SETUP and OPERATIONS GUIDE

PLEASE READ THIS GUIDE AND FOLLOW THE STEPS TOWARD SETTING UP THE CAMERA SENSOR IN WORKING MODE.
OPEN THE PACKAGE AND CHECK THAT YOU HAVE THE TOTAL KIT OF PARTS LISTED. SOME ITEMS NOTED ARE NOT
SUPPLIED WITH THE UNIT. THESE INCLUDE : MICROPHONE ATTACHMENT AND THE SPEAKER ATTACHMENT. PLEASE BE
AWARE THAT IT IS UNLAWFUL FOR THE MICROPHONE TO BE USED IN SURVEILLANCE CIRCUMSTANCES IN AUSTRALIA.
EYE CU TECHNOLOGY PTY. LTD. TAKES NO RESPONSIBILITY FOR ANY SUCH USE. ONCE YOU ARE FAMILIAR WITH
EACH PART UNDERTAKE THE ASSEMBLY AS FOLLOWS :
2.1
YOU WILL NEED A PHILLIPS HEAD SCREWDRIVER TO OPEN THE FRONT COVER.
2.2
INSERT THE SD MEMORY CARD
2.3
INSERT THE SIM CARD
2.4
INSERT THE BATTERY PACK
2.5
PLUG IN THE AC/DC POWER ADAPTOR
2.6
CHECK ASSEMBLY & TEST
2.7
TURN POWER ON TO CHARGE BATTERY PACK
YOU WILL THEN BE ABLE TO TEST THE CAMERA SENSOR UNIT, ADD OTHER DEVICES LIKE SMOKE SENSORS,REMOTE'S
ETC. AT THIS POINT YOU WILL NEED TO ACCESS THE WEBSITE AND FOLLOW THE INSTRUCTIONS TO ENABLE YOUR DE-
VICE TO OPERATE AND TO ACTIVATE THE WARRANTY AND ONGOING OPERATION.
STEP1 FAMILIARISATION
STEP 2 PREPARATION
