  • Page 1 Lumisys MX Series 1025 Cobb Place Blvd Suite 100 Kennesaw, GA 30144 • 800-241-9173 • www.anybas.com...
  • Page 2 Lighting and its affiliates assume no responsibility for any consequences related to the improper use of this manual. www.anybas.com 0726070122 Page 2 Lumisys is a Registered Trademark Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
  • Page 3: Table Of Contents

    Adding and Removing LTR Relays ..............Connecting to Digi-Touch Addressable Switch Network ........Terms and Conditions of Sale ................www.anybas.com 0726070122 Page 3 Lumisys is a Registered Trademark Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
  • Page 4: Overview

    Lighting Relay Panel Overview This document provides instructions on how to physically install the Lumisys MX Series Lighting Relay Panel. For panel configuration and programming refer to Maxiom User’s Guide- Hardware and Maxiom User’s Guide - Software. For network point descriptions and integrations to a building automation system refer to the appropriate Maxiom Integration Guide.
  • Page 5: Inspection

    Inspection The MX Series comes in five basic units based upon relay capacities: MX08, MX16, MX32, MX48, and the MX60. Each unit may contain up to the number of relays indicated. Enclosure sizes for each of the five units will vary Pictures of the MX08 and MX32 appear below showing the main components.
  • Page 6: Installation

    Use wall anchors capable of supporting 6lbs for MX08, 16lbs for MX32 and 25lbs for MX60.
  • Page 7: Connecting The Power Supply

    Power harness from transformer (24VAC) Figure 4 Connectors for power supply www.anybas.com 0726070122 Page 7 Lumisys is a Registered Trademark Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
  • Page 8: Connecting The Power Supply Con't

    Replace with 1.0A Select either 120 or 277V to HOT Slow Blow Fuse Only! Black - HOT www.anybas.com 0726070122 Page 8 Lumisys is a Registered Trademark Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
  • Page 9: Connecting Branch Circuit Wires

    The following figure is a typical wiring diagram. Be sure not to exceed 20 amperes per relay. If the high voltage wiring requires both 120V and 277V on the same high voltage of the panel, a Lumisys MXDIV will be required.
  • Page 10: Connecting Branch Circuit Wires Con't

    #14-8 AWG or two 10 AWG wires in each terminal opening. Terminal opening to Circuit Breaker Terminal opening to Lighting Load www.anybas.com 0726070122 Page 10 Lumisys is a Registered Trademark Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
  • Page 11: Connecting Switch Inputs

    24 VDC or dry (0 VDC). www.anybas.com 0726070122 Page 11 Lumisys is a Registered Trademark Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
  • Page 12: Connecting Switch Inputs Con't

    *A maximum of 500 feet wire total is allowed, measured from the switch to the LX5 socket. Use 18-22AWG wire. www.anybas.com 0726070122 Page 12 Lumisys is a Registered Trademark Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
  • Page 13: Connecting The Rs-485 Network

    A terminal block is provided to connect the two communication wires plus the shield wire. (RS-485 wires are not provided by Lumisys.) Use 18 AWG stranded 600V insulated wire, twisted pair with shield. The RS-485 connection location and labeling is illustrated in Figure 16.
  • Page 14: Connecting Lumisys Ls5 Photocell Inputs

    “G” on main board. 6. Reconnect power to the LX5. Figure 15 www.anybas.com 0726070122 Page 14 Lumisys is a Registered Trademark Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
  • Page 15: Adding And Removing Ltr Relays

    6. Close the LX5 hinged backplate if necessary, and reconnect power to the LX5. www.anybas.com 0726070122 Page 15 Lumisys is a Registered Trademark Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
  • Page 16: Connecting To Digi-Touch Addressable Switch Network

    For higher quantities of switches, use 24VCD auxiliary power supply. Refer to DigiTouch Installation Guide for details. Terminal Block Jumper www.anybas.com 0726070122 Page 16 Lumisys is a Registered Trademark Due to continuous product improvement, Lumisys reserves the right to change product specifications without notice.
  • Page 17: Terms And Conditions Of Sale

    Terms and Conditions of Sale AGREEMENT OF SALE: Acceptance by Lumisys, (hereinafter “Seller”) of any order, placed for the goods described on the Acknowledgment, Invoice or Sales Contract hereof shall be subject to Seller’s Standard Terms and Conditions of Sale and is conditioned upon the Buyer’s acceptance of these Standard Terms and Conditions of sale as stated on this Sales Contract.
