Anysecu DR880 Instruction Manual

Digital
Hide thumbs
Table of Contents

Advertisement

Quick Links

[键入公司名称]
XT
使用说明书
[选取日期]
[键入文档副标题]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DR880 and is the answer not in the manual?

Questions and answers

Related Manuals for Anysecu DR880

Summary of Contents for Anysecu DR880

  • Page 1 [键入公司名称] 使用说明书 [选取日期] [键入文档副标题]...
  • Page 2 We believe Anysecu dPMR two-way radio, which always incorporates the latest technology, can bring great convenience to your life and work. We also believe that the quality and function of Anysecu two-way radio can meet your demands for reliable communication.

  • Page 3: Safety Information

    Any design and materials may not be modified, copied, extracted or translated without the authorization of us or its authorized parities. Due to the update or modification of the product, Anysecu owns the right to change the specifications of software and hardware described in this manual without further notice. Specifications and information contained in this manual are for reference only.
  • Page 4 DR880 Digital Two-way Radio Anysecu Instruction Manual compliance with the IEEE and ICNIRP exposure limits, your radio radiates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. Your radio complies with the following of RF energy exposure standards and guidelines Institute of Electrical and Electronic Engineers (IEEE) C95.1-1992...
  • Page 5 DR880 Digital Two-way Radio Anysecu Instruction Manual may damage the product and result RF discomfort. ◆ Using the designated accessories Use the antenna, battery, adapter or charger supplied or sold by us only, or otherwise it causes damage to the product.
  • Page 6 DR880 Digital Two-way Radio Anysecu Instruction Manual 6. Do not place the radio in the area with great dust, moisture or drips, or on the unstable surface. ◆ Operating Attentions Antenna Do not use any portable radio that has a damaged antenna. If a damaged antenna comes into contact with your skin, a minor burn can result.
  • Page 7 DR880 Digital Two-way Radio Anysecu Instruction Manual Contact us or your local dealer for help if you want to re-develop or modify the radio.

  • Page 8: Table Of Contents

    DR880 Digital Two-way Radio Anysecu Instruction Manual Contents ◆ Copyright................................II ◆ Safety Information............................II Unpacking and checking........................1 Preparing Your Radio for Use.......................2 Identifying Radio Controls........................6 Basic Functions.............................14 Advanced Functions..........................18 Identifying Menu Structures........................ 25 Troubleshooting............................ 39 Specification............................40...

  • Page 10: Unpacking And Checking

    DR880 Digital Two-way Radio Anysecu Instruction Manual Unpacking and checking Unpack the radio carefully. We recommend that you check the radio and the supplied accessories listed in the following table before discarding the packing material. If any damage or loss has occurred during shipment, please contact the deliveryman or the dealer without delay.

  • Page 11: Preparing Your Radio For Use

    Digital Two-way Radio Instruction Manual Preparing Your Radio for Use Charging the Battery Plug the power adapter into an applicable AC outlet and connect the power adapter to the battery charger. The green LED lights up. Insert the battery or the radio into the charger slot. Make sure the battery is well connected with the charger.
  • Page 12 DR880 Digital Two-way Radio Anysecu Instruction Manual triple can let the battery capacity in the best status. When the battery is in low power, it needs to be charged or change another battery. ※ Do not recharge the battery if it has been fully charged or the radio is not in the low battery alarm state;...
  • Page 13 Digital Two-way Radio Instruction Manual first; match the two grooves on the battery to that of on the radio back. Then press down the bottom of the battery until it locks. Removing: Press down the battery latch and push backwards until it separates from the radio. Note: Do not short-circuit the battery or discard in the fire.
  • Page 14 DR880 Digital Two-way Radio Anysecu Instruction Manual Attaching the Belt Clip Match the holes on the belt clip to that of on the radio; fasten it with two 2.5*6.5 screws. To remove the belt clip, loosen the two screws. Attaching the External Earphone Open the cover for external equipment, and then insert the earphone plug into the jacks on the radio.

  • Page 15: Identifying Radio Controls

    Digital Two-way Radio Instruction Manual With the radio turned off, turn the On/Off/Volume Knob clockwise until you hear a click to turn on the radio; when the radio turns on, turn the On/Off/Volume Knob counterclockwise until you hear a click to turn off the radio.
  • Page 16 DR880 Digital Two-way Radio Anysecu Instruction Manual ○ Antenna ○ PTT Button Press the button to make a call. ○ PF Button (programmable)
  • Page 17 Digital Two-way Radio Instruction Manual This button can be programmed with different functions by dealer, the functions of which refer to Section of Programmable button. ○ Speaker To output voice. ○ LCD Display The display indicates the radio’s status. Details refer to Section of LCD display. ○...
  • Page 18 DR880 Digital Two-way Radio Anysecu Instruction Manual radio. With the radio turned on, turn it to increase/decrease the volume. ○ LED Indicator LED indicator lights in red when transmit signal; LED indicator lights in green when receive signal. LED indicator flashes red when the battery voltage is low.
  • Page 19 Digital Two-way Radio Instruction Manual Programmable Buttons In order to facilitate your usage, you can program the following buttons as function shortcut keys by your dealer: Functions Name Operation PF button Long/short press See below Menu Key Long press See below Cancel Key Long press See below...
  • Page 20 DR880 Digital Two-way Radio Anysecu Instruction Manual Power Level Adjust: Toggles transmit power level between high and low. Monitor: If the current analog channel is configured with CTCSS/CDCSS, the CTCSS/CDCSS will be canceled and the radio switches to carrier squelch mode when press the key, which means if the carrier received matches with the frequency of the current channel, the radio sounds.
  • Page 21 Digital Two-way Radio Instruction Manual Name Icon Descriptions No signal Signal Strength Indication Signal detected There is unread message in the inbox. Messages The inbox is full. Scan The radio is scanning. The transmit power of the current channel is low. Power The transmit power of the current channel is high.
  • Page 22 DR880 Digital Two-way Radio Anysecu Instruction Manual Alarm alarm), or receives emergency alarm. Battery Display Indicates the residual capacity of the battery. Private Call Indicates the current number is private call number. Group Call Indicates the current number is group call number.

  • Page 23: Basic Functions

    Digital Two-way Radio Instruction Manual Red LED lights on: the radio is transmitting. Green LED lights on: the radio is receiving. Red LED flashes: low battery, the battery needs to be charged. Basic Functions Selecting a channel Each channel in your radio can be programmed to analog channel or digital channel. Under the Home Screen, turn the Channel Knob to select a channel.
  • Page 24 DR880 Digital Two-way Radio Anysecu Instruction Manual When the radio receive the group call, a.The green LED indicator lights on b.The group call icon , group alias or ID and incoming call icon display on the LCD screen. c. Keep your mouth 3~6 inches away from the microphone;...
  • Page 25 Digital Two-way Radio Instruction Manual d. Press the PTT key to answer the call and the RED LED indicator lights on; e. Wait for the Talk Permit Tone to finish (if enabled*) and speak to the MIC; f. Release the PTT key to receive the call; g.

  • Page 26: Advanced Functions

    DR880 Digital Two-way Radio Anysecu Instruction Manual On an analog channel, when the radio receives a call, press the PTT Button to answer the call directly. Making a call On a digital channel, choose one of the following procedures to make a call: a.
  • Page 27 Digital Two-way Radio Instruction Manual Your radio also equips with the following advanced functions. Radio Check This function is used to check whether the radio is active in the system or not, while the checked radio user cannot detect it. Except the LED flashes, there is no audible or visual notification on the radio. The checked radio silently sends back a response to the check radio.
  • Page 28 DR880 Digital Two-way Radio Anysecu Instruction Manual Press “Back” to return to options feature list Radio Kill/Revive This function allows one radio sending the signaling to kill another radio. The radio to be killed cannot display anything, make or receive calls. The radio can only revive through CPS sends a revive order.
  • Page 29 Digital Two-way Radio Instruction Manual In the standby screen, press [Menu] key to enter into menu Press “ Menu” key to enter the menu; Press “Up/Down” key to select “Contacts”, and press OK to select; Press “Up/Down” key to select the target private call contact, Or Press “Down”...
  • Page 30 DR880 Digital Two-way Radio Anysecu Instruction Manual kill/revive Failed”. Emergency Alarm If you are in danger and this function is enabled, you can press Emergency Alarm On shortcut key to send an emergency alarm. The means of sending emergency alarm are decided by the following parameters: Alarm Type, which defines the audio and visual reaction when the radio sends an alarm;...
  • Page 31 Digital Two-way Radio Instruction Manual ◆Secret: No audio and visual indication. And the radio cannot receive the signal from others; ◆Secret with voice to follow: No audio and visual indication. But the radio can receive the signal from others. Alarm Mode: ◆...
  • Page 32 DR880 Digital Two-way Radio Anysecu Instruction Manual Keypad Lock If the keypad is locked, the keys have no reaction when pressing key except the PTT key, Emergency Alarm shortcut key, coding knob or the Keypad Lock key is pressed. Thus, it can avoid changing the current channel and working status unconsciously.
  • Page 33 Digital Two-way Radio Instruction Manual Press the Scan shortcut key to start scanning. During scanning, the radio checks every channel in the scan list and stops on the channel which a signal is detected. During scan, the radio checks and stops on a busy channel. Then the radio continues scanning until the channel is not busy for a while (this time is set by dealer, which is named as Scan Hold Time).

  • Page 34: Identifying Menu Structures

    DR880 Digital Two-way Radio Anysecu Instruction Manual shortcut message. The content of shortcut messages is set by local dealers. Users can use these functions under the menu prompt. Setting operating parameters You can set the radio’s operating parameters. Details refer to “Menu in Digital Mode”...
  • Page 35 Digital Two-way Radio Instruction Manual Your radio is able to record the call in and call out log. If the call log is full, the earliest log will be covered and disappeared when the new call record is saved. Procedures: Use the menu 1.
  • Page 36 DR880 Digital Two-way Radio Anysecu Instruction Manual Detailed information: You can view the detailed information of the selected call log. Add number: You can add the number of the selected call log into Only Individual Call log has this function.
  • Page 37 Digital Two-way Radio Instruction Manual set one default contact. The number can be programmed by your dealer or set on your radio. Set as default contact means to set the selected number as the default contact of the current channel. Only Group Call log has this function.
  • Page 38 DR880 Digital Two-way Radio Anysecu Instruction Manual 6.2.1 Contacts List You can view the entire Contacts list through menu or the Contact List shortcut key. These contacts can be edited by programming software or by inputting manually. Only the private call contact can be inputted manually.
  • Page 39 Digital Two-way Radio Instruction Manual Delete: Delete the selected contact. New contact： You can create an individual call contact into the contacts list. The contact number is made up of 7 digits. Scan Scan function helps you to receive calls from other channels, so as to supervise the activities of the personnel.
  • Page 40 DR880 Digital Two-way Radio Anysecu Instruction Manual While scanning, press the PTT button to make the radio transmit on a default channel. This channel can be programmed by your dealer. Procedures: Use the menu 1. Press the Menu Key to access the main menu.
  • Page 41 Digital Two-way Radio Instruction Manual such as nuisance channels, the unwanted channel can be temporarily deleted by selecting Delete Temp Channel function, and then the scan continues. And also, you can temporarily add a channel by selecting Add Temp Channel function. After existing scanning mode, the temporarily added or deleted channel is invalid.
  • Page 42 DR880 Digital Two-way Radio Anysecu Instruction Manual Procedures: Use the menu 1. Press the Menu Key to access the main menu. 2. Press the Up/Down Key to and press the OK Key to confirm. 6.4.1 Writing a message You can write a new message to send. The target contact can be chosen from the Contact List. The message can also be saved into Drafts, and the template message can be inserted while writing a new message.
  • Page 43 Digital Two-way Radio Instruction Manual forward and delete the message here. 6.4.4 Outbox The outbox stores the sent messages. If the outbox is full, the earliest sent messages will be covered and disappeared after sending a new message. You can check the detailed information, resend, forward and delete the message here.
  • Page 44 DR880 Digital Two-way Radio Anysecu Instruction Manual 2. Press the Up/Down Key to and press the OK Key to confirm. Settings You can set your radio parameters as required, including Power, Squelch Level, Whisper, Keypad Lock, Alert Tone, Home Screen, Battery Saving, Language and voice enhancement, encryption.
  • Page 45 Digital Two-way Radio Instruction Manual Whisper function can make the receiver hear clearly even if you speak in a low voice to MIC. You can set whisper function on/off here. 6.6.4 Keypad Lock If the function is enabled, the keypad will be locked automatically. And only the PTT Button, Emergency Alarm Key and Keypad Lock shortcut key are available when the keypad is locked.
  • Page 46 DR880 Digital Two-way Radio Anysecu Instruction Manual You can set battery saver function on/off here. This function can prolong the battery’s working time when enabled. 6.6.8 Language: You can choose Chinese or English as the working language. 6.6.9Voice Enhancement You can turn on/off Voice Enhancement function or set the enhancement level.

  • Page 47: Troubleshooting

    Digital Two-way Radio Instruction Manual frequency range. 6.10 Menu in analog mode In analog channel, there are Scan, Channel Info, Settings, APPs and Radio Info in the main menu, the contents of which are the same as on digital channel. (Refer to: Menu in digital mode) You can check the frequency and CTCSS of the current channel under Channel Info menu item.

  • Page 48: Specification

    DR880 Digital Two-way Radio Anysecu Instruction Manual radio cannot A. The power switch is in failure. Please change it. switched on or no display B. The battery is out of power, please recharge it or change it. after being switched on.
  • Page 49 Digital Two-way Radio Instruction Manual General UHF: 400-470MHz Frequency Range (UHF or VHF optional) VHF: 136-174MHz Channel Capacity Channel Spacing 6.25KHz/12.5KHz Operating Temperature -25℃~ +55℃ Operating Voltage 7.5V DC ±20% Battery 1500mAH Li-ion Frequency Stability ±2.5 ppm Dimension (with battery and antenna) 116mm x54mmx30mm Weight (with battery and antenna) 243g...
  • Page 50 DR880 Digital Two-way Radio Anysecu Instruction Manual Transmitter RF Power Output 4W/ 1W 16KφF3E/11KφF3E (Analog) Frequency Modulation 4FSK(Digital) Antenna Impedance 50Ω Modulation Limiting ±2.5kHz -36dBm < 1GHz Radiated Spurious Emission -30dBm > 1GHz 45dB @ 25KHz FM Noise 40dB @ 12.5KHz Modulation Distortion <...
  • Page 51 Digital Two-way Radio Instruction Manual Adjacent Channel Selectivity 60dB @ 12.5KHz Intermodulation 60 dB Spurious Response Rejection 60 dB Rated Audio Output 45/40 Rated Audio Distortion ≤3%...
  • Page 52 DR880 Digital Two-way Radio Anysecu Instruction Manual...
