Litemax Electronics PPS1831 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PPS1831 Series User Manual






(1st Edition June/14/2012)
All information is subject to change without notice.
Approved by
Checked by
(Version: V1.5)
Prepared by
LITEMAX
7F‐1, No. 135, Lane 235, Bau‐chiau Rd., Shin‐dian
Dist., New Taipei City, 23145 Taiwan.
Tel : 886‐2‐8919‐1858
Fax: 886‐2‐8919‐1300
Homepage: http://www.litemax.com/

1
Electronics Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPS1831 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Litemax Electronics PPS1831 Series

  • Page 1 PPS1831 Series User Manual (1st Edition June/14/2012) (Version: V1.5)     All information is subject to change without notice. Approved by Checked by Prepared by     LITEMAX Electronics Inc.    7F‐1, No. 135, Lane 235, Bau‐chiau Rd., Shin‐dian    Dist., New Taipei City, 23145 Taiwan.    Tel : 886‐2‐8919‐1858  Fax: 886‐2‐8919‐1300  Homepage: http://www.litemax.com/   ...
  • Page 2 Record of Revision Version    Date  Remark  1.1  Mar/30/2012  Initial Release  1.2  Apr/02/2012  Second Version  1.3  Apr/04/2012  Third Version  1.4  May/22/2012  Fourth Version  1.5  June/14/2012 Fifth Version       ...

  • Page 3: Copyright Notice

    Copyright Notice This document is copyrighted, 2012. All rights are reserved. The original manufacturer reserves the right to make improvements to the product. The information contained in this document is subject to change without notice. This Document contains proprietary information that is protected by copyright. No part of this document may be photocopied, reproduced, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer.

  • Page 4: Safety And Warranty

    Safety and Warranty 1. To disconnect the machine from the electrical power supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine. 2.
  • Page 5 Safety Symbol Description The following safety symbols are the further explanations for your reference.
  • Page 6 for FCC 15b devices This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 7 Legislation RoHS and WEEE Symbol Restriction of the use of certain Hazardous Substances This product uses components that comply with the requirements of the Restriction of the use of certain Hazardous Substances (RoHS) Directive 2002/95/ EC. WEEE 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components.
  • Page 8 Acknowledgments  Intel®, CoreTM 2 Duo / Celeron are registered trademarks of Intel® Corporation.  IBM, PC/AT, PS/2 are trademarks of International Business Machines Corporation.  Microsoft® Windows is a registered trademark of Microsoft® Corporation.  RTL is a trademark of Realtek Semi-Conductor Co., Ltd. ...

  • Page 9: Table Of Contents

    Table of Contents 1. Item Checklist ................11 2. General Information ..............13 2.1 Introduction ............... 13 2.2 Feature ................13 2.3 Specification ..............14 2.4 System View ..............15 2.5 Product Dimension ............17 3. Hardware Installation and Power on/off ........19 3.1 Safety Precautions ............
  • Page 10 6. OSD Setting ................44 6.1 Brightness Menu ............... 44 6.2 Audio Menu ............... 45 6.3 Auto Color Menu ............... 46 6.4 Color Temperature Menu ..........46 6.5 Auto Adjust Menu .............. 47...

  • Page 11: Item Checklist

    1. Item Checklist Take out the system unit from the carton. Remove the unit by carefully clutching the foam inserts and remove slowly to protect the system. The following contents should be found in the carton: 1 x PPS Series Panel PC ...
  • Page 12 AC/DC Power Adaptor CD for User Manual and Touch Driver Packing...

  • Page 13: General Information

    2.0 General Information 2.1 Introduction The intended use of the Litemax’s “Infotainment System：PPS1831” is made for the security staff and care takers in daycare, hospital and clinical settings for monitoring. PPS1831 is 18.5 inch fanless multi function panel PC, feature power efficient Intel embedded processor and advance long life LED backlight display.

  • Page 14: Specification

    2.3 Specification Model Number PPS1831 18.5" Fanless, Intel® ATOM™ D510 1.66GHz Processor, Description Multi-Function Panel PC Display 18.5" Wide LED Backlight 304.128x228.096 mm Active Display Area Brightness 250 cd/m2 Resolution 1366x768 (HD) Touch Screen Projective Capacitive Multi-Touch Computing Platform Intel® Atom D510 1.66GHz Processor Chip Set Intel®...

  • Page 15: System View

    Construction Antibacterial plastic housing Mounting VESA75/VESA100 Dimension 447.2x302.9.7x58.98 mm Net Weight 5.4Kg Environmental Operating 0°C~40°C Temperature Storage Temperature -20°C ~ 60°C Operating Humidity 5~95% @ 40°C, non-condensing 2.4 System View 2.4.1 Front View...
  • Page 16 2.4.2 Rear View 2.4.3 Buttom View...

  • Page 17: Product Dimension

    2.5 Product Dimension  ...

  • Page 19: Hardware Installation And Power On/Off

    3.0 Hardware Installation and Power on/off 3.1 Safety Precautions Always completely disconnect the power cord from your board whenever you are working on it. Do not make connections while the power is on, because a sudden rush of power can damage sensitive electronic components. Always ground yourself to remove any static charge before touching the board.
  • Page 20 3.2.2 Push HDD set into the HDD housing, the connector of HDD toward the housing. 3.2.3 Make sure HDD is connected properly with HDD bay, and then close HDD cover with screw.

  • Page 21: Cf Card Installation

    3.3 CF Card Installation 3.2.1 Remove the HDD cover screw. (CF card is set in the same bay with HDD) 3.2.2 Assembly CF card on the CF carrier metal. 3.2.2 Push CF set into the CF housing, the connector of CF card toward the housing. 3.2.3 Make sure CF card is connected properly with CF bay, and then close HDD cover with screw.

  • Page 22: Telephone Set Installation

    3.4 Telephone Set Installation 3.4.1 Tighten the mounting screws on the edge side of phone holder. 3.4.2 Put on the IP Phone and connect the phone cable with bottom side RJ11 connector.

  • Page 23: Msr Installation

    3.5 MSR Installation 3.5.1 Tighten the MSR metal set on the edge side of computer. 3.5.2 Assembly MSR module into the metal set. 3.5.3 Connect the MSR cable with edge side USB connector.

  • Page 24: Power On/Off Operation

    3.6 Power on/off 3.6.1 Power on the unit, touch the Power on/off symbol for 5 seconds till LED indicator lighting. 3.6.2 If the computer is working on Windows system, power off the unit through OS shut down bottom. Or touch the power on/off symbol for 5 seconds.

  • Page 25: Bios Setting

    4.0 BIOS Setting 4.1 Main Features Setup 4.2 Advanced Chipset Setup...

  • Page 26: Chipset Feature Setup

    4.3 Chipset Setup 4.4 Boot Devices Setup...

  • Page 27: Security And Password Setup

    4.5 Security and Password Setup 4.6 Save and Exit Option...

  • Page 28: Driver Installation

    5.0 Driver Installation 5.1 Wire-Less LAN Driver Installation Please found driver file in the driver CD, file name is ”Install Bluewu2.3.04.101224 driver” Please click ”Install”...
  • Page 29 Please click ”Yes” Please click ”OK”...
  • Page 30 Please click ”Next” Please select “I accept the terms in the license agreement”, and then click “Next”...
  • Page 31 Please click “Next” Please click “Install”...
  • Page 32 Please click “Finish” Please click “Next”...
  • Page 33 Please click “Install” Please click “Finish”...
  • Page 34 Please click “Yes”, and then restart the system...

  • Page 35: Card Reader Driver Installation

    5.2 Card Reader Driver Installation Please found the Card Reader Driver from CD, file name is “\\Driver\Setp 5 - Option\Castles_SCR & RFID\Win7 driver\Windows7 32bit\setup” Please click “ ok”...
  • Page 36 Please click “Next” Please click ”Install”...
  • Page 37 Please click “OK” Please click “Finish”...
  • Page 38 Setup EZ710 smart card in device manager Please select “Update Driver Software” Please select”Browse my computer for driver software”...
  • Page 39 Please found the Card Reader Driver from CD, file name is “\\Driver\Setp 5 - Option\Castles_SCR & RFID\Win7 driver\release_ez710” Please click “OK” Please click “Next”...
  • Page 40 Please click “Close” Please select “Update Driver Software”...
  • Page 41 Please select”Browse my computer for driver software” Please found the Card Reader Driver from CD, file name is “\\Driver\Setp 5 - Option\Castles_SCR & RFID\Win7 driver\release_ez710” Please click “OK”...
  • Page 42 Please click “Next” Please click “Close”...
  • Page 43 Completed...

  • Page 44: Osd Setting

    6.0 OSD Setting 6.1 Brightness Menu By pressing the “menu” button, you will see the below picture. Across from timing you will see resolution, frequency, and V-frequency of the panel. Version shows the firmware control version. These cannot be altered by the user. There are 7 sub menus within the OSD user interface: Brightness, Signal Select, Sound, Color, Image, Tools, and Exit.

  • Page 45: Audio Menu

    Press ’’right’’ key Press ’menu’’ once, to adjust minimum luminance to fit your application (OPTION) Contrast: Press “menu” and “right” buttons to adjust the contrast from “0” to “ 100”. To adjust from “100” to “0”, press “menu” and the “left” buttons. Exit: You can exit this sub menu back to normal screen.

  • Page 46: Auto Color Menu

    6.3 Auto Color Auto Color: By navigating over to the “Auto Color” option, optimal color performance is invoked. SRGB: Windows standard color setting 6.4 Color Temperature Menu Color Temperature: You have 3 options in this selection Color Temperature User Define: Default is 100 for “R”, “G”, and “B”. Color Tempture_6500K: Warm color scheme...

  • Page 47: Auto Adjust Menu

    HPos: You can shift the screen horizontally using this function. Vpos: You can shift the screen vertically using this function. Exit: Back to normal screen. Litemax Electronics Inc. 7F-1, No. 135, Lane 235, Bau-chiau Rd., Shin-dian Dist., New Taipei City, 23145 Taiwan. AlfaNet Computer & Electronic Handle...
