Page 1: Quick Start Guide
ZyWALL 1 Internet Security Gateway Quick Start Guide Version 3.50 November 2001... - Page 2 ZyWALL 1 Internet Security Gateway Introduction About Your ZyWALL 1 Internet Security Gateway The ZyWALL 1 is a dual Ethernet Internet Security Gateway with an integrated firewall and network management features designed for telecommuters and home offices to access the Internet via cable or xDSL modem. By integrating NAT (SUA), firewall and VPN capabilities, the ZyWALL 1 provides not only ease of installation and Internet access, but also a complete security solution that protects your Intranet and efficiently manages data traffic...
-
Page 3: Hardware Installation
ZyWALL 1 Internet Security Gateway Hardware Installation The Front Panel The LEDs on the front panel indicate the operational status of the ZyWALL. Description of LEDs COLOR STATUS DESCRIPTION The ZyWALL is receiving power. Green Flashing The ZyWALL is performing a self-test. The ZyWALL is not receiving power. - Page 4 ZyWALL 1 Internet Security Gateway Rear Panel and Connections WAN 10M Port Connect the WAN port on the ZyWALL to the Ethernet port on the cable or xDSL modem using the Ethernet cable that came with your modem. The Ethernet port on a cable modem is sometimes labeled "PC" or "Workstation". LAN 10/100M Ports When the ZyWALL is on and properly connected to a computer or a hub, the corresponding LAN LED on the...
- Page 5 ZyWALL 1 Internet Security Gateway POWER 5VDC Port Use only the included 5 VDC power adapter or one with the same specifications. Connect the female end of the power adapter to the port labeled POWER 5VDC on the rear panel of your ZyWALL. Additional Installation Requirements A computer(s) with an installed Ethernet NIC (Network Interface Card).
-
Page 6: Preparing Your Network
ZyWALL 1 Internet Security Gateway Preparing Your Network Since most Internet/network-related protocols are dependent on TCP/IP, you need to install and configure TCP/IP on your computer before you can access the Internet. Windows 95/98/Me/NT/2000, Macintosh OS 7 and later operating systems and all versions of UNIX (including Linux) include the software components you need to install and use TCP/IP on your computer. - Page 7 ZyWALL 1 Internet Security Gateway In the Network window, click Add. Select Protocol and then click Add. Select Microsoft from the list of manufacturers. Select TCP/IP from the list of network protocols and then click OK. If you need Client for Microsoft Networks: Click Add.
- Page 8 ZyWALL 1 Internet Security Gateway In the TCP/IP Properties window, select Specify an IP address. Type your information into the IP Address and Subnet Mask fields. Click the Gateway tab. Highlight any installed gateways and click the Remove button until there are none listed. Type your gateway address in the New gateway field and click Add.
- Page 9 ZyWALL 1 Internet Security Gateway Select the Internet Protocol (TCP/IP) entry and click the Properties button. Select Obtain an IP address automatically and click the Advanced button. Select any installed gateways and click Remove until there are none listed. Click the WINS tab and select any WINS addresses. Click Remove until there are none listed.
- Page 10 ZyWALL 1 Internet Security Gateway Macintosh Installing TCP/IP Components TCP/IP should already be installed on Macintosh OS 7 and later systems. Configuring TCP/IP Properties Click the Apple icon (located in the upper left corner of your screen), select Control Panels and then TCP/IP. From the "Connect Via"...
-
Page 11: Internet Account Checklist
ZyWALL 1 Internet Security Gateway Internet Account Checklist Your ISP (Internet Service Provider) should have given you most of the following information. You do not need to fill in every blank. FIELD DESCRIPTION YOUR INFO System Name (optional) Name for your ZyWALL. Domain Name (optional) Your domain name. -
Page 12: Using The Web Configurator
ZyWALL 1 Internet Security Gateway Using the Web Configurator Web Configurator Login The web configurator provides user-friendly setup for your ZyWALL. Step 1. Launch your web browser and enter 192.168.1.1 as the URL. Step 2. Enter "1234" (default) as the password and click Login. In some versions, the default password appears automatically - if this is the case, just click Login. -
Page 13: Troubleshooting
ZyWALL 1 Internet Security Gateway Troubleshooting PROBLEM CORRECTIVE ACTION None of the Make sure that you have the correct 5 VDC power adapter connected LEDs turn on to the ZyWALL and plugged in to an appropriate power source. when you turn If the error persists, you may have a hardware problem.
