Admiral ATV-NAV Operation Manual

Atv remote-controlled robotic pool cleaner
Hide thumbs
Table of Contents

Advertisement

Quick Links

ATV-NAV
ATV REMOTE-CONTROLLED
ROBOTIC POOL CLEANER
Installation - Operation - Warranty Manual
This equipment is to be installed and serviced by a qualified technician. Improper installation may result in
property damage, serious injury or death. Improper installation and/or operation will void the warranty.
WARNING
Notice to Installer
This manual contains important information about the installation, operation & safe use of this product.
.
Once the product has been sold or installed this manual must be given to the owner/operator of this equipment
www.waterco.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATV-NAV and is the answer not in the manual?

Questions and answers

Summary of Contents for Admiral ATV-NAV

  • Page 1 ATV-NAV ATV REMOTE-CONTROLLED ROBOTIC POOL CLEANER Installation - Operation - Warranty Manual This equipment is to be installed and serviced by a qualified technician. Improper installation may result in property damage, serious injury or death. Improper installation and/or operation will void the warranty.

  • Page 2: Table Of Contents

    We are sure you will find your new Remote Controlled Admiral ATV-NAV a pleasure to use. Before you use the cleaner, we recommend that you read through the relevant sections of this manual, which provides a description of your cleaner and its functions.

  • Page 3: General Instructions

    Disconnect the power supply supply from the outlet when not in use. ■ DO NOT switch the Admiral ATV-NAV to “ON” if it is not immersed in water. Operating the cleaner out of water may cause severe damage & will ■...

  • Page 4: Floating Swivel Setup

    The short power cord from cleaner to the Floating Swivel, 2.4m will need to be connected to the small end of the Floating Swivel (A). The long power cord from the Admiral ATV-NAV to the power supply, 15m will need to be connected to the large end of the Floating Swivel (B) as seen in Figure S1.
  • Page 5 3. Hold the swivel and hand tighten the black collar from the power cord to secure the connection (Figure S6A). 4. Insert the blue plug from the short power cable (from Admiral ATV-NAV to Floating Swivel, 2.4m) into the small end of the Floating Swivel (A) as shown in Figure S5, ensuring the gasket is in the Floating Swivel connector and the pins are properly aligned.

  • Page 6: Installation

    1. DO NOT RUN THE CLEANER OUT OF THE WATER. OPERATING THE CLEANER OUT OF THE WATER WILL DAMAGE THE MOTORS AND VOID THE WARRANTY 2. THE Admiral ATV-NAV SHOULD NOT BE CONNECTED TO A TIMING DEVICE AND LEFT CONTINUOUSLY WITHIN A POOL OR SPA.
  • Page 7 IMPORTANT NOTE: During normal operation, the Remote Controlled Admiral ATV-NAV may appear to shut off for a few seconds. This is a normal part of the pool cleaning program. The cleaner has multiple ways of cleaning the pool walls. It may climb to the top of the pool wall, scrub, then make a turn and drive back down the pool wall to the bottom of the pool.

  • Page 8: Removing Cleaner From Pool

    ■ up and out of the cleaner. Grip the bottom lid of the Admiral ATV-NAV firmly, with one hand and use your other hand to grab the filter bag material and pull it away from ■ and up from the bottom lid of the cleaner. Remove all large debris from the filter bag. Refer Figure 5.
  • Page 9 Figure 3 Figure 2 Figure 1 Figure 6 Figure 5 Figure 4 Figure 9 Figure 8 Figure 7...

  • Page 10: Power Cord Maintenance

    Wire Inner Core (+/- coated in non-conductive material) The Admiral ATV-NAV is equipped with the Floating Swivel to prevent power cord tangling, but the following five points can further prevent or greatly reduce tangling of the power cord: 1) Make sure there are no objects in the pool during the cleaning cycle for the power cord to get caught on (pool ropes, toys, etc).

  • Page 11: Storing The Power Cord

    GENERAL MAINTENANCE GUIDE To ensure the maximum life of the Admiral ATV-NAV, please follow the procedures below: 1. Clean The Admiral ATV-NAV’s filter bag after every use. 2. Maintain a correct chemical balance of your pool/spa water. The chemical balance of water is a relationship between its pH, total alkalinity, calcium hardness and water temperature.

  • Page 12: Warranty

    WARRANTY The Admiral ATV-NAV has been manufactured, tested and inspected in accordance with carefully specified engineering requirements. It is warranted to be free from defects in materials and workmanship under normal use and service, subject to qualifications, conditions and limitations described below.
  • Page 13 WARRANTY PERIOD Waterco Admiral ATV-NAV Robotic Pool Cleaners are covered by a two year warranty. All warranty periods commence on the date of purchase by the end user. The provisions of this warranty are not transferable and are in addition to and not in modification of or subtraction from any applicable statutory warranties, rights or remedies.
  • Page 14 This warranty gives specific legal rights. The purchaser may have other rights depending on the jurisdiction in which the Waterco product was purchased or the purchaser is located. Product Warranty Exclusions Admiral ATV-NAV Robotic Pool Cleaner 2 Year 1. Leaving cleaner in direct sunlight & out of water 2. Human intervention damaging the cleaner Remote Hand Control Unit 3.
  • Page 15 Most pool cleaner problems are caused by incorrect installation, poor water chemistry and wear and tear. Please regularly check the condition of the Admiral ATV-NAV filter bag, bottom lid, brushes and tracks, as these are like the tyres on a car & need replacement from time to time.

  • Page 16: Trouble Shooting

    Symptom Possible Reasons Cleaner Dead in water/Will not Restart Is time being allowed for the unit to reset? At least 30 second are needed between cycles to reset the power supply. Is the outlet working? Earth Leakage Circuit Breaker or breaker may have tripped Is an extension cord being used? Extension cord may be defective Are the connections to the swivel secure?
  • Page 17 Thoroughly rinse the filter bag. Dirty pools may require the bag to be cleaned part way through cycle. Check to see if there is water coming through the impeller during operation. The maximum depth of a swimming pool for proper operation of an Admiral ATV is 2.4m. Brush walls and check water chemistry.

  • Page 18: Notes

    NOTES...
  • Page 19 NOTES...
  • Page 20 www.waterco.com...
