- Page 1 SUKI Dehumidifier EUR 505 User’s Manual Lion Healthcare PO Box 566, Cottesloe, WA, 6911 Phone 1800 011 653 Email sales@salinplus.com www.salinplus.com...
-
Page 2: Table Of Contents
Contents Structure and principle Features ...........................3 Specifications ......................... 4 How dehumidifying works .................... 4 Device overview ......................5 Operation Control panel ........................5 Operation instructions ....................6 Continuous draining ......................7 Maintenance Storing the dehumidifier ....................8 Important safeguards ....................8 Caring for the dehumidifier ..................9 Troubleshooting ...................... -
Page 3: Features
Features Powerful dehumidifying capability Excellent drying laundry function The dehumidifier powerfully removes excess The dehumidifier dries laundry quickly. This can moisture from the air creating a drier, healthier prevent laundry and furniture from becoming home environment. damp and musty in a rainy season. Quiet operation Drainage tank with a large capacity The dehumidifier is suitable for over night... -
Page 4: Specifications
Specifications MODEL EUR 505 Power Supply 220 240V ~ 50Hz 50 L/D (30 C 80%RH) Moisture removal 740W Power input (W x H x D) 591 x 381 x 305mm Size of shell 20kg Weight Operating temperature Operating temperature C ~ 35... -
Page 5: Device Overview
Device Overview CONTROL PANEL HANDLE OUTLET FOR INTAKE OF DEHUMIDIFIED MOIST AIR DRY AIR FILTER CONTINUOUS DRAINAGE HOLE DRAIN ROLL BUCKET CASTORS Control panel... -
Page 6: Operation Instructions
Operation Instructions START OPERATION Place the device in an upright position on a flat, steady, stable, heat-resistant surface. Make sure there is nothing flammable or heat sensitive within 100 cm (39 inches). Operating the device in any other position could cause a hazard. Make sure the plug is firmly plugged into the wall socket. -
Page 7: Continuous Draining
Continuous Drainage CONTINUOUS DRAINAGE OPTION To save having to periodically empty the water tank, this unit can be configured for continuous drainage. You can use the supplied drain hose to connect to the continuous drainage connector. Unscrew and remove the drain cover at the rear of the unit. Remove the soft rubber pad. -
Page 8: Storing The Dehumidifier
Storing the Dehumidifier When the device is not to be used for a long period of time Fold up the power supply cord. Discard any water left in the drainage tank and wipe away any remaining drops with a cloth. Clean the air filter. -
Page 9: Caring For The Dehumidifier
Caring for your Dehumidifier Before cleaning your dehumidifier, first ensure that the device is disconnected from power supply. Outer case: Wipe the shell with a soft, slightly damp cloth. Do not immerse in any liquid. Dry with a dry cloth. Do not use harsh abrasives or solvents. -
Page 10: Warning
Warning Do not fold or knot the power Make sure the plug is inserted Do not insert multiple plugs cord as shown below! firmly and properly into the into the electrical socket as outlet! shown below! Make sure the plug is clean! After turning off the device, Do not plug in the power cord unplug the power cord! - Page 11 Cautions Do not pull the power cord as shown. Do not spray any aerosols near the device. Ensure the device is placed on a flat surface. Always keep the device at least 20 cm away from the wall to allow heat to dissipate properly. Hang clothing at least 50 cm above the device.
