected with the support backup devices, select backup file, press ok key to list the detected device type, name, total capacity space available and etc in table If there is no backup devices, select backup file, press ok key to pop up dialog window...

  • Page 71: Backup Operation

    without external device, see the following figure: 5.3.4.6.2 Backup Backup operation means to select files required to backup on external device. Select backup operation, press ok key, it will enter the following figure: Channel: Select channel number of file required for backup. Press up and down direction key to select. Start time: Search start time of video file;...
  • Page 72 directly the time. Search: search files according to channel, starting and terminal time, and display them in the list window. Select search, press ok key is ok. The list window will display starting time and terminal time of video file, as well as duration and selection state. Need space/free space: display space required for selected backup file and residual capacity of backup device Backup progress: display backup progress during the backup.
  • Page 73 Select Halt system on main menu, press ok key, it will enter the following figure: Confirm halt system, then select ok, press ok key to realize If not want shutdown system, then select cancel and then press ok key to realize. Page 73 of total 94 pages...

  • Page 74: Chapter 6 Network Operation

    Chapter 6 Network operation This Chapter will introduce mainly IE end operation of hard disk DVR, see the following for details. Input server IP address in address bar of IE browser. For example: 192.168.10.220 , it will enter figure as the following figure, then the system will prompt to select Chinese and English figure. If this is the first time to use IE for login, the system will prompt to install the extension.

  • Page 75: Ntroduction For Ie Display Figure

    6.1 Introduction to IE display figure After entering login figure, shown as the follow, click channel preview window first, then double click “number of channels” on the corresponding channel connection, when network connecting mark in the front becomes green, it can display normal connection of picture. Right key function Click right key on preview channel point as the figure Open sound: turn on sound of preview picture, monitor at IE end.
  • Page 76 Network save: save video file at IE end. Save automatically under IE end C: \Record. Network image connection After selecting the channel, double click corresponding channel as the figure, when the network connection icon in front of the channel becomes green, it can display the connected image. Pan/Tilt/Zoom function Operate Pan/Tilt/Zoom function as IE showing in the figure.

  • Page 77: Introduction For Configuration Function

    Introduction to function extension Talk: can connect IE end with video server to realize voice transmission. Stop: stop talk operation. Configuration: set detailed functions on IE end. (See section 6.2 Introduction to configuration function for details). Restart: restart server through IE end 6.2 Introduction to configuration function 6.2.1 Server parameter setting Click configuration to enter, show as the figure “server parameter setting”...

  • Page 78: Channel Parameter Configuration

    Time setting: change server time to PC time connecting server. 6.2.2 Channel parameter configuration Select the option card named “channel parameter configuration”, show as the figure. After the setting, press confirm revision — save parameter to complete the setting. Page 78 of total 94 pages...
  • Page 79 Start record It mainly sets the timing period of four recording types, such as timing recording, external alarm, motion detection and motion detection |external alarm, two timing periods can be set everyday for each type. Click to start setting button after the recording, and enter the following figure. Time of video prerecording and time delay will be effective only for motion detection and external alarm video.
  • Page 80 Click linkage mode button behind the motion detection, and enter the following figure, realize linkage set for motion detection. It can trigger any channel recording, alarm, sound alarm of linkage monitor, upload to the center and trigger alarm out. Mosaic setting Click setting button behind the mosaic, enter as the figure.
  • Page 81 Video loss alarm setup Click setting button behind the video loss alarm, enter as the follow. After the setting, it will cause monitor alarm if no video signal, sound alarm will upload to alarm center and trigger alarm out operation. Image quality: six grades, i.e.

  • Page 82: Serial Port Parameter Configuration

    Color setting: brightness: from 0——128 contrast: from 0——64 saturation: from 0——64 Tone: from 0——128. OSD setting: display OSD time and channel name. 6.2.3 Serial parameter configuration Select “serial parameter”, as the following figure. After the setting, press ok — save parameter to complete the setting.
  • Page 83 Channel number: display current selected channel. Boud: size of transmission data quantity, setting range from 1200 to 9600K. Data bit: Pan/Tilt/Zoom control data, from 5 bits to 8 bits setting. Suggest: usually adopt 8 bits. Stop bit: stop mark of data transmission. Only 1 or 2 stop bits. Parity: it is divided into three kinds, including none, odd parity and even parity.

  • Page 84: Alarm Parameter Configuration

    Decoder type: set Pan/Tilt/Zoom protocol for operation Suggest: according to adopted Pan/Tilt/Zoom, set supported agreement of Pan/Tilt/Zoom protocol. Decoder address: setting range from 0 to 100. Select setting scope according to the adopted supporting decoding address. 6.2.4 Alarm parameter configuration Select “alarm parameter”, as the figure.

  • Page 85: User Management Configuration

    Alarm out treatment: Alarm out number: setting 4 outputs. Output time delay: the time of delaying trigger alarm out It is divided into 8 types, 5sec, 10sec, 30sec, 1min, 2min, 5min, 10min, and manual. Exception setting: linkage treatment on five abnormal state, such as hard disk single, IP conflict, illegal access, hard disk error and input signal loss on linkage monitor alarm, sound alarm, upload to centre and trigger alarm out and etc.

  • Page 86: Device Management

    6.2.6 Device management Select “Device management”, show as the figure. select the update file name through browser , click update — save parameter — exit to complete the settings progress of update state and progress bar can be seen. In case of exception during the update, press cancel update to return to browser state.

  • Page 87: Device State

    6.2.7 Device state Select “device state”, show as the figure, display hard disk state and channel state, hard disk state includes hard disk capacity, residual capacity of hard disk and whether hard disk is in writing state Channel state includes recording state, signal state, code rate of main bit, whether starts using sub-bit and code rate of sub-bit.

  • Page 88: Chapter 7 System Update

    Chapter 7 System update The Chapter introduces mainly update mode of hard disk DVR, the product provides two update modes, including FTP and USB update, which will be introduced in detail as follows. 7.1 FTP update This update mode requires configuring firstly on host of FTP server procedure; the following will introduce how to set the configuration.

  • Page 89: A Dvanced Item

    c) Click “New User...”button, add new user, input username target, click “OK”: d) Input user password: e) Input update procedure contents, click “Done”, complete DVR setting: After setting the configuration, select main menu→ advanced item→ system update, it will enter the following figure: Page 89 of total 94 pages...
  • Page 90 Select FTP, press ok key to select, press left and right direction key to select OK, press ok key to enter FTP update mode window, see the following figure: FTP server address: input host IP address of configured FTP server procedure. Press number key to input directly.

  • Page 91: Usb Update

    7.2 USB update When you select USB update, please confirm first that USB device has been connected directly with the USB port, at the same time, update procedure has been copied to root directory of USB device. Select main menu→ advanced item→ system update, it will enter the following figure: Select USB, press ok key to select, press left and right direction key to select confirm, press ok key to enter USB partition figure, show as the following figure display as the first figure in case without USB, display as the second figure in case with USB :...
  • Page 92 In the right figure, press up and down direction key to select USB disc of update required, then select , press ok key , it will enter the following figure: Page 92 of total 94 pages...
  • Page 93 Two list windows on the figure will display all stored files in U flash disk, press left and right direction key to select list window of update file, then select update file with up and down direction key, file name column will appear selected file name, then press left and right direction key to select press ok key to start update.
  • Page 94 Page 94 of total 94 pages...
