CyberResearch STE 1xGTx Series User Manual

Nema 4 sealed touchscreen panel pc systems with vga, ethernet, pci expansion, ac or dc power input, and usb

page of 198

/ 198
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Download this manual

Panel PCs

STE 1xGTx Series

NEMA 4 Sealed Touchscreen Panel

PC Systems with VGA, Ethernet, PCI

Expansion, AC or DC Power Input,

and USB

USER'S MANUAL

VER. 2.0C• Feb-11

No part of this manual may be reproduced without permission

CyberResearch

, Inc.

www.cyberresearch.com

25 Business Park Dr., Branford, CT 06405 USA

203-643-5000 (9

. to 5

. EST) FAX: 203-643-5001

Table of Contents

Need help?

Do you have a question about the STE 1xGTx Series and is the answer not in the manual?

Questions and answers

Summary of Contents for CyberResearch STE 1xGTx Series

Page 1 ® Panel PCs STE 1xGTx Series NEMA 4 Sealed Touchscreen Panel PC Systems with VGA, Ethernet, PCI Expansion, AC or DC Power Input, and USB USER’S MANUAL VER. 2.0C• Feb-11 No part of this manual may be reproduced without permission ®...
Page 3 CyberResearch, Inc. In no event will CyberResearch, Inc. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of or inability to use the product or documentation, even if advised of the possibility of such damages.
Page 4 ® STE 1xGTx Series CyberResearch Panel PCs Revision History Revision # Description Date of Issue Initial Release August 1, 2008 2.0C Revision February 19, 2011 ©Copyright 2011 CyberResearch, Inc.
Page 5: Manual Conventions
® CyberResearch Panel PCs STE 1xGTx Series Manual Conventions WARNING! Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. Warnings are easy to recognize. The word “warning” is written as “WARNING,” both capitalized and bold and is followed by text.
Page 6 ® CyberResearch STE 1xGTx Series Panel PCs NOTE: These messages inform the reader of essential but non-critical information. These messages should be read carefully as any directions or instructions contained therein can help avoid making mistakes. Notes are easy to recognize. The word “note” is written as “NOTE,”...
Page 7: Packing List
Packing List NOTE: If any of the components listed in the checklist below are missing, please do not proceed with the installation. Contact a CyberResearch sales engineer immediately via our website www.cyberresearch.com, by phone: (203) 643-5000, or e-mail:sales@cyberresearch.com. The items listed below are included with the STE 1xGTx package, many are pre-installed...
Page 9: Table Of Contents
® CyberResearch Panel PCs STE 1xGTx Series Table of Contents 1 INTRODUCTION......................1 1.1 G ....................2 ENERAL VERVIEW 1.1.1 STE 1xGTx Model Variations................2 1.1.2 Applications ....................... 3 1.1.3 Features ......................3 1.2 E ....................4 XTERNAL VERVIEW 1.2.1 Front Panel ......................4 1.2.2 Rear Panel ......................
Page 10 ® CyberResearch STE 1xGTx Series Panel PCs 2.5 S ....................22 YSTEM HIPSETS 2.5.1 Intel® 945G Northbridge Chipset ..............23 2.5.2 ICH7 Southbridge Chipset................23 2.6 G ....................24 RAPHICS UPPORT 2.6.1 Analog CRT Support ..................25 2.6.2 LVDS Support ....................25 2.7 M...
Page 11 ® CyberResearch Panel PCs STE 1xGTx Series 4.5.4 CF Card Setup (JP7)..................43 4.5.5 COM Port RI and Voltage Selection (JP3, JP4, JP5, JP6, JP8) ..... 44 4.5.6 COM5 RS-232/422/485 Settings ..............45 4.5.6.1 COM5 RS-232/422/485 RX Select (J2) ........... 45 4.5.6.2 COM5 RS-422/485 TX Select (J3)............
Page 12 ® CyberResearch STE 1xGTx Series Panel PCs 5.3 A ....................... 70 DVANCED 5.3.1 CPU Configuration..................72 5.3.2 IDE Configuration ................... 74 5.3.2.1 IDE Master, IDE Slave ................76 5.3.3 Floppy Configuration..................81 5.3.4 Super IO Configuration ................... 82 5.3.5 Hardware Health Configuration..............87 5.3.6 Power Configuration..................
Page 13 ® CyberResearch Panel PCs STE 1xGTx Series 7.2 M ................141 OTHERBOARD EPLACEMENT 7.3 B ..................141 OVER EMOVAL 7.4 DIMM R ................... 142 EPLACEMENT 7.5 E ................143 LEVATED LATFORM EMOVAL 7.6 PSU M ................145 ODULE EPLACEMENT 7.6.1 Remove the Old PSU..................145 7.6.2 Install the New PSU ..................
Page 14 ® CyberResearch STE 1xGTx Series Panel PCs List of Figures Figure 1-1: STE 1xGTx ........................2 Figure 1-2: Front View ........................4 Figure 1-3: STE 1xGTx Rear View ....................5 Figure 1-4: STE 1xGTx Top View ....................5 Figure 1-5: Bottom View ........................6 Figure 1-6: Left View........................7 Figure 1-7: Right View ........................7...
Page 15 ® CyberResearch Panel PCs STE 1xGTx Series Figure 4-11: Optical Drive Blank Plate Assembly ..............53 Figure 4-12: Optical Drive Screws ....................54 Figure 4-13: Optical Drive SATA Cable ..................55 Figure 4-14: Optical Drive Bracket Screws ................55 Figure 4-15: Wall-mounting Bracket ...................57 Figure 4-16: Mount the Chassis ....................58...
Page 16 ® CyberResearch STE 1xGTx Series Panel PCs Figure 6-23: Select Network Drivers ..................136 Figure 6-24: Select All Windows ....................136 Figure 6-25: Setup Screen ......................137 Figure 6-26: Select Next t......................137 Figure 6-27: Select Install ......................138 Figure 6-28: Driver Installation Begins..................138 Figure 6-29: Select Finish ......................
Page 17 ® CyberResearch Panel PCs STE 1xGTx Series List of Tables Table 1-1: STE 1xGTx Model Variation ..................3 Table 2-1: STE 1xGTx Specifications ..................12 Table 2-2: Motherboard Specifications ..................13 Table 2-3: 15” TFT LCD Monitor Specifications ................14 Table 2-4: 17” TFT LCD Monitor Specifications ................15 Table 2-5: 19”...
Page 18 ® CyberResearch STE 1xGTx Series Panel PCs BIOS Menus BIOS Menu 1: Main ........................69 BIOS Menu 2: Advanced ......................71 BIOS Menu 3: CPU Configuration ....................72 BIOS Menu 4: IDE Configuration....................74 BIOS Menu 5: IDE Master and IDE Slave Configuration ............76 BIOS Menu 6: IDE Master and IDE Slave Configuration ............81...
Page 19: Introduction
® CyberResearch Panel PCs STE 1xGTx Series Chapter Introduction CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000; F: (203) 643-5001 Branford, CT USA www.cyberresearch.com...
Page 20: General Overview
® CyberResearch STE 1xGTx Series Panel PCs 1.1 General Overview Figure 1-1: STE 1xGTx The STE 1xGTx flat panel PC is for industrial environments like production lines and machine automation. The STE 1xGTx provides all the features of a PC, combined with a touch panel screen for mouse and keyboard free data input.
Page 21: Applications
® CyberResearch Panel PCs STE 1xGTx Series Socket / Touch Model Power Screen Screen STE 17GTA AC input 17” Dual Core STE 17GTC 24 V DC input 17” STE 19GTA AC input 19” STE 19GTC 24 V DC input 19”...
Page 22: External Overview
® CyberResearch STE 1xGTx Series Panel PCs 1 x PCI slot 1 x CompactFlash® slot 1 x VGA port 1 x Parallel port Dual 10/100/Gigabit Ethernet supported RoHS compliant 1.2 External Overview The STE 1xGTx flat panel PC is comprised of an LCD screen, aluminum front panel and heavy duty steel rear and side panels.
Page 23: Rear Panel
® CyberResearch Panel PCs STE 1xGTx Series 1.2.2 Rear Panel The rear panel has a fan vent, four VESA standard mounting holes and several retention screw holes. The VESA mounting holes are circled in Figure 1-3. Figure 1-3: STE 1xGTx Rear View 1.2.3 Top Panel...
Page 24: Bottom Panel
® CyberResearch STE 1xGTx Series Panel PCs 1.2.4 Bottom Panel The bottom panel shown in Figure 1-5 has the following interfaces: 1 x Power input connector 1 x Power switch 4 x USB connectors 1 x Reset button 2 x RJ-45 GbE connectors...
Page 25: Left Panel
® CyberResearch Panel PCs STE 1xGTx Series 1.2.5 Left Panel The left side panel has two fan vents and four retention screws for securing the two internal fans. The retention screws are circled in Figure 1-6. Figure 1-6: Left View 1.2.6 Right Panel...
Page 26: Internal Overview
® CyberResearch STE 1xGTx Series Panel PCs 1.3 Internal Overview The STE 1xGTx internal components are configured in three levels. The PSU cover bracket to the left (Figure 1-8) supports the hard drive and optical drive brackets. Below the PSU cover bracket is the power supply. On the same level as the power supply is the motherboard.
Page 27: Specifications
® CyberResearch Panel PCs STE 1xGTx Series Chapter Specifications CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000; F: (203) 643-5001 Branford, CT USA www.cyberresearch.com...
Page 28: Introduction
® CyberResearch STE 1xGTx Series Panel PCs 2.1 Introduction The STE 1xGTx flat panel PC has the following preinstalled components: 1 x Motherboard 1 x TFT LCD screen 1 x Power supply 2 x Cooling fans The technical specifications for these components and the system are shown in the sections below.
Page 29 ® CyberResearch Panel PCs STE 1xGTx Series SPECIFICATION DESCRIPTION Touch Screen Optional 5-wire resistive type touch screen with RS-232 interface Display Supports Dual Display Add-On Card (Optional) One PCI card Drive Bay One 2.5” HDD bay with anti-shock One slim type CD drive bay One slim type FDD bay One CompactFlash®...
Page 30: Motherboard Specifications
® CyberResearch STE 1xGTx Series Panel PCs SPECIFICATION DESCRIPTION Shock 10G Acceleration, peak to peak (11ms) Dimensions (W x D x H) STE 15GTx: 410 mm x 309 mm x 110.5 mm STE 17GTx: 452 mm x 356 mm x 115 mm STE 19GTx: 483 mm x 399 mm x 115.2 mm...
Page 31: Flat Panel Screen
® CyberResearch Panel PCs STE 1xGTx Series SPECIFICATION DESCRIPTION 1 x RS-232/422/485 port 5 x RS-232 ports (1 used internally for touch screen) USB 2.0 6 x USB 2.0 ports Drive Interfaces 2 x SATA drive connectors 1 x Parallel port...
Page 32: Ste 17Gtx Screen
® CyberResearch STE 1xGTx Series Panel PCs SPECIFICATION DETAILS Contrast Ratio 400:1 Response Time (ms) (at 25°C) 11.5 Power Consumption (W) Interface 1ch LVDS Supply Voltage (V) 2 CCFL Backlight Outline Dimensions (mm) 326.5 x 253.5 x 12.0 Weight (g) 1100 Table 2-3: 15”...
Page 33: Ste 19Gtx Screen
® CyberResearch Panel PCs STE 1xGTx Series SPECIFICATION DETAILS Response Time (ms) (at 25°C) Power Consumption (W) 25.8 Interface 2ch LVDS Supply Voltage (V) 4 CCFL Backlight Outline Dimensions (mm) 358.5 x 296.5 x 17.0 Weight (g) 1900 Table 2-4: 17” TFT LCD Monitor Specifications 2.1.3.3 STE 19GTx Screen...
Page 34: Power Supply
® CyberResearch STE 1xGTx Series Panel PCs SPECIFICATION DESCRIPTION Interface 2ch LVDS Supply Voltage (V) Backlight 4 CCFL Outline Dimensions (mm) 396.0 x 324.0 x 17.5 Weight (g) 2500 Table 2-5: 19” TFT LCD Monitor Specifications 2.1.4 Power Supply The STE 1xGTx flat panel PC comes with either a 180 W AC-DC 1U (model STx 1xGTA), or a 200 W DC 1U (model STx 1xGTC) RoHS compliant ATX power supply.
Page 35: Ste 1Xgta Power Supply
® CyberResearch Panel PCs STE 1xGTx Series 2.1.4.1 STE 1xGTA Power Supply Specifications for the STE 1xGTA PSU module are shown in (Table 2-6). Specification Rating INPUT Voltage AC90 V ~ 265 VAC Full Range Frequency 47 ~ 63Hz Input Current...
Page 36: Ste 1Xgtc Power Supply
® CyberResearch STE 1xGTx Series Panel PCs 2.1.4.2 STE 1xGTC Power Supply Specifications for the STE 17GTC PSU module are shown in (Table 2-7). Specification Rating INPUT Voltage 18 VDC ~ 36 VDC Full Range Input Current Inrush Current 100A...
Page 37: Ste 15Gtx Dimensions
® CyberResearch Panel PCs STE 1xGTx Series 2.2.1 STE 15GTx Dimensions The dimensions of the STE 15GTx flat panel PC are shown in Figure 2-1 below. Figure 2-1: STE 15GTx Dimensions (units in mm) CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000;...
Page 38: Ste 17Gtx Dimensions
® CyberResearch STE 1xGTx Series Panel PCs 2.2.2 STE 17GTx Dimensions The dimensions of the STE 17GTx flat panel PC are shown in Figure 2-2 below. Figure 2-2: STE 17GTx Dimensions (units in mm) ©Copyright 2011 CyberResearch, Inc.
Page 39: Ste 19Gtx Dimensions
® CyberResearch Panel PCs STE 1xGTx Series 2.2.3 STE 19GTx Dimensions The dimensions of the STE 19GTx flat panel PC are shown in Figure 2-3 below. Figure 2-3: STE 19GTx Dimensions (units in mm) CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000;...
Page 40: Motherboard
® CyberResearch STE 1xGTx Series Panel PCs 2.3 Motherboard The STE 1xGTx flat screen PC contains a motherboard. The motherboard is the heart of any computer and is responsible for transmitting, receiving and processing data as well as driving the different on-board devices. This chapter gives a brief introduction to the STE 1xGTx motherboard.
Page 41: Intel® 945G Northbridge Chipset
® CyberResearch Panel PCs STE 1xGTx Series 2.5.1 Intel® 945G Northbridge Chipset The Intel® 945G Northbridge chipset comes with the following features: Supports the Intel® 1.8 GHz Dual Core processor with Intel NetBurst® microarchitecture 400 MHz or 533 MHz system bus delivers a high-bandwidth connection between the processor and the platform Integrated graphics utilizing Intel®...
Page 42: Graphics Support
® CyberResearch STE 1xGTx Series Panel PCs Independent DMA operation on two ports. Data transfer rates up to 1.5 Gb/s (150 MB/s). Integrated IDE Controller Supports “Native Mode” Register and Interrupts Independent timing of up to 4 drives Ultra ATA/100/66/33, BMIDE and PIO modes...
Page 43: Analog Crt Support
® CyberResearch Panel PCs STE 1xGTx Series 2.6.1 Analog CRT Support The VGA port connects a peripheral monitor to the STE 1xGTx system. A DB-15 VGA connector on the external peripheral interface connector panel is interfaced to the Intel® 945G Northbridge. The Intel® 945G supports analog CRT monitors with the following...
Page 44: Storage
® CyberResearch STE 1xGTx Series Panel PCs Figure 2-5: SO-DIMM Socket 2.8 Storage There following storage options are available: CompactFlash® SATA hard drive ® 2.8.1 CompactFlash CompactFlash® socket supports standard CompactFlash® Type CompactFlash® Type II cards. The chipset flash interface is multiplexed with an IDE interface and can be connected to an array of industry standard NAND Flash or NOR Flash devices.
Page 45: Sata Hard Drive
® CyberResearch Panel PCs STE 1xGTx Series Figure 2-6: CompactFlash® Slot 2.8.2 SATA Hard Drive The integrated SATA controller supports two SATA drives with independent DMA operations. One SATA port is implemented internally for the internal 2.5” SATA hard drive.
Page 46: Expansion Slots
® CyberResearch STE 1xGTx Series Panel PCs Figure 2-7: SATA Hard Drive Slot 2.9 Expansion Slots The STE 1xGTx includes either a PCI or PCIe x4 expansion card slot. The expansion card slots add additional functionality to the STE 1xGTx.
Page 47: External Device Connectors
® CyberResearch Panel PCs STE 1xGTx Series Ethernet adapter cards Modem cards Sound cards PCIe x4 cards available for the STE 1xGTx include: Gigabit Ethernet adapter cards SATA II / RAID controller cards TV tuner cards Graphics cards Firewire & USB cards 2.10 External Device Connectors...
Page 48: Serial Ports
® CyberResearch STE 1xGTx Series Panel PCs 2.10.2 Serial Ports Serial ports provide communications to external devices. Four of the external serial ports provide short-range communications, while one provides for longer range communication. Figure 2-10: Serial Ports Some features of the serial ports include:...
Page 49: Gigabit Ethernet
® CyberResearch Panel PCs STE 1xGTx Series Standard setup connects to devices with a standard parallel port, like printers 2.11 Gigabit Ethernet The Broadcom BCM5787M PCI Express (PCIe) GbE controller is a 10/100/1000BASE-T Ethernet LAN controller. The BCM5787M combines a triple-speed IEEE 802.3 compliant Media Access Controller (MAC) with a triple-speed Ethernet transceiver, a PCIe bus interface, and an on-chip buffer memory.
Page 50: Flat Screen
® CyberResearch STE 1xGTx Series Panel PCs 2.12.1 Flat Screen The STE 1xGTx comes with a TFT LCD monitor. The tough construction of the TFT monitor allows the STE 1xGTx to withstand the conditions it is likely to be exposed to during regular use.
Page 51: Unpacking
® CyberResearch Panel PCs STE 1xGTx Series Chapter Unpacking CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000; F: (203) 643-5001 Branford, CT USA www.cyberresearch.com...
Page 52: Anti-Static Precautions
® CyberResearch STE 1xGTx Series Panel PCs 3.1 Anti-static Precautions WARNING! Failure to take ESD precautions during the installation of the STE 1xGTx may result in permanent damage to the STE 1xGTx and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the STE 1xGTx.
Page 53: Package Contents
3.3 Package Contents NOTE: If any components listed in the checklist below are missing, do not proceed with the installation. Contact a CyberResearch sales engineer immediately via our website www.cyberresearch.com, by phone: (203) 643-5000, or e-mail:sales@cyberresearch.com. The STE 1xGTx is shipped with the following components (many of the components listed...
Page 54: Table 3-1: Package List Contents
® CyberResearch STE 1xGTx Series Panel PCs Quantity Item and Part Number Image Power cord Screw set IDE adapter (for slim DVD/CD-ROM) Driver CD/DVD Touch pen Table 3-1: Package List Contents ©Copyright 2011 CyberResearch, Inc.
Page 55: Installation And Configuration
® CyberResearch Panel PCs STE 1xGTx Series Chapter Installation and Configuration CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000; F: (203) 643-5001 Branford, CT USA www.cyberresearch.com...
Page 56: Installation Precautions
® CyberResearch STE 1xGTx Series Panel PCs 4.1 Installation Precautions When installing the STE 1xGTx, please follow the precautions listed below: Turn power off: When installing the STE 1xGTx make sure the power is off. Failing to turn off the power may cause severe injury to the body and/or damage to the system.
Page 57: Installation And Configuration Steps
® CyberResearch Panel PCs STE 1xGTx Series 4.3 Installation and Configuration Steps The following installation steps must be followed. Step 1: Unpack the STE 1xGTx. Step 2: Set the jumper settings. Step 3: Install HDD, CompactFlash® and CD/DVD drive. Step 4: Mount the STE 1xGTx flat panel PC.
Page 58: Remove The
® CyberResearch STE 1xGTx Series Panel PCs 4.4 Remove the Back Cover Remove all the retention screws on the back cover. Lift the cover up to remove (Figure 4-1). Figure 4-1: Back Cover Retention Screws 4.5 Jumper Settings ©Copyright 2011 CyberResearch, Inc.
Page 59: At/Atx Power Selection (At_Pwr_Sw1)
® CyberResearch Panel PCs STE 1xGTx Series NOTE: A jumper is a metal bridge that is used to close an electrical circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover that slides over the pins to connect them. To...
Page 60: Clear Cmos Setup (Jp2)
® CyberResearch STE 1xGTx Series Panel PCs The AT/ATX selection jumper is connected to the AT/ATX switch on the I/O panel of the STE 1xGTx. AT_PWR_SW1 DESCRIPTION Closed AT power Open ATX power Table 4-2: AT/ATX Power Selection 4.5.2 Clear CMOS Setup (JP2) If the motherboard fails to boot due to improper BIOS settings, use this jumper to clear the CMOS data and reset the system BIOS information.
Page 61: Cf Card Setup (Jp7)
® CyberResearch Panel PCs STE 1xGTx Series The monitor setup jumper sets the default settings for all monitors connected to the STE 1xGTx. Pins 1-4 adjust the resolution of the screen. JP1 (pins 1-4) LCD Resolution OPEN 1024 x 768 (18-bit)
Page 62: Com Port Ri And Voltage Selection (Jp3, Jp4, Jp5, Jp6, Jp8)
® CyberResearch STE 1xGTx Series Panel PCs 4.5.5 COM Port RI and Voltage Selection (JP3, JP4, JP5, JP6, JP8) Use the COM port settings jumpers to select the voltage of serial port pin 9. COM1 Pin-9 Setting 12 V Table 4-7: COM1 RI and Voltage Selection Jumper...
Page 63: Com5 Rs-232/422/485 Settings
® CyberResearch Panel PCs STE 1xGTx Series 4.5.6 COM5 RS-232/422/485 Settings To enable RS-232, RS-422 or RS-485 on COM5, all the following jumpers should be setup. 4.5.6.1 COM5 RS-232/422/485 RX Select (J2) Jumper J2 sets the COM5 serial port as RS-232, RS-422 or RS-485.
Page 64: Com5 Termination Resistors (J5, J6)
® CyberResearch STE 1xGTx Series Panel PCs 4.5.6.4 COM5 Termination Resistors (J5, J6) The termination resistors J5 and J6 can remedy communication errors for RS-422/485 setups with cables over 1.5 km in length DESCRIPTION Open Open No terminator resistor set...
Page 65: Touch Screen Selection (Jp7)
® CyberResearch Panel PCs STE 1xGTx Series 4.5.8 Touch Screen Selection (JP7) The touch screen selection jumper selects the type of touch screen panel connected to the system. DESCRIPTION 5-wire touch panel 2-3 closed 4-wire or 8-wire touch panel Table 4-17: Touch Screen Selection 4.6 Drive Installation...
Page 66: Figure 4-2: Hdd Retention Screws
® CyberResearch STE 1xGTx Series Panel PCs Figure 4-2: HDD Retention Screws Step 3: Attach the SATA connector cable to the bracket. Figure 4-3: HDD SATA Connector Step 4: Attach the hard drive in the bracket. To do this, slide the hard drive onto the bracket until it connects with the SATA connector at the back.
Page 67: Figure 4-4: Hdd Retention Screws
® CyberResearch Panel PCs STE 1xGTx Series Figure 4-4: HDD Retention Screws Step 5: Install the hard drive bracket (with hard drive and SATA cable attached) into the STE 1xGTx and fasten the four hard drive bracket screws.Step 0: Figure 4-5: HDD Retention Screws CyberResearch, Inc.
Page 68: Compactflash Installation
® CyberResearch STE 1xGTx Series Panel PCs ® 4.6.2 CompactFlash Installation To install the CompactFlash® card, please follow the steps below: Step 1: Undo the CompactFlash® slot cover screw and remove the CompactFlash® cover plate. Figure 4-6: CompactFlash® Cover Plate Step 2: Insert the CompactFlash®...
Page 69: Cd/Dvd Drive Installation
® CyberResearch Panel PCs STE 1xGTx Series Step 3: Fasten the CompactFlash® cover plate.Step 0: Figure 4-8: CompactFlash® Cover Plate 4.6.3 CD/DVD Drive Installation To install a CD/DVD drive, please follow the steps below. Step 1: Remove the back cover (Section 4.4).
Page 70: Figure 4-9: Cd/Dvd Drive Adapter Installation
® CyberResearch STE 1xGTx Series Panel PCs Figure 4-9: CD/DVD Drive Adapter Installation Step 5: Undo the optical drive bracket screws and remove the optical drive bracket. Figure 4-10: CD/DVD Drive Retention Screws ©Copyright 2011 CyberResearch, Inc.
Page 71: Figure 4-11: Optical Drive Blank Plate Assembly
® CyberResearch Panel PCs STE 1xGTx Series Step 6: Remove the four screws from the optical drive bracket assembly. Remove the blank drive plate. Figure 4-11: Optical Drive Blank Plate Assembly CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000; F: (203) 643-5001 Branford, CT USA www.cyberresearch.com...
Page 72: Figure 4-12: Optical Drive Screws
® CyberResearch STE 1xGTx Series Panel PCs Step 7: Install the optical drive in the same position as the previously removed blank optical drive plate. Fasten the same four screws to attach the optical drive to the bracket. Figure 4-12: Optical Drive Screws...
Page 73: Figure 4-13: Optical Drive Sata Cable
® CyberResearch Panel PCs STE 1xGTx Series Step 8: Attach the SATA cable to the back of the optical drive and fasten the SATA cable screws. Figure 4-13: Optical Drive SATA Cable Step 9: Reinstall the optical drive bracket into the STE 1xGTx and fasten the optical bracket screws.Step 0:...
Page 74: Mounting The System
® CyberResearch STE 1xGTx Series Panel PCs 4.7 Mounting the System WARNING! When mounting the STE 1xGTx flat panel PC onto an arm, wall or into a panel, it is advisable to have more than one person help with the installation to prevent accidental damage to the panel and avoid personal injury.
Page 75: Figure 4-15: Wall-Mounting Bracket
® CyberResearch Panel PCs STE 1xGTx Series Figure 4-15: Wall-mounting Bracket Step 6: Insert the four monitor mounting screws provided in the wall mounting kit into the four screw holes on the real panel of the monitor and tighten until the screw shank is secured against the rear panel (see Figure 3-12).
Page 76: Figure 4-16: Mount The Chassis
® CyberResearch STE 1xGTx Series Panel PCs Figure 4-16: Mount the Chassis Step 9: Secure the panel PC with the wall-mounting kit. To do this, stick the protective cushion to the wall-mounting kit first. Then, put the wall-mounting kit on the top panel of the panel PC.
Page 77: Panel/ Mounting
® CyberResearch Panel PCs STE 1xGTx Series Figure 4-17: Secure the Chassis 4.7.2 Panel/ Mounting To mount the STE 1xGTx flat panel PC into a panel, please follow the steps below. NOTE: The maximum panel thickness should be no more than 6 mm.
Page 78: Figure 4-18: 15" Panel Cutout Dimensions
® CyberResearch STE 1xGTx Series Panel PCs Figure 4-18: 15” Panel Cutout Dimensions Figure 4-19: 17” Panel Cutout Dimensions ©Copyright 2011 CyberResearch, Inc.
Page 79: Figure 4-20: 19" Panel Cutout Dimensions
® CyberResearch Panel PCs STE 1xGTx Series Figure 4-20: 19” Panel Cutout Dimensions Step 3: Slide the STE 1xGTx through the hole until the metal frame is flush against the panel. Step 4: Insert the panel mounting clamps into the pre-formed holes along the edges of the STE 1xGTx, behind the metal frame (Figure 4-21).
Page 80: Rack And Cabinet Installation
® CyberResearch STE 1xGTx Series Panel PCs Figure 4-21: Panel Mounting Clamp Positions Step 5: Tighten the screws that pass through the panel mounting clamps until the plastic caps at the front of all the screws are firmly secured to the panel (Figure 4-22).
Page 81: Arm Mounting
® CyberResearch Panel PCs STE 1xGTx Series Step 1: Secure the rack mounting bracket to two sides of the monitor using the supplied retention screws (Figure 3-17). Each bracket requires four screws. Step 2: Secure the rack mounting bracket to the rack by inserting and tightening the supplied mounting nuts and bolts (Figure 3-17).
Page 82: External Peripheral Interface Connectors
® CyberResearch STE 1xGTx Series Panel PCs Figure 4-23: Arm Mount Retention Screw Holes Step 4: Secure the STE 1xGTx to the interface pad by inserting four retention screws through the mounting arm interface pad and into the STE 1xGTx flat panel PC.
Page 83: Usb Connection
® CyberResearch Panel PCs STE 1xGTx Series 4.8.3 USB Connection The external peripheral interface USB connectors provide easy and quick access to external USB devices. The external peripheral interface USB connectors are a standard connector and can easily be connected to other USB devices.
Page 85: Introduction
® CyberResearch Panel PCs STE 1xGTx Series 5.1 Introduction A licensed copy of AMI BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options that may be changed.
Page 86: Getting Help
® CyberResearch STE 1xGTx Series Panel PCs Function F1 key General help, only for Status Page Setup Menu and Option Page Setup Menu F2 /F3 key Change color from total 16 colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 5-1: BIOS Navigation Keys 5.1.3 Getting Help...
Page 87: Main
® CyberResearch Panel PCs STE 1xGTx Series 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS Menu 1: Main System Overview The System Overview lists a brief summary of different system components.
Page 88: Advanced
® CyberResearch STE 1xGTx Series Panel PCs System Memory: Displays the auto-detected system memory. Size: Lists memory size The System Overview field also has two user configurable fields: System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.
Page 89: Bios Menu 2: Advanced
® CyberResearch Panel PCs STE 1xGTx Series BIOS Menu 2: Advanced CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000; F: (203) 643-5001 Branford, CT USA www.cyberresearch.com...
Page 90: Cpu Configuration
® CyberResearch STE 1xGTx Series Panel PCs 5.3.1 CPU Configuration Use the CPU Configuration menu (BIOS Menu 3) to view detailed CPU specifications and configure the CPU. BIOS Menu 3: CPU Configuration The CPU Configuration menu (BIOS Menu 3) lists the following CPU details:...
Page 91 ® CyberResearch Panel PCs STE 1xGTx Series Hyper-Threading Technology (HTT). If the operating system recognizes the installed processor, then this option should be kept in the default Disabled setting. CPUID is reported in full. Disabled EFAULT Enabled Limits the maximum CPUID to 30h.
Page 92: Ide Configuration
® CyberResearch STE 1xGTx Series Panel PCs 5.3.2 IDE Configuration Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration of the IDE devices installed in the system. BIOS Menu 4: IDE Configuration ATA/IDE Configurations [Enhanced] Use the ATA/IDE Configurations option to configure the ATA/IDE controller.
Page 93 ® CyberResearch Panel PCs STE 1xGTx Series Enhanced Configures the on-board ATA/IDE controller to be in EFAULT Enhanced mode. In this mode, IDE channels and SATA channels are separated. Some legacy OS do not support this mode. Configure SATA as [IDE] The “Configure SATA as”...
Page 94: Ide Master, Ide Slave
® CyberResearch STE 1xGTx Series Panel PCs Primary IDE Master Primary IDE Slave The IDE Configuration menu (BIOS Menu 4) allows changes to the configurations for the IDE devices installed in the system. If an IDE device is detected, and one of the above listed four BIOS configuration options are selected, the IDE configuration options shown in Section 5.3.2.1 appear.
Page 95 ® CyberResearch Panel PCs STE 1xGTx Series Device: Lists the device type (e.g. hard disk, CD/DVD-ROM etc.) Type: Indicates the type of devices a user can manually select Vendor: Lists the device manufacturer Size: List the storage capacity of the device.
Page 96 ® CyberResearch STE 1xGTx Series Panel PCs ARMD This option specifies an ATAPI Removable Media Device. These include, but are not limited to: LS-120 LBA/Large Mode [Auto] Use the LBA/Large Mode option to disable or enable BIOS to auto detects LBA (Logical Block Addressing).
Page 97 ® CyberResearch Panel PCs STE 1xGTx Series Auto BIOS auto detects the PIO mode. Use this value if the IDE disk EFAULT drive support cannot be determined. PIO mode 0 selected with a maximum transfer rate of 3.3 MB/s PIO mode 1 selected with a maximum transfer rate of 5.2 MB/s PIO mode 2 selected with a maximum transfer rate of 8.3 MB/s...
Page 98 ® CyberResearch STE 1xGTx Series Panel PCs UDMA1 Ultra DMA mode 1 selected with a maximum data transfer rate of 25 MB/s Ultra DMA mode 2 selected with a maximum data transfer UDMA2 rate of 33.3 MB/s Ultra DMA mode 3 selected with a maximum data transfer...
Page 99: Floppy Configuration
® CyberResearch Panel PCs STE 1xGTx Series 5.3.3 Floppy Configuration Use the Floppy Configuration menu (BIOS Menu 6) to configure the floppy disk drive connected to the system. BIOS Menu 6: IDE Master and IDE Slave Configuration Floppy A/B Use the Floppy A/B option to configure the floppy disk drive. Options are listed below: Disabled 360 KB 51/4”...
Page 100: Super Io Configuration
® CyberResearch STE 1xGTx Series Panel PCs 5.3.4 Super IO Configuration Use the Super IO Configuration menu (BIOS Menu 7) to set or change the configurations for the FDD controllers, parallel ports and serial ports. BIOS Menu 7: Super IO Configuration Digital I/O Address [2D8] Use the Digital I/O Address option to select the digital I/O port base address.
Page 101 ® CyberResearch Panel PCs STE 1xGTx Series Disabled No base address is assigned to Serial Port 1 3F8/IRQ4 Serial Port 1 I/O port address is 3F8 and the interrupt EFAULT address is IRQ4 Serial Port 1 I/O port address is 3E8 and the interrupt...
Page 102 ® CyberResearch STE 1xGTx Series Panel PCs IrDA Serial Port 2 mode is IrDA Serial Port 2 mode is ASK IR ASK IR Parallel Port Address [Disabled] Use the Parallel Port Address option to select the parallel port base address.
Page 103 ® CyberResearch Panel PCs STE 1xGTx Series ECP+EPP The parallel port operates in the extended capabilities port (ECP) mode. The ECP mode supports bi-directional communication between the system and the parallel port device and the transmission rates between the two are much faster...
Page 104 ® CyberResearch STE 1xGTx Series Panel PCs Serial Port5 Address [2F0] Use the Serial Port5 IRQ option to select the interrupt address for serial port 5. Disabled No base address is assigned to serial port 5 Serial port 5 I/O port address is 3E8...
Page 105: Hardware Health Configuration
® CyberResearch Panel PCs STE 1xGTx Series 5.3.5 Hardware Health Configuration The Hardware Health Configuration menu (BIOS Menu 8) shows the operating temperature, fan speeds and system voltages. BIOS Menu 8: Hardware Health Configuration CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000;...
Page 106 ® CyberResearch STE 1xGTx Series Panel PCs CPU FAN 1 Mode Setting [Full On Mode] Use the CPU FAN 1 Mode Setting option to configure the CPU fan. Full On Mode Fan is on all the time EFAULT FAN x Mode Setting [Automatic Mode] Use the FAN x Mode Setting option to configure the second fan.
Page 107 CyberResearch Panel PCs STE 1xGTx Series The CPU Temp. Limit of OFF option can only be set if the FAN x Mode Setting option is set to Automatic Mode. Use the CPU Temp. Limit of OFF option to select the CPU temperature at which the cooling fan should automatically turn off.
Page 108 ® CyberResearch STE 1xGTx Series Panel PCs The Temperature Limit of Full option can only be set if the FAN x Mode Setting option is set to Automatic Mode. Use the Temperature Limit of Full option to select the CPU temperature at which the cooling will reach full speed.
Page 109 ® CyberResearch Panel PCs STE 1xGTx Series The following system parameters and values are shown. The system parameters that are monitored are: System Temperatures: The following system temperatures are monitored CPU Temperature System Temperature 1 System Temperature 2 Fan Speeds: The CPU cooling fan speed is monitored.
Page 110: Power Configuration
® CyberResearch STE 1xGTx Series Panel PCs 5.3.6 Power Configuration The power configuration menu (BIOS Menu 9) sets the power features options. BIOS Menu 9: ACPI Configuration Power Supply Mode [ATX] Use the Power Supply Mode BIOS option to select the power supply that is connected to the system.
Page 111: Acpi Configuration
® CyberResearch Panel PCs STE 1xGTx Series 5.3.6.1 ACPI Configuration The ACPI Configuration menu (BIOS Menu 10) configures the Advanced Configuration and Power Interface (ACPI) and Power Management (APM) options. BIOS Menu 10: ACPI Configuration Suspend Mode [S3(STR)] Use the Suspend Mode option to specify the sleep state the system enters when it is not being used.
Page 112: Apm Configuration
® CyberResearch STE 1xGTx Series Panel PCs 5.3.6.2 APM Configuration The APM Configuration menu (BIOS Menu 11) allows the advanced power management options to be configured. BIOS Menu 11:Advanced Power Management Configuration Power Button Mode [On/Off] Use the Power Button Mode BIOS to specify how the power button functions.
Page 113 ® CyberResearch Panel PCs STE 1xGTx Series Power Off The system remains turned off Power On The system turns on The system returns to its previous state. If it was on, it Last State EFAULT turns itself on. If it was off, it remains off.
Page 114 ® CyberResearch STE 1xGTx Series Panel PCs Resume On RTC Alarm [Disabled] Use the Resume On RTC Alarm option to specify the time the system should be roused from a suspended state. The real time clock (RTC) cannot generate a wake...
Page 115: Remote Access Configuration
® CyberResearch Panel PCs STE 1xGTx Series 5.3.7 Remote Access Configuration Use the Remote Access Configuration menu (BIOS Menu 12) to configure remote access parameters. The Remote Access Configuration is an AMIBIOS feature and allows a remote host running a terminal program to display and configure the BIOS settings.
Page 116 ® CyberResearch STE 1xGTx Series Panel PCs Enabled Remote access configuration options shown below appear: Serial Port Number Serial Port Mode Flow Control Redirection after BIOS POST Terminal Type VT-UTF8 Combo Key Support These configuration options are discussed below. Serial Port Number [COM1] Use the Serial Port Number option allows to select the serial port used for remote access.
Page 117 ® CyberResearch Panel PCs STE 1xGTx Series NOTE: Identical baud rate setting musts be set on the host (a management computer running a terminal software) and the slave Redirection After BIOS POST [Always] Use the Redirection After BIOS POST option to specify when console redirection should occur.
Page 118: Usb Configuration
® CyberResearch STE 1xGTx Series Panel PCs 5.3.8 USB Configuration Use the USB Configuration menu (BIOS Menu 13) to read USB configuration information and configure the USB settings. BIOS Menu 13: USB Configuration USB Configuration The USB Configuration field shows the system USB configuration. The items listed are: Module Version: x.xxxxx.xxxxx...
Page 119 ® CyberResearch Panel PCs STE 1xGTx Series Disabled USB function support disabled Enabled USB function support enabled EFAULT USB 2.0 Controller [Enabled] Use the USB 2.0 Controller BIOS option to enable or disable the USB 2.0 controller Disabled USB 2.0 controller disabled Enabled USB 2.0 controller enabled...
Page 120: Usb Mass Storage Device Configuration
® CyberResearch STE 1xGTx Series Panel PCs 5.3.8.1 USB Mass Storage Device Configuration Use the USB Mass Storage Device Configuration menu (BIOS Menu 14) to configure USB mass storage class devices. BIOS Menu 14: USB Mass Storage Device Configuration USB Mass Storage Reset Delay [20 Sec] Use the USB Mass Storage Reset Delay option to set the number of seconds POST waits for the USB mass storage device after the start unit command.
Page 121 ® CyberResearch Panel PCs STE 1xGTx Series 40 Sec POST waits 40 seconds for the USB mass storage device after the start unit command. Device ## The Device## field lists the USB devices that are connected to the system. Emulation Type [Auto] Use the Emulation Type BIOS option to specify the type of emulation BIOS has to provide for the USB device.
Page 122: Pci/Pnp
® CyberResearch STE 1xGTx Series Panel PCs CDROM Assumes the CD-ROM is formatted as bootable media. All the devices that support block sizes greater than 512 bytes can only be booted using this option. 5.4 PCI/PnP Use the PCI/PnP menu (BIOS Menu 15) to configure advanced PCI and PnP settings.
Page 123 ® CyberResearch Panel PCs STE 1xGTx Series IRQ# [Available] Use the IRQ# address to specify what IRQs can be assigned to a particular peripheral device. Available The specified IRQ is available to be used by EFAULT PCI/PnP devices The specified IRQ is reserved for use by Legacy ISA...
Page 124: Boot
® CyberResearch STE 1xGTx Series Panel PCs DM Channel 5 DM Channel 6 DM Channel 7 Reserved Memory Size [Disabled] Use the Reserved Memory Size BIOS option to specify the amount of memory that should be reserved for legacy ISA devices.
Page 125: Boot Settings Configuration
® CyberResearch Panel PCs STE 1xGTx Series 5.5.1 Boot Settings Configuration Use the Boot Settings Configuration menu (BIOS Menu 17) to configure advanced system boot options. BIOS Menu 17: Boot Settings Configuration Quick Boot [Enabled] Use the Quick Boot BIOS option to make the computer speed up the boot process.
Page 126 ® CyberResearch STE 1xGTx Series Panel PCs Enabled OEM Logo displayed instead of POST messages EFAULT AddOn ROM Display Mode [Force BIOS] Use the AddOn ROM Display Mode option to allow add-on ROM (read-only memory) messages to be displayed. The system forces third party BIOS to display...
Page 127: Boot Device Priority
® CyberResearch Panel PCs STE 1xGTx Series Enabled Can be booted from a remote system through the EFAULT 5.5.2 Boot Device Priority Use the Boot Device Priority menu (BIOS Menu 18) to specify the boot sequence from the available devices. Possible boot devices may include:...
Page 128: Bios Menu 19: Hard Disk Drives
® CyberResearch STE 1xGTx Series Panel PCs 3rd Drive [HDD: SM-(part number)] 4th Drive [HDD: SM-(part number)] NOTE: Only the drives connected to the system are shown. For example, if only two HDDs are connected only “1st Drive” and “2nd Drive” are listed.
Page 129: Cd/Dvd Drives
® CyberResearch Panel PCs STE 1xGTx Series 5.5.4 CD/DVD Drives Use the CD/DVD Drives menu to specify the boot sequence of the available CD/DVD drives. When the menu is opened, the CD drives and DVD drives connected to the system...
Page 131: Security
® CyberResearch Panel PCs STE 1xGTx Series 5.6 Security Use the Security menu (BIOS Menu 21) to set system and user passwords. BIOS Menu 21: Security Change Supervisor Password Use the Change Supervisor Password to set or change a supervisor password. The default for this option is Not Installed.
Page 132: Chipset
® CyberResearch STE 1xGTx Series Panel PCs 5.7 Chipset Use the Chipset menu (BIOS Menu 22) to access the Northbridge and Southbridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.
Page 133: Northbridge Configuration
® CyberResearch Panel PCs STE 1xGTx Series 5.7.1 Northbridge Configuration Use the Northbridge Configuration menu (BIOS Menu 22) to configure the Northbridge chipset. BIOS Menu 23:Northbridge Chipset Configuration Memory Hole [Disabled] Use the Memory Hole option to reserve memory space between 15 MB and 16 MB for ISA expansion cards that require a specified area of memory to work properly.
Page 134 ® CyberResearch STE 1xGTx Series Panel PCs Boot Display Device Use the Boot Display Device option to select the display device used by the system when it boots. Configuration options are listed below. Auto CRT - Default CRT + LFP Flat Panel Type [By Jumper] Use the Flat Panel Type is set using the onboard jumper settings.
Page 135: Southbridge Configuration
® CyberResearch Panel PCs STE 1xGTx Series 5.7.2 Southbridge Configuration The Southbridge Configuration menu (BIOS Menu 24) allows the Southbridge chipset to be configured. BIOS Menu 24:Southbridge Chipset Configuration Spectrum [Disabled] Use the Spectrum option to reduce the EMI. Excess EMI is generated when the system clock generator pulses have extreme values.
Page 136: Exit
® CyberResearch STE 1xGTx Series Panel PCs Audio Controller [Azalia] Use the Audio Controller Selection option to enable or disable the High Definition Audio CODEC. The onboard HD Audio is disabled Disabled Azalia The onboard HD Audio is enabled EFAULT 5.8 Exit...
Page 137 ® CyberResearch Panel PCs STE 1xGTx Series Discard Changes and Exit Use the Discard Changes and Exit option to exit the BIOS configuration setup program without saving the changes made to the system. Discard Changes Use the Discard Changes option to discard the changes and remain in the BIOS configuration setup program.
Page 139: Available Software Drivers
Audio Driver Installation instructions are given below. 6.2 DVD Driver Auto-run All the drivers for the STE 1xGTx Series are on the installation DVD that came with the system. To install the drivers, please follow the steps below. Important Note: The following steps must be repeated by the user for each driver installed. To avoid redundancy, ...
Page 140: Figure 6-1: Dvd Interface
® CyberResearch STE 1xGTx Series Panel PCs Figure 6-1: DVD Interface Step 3: Select “Panel PC/Monitor Drivers” as shown in Figure 6-1. Step 4: Select “STMxx/STExx Series” from the secondary menu options as shown in Figure 6-2. Figure 6-2: Select STExx Series Step 5: A tertiary menu appears;...
Page 141: Audio Driver Installation
® CyberResearch Panel PCs STE 1xGTx Series Figure 6-3: Select STE GTx Series Step 6: The list of available drivers appears as shown below. Figure 6-4: Available Drivers Step 7: Read subsequent sections in this chapter for installation procedure of each driver.
Page 142: Figure 6-5: Select Audio Drivers
® CyberResearch STE 1xGTx Series Panel PCs If you are unsure how to arrive at the Figure below, see section 6.2 DVD Driver Auto‐run before completing next steps. To install the Audio drivers, please follow the steps below: Step 1: Choose A from the menu as shown below. UDIO RIVERS Figure 6-5: Select Audio Drivers Step 2: Select A as shown in Figure 6-6 below.
Page 143: Figure 6-7: Audio Driver Installation
® CyberResearch Panel PCs STE 1xGTx Series Step 3: The audio setup window appears as shown below. Figure 6-7: Audio Driver Installation Step 4: Click N to start the driver installation as shown above. Step 5: The audio driver installation begins.
Page 144: Figure 6-8: Windows Logo Testing
® CyberResearch STE 1xGTx Series Panel PCs Figure 6-8: Windows Logo Testing Step 7: The confirmation screen offers the option of restarting the computer now or later. For the settings to take effect, the computer must be restarted. Click F INISH restart the computer.
Page 145: Chipset Driver
® CyberResearch Panel PCs STE 1xGTx Series 6.4 Chipset Driver To install the Chipset driver, please follow the steps below. Note: If you are unsure how to arrive at the Figure below, see section 6.2 DVD Driver Auto‐run before completing next steps. To install the Chipset drivers, please follow the steps below: Step 1: Choose C from the menu as shown below.
Page 146: Figure 6-11: Chipset Driver Installation Welcome Screen
® CyberResearch STE 1xGTx Series Panel PCs Figure 6-11: Chipset Driver Installation Welcome Screen Step 3: Click N to continue the installation process. Step 4: The license agreement in Figure 6-12 appears. Figure 6-12: Chipset Driver Installation License Agreement ©Copyright 2011 CyberResearch, Inc.
Page 147: Figure 6-13: Chipset Driver Readme File Information
® CyberResearch Panel PCs STE 1xGTx Series Step 5: Read the license agreement. To accept the terms and conditions stipulated in the agreement, click YES. Step 6: The Readme file in Figure 6-13 appears. Figure 6-13: Chipset Driver Readme File Information...
Page 148: Figure 6-14: Chipset Driver Installation Complete
® CyberResearch STE 1xGTx Series Panel PCs Figure 6-14: Chipset Driver Installation Complete Step 9: After the driver installation process is complete click N to continue. Step 10: The Setup is Complete windows appears (Figure 6-15). Figure 6-15: Chipset Driver Installation Complete...
Page 149: Video Driver
® CyberResearch Panel PCs STE 1xGTx Series The computer must be restarted for changes to take effect. Select “Yes, I want to restart this computer now,” to restart the computer when finished, or “No, I will restart this computer later,” to manually restart the computer later. Click F...
Page 150: Figure 6-17: Vga Driver
® CyberResearch STE 1xGTx Series Panel PCs Figure 6-17: VGA Driver Step 3: Click N to continue the driver installation process (Figure 6-17). Step 4: The driver welcome screen appears (Figure 6-18). Figure 6-18: Graphics Driver Installation Step 5: Click N to continue the driver installation (Figure 6-18).
Page 151: Figure 6-19: Graphics Driver License Agreement
® CyberResearch Panel PCs STE 1xGTx Series Figure 6-19: Graphics Driver License Agreement Step 7: Read the license agreement carefully. Click Y to accept the terms of the license agreement and continue installation. Step 8: A new window appears with details of the drivers to be installed (Figure 6-20).
Page 152: Figure 6-21: Graphics Driver Installation Notice
® CyberResearch STE 1xGTx Series Panel PCs Step 10: The driver installation progress window appears and shows details for each of the drivers as they are installed (Figure 6-21). Figure 6-21: Graphics Driver Installation Notice ©Copyright 2011 CyberResearch, Inc.
Page 153: Gigabit Ethernet Driver Installation
® CyberResearch Panel PCs STE 1xGTx Series Step 11: The confirmation screen offers the option of restarting the computer now or later. For the settings to take effect, the computer must be restarted. Click F INISH restart the computer. Figure 6-22: Graphics Driver Installation Complete Step 0: 6.6 Gigabit Ethernet Driver Installation...
Page 154: Figure 6-23: Select Network Drivers
® CyberResearch STE 1xGTx Series Panel PCs Figure 6-23: Select Network Drivers Step 2: When the screen below appears, click A INDOWS Figure 6-24: Select All Windows Step 3: The Setup screen appears and prepares the InstallShield Wizard for the installation sequence.
Page 155: Figure 6-25: Setup Screen
® CyberResearch Panel PCs STE 1xGTx Series Figure 6-25: Setup Screen Step 4: Click N as shown below. Figure 6-26: Select Next t Step 5: Click I to begin the installation as shown in Figure 6-27, NSTALL CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000;...
Page 156: Figure 6-27: Select Install
® CyberResearch STE 1xGTx Series Panel PCs Figure 6-27: Select Install Step 6: The InstallShield Wizard begins driver installation as shown in Figure 6-28 Figure 6-28: Driver Installation Begins Step 7: When the InstallShield Wizard ends, click F as shown below to complete INISH the installation.
Page 157: Figure 6-29: Select Finish
® CyberResearch Panel PCs STE 1xGTx Series Figure 6-29: Select Finish CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000; F: (203) 643-5001 Branford, CT USA www.cyberresearch.com...
Page 159: System Maintenance Introduction
Motherboard DIMM module PSU module Cooling fans If these components fail, they must be replaced. Please contact CyberResearch, Inc to purchase replacement parts. Replacement instructions for the above listed components are described below. 7.2 Motherboard Replacement A user cannot replace a motherboard. If the motherboard fails it must be shipped back to CyberResearch, Inc.
Page 160: Dimm Replacement
® CyberResearch STE 1xGTx Series Panel PCs WARNING! Please take antistatic precautions when working with the internal components. The interior of the STE 1xGTx contains very sensitive electronic components. These components are easily damaged by electrostatic discharge (ESD). Before working with the internal components, make sure all anti-static precautions described earlier have been observed.
Page 161: Elevated Platform Removal
® CyberResearch Panel PCs STE 1xGTx Series Figure 7-1: DIMM Socket Clip Locations Step 3: Push the new DIMM module until it engages and the white plastic end clips click into place. Make sure the end clips are fully secured after installation.
Page 162: Figure 7-3: Side Panel Elevated Platform Screws
® CyberResearch STE 1xGTx Series Panel PCs Step 2: Unfasten the elevated platform screws on the side panel (Figure 7-3). Figure 7-3: Side Panel Elevated Platform Screws Step 3: Unfasten the elevated platform screws on the bottom panel (Figure 7-4).
Page 163: Psu Module Replacement
® CyberResearch Panel PCs STE 1xGTx Series Step 4: Unfasten the internal elevated platform screws (Figure 7-5). Figure 7-5: Internal Elevated Platform Screws Step 5: Slide the elevated platform out of the chassis. Step 0: 7.6 PSU Module Replacement Please read the warnings at the beginning of Section 4.3 before attempting to access any STE 1xGTx internal components.
Page 164: Figure 7-6: Psu Power Cables
® CyberResearch STE 1xGTx Series Panel PCs Step 3: Disconnect all PSU connections including those to the motherboard (Figure 7-6) and any disk drives. Figure 7-6: PSU Power Cables Step 4: Unfasten the screws on the inside panel (Figure 7-7).
Page 165: Install The New Psu
® CyberResearch Panel PCs STE 1xGTx Series Step 5: Remove the retention screws that connect the PSU bracket to the chassis (Figure 7-8). Figure 7-8: PSU Rear Panel Screws Step 6: Remove the retention screws that connect the PSU to the PSU bracket.Step 0:...
Page 166: System Cooling Fan Replacement
® CyberResearch STE 1xGTx Series Panel PCs 7.7 System Cooling Fan Replacement If the system cooling fans have been damaged, they must be replaced. To replace the system cooling fans, please follow the steps below. 7.7.1 Remove the Old System Cooling Fans Step 1: Remove the back cover (Section 4.4).
Page 167: Install The New System Cooling Fans
® CyberResearch Panel PCs STE 1xGTx Series Step 4: Remove the system cooling fans retention screws from the left panel (Figure 7-10). Figure 7-10: System Cooling Fans Left Panel Retention Screws Step 5: Remove the system cooling fans from the chassis.
Page 169 ® CyberResearch Panel PCs STE 1xGTx Series Below is a list of BIOS configuration options in the BIOS chapter. System Overview .........................69 System Time [xx:xx:xx] .......................70 System Date [xx/xx/xx] ......................70 Max CPUID Value Limit [Disabled] ..................72 Intel® SpeedStep® Technology [Enabled]................73 ATA/IDE Configurations [Enhanced] .................74...
Page 170 ® CyberResearch STE 1xGTx Series Panel PCs FAN x Mode Setting [Automatic Mode] ................88 Temperature Limit of OFF [025] ..................88 Temperature Limit of Start [025] ..................89 Temperature Limit of Full [080] ..................89 Fan Start PWM [070] ......................90 Slope PWM [4 PWM] ......................90 Power Supply Mode [ATX] ....................92...
Page 171 ® CyberResearch Panel PCs STE 1xGTx Series Boot From LAN Support [Disabled] ................108 Change Supervisor Password ..................113 Change User Password....................113 Memory Hole [Disabled] ....................115 Boot Display Device ......................116 Flat Panel Type [By Jumper].................... 116 PID Current Jumper Setting [1-1024x768x24] ..............116 Internal Graphics Mode Select [Enable, 8 MB] ..............
Page 173 ® CyberResearch Panel PCs STE 1xGTx Series AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface.
Page 174 ® CyberResearch STE 1xGTx Series Panel PCs Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory. DIMM Dual Inline Memory Modules are a type of RAM that offer a 64-bit data bus and have separate electrical contacts on each side of the module.
Page 175 ® CyberResearch Panel PCs STE 1xGTx Series Liquid crystal display (LCD) is a flat, low-power display device that consists of two polarizing plates with a liquid crystal panel in between. LVDS Low-voltage differential signaling (LVDS) is a dual-wire, high-speed differential electrical signaling system commonly used to connect LCD displays to a computer.
Page 177: Introduction
® CyberResearch Panel PCs STE 1xGTx Series C.1 Introduction The DIO connector on the STE 1xGTx is interfaced to GPIO ports on the Super I/O chipset. The DIO has both 4-bit digital inputs and 4-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices.
Page 178: Assembly Language Samples
® CyberResearch STE 1xGTx Series Panel PCs C.3 Assembly Language Samples C.3.1 Enable the DIO Input Function The BIOS interrupt call INT 15H controls the digital I/O. An assembly program to enable digital I/O input functions is listed below. AX, 6F08H...
Page 179: D Watchdog Timer
® CyberResearch Panel PCs STE 1xGTx Series Appendix Watchdog Timer CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000; F: (203) 643-5001 Branford, CT USA www.cyberresearch.com...
Page 180 ® CyberResearch STE 1xGTx Series Panel PCs NOTE: following discussion applies environment. Visit www.cyberresearch.com for the latest Windows drivers. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMIs or a software bug.
Page 181: Example Program
® CyberResearch Panel PCs STE 1xGTx Series NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. EXAMPLE PROGRAM: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds...
Page 183: Direct Memory Access (Dma)
® CyberResearch Panel PCs STE 1xGTx Series E.1 Direct Memory Access (DMA) Figure E-1: Direct Memory Access (DMA) CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000; F: (203) 643-5001 Branford, CT USA www.cyberresearch.com...
Page 185 ® CyberResearch Panel PCs STE 1xGTx Series Figure E-3: Input/Output (IO) (2 of 2) CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000; F: (203) 643-5001 Branford, CT USA www.cyberresearch.com...
Page 187: Memory
® CyberResearch Panel PCs STE 1xGTx Series E.4 Memory Figure E-5: Memory CyberResearch, Inc. 25 Business Park Drive P: (203) 643-5000; F: (203) 643-5001 Branford, CT USA www.cyberresearch.com...
Page 189: Compatible Operating Systems
® CyberResearch Panel PCs STE 1xGTx Series NOTE: The compatible items described here have been tested and were found to be compatible with the STE 1xGTx F.1 Compatible Operating Systems The following operating systems have been successfully run on the STE 1xGTx.
Page 191 ® CyberResearch Panel PCs STE 1xGTx Series DIMM Replacement ........ 142 Drivers Audio ..........123 ACPI ............93 Broadcom GbE LAN ......135 anti-static precautions........34 ® Intel Chipset ........127 anti-static pad ........34 anti-static wristband.......34 handling ..........34 self-grounding........34 electrostatic discharge .......34 Applications ..........3...
Page 192 ® CyberResearch STE 1xGTx Series Panel PCs ...............47 Safety Precautions........171 SATA LCD Panel Connection ......64 controller..........27 LCD Voltage Setup ......42, 46 Serial Port Connection.......65 SiS964 .............117 Southbridge..........23 Specifications ..........10 Model Variation ..........2 System Specifications........10 Motherboard Replacement ......141 system voltages ........87, 91 Motherboard Specifications .......12...
Page 193: Product Service
Signal connections and programming are the two most common sources of difficulty. CyberResearch support personnel can help you solve these problems, especially if you are prepared for the call.
Page 195 CyberResearch, Inc. will, at its option, repair or replace the defective item under the terms of this warranty, subject to the provisions and specific exclusions listed herein.
Page 198 CyberResearch, Inc. 25 Business Park Drive Branford, CT 06405 USA P: (203) 643-5000; F: (203) 643-5001 www.cyberresearch.com...

CyberResearch STE 1xGTx Series User Manual

1 Introduction

Figure 1-1: STE 1Xgtx

Table 1-1: STE 1Xgtx Model Variation

Figure 1-2: Front View

Figure 1-3: STE 1Xgtx Rear View

Figure 1-4: STE 1Xgtx Top View

2 Specifications

Figure 2-5: SO-DIMM Socket

Figure 2-7: SATA Hard Drive Slot

Figure 2-8: Expansion Card Slot

Figure 2-6: Compactflash® Slot

Figure 2-9: USB Ports

Figure 2-10: Serial Ports

Figure 2-11: Parallel Port

Figure 2-12: Ethernet

3 Unpacking

Table 3-1: Package List Contents

4 Installation and Configuration

Figure 4-1: Back Cover Retention Screws

Cyberresearch, Inc

Table 4-1: Onboard Jumpers

Table 4-3: Clear CMOS Jumper Settings

Table 4-2: AT/ATX Power Selection

Table 4-5: Monitor Settings

Table 4-6: CF Card Setup Jumper Settings

Table 4-4: LCD Resolution Settings

Table 4-9: COM3 RI and Voltage Selection Jumper

Table 4-11: COM5 RI and Voltage Selection Jumper

Table 4-7: COM1 RI and Voltage Selection Jumper

Figure 4-17: Secure the Chassis

Figure 4-13: Optical Drive SATA Cable

Figure 4-14: Optical Drive Bracket Screws

5 Bios Setup

Table 5-1: BIOS Navigation Keys

BIOS Menu 1: Main

BIOS Menu 2: Advanced

BIOS Menu 3: CPU Configuration

BIOS Menu 4: IDE Configuration

BIOS Menu 5: IDE Master and IDE Slave Configuration

BIOS Menu 6: IDE Master and IDE Slave Configuration

BIOS Menu 7: Super IO Configuration

BIOS Menu 8: Hardware Health Configuration

BIOS Menu 9: ACPI Configuration

BIOS Menu 10: ACPI Configuration

BIOS Menu 11:Advanced Power Management Configuration

BIOS Menu 12: Remote Access Configuration [Advanced]

BIOS Menu 13: USB Configuration

BIOS Menu 14: USB Mass Storage Device Configuration

BIOS Menu 15: Pci/Pnp Configuration

BIOS Menu 16: Boot

BIOS Menu 17: Boot Settings Configuration

BIOS Menu 18: Boot Device Priority Settings

BIOS Menu 19: Hard Disk Drives

BIOS Menu 20: CD/DVD Drives

BIOS Menu 21: Security

BIOS Menu 22: Chipset

BIOS Menu 23:Northbridge Chipset Configuration

BIOS Menu 24:Southbridge Chipset Configuration

BIOS Menu 25:Exit

6 Software Installation

Figure 6-2: Select Stexx Series

Figure 6-1: DVD Interface

Figure 6-4: Available Drivers

Figure 6-12: Chipset Driver Installation License Agreement

Figure 6-11: Chipset Driver Installation Welcome Screen

Figure 6-13: Chipset Driver Readme File Information

Figure 6-14: Chipset Driver Installation Complete

Figure 6-15: Chipset Driver Installation Complete

Figure 6-3: Select STE Gtx Series

Figure 6-6: Select All Windows

Figure 6-5: Select Audio Drivers

Figure 6-7: Audio Driver Installation

Figure 6-8: Windows Logo Testing

Figure 6-9: Installshield Wizard Complete

Figure 6-22: Graphics Driver Installation Complete

Figure 6-23: Select Network Drivers

Figure 6-24: Select All Windows

Figure 6-25: Setup Screen

Figure 6-26: Select Next T
