Satechi Swift BT User Manual

Satechi swift bt bluetooth 3.0 portable speaker system

Swift BT Speaker User Manual

INTRODUCTION

Thank you for purchasing the Swift BT Speaker. The speaker is a high quality wireless audio device that

provides users the freedom to share music and calls whenever you want.

The Speaker contains the following parts as show in the figure:

1. Multi-function button (MFB)

2. LED light

3. USB charging port

4. On/Off Button

5. Microphone

1. Turn on: When the speaker is in the OFF state, switch the On/Off Button to "ON" and the LED will flash

with a blue light along with an audible tone.

2. Turn off: When the speaker is in the ON state, switch the On/Off Button to "OFF" and the LED will flash

with a red light along with an audible tone.

3. Pairing: When the speaker is in the ON state, press the MFB button for about 6 seconds until the LED

flashes blue and red. The speaker is now in the pairing mode. Go to your device's Bluetooth settings and

select the speaker and enter "0000" for the passcode.

- Answer a call: press the MFB once

- Reject an incoming call: press and hold the MFB for 2 seconds

- End a call: Press the MFB once

- Redial last number: Press the MFB for about 3 seconds when on standby mode

- Voice dialing: It is possible to make a call directly from the headset using voice recognition. To use this

voice dialing function, your mobile phone must support this option: enable voice recognition on your

phone; when no call is in progress, press and hold the MFB.

Table of Contents

Do you have a question about the Swift BT and is the answer not in the manual?

Page 1 Swift BT Speaker User Manual INTRODUCTION Thank you for purchasing the Swift BT Speaker. The speaker is a high quality wireless audio device that provides users the freedom to share music and calls whenever you want. OVERVIEW The Speaker contains the following parts as show in the figure: 1.
Page 2: Specifications
- Voice transfer: During a call, press and hold the MFB for about 3 seconds until a beep is heard from the speaker. The call will be transferred from the speaker to your phone or vice versa. - Muting: Mute the built-in microphone by double pressing the MFB. - Support for A2DP / No support for AVRCP: Some phones may not support Bluetooth AVRCP which allows some of these MFB functions to perform;...
Page 3 hundreds of times, but it will eventually wear out. Unplug the charger from the electrical plug and the device when not in use. Do not leave a fully charged battery connected to a charger, since overcharging may shorten its lifetime. If left unused, a fully charged battery will lose its charge over time.
