Summary of Contents for FortelDTV Integrity RCP-502
- Page 1 Integrity RCP-502 Compact Remote Control Panel User Manual Revised January 2005 RCP-502 User Manual Page 1...
- Page 2 OVERVIEW The RCP-502 Compact Remote Control Panel provides simple access to Integrity system AV cards and frames. Though this control panel may control all cards on the network, it is recommended for either light duty in managing multiple devices or heavy duty when managing a single card or card pair from a remote location in your facility.
- Page 3 CONFIGURATION When the vacuum fluorescent display screen lights, it will display a prompt to “Press SETUP button to select a device”. Press [SETUP], then rotate the [SEL] knob to the right of the VF display to scroll the window text screen up until “Set IP address” is displayed.
- Page 4 Control Layout Bypass Test Preset Input ALIAS001 Three Four Five Freeze Setup [Input] LED illuminates on loss of currently selected video input. Press [Bypass] to toggle bypass mode (if allowed). Bypass LED will illuminate when currently selected video card is in Bypass. Press [Test] to toggle Test Out mode.
- Page 5 Control Layout (continued) Menu Video Take/Enter Back Audio Navigation in the menu tree allows the following: [Menu] takes you deeper into the highlighted item. [Back] takes you up one level. [Video] takes you directly to the Video Proc Amp Screen of the current video card. [Audio] takes you directly to the default audio gain screen of the current audio card.
- Page 6 SETUP MENU Press [Setup] to display the menu below. Rotate the [Sel] knob to highlight the desired function and press [Menu] to select it. PANEL SETUP Select Frame/Card Alarms Panel Info Set Brightness Set IP Address The currently selected (last used) card is highlighted. Under each frame name, a list of cards appears.
- Page 7 Press [Menu] to enter the ALARMS submenu when highlighted. ALARMS Panel Alarms Device Alarms Scroll to select a sub list, either PANEL ALARMS or DEVICE ALARMS. Alarms found will be displayed. PANEL INFO PANEL INFO SW VERSION 8.5.1 11/01/2005 BOARD DEF FILES FS-412A 8.5.1 DAS-441A 8.5.1 Scroll list of Board Def Files (BDF) using the Selector Knob.
