Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Email our technical support at: productsupport@harborfreight.com
REV 14e
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2014 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
ITEM 62359
ITEM 62359
Advertisement
Table of Contents
Related Manuals for CEN-TECH 62359
Summary of Contents for CEN-TECH 62359
- Page 1 (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. ITEM 62359 ITEM 62359 Visit our website at: http://www.harborfreight.com Email our technical support at: productsupport@harborfreight.com...
-
Page 2: Important Safety Information
Avoid body contact with grounded Make sure your hands are dry surfaces such as pipes, radiators, before operating the Camera ranges and refrigerators. or charging the battery. For technical questions, please call 1-888-866-5797. Page 2 Item 62359... -
Page 3: Personal Safety
Service There are no user serviceable parts. Camera service must be performed only by qualified repair personnel. For technical questions, please call 1-888-866-5797. Item 62359 Page 3... -
Page 4: Specifications
8.5mm (0.3") Imager Head Lights Adjustable LED Image Sensor CMOS Imager Head and Cable Waterproof to 3m Imager Head and Cable 14°F to 176°F Operating Temperature Video Output RCA Cable For technical questions, please call 1-888-866-5797. Page 4 Item 62359... - Page 5 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For technical questions, please call 1-888-866-5797. Item 62359 Page 5...
-
Page 6: Setup- Before Use
Components Cable Connector Video Out Port Cable Display Screen Imager Handheld Head with Display Light Unit Magnet Hook 45° Mirror Cable Figure A For technical questions, please call 1-888-866-5797. Page 6 Item 62359... -
Page 7: Installing Batteries
Monitor with RCA Cable: Cable Plug one end into the RCA Video Out Port on Camera, then plug other end into RCA Video In Port on monitor. Cable Connector Figure C For technical questions, please call 1-888-866-5797. Item 62359 Page 7... - Page 8 Before inspecting pipes that may contain an electric charge, have them checked by a qualified electrician. Before inspecting an engine, turn off the automobile. Handheld Display Unit Controls Brighten Light Power Light Flip Image Figure E For technical questions, please call 1-888-866-5797. Page 8 Item 62359...
-
Page 9: Live Viewing
Camera off, then clean Press Right button to turn and store according to “Inspection on light and increase brightness. and Maintenance” on page 10. For technical questions, please call 1-888-866-5797. Item 62359 Page 9... -
Page 10: Inspection And Maintenance
2. Display turns itself off. Low Batteries. Replace Batteries. 3. Camera will not turn on. Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect power supply before service. For technical questions, please call 1-888-866-5797. Page 10 Item 62359... -
Page 11: Please Read The Following Carefully
Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. For technical questions, please call 1-888-866-5797. Item 62359 Page 11... - Page 12 Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
