Page 1 ATEIS INTERNATIONAL UAPG2 G2 MANUAL Full instruction guide for the Universal Audio Processor Generation 2 Ateïs International 13/4/2010 Version : EN.24a...
Page 2: Table Of Contents
INTRODUCTION ..........................7 WELCOME ............................. 7 PRESENTATION ..........................7 PRODUCTS ..........................7 DEVELOPMENT.......................... 7 ATEÏS Field of applications ......................8 UAPG2 G2 PRESENTATION ........................ 8 INSTALLATION ........................... 9 SYNOPTIC ............................10 SYSTEM OVERVIEW ......................... 11 MACHINE............................. 11 AUDIO ............................11 LINKING ............................
Page 3 UAPG2 MANUAL Version EN.24 SOFTWARE INSTALLATION ......................22 ACCESS / PASSWORD ........................24 UPDATE UAPG2 SOFTWARE AND FIRMWARE ................25 PREPARATIONS ........................... 25 1. Get Recent Software from the WWW ................25 2. Remove Older Version ......................25 Install New Version ........................25 FIRMWARE UPDATE ........................
Page 4 UAPG2 MANUAL Version EN.24 Check UAPG2 version ........................75 Updating Software UAPG2/URC/PPM firmware version ............76 Update DSP ..........................76 Update MCU ........................... 76 Update URC ..........................77 Update PPM ..........................77 Upload (Store) a design file into UAPG2 ..................78 Adjust Time / Date ........................
Page 5 UAPG2 MANUAL Version EN.24 Read a Parameter Value ....................... 136 Checksum calculation ......................137 Set RS232 Third party control parameters ................137 Use third party over IP ......................138 Use Events (Element adjustment, Master-Preset, Sub-Preset) ..........140 Event Triggering ........................140 Events types ..........................
Page 6 UAPG2 MANUAL Version EN.24 Compressor ........................... 185 Expander ........................... 187 Comp-Limiter ........................188 Equalizer............................ 188 PEQ ............................189 GEQ ............................190 Delay ............................191 Delay (basics) ........................191 Delay (advanced) ........................192 Gate ............................193 Gate Mono ..........................193 Gate With Sidechain ......................194 Gate Stereo ...........................
Page 7: Introduction
This manual can be updated at any time without prior notice in order to keep this manual up to date. In case of errors in this manual or not clear process description, feel free to submit us mistakes, suggestions or questions by sending an email: info@ateis-international.com subject: UAPG2 manual corrections.
Page 8: Ateïs Field Of Applications
- Industrial plants - Commercial buildings UAPG2 G2 PRESENTATION The ATEÏS UAPG288 G2 is the new generation of Universal Audio Processor developed by ATE ÏS. Why Generation 2? Our developers completely re-design the old UAP88. Now the processor is the state-of-the-art solution to meet almost all requirements of modern sound design in contemporary applications.
Page 9: Installation
UAPG2 MANUAL Version EN.24 RS485 network). Wall mounted source selectors, smart controllers and programmable paging mikes are available. INSTALLATION RACK MOUNTING: If needed, fit the rack mounting brackets to each side of the UAPG2 by using the 6 pcs Phillips M3X screws supplied with the package.
Page 10: Synoptic
UAPG2 MANUAL Version EN.24 SYNOPTIC...
Page 11: System Overview
UAPG2 MANUAL Version EN.24 SYSTEM OVERVIEW MACHINE The UAPG2 is made of: • 4 slots of 4 audio channels • 8 Front knobs (ability to pilot every adjustment you define in the UAPG2) • 16 (0 to 5 VDC) Control inputs either analogue or Logical (contacts) •...
Page 12: Preset Management
UAPG2 MANUAL Version EN.24 PRESET MANAGEMENT The UAPG2 includes two types of presets: Sub-preset: They enable values of multiple parameters of the same design, such as levels, gains, EQ, etc. to be restored either from the PC software, the remote controllers or the control inputs. Master preset: They enable completely different designs to be restored.
Page 13: Additional Features
UAPG2 MANUAL Version EN.24 ADDITIONAL FEATURES • User-management: Up to 40 users with individual access rights, password protected • Control table, with the addresses (names) and commands of all the control parameters accessible via the RS232 serial port and through TCP/IP. SCHEDULER The scheduler allows planning of events (preset change, message play, close/open TTL out or change component’s adjustments).
Page 14: For Your Safety
UAPG2 MANUAL Version EN.24 FOR YOUR SAFETY Please follow the instructions in this chapter to get the optimum results from these units. EXCLUSION OF RESPONSIBILITY Manufacturer, importer, or dealer shall not be liable for any incidental damages including personal injury or any other damages caused by improper use or operation of the UAPG2. INTERFERENCE Like all computing devices, the UAPG2 uses high frequency digital circuitry that may cause interference on radio or television equipment placed close to the unit.
Page 15: Contacts
Ateïs Middle East Building SEA, room 324, DAFZA, DUBAÏ, United Arab Emirats Phone: +971 4609 1325/24 Fax: +971 4609 1326 Web, contact: http://www.ateis-international.com/ Ateïs France 34, avenue de l’Europe, Z.A Font Ratel, CLAIX, FRANCE Phone: +33 (0) 4 76 99 26 30 Fax: +33 (0) 4 76 99 26 31 Web, contact: http://www.ateis-france.fr/...
Page 16: Hardware Description
UAPG2 MANUAL Version EN.24 HARDWARE DESCRIPTION FRONT PANEL 1) CONFIGURABLE AUDIO I/O Inside the UAPG2 you have 4 audio slots (named A, B, C and D). Each of these audios slots receives either 4 audio inputs channels or 4 audio outputs channels. When you switch on the UAPG2 you can see which kind of audio card is fitted in each slots: •...
Page 17: Ethernet Led
UAPG2 MANUAL Version EN.24 5) ETHERNET LED Light when the UAPG2 is connected (on-line) to TCP/IP network. 6) STANDBY BUTTON Activates standby mode REAR PANEL 1) POWER SECTION Insert provided power cable first into UAPG2 then in the wall power connector. Power switch: •...
Page 18: Link Connectors
UAPG2 MANUAL Version EN.24 4) LINK CONNECTORS If you want to put several UAPG2 in your rack (increase the number of input/output or remote controllers) simply use straight CAT5 cable to connect “digilink” output to the “digilink” input of the next sub-UAPG2.
Page 19: Control Input Conectors
UAPG2 MANUAL Version EN.24 7) CONTROL INPUT CONECTORS Either connects logical input (TTL IN, dry contact) or analogical input (10 k Ohm potentiometer). Simply connect the switch or relay or potentiometer between the number (1 and 16) and the G (ground).
Page 20: Logic Outputs Connectors
UAPG2 MANUAL Version EN.24 9) LOGIC OUTPUTS CONNECTORS The Contact closes when the Logic Output is active. The logic outputs are simple dry contact or relay contact, with a common rail. The common rail is linked to the ground. Caution: Do not connect voltage (24V) to the common rail. No voltage is provided.
Page 21: System Installation
UAPG2 MANUAL Version EN.24 SYSTEM INSTALLATION SOFTWARE GENERALITIES The UAPG2 software is a powerful, yet easy to handle tool to assist you creating, controlling and monitoring DSP-Designs for UAPG2 systems, supporting up to 12 processors including all the controlling gear connected to it. After the determination of which type and how many units would make up your network, you can start designing signal paths with all the exiting features the huge component library offers simply by drag and drop and connect different audio component.
Page 22: System Requirements
You may need to update firmware see FIRMWARE UPDATE chapter. Copy the file 'ATEIS UAPG2 v.1.x.x setup' using the copy and paste commands or by drag and drop to the 'Desktop'. Wait until the task has finished. Start the program 'ATEIS UAPG2 v.1.x.x setup' by double click on its icon and follow the instructions to install the UAPG2 software onto your hard drive.
Page 23 If there is nothing to change click to execute the installation. After all installation tasks have been finished successfully click to exit wizard. The installation program creates a shortcut to the 'ATEIS UAPG2 v.1.x.x .exe' named 'UAPG2 v1.x.x' on your 'Desktop' with the UAPG2 icon.
Page 24: Access / Password
UAPG2 MANUAL Version EN.24 Double click the icon to start the program. Plug in your UAPG2's and install the drivers. ACCESS / PASSWORD At the software start-up an UserID will be requested to have an access to the software. • UserID: software &...
Page 25: Update Uapg2 Software And Firmware
Double click the 'Add or Remove Programs' icon • Locate and choose 'ATEIS UAPG2-PPM v1.x.x' and click the 'Remove' button • Follow the instructions to remove the 'ATEIS UAPG2-PPM v1.x.x' software from your hard drive Install New Version Proceed similar as stated in software installation chapter.
Page 26: Additional Devices For Uapg2 System
UAPG2 MANUAL Version EN.24 ADDITIONAL DEVICES FOR UAPG2 SYSTEM To maintain simple, secure and intuitive interfaces for operators, the UAPG2 offers different types of remote controllers: • Universal Remote Control (URC) • Programmable Paging Microphone (PPM) • RAC5 or RAC8 •...
Page 27: Rac (Remote Access Control)
UAPG2 MANUAL Version EN.24 RAC (REMOTE ACCESS CONTROL) Allow using analogue inputs for selecting a channel among 5 or 8 and setting the volume. • RAC5 - Wall-mounted level and 5 sources selectors • RAC8 - Wall-mounted level and 8 sources selectors JB (JUNCTION BOX) Easy chain connection of UAPG2 peripherals (URC and PPM), using standard CAT5 cables.
Page 28: Software Presentation
UAPG2 MANUAL Version EN.24 SOFTWARE PRESENTATION General View TITLE BAR Displays the path name of the current file Holds all the functionalities of the software (windows and MENU BAR tools), arranged by topic. Short access to main functionalities that are hidden into menu TOOLS BAR bar.
Page 29: Title Bar
UAPG2 MANUAL Version EN.24 TITLE BAR The title bar displays UNIVERSAL AUDIO PROCESSOR G2- untitled, if you start a new system design, or the full path name of the current saved file. At the right hand corner you can find the usual Windows minimize button and the close box (in red), which exit the program.
Page 30 UAPG2 MANUAL Version EN.24 Save Saves the current file you are currently working with Save as… Opens the “Save as…” dialog box to save the current working project with a different name and/or path Open… Opens the “Open...” dialog box which allows you to select a path and open a saved file Open autosaved Opens the last auto saved file Recent files...
Page 31 UAPG2 MANUAL Version EN.24 Print Preview Opens the “Print preview “dialog box which allows you to see before printing what your print will look like. Here is an example with a factice simple design: Top left you can see the header (blue box), defined via the “print header settings” window. Opens the “Windows©...
Page 32: Exit
UAPG2 MANUAL Version EN.24 Exit Terminates the current UAPG2 session after asking to save modified files Edit Here you will find all the common basic edition tools of windows based software. The Edit menu contains the following items: • undo •...
Page 33 UAPG2 MANUAL Version EN.24 Alignment You can select several elements (by maintaining left click and move the mouse you will have a selection square) then you can align all the elements. Pack You can select several elements (by maintaining left click and move the mouse you will have a selection square) then you can pack the elements.
Page 34: View
UAPG2 MANUAL Version EN.24 View In this topic you will find practically every windows of the software. Most part of those windows has short access from the TOOL BAR. We are going to introduce you every items. To learn how to use those items please refer to the “create a project”...
Page 35 UAPG2 MANUAL Version EN.24 Components Opens the Components window, in the DESIGN COMPONENTS AREA Once your (virtual) system has been defined you will define what the processor will do between Inputs and Outputs. Here are all the tools you can use for signal processing and for Audio routing etc.
Page 36 UAPG2 MANUAL Version EN.24 Third Party control Opens the Third Party Control window in the PROPERTIES CONTROL AREA This section shows you all the detail of all the elements or events which are designated to be controlled via third party device (Crestron, AMX, VITY, …) Two different TABS, One to show the Elements controlled via third party protocol: The second to show the Events controlled via third party protocol...
Page 37 UAPG2 MANUAL Version EN.24 3) You can use logic in to pilot every logic adjustments in every UAPG2 of the system (bypass, mute, routing, solo,…): 4) Finally you can choose to start events with logic input: For more information, see the “HOW TO: use Logic Input” chapter of this manual. Logic out Opens the Logic OUT Control window in the PROPERTIES CONTROL AREA You have two possibilities to control the 8 logic outputs of one UAPG2.
Page 38 UAPG2 MANUAL Version EN.24 2) Logic inputs of a UAPG2 can control a Logic output of a remote UAPG2 (in order to give some logic signal to a remote device for example): For more information, see the “HOW TO: use Logic Output” chapter of this manual. Analogue in Opens the Analogue in window in the PROPERTIES CONTROL AREA You can control some analogical elements with remote 10kOhm potentiometer (volume, attack time...
Page 39 UAPG2 MANUAL Version EN.24 Remote List Opens the Remote List window in the PROPERTIES CONTROL AREA When you want to use Ateïs remote device (PPM or URC, through RS-485 network), you have to follows few steps (see HOW TO use PPM or URC chapters), one of those step is the searching process: •...
Page 40 UAPG2 MANUAL Version EN.24 Wave File Manager Opens the Wave Files List window (floating window) With this window you select which wave file will be used with your project. PPM versus Wave Table Opens the PPM vs Wave Table window (floating window) Gives details about which wave file is loaded in which PPM (wave file associated to which UAPG2 and input’s number) Logo Manager...
Page 41 UAPG2 MANUAL Version EN.24 Logo Library Opens the Logo Library window (floating window) With this window, you choose which logo you will use in your project. Event Management Opens the Event Management window (floating window) Here you can add, define, select or clear some events.
Page 42 UAPG2 MANUAL Version EN.24 Virtual Control Opens the Virtual Control window (floating window) and Virtual tools in the DESIGN COMPONENTS AREA The “virtual Control” allow you to define group of buttons, LEDs, or faders. You can import these groups in the Monitor Window. You can add as many “virtual logical in”, “virtual logical out”...
Page 43 UAPG2 MANUAL Version EN.24 When a specific restricted access user will start the software he will see the monitor window. So it is why there are a lot of small sized tools (the same as in the TOOLS BAR). Establish Ethernet link Open UAPG2 project file Save UAPG2 project file Connect PC too UAPG2 system...
Page 44: Monitor Settings
UAPG2 MANUAL Version EN.24 Monitor Settings Opens the Monitor settings window (floating window) When you use monitor window you can choose to hide some tools (of the monitor window tools bar) Disable the possibility to change Master or Sub presets from the monitor window. The master-Preset menu on the monitor window is greyed out.
Page 45: User
UAPG2 MANUAL Version EN.24 User In this topic you will find windows related to system communication (Ethernet: ID and UAPG2 system: User). Most part of those windows has short access in the TOOL BAR. We are going to introduce you every items. To learn how to use those items please refer to the “create a project” and “how to”...
Page 46: Id Management
UAPG2 MANUAL Version EN.24 ID Management Opens the ID Management window (floating window) This feature is available to prevent all unauthorized people to connect to the system via the network. The ID management allows to gives access to the Master-Preset with an user name and password. With this window you can create new user ([Add]) Erase users ([Delete]) Close the window ([Close])
Page 47: Operation
Disconnects your computer from the UAPG2 system Allow you to change settings and re-upload them into UAPG2 system Audio Enable Activates the Audio (Outputs) of the UAPG2 g2 system Audio Disable Stops every audio signals going out of the UAPG2 system...
Page 48: Tools
UAPG2 MANUAL Version EN.24 Tools In this topic you will find windows related to system configuration and software settings. We are going to introduce you every items. To learn how to use those items please refer to the “create a project”...
Page 49 UAPG2 MANUAL Version EN.24 Machine Configuration Opens the Machine Configuration window (floating window) When you are connected to the UAPG2 system This window allows you to read and set some internal UAPG2 information. Date/time: set the internal date and time of the UAPG2g. Click [read] to see which settings are into each UAPG2 of the system Click [SET] to load some settings changes Click [Get Current Time] to get computer date and time directly.
Page 50 UAPG2 MANUAL Version EN.24 RS-232 SET: Set the RS232 communication, Baud rate, parity, Stop bit and connected target Click [read] to see which settings are into each UAPG2 of the system Click [SET] to load some settings changes NTP: Set the UAPg2 to have the date/time updated in real-time by the NTP servers. NTP means Network Time Protocol.
Page 51: Parameter Setting
UAPG2 MANUAL Version EN.24 Parameter Setting Opens the Parameter setting window (floating window) This window is applied to setting the parameter of dsp elements with maximum and minimum value. There are two tab sheets: Global: Here you can define a range or specifics values and give a name to this specific range then in the Private tab you can assign this specific range to specific component.
Page 52: Clear Mcu Data
UAPG2 MANUAL Version EN.24 Clear Remote IP Opens the Parameter setting window (floating window) Clear the IP addresses of the remote devices (PPM, URC) connected to the selected UAPG2(s). If you add new remote device or change something in the system you may have to clean all IP addresses and re-give addresses (Search process in the remote list window: sheet 39).
Page 53 UAPG2 MANUAL Version EN.24 Option Opens the options window (floating window) This option window contains 6 different tabs. Here are the details of each tab: DSP design: Active some option regarding design (working area): 1) Show animation, the Icons are animated 2) Show print boundaries, you will see on the working area the limits of each page.
Page 54 UAPG2 MANUAL Version EN.24 Results: Store: 1) Auto Connect to system, notch it if you want that UAPG2 software auto connect after uploading a design file into UAPG2 system. If you do not active this option a message box will appears asking you if you want to connect or not. 2) Auto enable Audio after connecting, notch if you want that audio can go out from UAPG2 after uploading a design.
Page 55 UAPG2 MANUAL Version EN.24 Establish Ethernet Link Opens the IP Setting window (floating window) When you want to use UAPG2 system you have first to open communication (Ethernet link) between your computer and the UAPG2 system. 1) If you do not know the UAPG2 IP address click on [search].
Page 56: Lock
UAPG2 MANUAL Version EN.24 Lock In this topic you will find windows related to secure the software when you leave it. You have the possibility to lock the software in order to prevent unwanted use when you are away from it. The Lock menu contains the following items: •...
Page 57: Window
UAPG2 MANUAL Version EN.24 Window In this topic you will find tools to re-arrange windows or find hidden opened windows. The Window menu contains the following items: • Cascade • Tile • Arrange Icons • Current opened windows list name Cascade Arrange every opened window in cascade mode Tile...
Page 58: Help
UAPG2 MANUAL Version EN.24 Help In this topic you will find some features. The Tools menu contains the following items: • Version • Activate • About • Soft-Keyboard Version Opens the Version window (floating window) This window allows you to know which versions are installed into UAPG2, PPM, URC and which version has to be used with the current software.
Page 59: Start A Project (Basics And Generalities)
UAPG2 MANUAL Version EN.24 Start a project (basics and generalities) Generalities (software philosophy) When you want to design a project: After installing hardware (connection, powering etc.) see Connect PC to UAPG2 (page 68 ), you will use UAPG2 software to: 1.
Page 60: Prepare Your New Project
UAPG2 MANUAL Version EN.24 1) Prepare your new project To start a new project file choose: > File > New from the main menu. You can also type: [Ctrl]+[N], or click the 'New' icon in the toolbar. < or > 2) Define which hardware is used in your project The term 'System' in UAPG2's terminology refers to one or up to 12 UAPG2 machines linked via digilink cards, with the 'System' window in the 'Design View Area' providing the canvas to build it up...
Page 61 UAPG2 MANUAL Version EN.24 Since there are many combinations audio boards can be fitted or omitted, let's just take a detailed look to the configuration of the UAPG2 0808. Configurations of other machines are made respectively to their I/O boards fitted similar to the following instructions below. By default the UAPG20808 comes with the following boards fitted: Slot A: Analogue Input...
Page 62: Define Control Inputs As Ttl (Logic) Or Analogue Inputs
UAPG2 MANUAL Version EN.24 If you right click on the dragged and dropped UAPG2 icon you will have access to some features: • Name: give a name to this UAPG2 • Delete: same issue as selecting and press “DEL” key (delete the virtual UAPG2) •...
Page 63: Ttl And Groups
UAPG2 MANUAL Version EN.24 TTL and Groups In this example we will change the control 10 from analogue to TTL. By default the controls input are defined like this in the external settings: At first, change the control 10 to TTL: Then open View/Logic IN, and select the tab "Groups".
Page 64: Create Audio Signal Path
UAPG2 MANUAL Version EN.24 4) Create audio signal path All of the DSP functions of a processor are made in their DSP function design windows. To access these windows double click the processors icon in the 'System' window or choose: >...
Page 65: Assignation Philosophy (Choose Which Adjustments Will Be Piloted By What)
UAPG2 MANUAL Version EN.24 5) Assignation philosophy (choose which adjustments will be piloted by what) Once your signal path is created by using component you can choose how to pilot or which action will produce each parameters of every components. To have access to parameters of components simply double click on the desired component.
Page 66: Right Click On A Analogical Button Of A Parameters Of A Component
UAPG2 MANUAL Version EN.24 defined). If you click none you erase all previous assignment of this parameter in this UAPG2. Control: Here you can choose to active one (or several) Logic connector(s) of the UAPG2 system with this button (logic in) or to activate this button with hardware control input. 1) Type of hardware connectors assigned to this software logic In.
Page 67 UAPG2 MANUAL Version EN.24 Control: Here you can choose to pilot this fader with hardware control input. 1) Type of hardware connectors assigned to this software analogue in. 2) Name of UAPG2 in the system which will have the assigned connector.
Page 68: How To
UAPG2 MANUAL Version EN.24 How to… In this section you will have quick access to learn in details how to exploit UAPG2 capabilities. Please, except the first four sections, read the Start a project (basics and generalities)chapter before this section in order to learn the basics. Connect PC to UAPG2 Generalities There are two types of connections with UAPG2 software:...
Page 69 UAPG2 MANUAL Version EN.24 This action will open your Network connection window: Right click on the icon of your connection (normally it is your local network) and choose “PROPERTIES” Then double click on “internet protocol TCP/IP” Choose: Use the following IP address And enter the desired IP address for your computer...
Page 70 UAPG2 MANUAL Version EN.24 2) Set Ethernet connection Now the computer is set for the right network let’s see how to choose which computer net card will be used by the UAPG2 software. Open the option window (menu tools) and choose the Network Tab Here you can see which net card is used by UAPG2 software.
Page 71 UAPG2 MANUAL Version EN.24 To scan the network and detect UAPG2 click on [search] button If you have this message box Verify the steps 1) and 2) . And close UAPG2 software and re-open it Open Ethernet connection Select the UAPG2 you want to connect to (it makes sense when you have several UAPG2) and click [connect] button.
Page 72: Uapg2 System Connection
UAPG2 MANUAL Version EN.24 UAPG2 system connection This connection allows you to pilot audio settings of UAPG2 system, change sub preset or master preset, use monitor window… To connect to the UAPG2 you have to be sure that the configuration file in the UAPG2 is the same as the file opened with the software.
Page 73: Set Up Several Uapg2 Linked Together
UAPG2 MANUAL Version EN.24 Set Up several UAPG2 Linked together You can link up to 12 UAPg2 together. This not a redondant network. That's means if one link fails, the system fails. • Link all the UAP together : Connect each Digilink output to the Digilink input of the next UAP, with RJ45 cable.
Page 74 UAPG2 MANUAL Version EN.24 • Then draw your design by drag and drop the UAP icon to the design area. For each UAP the "Configure Modules" window ask you about the Audio modules. As the system is configured, the Inputs/Outputs choice appears already correctly.
Page 75: Check Uapg2 Version
UAPG2 MANUAL Version EN.24 Check UAPG2 version To know which versions are loaded in the devices and which version are available with the UAPG2 software: • Choose menu: > Help > Version If you have trouble to read version it is probably due to the fact that the system is not configured. It means that the software doesn't know how many UAPG2 are connected to it and the UAPG2s doesn't know their place in the network (even if you have one UAPG2) to set up the system: 1) clean MCU...
Page 76: Updating Software Uapg2/Urc/Ppm Firmware Version
UAPG2 MANUAL Version EN.24 Updating Software UAPG2/URC/PPM firmware version For the software: New versions are available on the net. Read carefully the release note in order to determinate if updating is required or not for your specific system For the firmware: The purpose is to match the version contained in your UAPG2-PPM software with the version contained in UAPG2's hardware.
Page 77: Update Urc
UAPG2 MANUAL Version EN.24 Update URC • Open the Ethernet connection • Be sure the URC is detected (search process and IP address given) and connected • Choose menu: > Tools > Update... (URC tab) • Select the URC you want to update (click on the box on the left) (you can update several URC at same time) •...
Page 78: Upload (Store) A Design File Into Uapg2
UAPG2 MANUAL Version EN.24 Upload (Store) a design file into UAPG2 When all the settings (signal path) are Ok, we just have to upload them into the UAPG2 system. 1) Compile your project: menu: “Compile >Compile...” or hit Ctrl+F4 or click on this icon: 2) When this window appears click OK: If this window does not appear, or if there are warnings, there is some trouble with the configuration (design).
Page 79: Adjust Time / Date
UAPG2 MANUAL Version EN.24 7) Click Yes, the URCs and PPMs are configured when this dialogue box appears: 8) Click Ok. A dialogue box appears and asks if you want to connect to the machine. Click Yes if you want to pilot some settings with your computer. 9) Another dialogue box appears and asks if you want to “order audio_enable”.
Page 80 UAPG2 MANUAL Version EN.24 Time adjustment: If you use the UAPg2 connected to internet, our advice is to synchronize the time with NTP protocol. If you use the UAPg2 in stand alone, then the only way to adjust the time if needed is to use the parameter "Time error (Sec)".
Page 81: Adjust Time/Date With Ntp
UAPG2 MANUAL Version EN.24 Adjust Time/Date with NTP Set the UAPg2 to have the date/time updated in real-time by the NTP servers. NTP means Network Time Protocol. First of all, Select Tools Option Check the IP address on the both "Network" and "Internet Protocol" tab. The IP address of your PC (Network tab) must be in the same network than the IP address of the UAPg2 (Internet Protocol tab).
Page 82: Create New Users And Assign Specific Rights
UAPG2 MANUAL Version EN.24 Create new users and assign specific rights You can define up to 40 users. Each user is protected by password. Different user's right are adjustable for each user. To set users right: Click menu: "User --> User management" A windows appears you can add new users click or you can delete user by selecting it and clicking...
Page 83: Use The Virtual Window (Create Virtual Control)
UAPG2 MANUAL Version EN.24 Use the Virtual window (Create Virtual control) The Virtual Control allows you to define group buttons, LEDs, or Fader. You can import those groups in the Monitor Window. Open Virtual Window: menu: > View > Virtual control (or F11) 1) Select by drag and drop (from the Design Control Area to the Virtual control window) which kind of controls or indicators (Logical In, Logical Out or Knob) you want.
Page 84: Use The Monitor Window
UAPG2 MANUAL Version EN.24 Use the Monitor window The Monitor window is a window in which you can bring all the adjustments and indicators you need for your project. This is helpful if you want to have a graphical control interface. View/Monitor settings to set the options of the monitor window.
Page 85 UAPG2 MANUAL Version EN.24 Password Setup / Lock If you want to protect the access to the UAP, click on Chose and type two times a password (this is not an user or ID user management). Now you can lock the system by clicking on To unlock, click on the button and type the password.
Page 86: Use The Monitor Window In Auto-Logon
UAPG2 MANUAL Version EN.24 Use the monitor window in auto-logon You can create a specific user to have only an access to the monitor window. This user must be associate with a configuration file (*.lap). At first, disconnect with the LAP, and open File -> Save As. Save the configuration. Open User ->...
Page 87 UAPG2 MANUAL Version EN.24 Click [Ok] to save and close the window. Click [Close]. Open View -> Monitor Settings: Notch the options of the monitor window. See View/Monitor settings for more details. To have an automatic logon, notch at least "Auto Connect". Click on [Close] to close the window.
Page 88 UAPG2 MANUAL Version EN.24 Now to access to the machine, the monitor user has to follow these steps: 1. Open the LAPg2 software 2. Type the User and Password The ethernet connection and also the machine connection will be done automatically: Auto ethernet connection Auto machine connection Close these windows.
Page 89 UAPG2 MANUAL Version EN.24 To return in administrator mode, the user has to disconnect with the machine Click on the User Login , and then type the default user ADMIN. If you find trouble check the following points: • Control the settings in View -> Monitor Settings. •...
Page 90: Use Master-Preset / Sub-Preset
UAPG2 MANUAL Version EN.24 Use Master-Preset / Sub-Preset Master preset allows storing of several different DSP design in a same configuration. For example if you have room which can be separated into two smaller sized rooms etc. Sub Preset allows you to store different adjustments (Level, mute) but not (as Master preset) to change DSP design (change routing, modules...) Master preset Master preset allows storing of several different DSP design in a same configuration.
Page 91 UAPG2 MANUAL Version EN.24 2) Click and enter the name of the Sub Preset: 3) Click the name of the current Sub Preset appears: 4) Then we are going to choose which adjustments we want to assign to the Sub preset: Double click on the component you want, (for our example double click input C), then right click on the adjustments and assign the adjustment to the Sub preset.
Page 92: Use A Ppm
UAPG2 MANUAL Version EN.24 6) When the adjustments are OK. Click to (save) in order to store your adjustments in the current Sub Preset (you make a kind of photocopy of the adjustments you have selected in this Sub preset). Repeat those actions with the other Sub preset.
Page 93: Define System With Ppm
UAPG2 MANUAL Version EN.24 Maximum lengths: Without External Power Distance: • Between LAP and JB: 300m Between JB and PPM: 2m • With External Power Distance: • Between LAP and JB: 850m Between JB and PPM: 2m • Cable specifications : 4 Pairs Enhanced Cat.5e UTP Define system with PPM Drag and drop the PPM in one of the UAPG2 inputs (A3 for our example) in accordance to the inputs you have physically connected the PPMs.
Page 94: Search And Set Ppm
UAPG2 MANUAL Version EN.24 Search and set PPM First make sure to clear all old remote IP address. Click “View Remote list” or hit 2) A window appears, click on PPM’s page, not on URC’s one. 3) Click 4) A new dialogue window appears, Click again...
Page 95 UAPG2 MANUAL Version EN.24 6) Click 7) Select the PPM in the first window by assigning the corresponding serial number to each PPM (For our example on Input A2 of UAPG21 we have connected the PPM R00126): 8) Click , then click The system is now ready to work with the PPM connected on the input A2 of the UAPG21 (according to the last picture).
Page 96: Adjust Ppm Parameter
UAPG2 MANUAL Version EN.24 Adjust PPM parameter Double click on the PPM icon in the system window: 2) A window appears: Serial No.: Serial number of the PPM connected on this input (on which we double clicked). Name: Assign a name for this PPM Priority: Fix the priority of this PPM compared to others.
Page 97: Rear Ppm Adjustments
UAPG2 MANUAL Version EN.24 By default the PPM has two chimes in his internal memory, click on the "active" box and select which chime you want by clicking in the "Index" field. When all the settings are Ok, the PPM is ready to be used like any other kind of input sources. To learn how to configure the system in order to control the access of the sound to various areas through the PPM’s keys, see the "define paging with PPM"...
Page 98 UAPG2 MANUAL Version EN.24 Select chime Open the window “Wave File Manager”, menu “view”: Select which gong you want to use. Click [save to library ]. Click Note: If the file is already transfer the message says: "there are 0 wave file transfer to Wave library". Then close this window: You can also load your own wave file: 16bits, mono, 16kHz in the wave file manager window (menu “view”): by clicking (add from)[ File]:...
Page 99 UAPG2 MANUAL Version EN.24 Load chime Open the window “Chime data store” menu “view”: If you have several PPM connected, choose in which you want to load the gong. Click on the to open the Wave library. Select the files to upload in each PPM. To import a wave from your computer, click on To import a ZIP file from your computer, click on Click on...
Page 100 UAPG2 MANUAL Version EN.24 Click (or if you change only one PPM chime select it and click Ind) The wave files are uploaded in the PPM. Depending on your system, this operation takes time. When the process complete, close the window.
Page 101 UAPG2 MANUAL Version EN.24 Adjust PPM’s chime Open the PPM manager window menu “View” “PPM Manager” Click in the “Chime” field of the PPM which you want to authorize the chime. You can also reach this window by double clicking the PPM’s icon, and click on the “Announcement”...
Page 102: Create Paging Of Ppm With Lpc
UAPG2 MANUAL Version EN.24 Create paging of PPM with LPC To page the audio signal of PPMs you will use LPC (Link Page Control). You cannot add more than one LPC per UAPG2. If you have several PPMs on a UAPg2, then you have to use the different input of the LPC component.
Page 103 UAPG2 MANUAL Version EN.24 First select the "input 1" tab to set the first PPM. Unroll the menu "Audio Module" and select the input used by this PPM. As soon as the input is selected, the paging matrix is displayed. Here you can choose on which zones you will have microphone signal when a key is pressed by notching the boxes: Then do the same for the second PPM.
Page 104: Use Ppm Keypadg2 To Trig Message Events
UAPG2 MANUAL Version EN.24 Use PPM KeypadG2 to trig Message Events (only with PPM-SP) Connect to your PPM-SP a PPM-KeypadG2. Wire it physically to the UAPg2. Only the last KeypadG2 can be used to trigger messages. In the System page, add the remote PPM icon to an input. In the menu Tools, clear the remote IP and search the PPM device.
Page 105 UAPG2 MANUAL Version EN.24 Double click on the "Message player" component, add one "Message Play" events for each message to be triggered by KeypadG2 (8 max) and assign them to audio files. Open the Event management windows, and notch the "Third Party Cont." option for each message event.
Page 106: Use Ppmtouch
UAPG2 MANUAL Version EN.24 Use PPMTouch At first connect the PPMTouch to your TCP/IP network. If your switch/hub provides PoE (power over ethernet) then you don't need to use a power supply. The switch/hub will bring power to the PPMTouch. If you don't have PoE, then power the PPMTouch with the external power supply. Set the IP settings of your PC to be on the same network than the PPMTouch.
Page 107: Define The Ppmtouch In The Uapg2 Software
UAPG2 MANUAL Version EN.24 Define the PPMTouch in the UAPg2 software With the PPMTouch, there is no need to put it in the System window as we do with the PPM and PPM-SP. Double-click in the UAPg2 icon, to open the component list. Drag and drop one of the LPC to the design area.
Page 108: Setup The Ppmtouch
UAPG2 MANUAL Version EN.24 Setup the PPMTouch Open your web browser, and type the IP address of the PPMTouch. That will open the web interface of the PPMTouch. In the window's top, there is three buttons to access to the main pages: To configure the settings, click on [SETUP].
Page 109: Define Paging
UAPG2 MANUAL Version EN.24 Define Paging Open your web browser, and type the IP address of the PPMTouch. To configure the paging, click on [PAGING]. The PPMTouch provides 30 programmable keys. These keys are displayed on three pages, available with the Page buttons. Each key on the PPMTouch is configurable on an independent box: Btn* name : The label displayed in the key number * of the PPMTouch.
Page 110: Define Messages
UAPG2 MANUAL Version EN.24 Define Messages Open your web browser, and type the IP address of the PPMTouch. To configure the paging, click on [PAGING]. Don't forget to click on to store these settings. Define Control Control a fader In the UAPg2 software, open the component to control. To control a fader, right-click on the fader and select "Third Party".
Page 111 UAPG2 MANUAL Version EN.24 Here you can see three different command: Increase, Decrease, Read and Write. If you want to increase or decrease the fader, then you have to write the step (in dB) in the horizontal fader in the window top. The Command will change, depending of the step.
Page 112 UAPG2 MANUAL Version EN.24 Then do the same for the other button position. Release the button and assign it to the event for the release (in our example, Mute Off). Now open again View/Events Management. Notch the "third Party" option for the both events. Check on "Mount", it must be 1 if the event is assigned to an element parameter.
Page 113 UAPG2 MANUAL Version EN.24 You can read, under Command, the Command string to be set in the PPMTouch. Compile and store the configuration. Please see Set Control on PPMTouch chapter. Set the controls on PPMTouch Open your web browser, and type the IP address of the PPMTouch. That will open the web interface of the PPMTouch.
Page 114 UAPG2 MANUAL Version EN.24 In this page, you can see twelve boxes. Each one is a key on the PPMTouch. For example we will set the three controls, set in the previous chapters (See Control a button, and Control a fader chapters) : "Volume", "Mute On"...
Page 115: Use An Urc
UAPG2 MANUAL Version EN.24 Use an URC Because every remote device needs power, you will have to add external power supply every three remotes devices or every 300 meters. Except for the first three remote devices or the first 300m, power will be delivered by the UAPG2.
Page 116: Search And Set Urc
UAPG2 MANUAL Version EN.24 Search and set URC After defining the system, it is necessary to communicate where and who are the URCs to the system. The research procedure is automatic, but requires to be launched. First make sure to clear all old remote IP address. Click “View Remote list”...
Page 117 UAPG2 MANUAL Version EN.24 5) When the system has finished the search, a list with the various connected URCs or PPMs appears. Each URC is identified by its own serial number. This number is written on a sticker on the URC. The system finds automatically each URC (in our example the URC’s serial numbers are: U00132 and U00117).
Page 118: Define And Adjust Urc's Parameters
UAPG2 MANUAL Version EN.24 Define and adjust URC’s parameters Double click on the URC icon (Ux) in the system window, the URC setting window opens: Serial No: Indicates which URC you are going to configure. Name: Gives a name for this URC. Essential when you have several URCs connected. All the following options will be explained in details.
Page 119 UAPG2 MANUAL Version EN.24 Assign right By clicking on Assign Right you can protect some adjustments you have created in the URC. Just select if you want the adjustment to the first layer (not protected) or in the protected layer. To access to the protected layer: Hold exit and back and push the knob.
Page 120: Global Parameters Tab
UAPG2 MANUAL Version EN.24 Open: You can search and assign to the URC any images (be careful about the size...) you have on your computer by clicking on Windows File or Logo Library button. By clicking Logo manager, a window shows you which images you have selected for your URC: You can use any type of image you want.
Page 121 UAPG2 MANUAL Version EN.24 Click on [+ Add], to create a Master-Preset selector. You can change the name in the Label space. Click on the three dots ( ) on the right of the “Assigned” space, a window opens and you can choose which Master Preset is accessible with this function (Here named: MP-SP SEL.)
Page 122 UAPG2 MANUAL Version EN.24 With this adjustment, you can then choose to switch between two modes/master preset pages (conference or music for example) by clicking twice on the rotate knob of the URC and clicking on “MP-SP SEL.” on the URC. You can have several "MP-SP SEL."...
Page 123: Sub Preset And Parameters Tab
UAPG2 MANUAL Version EN.24 Sub Preset and Parameters tab On this tab you can assign adjustments of component to a URC for a specific Master Preset. The parameter of this tab depends of the Master-Preset. You have to create the parameters for each Master-Preset individually.
Page 124: Sub-Preset
UAPG2 MANUAL Version EN.24 Unroll the "Control Type" menu, and select if it is a Sub-Preset control or an Element control. Follow the step in the chapter "Sub-Preset" or "Element Control". Sub-Preset Now that we have create the Sub-Preset parameter (Sub Preset and Parameters tab chapter), we have to assign this control the sub-presets.
Page 125 UAPG2 MANUAL Version EN.24 On the URC settings window, click on the three dots ( ) on the right of the “Assigned” space, a window opens and you can choose which Sub-Preset is accessible with this function. Close this window. Now you can see the number 1 under "Assigned".
Page 126: Element Control
UAPG2 MANUAL Version EN.24 Element Control Now that we have create the Element parameter (Sub Preset and Parameters tab chapter), we have to assign this element control to an adjustment. To assign the control to a specific action (adjustments), go to the design (double click on the UAPG2’s icon), then double click on the component (module) of which you want to use an adjustment.
Page 127: Set Adjustments
UAPG2 MANUAL Version EN.24 If you see an asterisk, it means that another adjustment is linked to this label. It is impossible to assign two different types of adjustment s (for example a mute with a fader) on a same Label; they must be the same type of adjustment. Please see Assignation Philosophy chapter for more details.
Page 128 UAPG2 MANUAL Version EN.24 By clicking on the three dots ( , in assigned column) a box appears. According to the assigned function some adjustments are available by clicking in the box and set the value): UAPG2 Column: If there are several UAPG2s: shows on which the action is undertaken Component, ID Element, Input, Output, Band: Shows which components and which kind of adjustments are assigned to this label.
Page 129: Protect The Access To Urc With Password
UAPG2 MANUAL Version EN.24 Protect the access to URC with Password You can protect the access to the element of the URC with a Password. To do this, you have to use the IDM (access to Master-Presets), not the UserID. Open User->ID Management, and then create a new IDM associated with the Master-Presets.
Page 130: Use Front Knobs
UAPG2 MANUAL Version EN.24 Use front knobs Right click on the software adjustments you want to pilot with the control input and choose control option: 1) Type of control you can assign to this software control (adjustments) 2) Name of the UAPG2 in the system 3) Connector channel number (control input 9 to 16 defined as analog input…) FP = Front Panel knob Use Control inputs...
Page 131: Analogue Inputs
UAPG2 MANUAL Version EN.24 Analogue Inputs Second step right click on the software adjustments you want to pilot with the control input and choose control option: 1) Type of control you can assign to this software control (adjustments) 2) Name of the UAPG2 in the system 3) Connector channel number (FP = front panel knob) Note : An analogue input can control a component's parameter only if his corresponding component's input and output are linked to something in the design.
Page 132: Logic Inputs In Binary Mode (Group, Only For Selector Component Or Presets Selection)
UAPG2 MANUAL Version EN.24 Logic inputs in binary mode (group, only for selector component or presets selection) The binary mode means use Logic inputs as “bit” for different choice. The analog/logic input must be set as TTL IN in the external settings. To use the TTL IN in binary mode, several TTL IN must be assigned to a group.
Page 133: Use Control Inputs To Trig Events (As Messages)
UAPG2 MANUAL Version EN.24 Multi-logic (Binary mode) single logic Use Control Inputs to trig Events (as messages) Open Event management window menu view: According to the TTL state (High or Low) click on one of the two fields: Login IN (High or Low) And select the logic channel number: Do not forget to activate your choice by clicking [Save].
Page 134: Use Logic Output
UAPG2 MANUAL Version EN.24 Use Logic Output Right click on the software adjustments you want to pilot with the control input and choose control option: 1) Type of control you can assign to this software LED 2) Name of the UAPG2 in the system 3) Connector channel number (here we have define control 9 to 16 as analog input…) FP = front panel knob These logic output are simple dry contact, there is no voltage on the output.
Page 135: Use Third Party Control
UAPG2 MANUAL Version EN.24 Use Third party Control Select the adjustments you want to pilot with third party control: Double click on the component's icon then right click on the adjustment you want to control and select > Third party control.
Page 136: Read A Parameter Value
UAPG2 MANUAL Version EN.24 To see which frame you have to send from the third party controller to pilot the UAPG2, simply click on the three dots ( ) in the Command field. Move the cursor on the left to see how to change value. For example: if you want to increase volume of the parameter C001 by step of 2 dB the “command”...
Page 137: Checksum Calculation
UAPG2 MANUAL Version EN.24 Checksum calculation The checksum is the sum of all data between STX and ETX. And keep only the least significant byte. In the following example: Data = WC0010 = 57 43 30 30 31 30 (in hexa) Sum of Data (in hexa) = 57+43+30+30+31+30 = 15B Checksum = the least significant byte of 15B = 5B Set RS232 Third party control parameters...
Page 138: Use Third Party Over Ip
UAPG2 MANUAL Version EN.24 Use third party over IP Since UAPg2 software version 1.0.2.44, the UAPg2 can be control by third party equipment, through the IP network. Both third party over RS232 and UDP/IP work together. The way to define the third party control is the same as with RS232. Please read "Define third Party control"...
Page 139 UAPG2 MANUAL Version EN.24 Now you can past or write the command string in the Data area. Then click on "Send" to send the string to the UAP. You can see the answer in the received data area. The UAP answer "06 0D" as acknowledge, otherwise it answer "10D" or nothing. You can also use the test command “02 54 03 54 0D".
Page 140: Use Events (Element Adjustment, Master-Preset, Sub-Preset)
UAPG2 MANUAL Version EN.24 Use Events (Element adjustment, Master-Preset, Sub-Preset) Event Triggering There are several ways to trig (start) the events as "message play event" or "Stop Event": • With Contact input > see Use Control Inputs In to trig Events (as messages) •...
Page 141: Change Master Preset
UAPG2 MANUAL Version EN.24 Change master preset Once you have define several master preset and define an event which control master preset (Control Type) click on Mount field: And select which master preset will be called by this event (notch select box and click OK) Change Sub preset Once you have define several sub preset and define an event which control sub preset (Control Type) click on Mount field:...
Page 142 UAPG2 MANUAL Version EN.24 Once all the adjustment s are assigned to desired events go on the Event manager window (menu view) and click on the Mount field of the event Note: you will see the number of adjustments assigned to the event in this mount field And adjust the value of each element (click on the virtual button or knob to fix the value)
Page 143: Set Ttl-Out
UAPG2 MANUAL Version EN.24 Set TTL-Out This event pilot a Logic output of any UAPG2 of the system. Create an event which control TTL out (control type) then click in the Mount field of this event Select which output of which UAPG2 (if several UAPG2 in a system) will be open (and also the time of (kind of pulse capability) Enable: Notch it to active the Logic output channel.
Page 144: Stop Event
UAPG2 MANUAL Version EN.24 Stop event Two kind of event can be stopped: TTL output activation and Message play To stop an event, create an event which stop event (control type). Then click in the Mount field of this event. And then select which event you want to stop.
Page 145: Message Play Event
UAPG2 MANUAL Version EN.24 Message play event (see also Use the message component) First of all, Load messages into UAPG2 by using wav file manager and Message storage component. Then into the message storage component, choose the Event Settings tab: Click [Add] to add a message play event (events which start the selected message) If you want to delete an event: [Select] select all event(s)
Page 146 UAPG2 MANUAL Version EN.24 Choose the wave file which will be played You can choose to repeat the message a fixed number of times: (Repeat field) or until a stop event appears (Forever field). (In the assigned field you will see the number of wave file assigned). Priority allows you to fixe if the event has a higher priority regarding another message event.
Page 147: Use Third Party To Trig Events (As Messages)
UAPG2 MANUAL Version EN.24 Use Third Party to trig Events (as messages) Open View > Event management: Here you can see the list of your events. To control an event from a third party, notch the "Third Party Cont." function of the event. Close this window.
Page 148: Use Scheduler To Trig Events (As Messages)
UAPG2 MANUAL Version EN.24 Use Scheduler to trig Events (as messages) Open the schedule management window: menu view Schedule management This windows lists all the programmed schedule(s) [Add]: to add a schedule [Edit]: open the Schedule setting window to edit an existing schedule [Delete]: erase an existing schedule [Select]: select all schedules...
Page 149: Occurrence Field
UAPG2 MANUAL Version EN.24 Occurrence field Schedule Name: Name of the current schedule Start time: Beginning date of the current schedule End time: ending of the current schedule Enable: active the schedule Period: gives the repetition frequency for the event sequence (schedule) Event list List all the defined events to create events.
Page 150 UAPG2 MANUAL Version EN.24 Click [Add] Event [Delete]: clear selected (click on the event) event Simply drag and drop event from the event list to the event group or event field Note: By double clicking on the event field in the sequence you will open the event setting window. A time setting allows you to fix interval time between event groups (time displayed at the right of the event group) : Be carefully if you start a message before the end of the previous message, it won't be played.
Page 151: Use The Message Player Component
UAPG2 MANUAL Version EN.24 Use the Message player component The audio file must be a wave mono file, 16 bits and with a bit rate of 16, 24 or 48kHz. Otherwise it won’t appear in the library. Caution: The message player cannot be used with the UAPg2 set at 96kHz. The UAPg2 must be set at 48kHz.
Page 152: Uap Messages Management
UAPg2. Of course you can also retrieve a message from the UAPg2 to the library by clicking on the other arrow You can find the library directly in your PC: C:\Programs\ATEIS\UAP-G2 v1.0.3.50\wave file...
Page 153: Message Play Event
UAPG2 MANUAL Version EN.24 Message play Event This window allows managing of the message event. The messages use one "Message play" event to start the message. The messages use one "Stop Event" linked to the event, to stop the message. First, click on "Add"...
Page 154 UAPG2 MANUAL Version EN.24 You can either select a file from the library or from the UAPg2. Message selection from UAP As to be played, the message must be in the LAPg2, my advice is to click on "+Add from LAP" to open this window. Click on the reading glass to display the files, select one and then click on to assign the message file to the message event.
Page 155 UAPG2 MANUAL Version EN.24 Message selection from Wave Library But if you want to import a file from your PC, click on "+Add from Wave library": Then click on "+Add" to open the browser which allows you to select the file to import. Click on "Close"...
Page 156: Stop Event
UAPG2 MANUAL Version EN.24 Stop Event If you want to be able to stop the message when it's playing before its end, you have to create a "stop event" associate with the message. In the View menu, open the Event Management: Click on [+Add] to add a new event.
Page 157: Store Message Into Uapg2
UAPG2 MANUAL Version EN.24 Store message into UAPG2 The audio file must be a wave mono file, 16 bits and with a bit rate of 16, 24 or 48kHz. The left window display the audio files available to be stored into UAPg2, the right window display which files are already stored into UAPg2.
Page 158: Recover Wave File From Uapg2
UAPG2 MANUAL Version EN.24 Recover wave file from UAPG2 You can recover message or music loaded into UAPG2, on the message storage field of the Message player component. To display the files click on the reading glass. Select wave file you want to copy from UAPG2 to your computer and click on the retrieve button,, wave file is copied into your computer.
Page 159: Use The Auto Noise Gain Component (A.n.g)
UAPG2 MANUAL Version EN.24 Use the Auto Noise Gain Component (A.N.G) Procedure to set the ANG Connect the sensing microphone to the S.M. input, and the paging audio source to the P.M. input. The NSM sensing microphone need an input sensitivity of 0dB ( software). The max cable length between the NSM and the UAPg2 is 500 meter with CAT-5 cable.
Page 160 UAPG2 MANUAL Version EN.24 The system is properly set. Even when the paging is not active, the ANG is still adjusting the AGC level with the ambient noise to be ready when the paging will begin. Notice: • The calibration should be done in normal ambient noise (shouldn't have suddenly loud noise during calibration).
Page 161: Use The A.n.g
UAPG2 MANUAL Version EN.24 Use the A.N.G When the calibration green led lit, the system is ready. In our example, the A.N.G has detected an ambient noise average of -12dB. We choose a medium "response speed" and a short "sampling time" to be enough reactive quickly. Now the A.N.G will automatically adjust the level on the (P.M) signal depending on the ambient noise detected on the sensing microphone.
Page 162 UAPG2 MANUAL Version EN.24 You can see the AGC level near from 0 dB, meaning no compensation. Increase Zone: If the sensing microphone detects more noise than during the calibration, the A.N.G works in the "Increase Zone" which means that the gain must be increased to compensate the ambient noise. In our example, the noise is now louder than during the calibration.
Page 163: Nsm Sensing Microphone
UAPG2 MANUAL Version EN.24 NSM Sensing Microphone The software module lets you handle any kind of microphone signal; line-level would be preferred because of the noise-picked-up by the cable length. For that reason we will provide a microphone module with a level raising amplifier, fed by Phantom power and/or 24VDC. There is a screw in the front hole, allowing you to modify the pre-amplifier gain of the microphone.
Page 164 UAPG2 MANUAL Version EN.24 Audio Specification: Item Condition Typ. Max. Microphone Input 1 kHz -40 dBu Sensitivity 1 kHz 48 dB 60 dB Audio Output 1 kHz 20 dBu Output 10 KOhm Impedance Frequency +0.2/-4dBu 60 Hz 10 kHz Response T.H.D Ratio 50Hz ~ 20 kHz 0.3 %...
Page 165: Use The Ducker Component
UAPG2 MANUAL Version EN.24 Use the Ducker Component As simple example, we will set a system for a speaker with background music. When the speaker is talking, the background music must decrease its level. The speaking is using a standard dynamic microphone type SM58. The microphone is connected to the channel 2 of the "Input A"...
Page 166: Remote Devices Hardware Connections
UAPG2 MANUAL Version EN.24 Remote Devices Hardware Connections Because of the bus 485 and the audio, the connection of several PPM is not easy. You normally have to create a bus with the RS485 (data and power) by using junction box (daisy-chain). All audio from PPM must be sent to the LAP.
Page 167: Connection Example For One Ppm With Jb
UAPG2 MANUAL Version EN.24 Connection example for one PPM with JB...
Page 168: Connection Example For Several Ppms With Jb
UAPG2 MANUAL Version EN.24 Connection example for several PPMs with JB...
Page 169: Connection Example For Several Ppm With And Without Jb
UAPG2 MANUAL Version EN.24 Connection example for several PPM with and without JB Be caution with the wire colours, which are depending of the cable you use, 4 pairs or 5 pairs.
Page 170: Rj45 Pin Out
UAPG2 MANUAL Version EN.24 Rj45 pin out For practically all the wiring you'll need straight CAT5 cable (4 pairs): With PPM, a straight CAT5 cable 5 pairs is needed (provided with PPM): Junction Box 24VDC <- from UAP Line OUT (+ -) 24VDC <- from adapter Line IN (+ -) 24VDC...
Page 171 UAPG2 MANUAL Version EN.24 Connectors: AUDIO OUTPUT (line out): This signal comes from the PPM's microphone to be connected in a UAPG2 input (Shielded audio cable) RS-485 MAIN-IN + AUDIO OUT (To UAPG2): It is the BUS 485 to be connected into the UAPG2. You can also have access with this JB output to the PPM's microphone signal (to be connected to a UAPG2 input) Pin 1.
Page 172: Connect Jb To Uapg2
UAPG2 MANUAL Version EN.24 AUDIO INPUT: To send audio signal from a UAPG2 output to the PPM speaker (Shielded audio cable) SLAVE PPM (CAT5 5 pairs): NOT AVAILABLE FOR THE MOMENT (to connect Slave PPM) Pin 1. Slave RS-485 B Pin 2.
Page 173: Connect Ppm To Jb
UAPG2 MANUAL Version EN.24 Connect PPM to JB Simply use the CAT5 5 pairs provided with your PPM or a standard CAT5 4 pairs (Straight): from PPM to MASTER PPM of the JB. If you use a CAT5 4 pairs you probably will hear some data into the speaker of the PPM. This is due to the internal wiring (if you do not use speaker, simply disconnect it).
Page 174: Audio Component Description
UAPG2 MANUAL Version EN.24 Audio component description Audio component are all features tools you can use in the UAPG2 DSP to route, change or modify signal between inputs and outputs of UAPG2 system. Here are the details of all the components: Input Control the input signals parameters and monitor it.
Page 175 UAPG2 MANUAL Version EN.24 Analog Input Adjustments Parameter Range Comment Bypass On/Off Bypasses the channel fader settings. The channel gain will be equal to unity gain (0 dB); LED, lit green when activate. Mute On/Off Mutes or un-mutes the input channel; LED, lit red with channel muted.
Page 176: Output
UAPG2 MANUAL Version EN.24 Output Control the output signals parameters and monitor it. The analogue output modules represent the physical analogue outputs accessible on the rear panel of the UAPG2. There are four separate modules for use with each of the audio board slots A, B, C and D.
Page 177: Mixer
UAPG2 MANUAL Version EN.24 Mixer Mix or route several signal to an Output. Since the UAPG2 software only compiles active nodes, there is no use having a whole bunch of mixers, like 2x1, 3x1, to (n)x1, then 2x2, 3x2, to (n)x2, etc. It simply makes no difference if you take a 4x4 from the 4x4 component or the 16x16.
Page 178 UAPG2 MANUAL Version EN.24 Clicking the orange coloured function [Output(n)] buttons under the label 'Variable Matrix' in the middle of the window opens the sub control windows of the particular output channels. In here you can create an individual mix of the input signals independently for the specified output. By default all levels are set to 0 db, which basically means, that all audio signals at the input are mixed with no attenuation and appear like this on every output.
Page 179: Standard Mixer
UAPG2 MANUAL Version EN.24 Standard Mixer Route several signals to Output(s) The matrix components are organized in a subfolder named 'Matrix' holding the modules '4x4', '8x8' and '16x16': Since the only difference of these modules is their number of in- and outputs, let's take a detailed look just to the smallest one, the 4x4.
Page 180: Automixer
UAPG2 MANUAL Version EN.24 AutoMixer Allows mix several signals to one output. The Activation of channel(s) can be done manually or automatically by signal threshold and priority. The 'Automixer' components are organized in a subfolder named 'AutoMixer' holding the modules '4x1', '8x1' and '16x1': Since the only difference of these modules is their number of inputs, let's take a detailed look just to the smallest one, the 4x1.
Page 181 UAPG2 MANUAL Version EN.24 Automixer Parameters Parameter Range Comment Mute On/Off Mutes or un-mutes the input channel. Invert 0°/180° Inverts the polarity of the input channel. Solo On/Off Solos the input channel. (the channel goes directly to the output) Gate On LED, lit green Shows activation status of the input channel.
Page 182 UAPG2 MANUAL Version EN.24 Channel activation: At first, on the "Manual/Automatic" selector chose if you want manual or automatic channel activation. Manual: The activation is only done manually with the "Manual" buttons. The threshold and the priority are ignored. Automatic: The activation is depending of the threshold, and of the priority. It will pass only highest priority channel out.
Page 183: Compressor/Limiter/Expander
UAPG2 MANUAL Version EN.24 Compressor/Limiter/Expander The 'Compressor/Limiter/Expander' folder in the 'Component' control window holds for items: They represent the dynamic section and consist of the following modules: • Limiter Single channel limiter, triggered by input level (Feed-Forward type). • Compressor Single channel compressor, triggered by input level (Feed-Forward type).
Page 184 UAPG2 MANUAL Version EN.24 The display/editor window displays an output to input graph, where the vertical axis corresponds to the output signal level in dB, while the horizontal axis displays the input signal level in dB. The green line reflects the currently set dynamic response graph of the compressor. The small squares act as handles that can be dragged to the desired position and show the following parameters: Ratio x:1...
Page 185: Compressor
UAPG2 MANUAL Version EN.24 Compressor A compressor is an automatic volume control. Loud sounds over a certain threshold are reduced in level while quiet sounds remain untreated. In this way it reduces the dynamic range of an audio signal. This may be done for aesthetic reasons, to deal with technical limitations of audio equipment, or to improve audibility of audio in noisy environments.
Page 186 UAPG2 MANUAL Version EN.24 The small squares act as handles that can be dragged to the desired position and show the following parameters: Ratio x:1 blue Threshold (dB) yellow Threshold range (dB) Compressor Parameters Parameter Range Comment Graph... Button Opens the graphical display/editor window. Ratio x:1 0.10 to 1.00 Sets compression ratio.
Page 187: Expander
UAPG2 MANUAL Version EN.24 Expander An expander works in an opposite fashion than the compressor, the threshold is set and any part of the signal dropping below this threshold will be affected by the expander and this level will be raised. The expander therefore like the compressor balances out the signal making it sound more professional.
Page 188: Comp-Limiter
UAPG2 MANUAL Version EN.24 Comp-Limiter The third module within the 'Compressor/Limiter' folder is a combination of the compressor and the limiter modules described earlier: The control window of the 'CompLimiter' module is opened by a double click on the icon in the 'LAPG2' design window and appears like this: As this component is works exactly like the separately described modules please refer to the parameter list of these modules.
Page 189: Peq
UAPG2 MANUAL Version EN.24 You have six different PEQ modules, 2, 4, 6, 8, 10, 16 bands: The control window of the 'PEQ' module is opened by a double click on the icon in the 'UAPG2' design window and appears like this (example for 6 bands): The display/editor window displays an output to input graph, where the vertical axis corresponds to the output signal level in dB, while the horizontal axis displays the frequencies.
Page 190: Geq
UAPG2 MANUAL Version EN.24 You have three different GEQ modules, 1 Octave, 2/3 octave, 1/3 octave: The control window of the 'GEQ' module is opened by a double click on the icon in the 'UAPG2' design window and appears like this (example for 1/3 octave): The display/editor window displays an output to input graph, where the vertical axis corresponds to the output signal level in dB, while the horizontal axis displays the frequencies.
Page 191: Delay
UAPG2 MANUAL Version EN.24 Delay Delay (basics) Delay (basics) provides all to delay the signal. You have choice between seven times (you can adjust precise time) and each sub-folders contains three components with various numbers of outputs. The difference between basic and advanced is that for the advanced you can mute or bypass delayed channels.
Page 192: Delay (Advanced)
UAPG2 MANUAL Version EN.24 Delay (advanced) Delay (Advanced) provides all to delay the signal. You have choice between seven times (you can adjust precise time) and each sub-folders contains three components with various numbers of outputs. The difference between basic and advanced is that for the advanced you can mute or bypass delayed channels.
Page 193: Gate
UAPG2 MANUAL Version EN.24 Gate The gate allows you to cut off the signal below a chosen threshold. You can choose between four different gates: • Mono • With Sidechain • Stereo Gate Mono The first module within the "Gate" folder is a simple single channel: The control window of the "Gate - Mono"...
Page 194: Gate With Sidechain
UAPG2 MANUAL Version EN.24 Gate With Sidechain With this gate, you can control a gate on an audio channel (I) with an external sidechain signal(S). When the Sidechain input (S) input goes above the threshold, the gate becomes active and the signal on Input (I) goes to the output.
Page 195: Gate Stereo
UAPG2 MANUAL Version EN.24 Gate Stereo Simple double channel Gate The control window of the "Gate - Stereo" module is opened by a double click on the icon in the'UAPG2' design window and appears like this: When one of the inputs goes above the threshold, the gate becomes active and the both left and right input signals are routed to the output.
Page 196: Agc
UAPG2 MANUAL Version EN.24 With this Automatic Gain Control, you can adjust automatically the gain of the source by setting a target level. AGC Parameters Parameter Range Comment Release Button If the release button is pushed to green colour, the release time will be the user’s setting. Otherwise, the release time will be 10 Bypass Button...
Page 197 UAPG2 MANUAL Version EN.24 Example of AGC using: As example, we want to automatically adjust the gain of a kind of SM58 microphone. On the "Input A" component, the input sensitivity is set to -40dB for standard dynamic microphone. Threshold: Set at -25dB.
Page 198: Inverter
UAPG2 MANUAL Version EN.24 You can see on the vu-meter that when the speaker talks at 8 dBu, the final level is around -10.6 dBu: Input level: level: RMS vu-meter: AGC in AGC out Inverter The control window of the "Inverter" module is opened by a double click on the icon in the 'UAPG2' design window and appears like this: Invert Parameters Parameter...
Page 199: High Or Low Pass
UAPG2 MANUAL Version EN.24 High or Low Pass Allows you to filter Hi or low frequencies The small squares act as handles that can be dragged to the desired position and show the following parameters): • Blue Frequency (Hz) Hi/Lo pass Parameters Parameter Range Comment...
Page 200: Band Pass
UAPG2 MANUAL Version EN.24 Band Pass Allow you to filter to have only a band of frequency The small squares act as handles that can be dragged to the desired position and show the following parameters): • Blue Frequency (Hz) •...
Page 201: Band Stop
UAPG2 MANUAL Version EN.24 Band Stop Allow you to filter to cut a band of frequency The small squares act as handles that can be dragged to the desired position and show the following parameters): • Blue center Frequency (Hz) •...
Page 202: Notch Filter
UAPG2 MANUAL Version EN.24 Notch filter Allow you to filter to cut a frequency The small squares act as handles that can be dragged to the desired position and show the following parameters): • Blue center Frequency (Hz) • Yellow Bandwidth (-) Notch filter Parameters Parameter...
Page 203: Shelving Filter
UAPG2 MANUAL Version EN.24 Shelving filter Allows you to smoothly filter Hi or low frequencies The small squares act as handles that can be dragged to the desired position and show the following parameters): • Blue Frequency (Hz) Hi/Lo pass Parameters Parameter Range Comment...
Page 204: Cross Over
UAPG2 MANUAL Version EN.24 Cross over Use to filter signal for active audio pre amplifier for pro-audio sound. Three choice 2, 3 or 4 way In the example we have open the three way cross-over The small squares act as handles that can be dragged to the desired position and show the following parameters): •...
Page 205: Feedback
UAPG2 MANUAL Version EN.24 Feedback The feedback analyzes the signal, detects feedback and attenuates the responsible frequency. There is several kind of feedback component. The difference is only the bandwidth which are tuned for Music high than speech (between it the bandwidth is decreasing). Each category has 4 different feedback it is only the number of filter (4, 8 12 or 16) that the feedback will use.
Page 206: Digilink Input And Digilink Output
UAPG2 MANUAL Version EN.24 DigiLink input and Digilink output Create a virtual audio channel to send Audio through the Link protocol. 16 audio channels at 48 kHz are available from each UAP device to the next linked UAP, and 5 audio channel at 96 kHz. Send audio to the next UAP Receive audio from the previous UAP Caution : The digilink component send the audio only to the next UAPg2 in the system (the first is...
Page 207 UAPG2 MANUAL Version EN.24 In this is an example, the paging microphone is able to page on the three UAPg2. UAP 1 : UAP 2 : UAP 3 :...
Page 208: Page Control
UAPG2 MANUAL Version EN.24 Page control This component allows you to route (page) audio signal to one or several desired outputs. Two kinds of page control with various number of inputs and outputs • S/W page control: for signal paging with contact IN and VOX. •...
Page 209 UAPG2 MANUAL Version EN.24 VOX: The gate is activated when the audio signal on the input is above the threshold. (Choose the threshold with knobs on the bottom). Only the highest priority channel of the activated channels will be routed to the output. Contact: The gate of the channel is activated when the "TTL In button"...
Page 210 UAPG2 MANUAL Version EN.24 Parameter Range Comment Input Channel number of the input Output button Click on the desired output’s button to rout input to desired outputs Activation Type of activation of the routing (fixe, with TTL, or with a gate) TTL In Button If you want to active the routing with a logical input (rear panel of UAP)
Page 211: Lpc
UAPG2 MANUAL Version EN.24 There are several types of LPCs, various numbers of inputs as well as outputs. All the PPM connected to an UAPg2 will be configured in the same LPC component. Connect the component’s inputs to the virtual inputs of the UAPg2 where the PPMs are physically connected, then connect outputs of the component to virtual outputs (you can add audio component to adjust signal before and after the component: ducker, Eq, Mixer….).
Page 212: Selector
UAPG2 MANUAL Version EN.24 Selector Simple selector to select different inputs to output It can be used with URC, RAC, analogue input or contact input in binary mode.
Page 213: Ducker
UAPG2 MANUAL Version EN.24 Ducker The ducker is a kind of “sophisticated switch” allowing to attenuate or switch off automatically the signal arriving in input A when a chosen level (in dB) is perceived in input S. By double clicking on the Ducker icon the following window appears: Ducker Parameters Parameter Range...
Page 214: Noise Generator
UAPG2 MANUAL Version EN.24 Noise generator White noise generator This component generates a White noise. The White noise is a random signal (or process) with a flat power spectral density. In other words, the signal contains equal power within a fixed bandwidth at any center frequency.
Page 215: Pink Noise Generator
UAPG2 MANUAL Version EN.24 Pink noise generator This component generates a Pink noise. Pink noise or 1/ƒ noise is a signal or process with a frequency spectrum such that the power spectral density is inversely proportional to the frequency. In pink noise, each octave carries an equal amount of noise power.
Page 216: Tone Generator
UAPG2 MANUAL Version EN.24 Tone generator Generates either tone (single frequency) or sweep sequence (between two fixed frequencies and in a defined interval of time) Parameter Range Comment Mute Button Mute the sound coming out from the component Level -100 to +20 Level of the signal (dB) Sweep...
Page 217: Meter
UAPG2 MANUAL Version EN.24 Meter This component able to see the audio level. Peak value : Maximum value of the signal RMS value : Power average of the signal Parameter Range Comment Indefinite Button Block the display of level value Measure type Rms/Peak Type of measure...
Page 218: Level Control
UAPG2 MANUAL Version EN.24 Level control Various numbers of level controllers allows you to adjust the signal level after a signal treatments Parameter Range Comment Mute Button Mute the sound coming out from the component Bypass Button Switches off the Ducker’s operations Level -100 to +20 Increase Level of the signal...
Page 219: Auto Noise Gain
UAPG2 MANUAL Version EN.24 Auto Noise Gain Adjust the audio level of the paging input (P.M.) depending of the ambient noise. The ambient noise is measured with a sensing microphone connected to the sensing microphone input (S.M.). Our advice is to use the sensing microphone MSN (Ateïs), but you can also use another one.
Page 220 UAPG2 MANUAL Version EN.24 Parameter Range Comment Ambiant noise Meter AGC Level Meter Display the current compensation gain Hold time 1 to 5 sec Holding time between when the P.M. signal passes below the mode threshold and the end of the paging activity. Paging activity Light up when the paging is active.
Page 221: Bus
UAPG2 MANUAL Version EN.24 This component is like a level control, but with a global output level in more. Parameter Range Comment Mute button Cut sound coming out from the component Input level -90 to 20 dB Level of each input channels Output level -90 to 20 dB General output (increase all the input)
Page 222: Message Player
UAPG2 MANUAL Version EN.24 Message Player This component is an internal messages player. It is able to play two different messages in the same time on two separate outputs M1 and M2 You will have to store your Wave messages into the UAPg2 device. The component contains two Tabs: •...
Page 223 UAPG2 MANUAL Version EN.24 UAP Music management tab: load wave file into UAPG2 or recover wave file from UAPG2 to Computer. (Don't mind about "Music", it is the messages management) This tab contains two sides: • Message Storage: files in the computer (in the wave library) •...
Page 224 UAPG2 MANUAL Version EN.24 We all hope at Ateïs you will enjoy using this master piece of technology! We remains at your entire disposal for any comments or request do not hesitate to contact your local dealer for further information.

Ateis UAPG2 G2 Full Instruction Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ateis UAPG2 G2
