Summary of Contents for HD Communications HD29596
- Page 1 HD29596 PoE POWER OVER ETHERNET SWITCH USER’S MANUAL HD29596 User’s Manual PoE Series Version V1.1 Page 1 of 8...
-
Page 2: Table Of Contents
CONTENTS Chapter 1: System Overview 1.1 Features and functions ..............page 3 1.2 Technical features and specifications ..........page 4 Chapter 2: Electrical Connection and Structure 2.1 The structure and outline picture ............ page 5 Chapter 3: Installation and Debugging 3.1 Open Case Inspection .............. -
Page 3: Chapter 1: System Overview
Chapter 1: System Overview 1.1: Features and Functions HD29596 PoE is designed specifically for the device implemented advanced MCU control technology and it has efficient protection of each port. It is used with wireless access points (AP’s), IP cameras, VoIP, and other devices that require network and power supplies. -
Page 4: Technical Features And Specifications
1.2: Technical Features and Specifications Technical Specifications IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE standard IEEE 802.3x Flow Control and Back Pressure IEEE 802.3af Power Over Ethernet IEEE 802.3at Power Over Ethernet Back-plane (switch): 1.0Gpbs Switching structure Transfer Rate: 14,880pps for Ethernet port 148,800pps for fast Ethernet port Ethernet: 10Mbps half duplex, 20Mbps full duplex... -
Page 5: Chapter 2: Electrical Connection And Structure
71.4mm 2.81 inches Weight <0.5kg 1.1 lbs HD29596 PoE Protect Function: Range of output over-voltage protection: 52VDC Over current protection: (single channel): 750mA Over voltage protection: Input voltage is over 260VAC Over voltage recovery point: Input voltage is below 255VAC... - Page 6 Ethernet Port Lights Instructions: H29596 PoE LED Description Indicator Color State Indicator Light signification Light Power Green Normal power supply for device No power supply for the device The device with problem of any Alarm Flashing port or power overload Normal status Link/Act Green...
-
Page 7: Chapter 3: Installation And Debugging
Chapter 3: Installation and Debugging 3.1 Open case inspection Package contains: • PoE device • User’s manual • An input power cable • 48V power adaptor 3.2 Installation 1. Power cord to be plugged into 110 VAC input socket. 2. Connect network cable to ports as needed. ... -
Page 8: Chapter 4: Routine Maintenance
5.2: Storage HD29596 PoE should be stored in a dry environment with no direct sunlight. Storage period is one year. Storage temperature: -20°C ~ +70°C (the restoration time from low temperature is at least 4 hours).
