Apro AP-B9511SKTL User Manual

High Resolution Camera

1. Specifications

ITEM High Resolution Camera
Power Source DC 12V & AC 24V ( Option )
1/3 " , SONY SUPER HAD CCD II 410,000 pixels
Image Sensor
Effective Pixels 768(H) x 494(V) (NTSC) , 755(H) x 582(V) (PAL)
Maximum Aperture Ratio 1 : 1.3 ~2.0
Scanning System 2 : 1 Interlaced 525 Lines / 60 Fields / 30 Frames
Video Output 1.0V [p-p] NTSC Composite, 75Ω
Resolution 580 TV Line
0.3Lux (F.1.2), 0. 001Lux (Sens-Up : Auto),
Min. Illumination
0.00Lux(LED On)
S/N ( Y signal) 52dB (AGC Off, Weight On)
On Screen Display Built - in
Back Light Compensation OFF / BLC / HSBLC Selectable
D-WDR OFF / INDOOR / OUTDOOR
Gain Control OFF / LOW / MIDDLE / HIGH Selectable
1/60 ~ 1/120,000 sec (NTSC)
Electric Shutter Speed
1/50~1/100,000 sec (PAL)
ATW / AWB/ AWC – SET / MANUAL
WHITE BALANCE
/ INDOOR / OUTDOOR
DAY / NIGHT COLOR / AUTO / EXT / BW
3DNR ON / OFF
SENS-UP OFF / AUTO (0-256X Level Selectable)
Motion Detection MD4 Areas Selectable / OFF
PRIVACY Function ON / OFF (8 Programmable Zone)
D-EFFECT DIGITAL ZOOM (0~32X Level Selectable)
-20 ℃ ~ +50 ℃ ( - 20 ℉ ~122 ℉ )
Operational Temperature
Operational Humidity 30% ~90% RH

2. Features

1) SUPER HIGH
New Sony Super HAD II 410K CCD combined with an
innovated new DSP Technology will enable to achieve
Super High Resolution 580TVL with high S/N Ratio.
2) EXCELLENT
It can clearly distinguish the outline and color of a
subject in an extremely low luminance environment with
enhancement of Sens-Up feature.
3) 3DNR
3 Dimensional Digital Noise Reduction Technology will
dramatically reduce the Gain noise in digital image
processing and enable to produce clear, sharp images
in low light conditions.
4) D-WDR(Digital Wide Dynamic
With the newly innovated DSP Technology, the camera
enable to obtain clear, high quality pictures even in
strong backlight.
5) DAY/NIGHT
The camera identifies whether it is day or night, and
automatically switches to the appropriate mode
according to its external environment.
6) MOTION DETECT
The camera detects motion and generates signals
without additional external sensors, which enable to
monitor activity efficiently by connecting to an alarm
USER'S MANUAL

3. Camera OSD Control

4. OSD Menu Structure

Please read this manual thoroughly before operation and
keep it handy for further reference.
UP
LEF RIGHT
SETUP(MENU):Push Down
DOWN
Press this control
UP, DOWN
LEFT, RIGHT
SETUP(MENU)
SETUP MENU
LENS Option
DC
MANUAL
EXPOSURE
BRIGHTNES
SHUTTER
D-WDR RETURN
WHITE BALANCE
ATW INDOOR OUTDOO
DAY/NIGHT
COLOR AUTO
3DNR
ON OFF
SPECIAL
CAMTITL D-
PRIVACY SYNC
ADJUST
SHARPNESS BLUE
RESET
RETURN
FACTORY
EXIT

5. SETUP Menu Functions

1) LENS
<DC / MANUAL>
Selects Lens Type.
BRIGHTNESS : Adjust Brightness of the lens (DC Lens only)
2) EXPOSURE
<SHUTTER/ BRIGHTNESS /AGC / SENS-UP / BLC /
D-WDR / RETURN>
SHUTTER : Adjust shutter settings : AUTO/FLK/MANUAL
FLK : Flicker - Less Mode
BRIGHTNESS : Adjust Brightness of the lens (Manual Lens
only).
AGC(Auto Gain Control) : To get brighter picture
- High / Middle / Low / Off
SENSE-UP : To get clear image under night or low lighting
level.
- AUTO : In condition of low light or night time, select this
feature.
Select proper level from X2 to X256
- OFF : Deactivate Sense-Up feature
BLC (Back Light Compensation) : To distinguish a subject
and background at the same time, even when the
subject is in backlight.
- OFF / BLC / HSBLC (High Suppress BLC)
* HSBLC : This feature is to enable a user to select Mask
To do this
Select a new item
Select a menu item
Access a submenu
AGC SENSE-UP BLC
AWC- MANUAL
B/W
EXT
RS-485 MOTION
LANGUAGE RETURN
RED RETURN
