- Page 1 Operation and Installation Manual OPEN DISP WM1-CD Waterproof Marine AM / FM Stereo Receiver with CD Player...
-
Page 2: Table Of Contents
Introduction Please take the time to read all of the information in this manual. Familiarity with operation and installation procedures will help you obtain the best possible performance from your new AM/FM Stereo Receiver with CD Player. Safety Information CAUTION! THIS MARINE CD PLAYER IS A CLASS DO NOT OPEN COVERS AND DO NOT REPAIR BY 1 LASER PRODUCT. -
Page 3: Button Locations And Functions
Button Locations and Functions OPEN DISP 11 10 1. Power On/Off and Display Dimmer: Press to turn the unit On or Off. Press and hold to dim the dis- play. Press and hold again to restore display’s illumination. 2. Volume Control: Press the button to increase the volume level, and press the button to decrease the volume level. - Page 4 Button Locations and Functions 9. Display Button (DISP): Radio Mode: Press to display radio RBDS (Radio Broadcast Data System) information. CD and CD Changer Mode: Press to display track information. 10. Setup Button: Press to access Bass, Treble, Balance, Fader and Subwoofer controls. Press and hold for 10 seconds to access Beep Confirmation, Default Volume and AM/FM Tuning System.
-
Page 5: Remote Control Button Locations And Functions
Remote Control Button Locations and Functions (Optional) 14. Multi-Function Button #4: Radio Mode: Press and hold until a beep is heard to memorize a radio station into memory #4 (CH4). Press and release when recalling preset radio station #4. MODE MUTE LOUD CD Mode: Press to play all the tracks on the... -
Page 6: General Operation
General Operations Power On/Off: Press the button to turn the unit On or Off. OPEN DISP Selecting a Play Source: To select a play source, press the MODE button OPEN until the desired source appears in the display: DISP AM1, AM2, FM1, FM2 or FM3 (AM and FM Radio), SIRIUS (Satellite Radio Input, if connected), CD (Built-in CD Player),... - Page 7 AM/FM Radio Operation (Continued) Selecting the AM or FM Band: Press the ENT BND button repeatedly and select OPEN from FM1, FM2, FM3, AM1 or AM2. D SP Manually Tuning in a Radio Station: Press and hold either the button until OPEN “MANUAL”...
- Page 8 AM/FM Radio Operation (Continued) Automatically Store Radio Stations: 1. Press the ENT BND button to select either the OPEN FM1, FM2, FM3, AM1 or AM2 radio band. D SP 2. Press and hold the ASM button until “AST” appears in the display. The tuner will search for the strongest stations and store them into memory.
-
Page 9: Sound Controls
Sound Controls Volume: Increase the volume by pressing the button. OPEN Decrease the volume by pressing the button. Increase Decrease Bass, Treble, Balance, Fader and Subwoofer Controls OPEN Select the desired sound mode by pressing the D SP SETUP button. The modes will be displayed in the following order: Bass, Treble, Balance, Fader, Subwoofer Line Level Output and Subwoofer Cutoff Frequency. - Page 10 Sound Controls (Continued) Fader: 1. Select the Fader mode (FAD) by pressing the OPEN SETUP button. Rear 2. To adjust the amount of sound output to the Rear speakers press the button. To adjust the amount of sound output to the Front Front speakers press the button.
-
Page 11: Disc Warnings
Sound Controls (Continued) Subwoofer Output: Press and hold the EQ button to turn subwoofer OPEN output On and Off. “SUBW ON” appears in the DISP display when the subwoofer is On and “SUBW Hold OFF” appears when the subwoofer output is Off.“SW”... -
Page 12: Cd Operation (Compact Disc)
Disc Warnings (Continued) Preparing New Discs with Rough Spots: Rough spots on Rough spots on outside edge A new disc may have rough edges on its inside and inside edge outside edges. If a disc with rough edges is used, the proper setting will not be performed and the player will not play the disc. - Page 13 CD Operation (Continued) Pausing a CD: Press the button to pause the disc. Press it OPEN again to resume play. D SP Ejecting a CD: Press the OPEN button to fold down the front panel to access the disc slot. Press the but- ton to eject the disc.
-
Page 14: Mp3 Disc Operation
MP3 Disc Operation General Operations: 1. Press the button to turn the unit On. OPEN 2. Press the OPEN button to fold down the front DISP panel to access the disc player slot. 3. Gently insert the disc into the slot with the label side up. -
Page 15: Cd Changer Operation
CD Changer Operation (Option) Load CDs into Changer: Insert the CD magazine into the external CD changer. Power On/Off: Press the button to turn the unit On. OPEN DISP Selecting the Play Source: Press the MODE button until “CDC” appears in the display. -
Page 16: Cd Changer Operation
CD Changer Operation (Continued) (Option) Repeating a CD Track or Disc: Select the desired track to be repeated. Then press OPEN the RPT button and “RPT” will appear in the dis- DISP play. This track will play repeatedly. Press and hold the RPT button. “RPT” and will appear in the display. -
Page 17: Sirius Satellite Radio Setup
Sirius Satellite Radio Setup (Option) Note: If your Sirius tuner is not activated, call 1-888-539-7474 to activate. The Sirius Tuner ID Number (ESN) is required during the activation process. Following the instructions below to access the Sirius Tuner ID Number (ESN): Accessing your Sirius Tuner ID Number (ESN): Press the MODE button until “SIR1 RADIO”... - Page 18 Sirius Satellite Radio Operation (Option) (Continued) Manual Tuning: Press the button until the desired OPEN channel appears in the display. D SP Lower Higher Channel Channel Channel Number Direct Tuning: 1. Press the MENU button until “DIR - - -” OPEN appears in the display.
- Page 19 Sirius Satellite Radio Operation (Option) (Continued) Category Tuning: 1. Press the MENU button and “CATEGORY” OPEN starts flashing in the display. DISP Category Mode “Flashes” 2. Press the 1 or 2 button to select the OPEN desired category. D SP Category 3.
- Page 20 Sirius Satellite Radio Operation (Option) (Continued) Memorizing a Preset Channel: Preset Channel Indicator 1. Press the ENT BND button to select either the SIR1, SIR2 or SIR3 Sirius band. Each band OPEN can memorize 6 channels for a total of 18 channels.
-
Page 21: Ipod Operation
WM1-CD. 3. The unit will automatically switch to the IPOD mode and start playing. Note: The IPOD controls will become inoperable, and the WM1-CD now controls the IPOD. IPOD Mode Button Location and Functions: OPEN DISP 1. Menu Button: Same operation as the MENU 3. - Page 22 IPOD Operation (Option) (Continued) Browse for a Song: 1. Press the MENU button until PLAYLIST OPEN appears in the display. DISP 2. Press the button to select the OPEN “SONG” menu. DISP 3. Press the ENT BND button to activate the “SONG”...
-
Page 23: Usb Operation
2. Connect a MP3 player to the USB cable com- ing from the WM1-CD. 3. The unit will automatically switch to the USB mode and start playing. Note: The controls on the MP3 player will become inoperable, and the WM1-CD will now control the MP3 player. -
Page 24: Auxiliary Audio Input Operation
On. DISP 2. Press the MODE button until “AUX IN” appears in the display. 3. Refer to the audio device’s owners manual for proper operation. Note: The WM1-CD will not control the auxiliary source, but can adjust the sound controls. -
Page 25: Setup Features
Setup Features Button Beep On and Off Confirmation: Follow the instructions below to turn On or Off the OPEN button when pressed beep confirmation. DISP 1. Press and hold the SETUP button approxi- mately 10 seconds until “BEEP ON” appears in the display. -
Page 26: Installation
Installation Sheet Metal Metal Strap Screw Attach Metal Washer Strap Here Dashboard Mounting Screws Snap-On Gasket End Cap Snap-On End Cap... -
Page 27: Speaker Connections
Speaker Connections Left Right Front Front Speaker Speaker White/Black Wire Gray/Black Wire White Wire Gray Wire Left Right Rear Rear Speaker Speaker Violet/Black Wire Green/Black Wire Green Wire Violet Wire Powered Subwoofer (Optional Model: LS-SUB-75) Subwoofer Output (Mono) Green Cable... -
Page 28: Auxiliary Connections
Auxiliary Connections This unit for use only with a 12 Volt DC power source with a negative ground. Red Wire (+) to 12 Volt Ignition Yellow Wire (+) to 12 Volt Constant Black Wire Ground Blue Wire Amplifier Control Front Line Out Brown Cable 2-Channel... -
Page 29: Input Connections
Input Connections Sirius Antenna (Optional) Sirius Receiver (Optional) IPOD (Optional) iPod Cable (Optional) RCA Connectors Audio Input Yellow Cable Audio Output (Optional) MP3 Player (Optional) MP3 Cable (Optional) -
Page 30: Input Connections
Input Connections (Continued) External Automotive Type Antenna (Optional) Infrared Remote Sensor (Optional) CD Changer (Optional) Wired Remote Controller (Optional Model: WRC-P1, WRC-S1, WRC-S2) -
Page 31: Replaceable Fuse
Replaceable Fuse If the fuse should blow, check that the wiring is correct. If the wiring is correct, replace the fuse with the same amperage rating as the original (15 amp). 15 Amp Fuse... -
Page 32: Warranty
