Summary of Contents for Exterior NVR21 Series

  • Page 1 Network Video Recorder User’s Manual V 3.5.0...

  • Page 2: Table Of Contents

    Table of Contents Features and Specifications .......................1 Overview ............................1 Features ............................1 Specifications ..........................2 NVR21/21-P/21-S Series .....................2 1.3.1 1.3.2 NVR21H Series ........................4 NVR22 Series ........................5 1.3.3 NVR24 Series ........................7 1.3.4 1.3.5 NVR31H Series ........................8 NVR31/31-W/31-S/31-P Series ..................10 1.3.6 NVR32/32-P/32-8P Series ....................11 1.3.7 1.3.8 NVR32V/32V-P Series......................13...
  • Page 3 NVR32 Series ........................45 2.2.6 NVR32-P/32-8P Series .......................46 2.2.7 2.2.8 NVR32V/32V-P Series ......................48 NVR34V/34V-P Series ......................51 2.2.9 NVR38 Series ........................53 2.2.10 2.2.11 NVR50 Series ........................55 NVR52 Series ........................57 2.2.12 NVR52-P Series ........................58 2.2.13 2.2.14 NVR54/54-8P/54-16P ......................60 NVR58 Series ........................63 2.2.15 Alarm Connection ........................64 2.3.1 Alarm Port ..........................65 Alarm input port ........................65...
  • Page 4 5.3.1 Remote Device Connection ....................79 5.3.2 Short-Cut Menu ........................82 5.3.3 UPNP ............................83 5.3.4 Built-in Switch Setup ......................83 Preview ............................83 5.4.1 Preview Interface .........................84 5.4.2 Preview Control ........................84 5.4.3 Right Click Menu .........................86 5.4.4 Preview Display Effect Setup ....................86 5.4.4.1 Video Color ........................86 5.4.4.2 Display .........................86 5.4.5...
  • Page 5 5.6.7 Holiday Record/Snapshot ....................101 5.6.7.1 Holiday Record ......................101 5.6.7.2 Holiday Snapshot .....................102 5.6.8 Other Record/Snapshot ....................102 Playback and Search .......................102 Real-time Playback ......................102 5.7.1 5.7.2 Search Interface ........................102 Accurate playback by time ....................106 5.7.3 Smart Search ........................107 5.7.4 5.7.5 Picture Playback ........................108 Backup ............................108 5.8.1 File Backup .........................108...
  • Page 6 5.10.3.2 Network Load ......................140 5.11 HDD Setup ..........................141 5.11.1 Format ..........................141 HDD Information ........................141 5.11.2 HDD Management ......................143 5.11.3 5.11.4 eSATA..........................145 5.12 Basic Setups ..........................146 5.12.1 General ..........................146 Device Setup ........................147 5.12.2 Other Setups ........................147 5.12.3 5.13 Device Maintenance and Manager ..................148 System Info.........................148 5.13.1 5.13.1.1...
  • Page 7 7.5.1 Image ..........................165 Alarm output ........................165 7.5.2 WAN Login ..........................166 Playback ............................167 Alarm ............................171 Setup ............................172 Remote ..........................172 7.9.1 7.9.1.1 Add Device ........................172 7.9.1.2 Conditions ........................174 7.9.1.3 Video/Audio .......................176 7.9.1.3.1 Encode........................176 7.9.1.3.2 Snapshot ........................177 7.9.1.3.3 Video Overlay ......................178 7.9.1.3.4 Path ...........................179 7.9.1.4 Channel Name ......................179 7.9.1.5...
  • Page 8 7.9.3.1.3 Tampering .........................202 7.9.3.2 Alarm ..........................203 7.9.3.2.1 Local Alarm ......................203 7.9.3.2.2 Net Alarm ........................205 7.9.3.2.3 IPC external alarm ....................206 7.9.3.2.4 IPC Offline Alarm .....................207 7.9.3.3 Abnormality .......................207 Storage ..........................209 7.9.4 7.9.4.1 Schedule ........................209 7.9.4.2 HDD Manager ......................211 7.9.4.2.1 Local Storage ......................211 7.9.4.2.2 HDD ..........................
  • Page 9 FAQ ..............................229 Glossary.............................234 Appendix A HDD Capacity Calculation ..................235 Appendix B Compatible Network Camera ................236 Appendix C Compatible Backup Device List ................240 Appendix D Compatible CD/DVD ....................248 Appendix E Compatible Displayer List ..................249 Appendix F Toxic or Hazardous Materials or Elements ............250 viii...
  • Page 10 Welcome Thank you for purchasing our network video recorder! This user’s manual is designed to be a reference tool for your system. Please open the accessory bag to check the items one by one in accordance with the list below. Contact your local retailer ASAP if something is missing or damaged in the bag.

  • Page 11: Installation Environment

    Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.
  • Page 12  Accessories Check the following accessories after opening the box：  Please refer to the packing list in the box *...

  • Page 13: Features And Specifications

    1 Features and Specifications 1.1 Overview This series NVR is a high performance network video recorder. This series product support local preview, multiple-window display, recorded file local storage, remote control and mouse shortcut menu operation, and remote management and control function. This series product supports centre storage, front-end storage and client-end storage.

  • Page 14: Specifications

     Through network, sending audio/video data compressed by IPC or NVS to client-ends, then the data will be decompressed and display. If bandwidth is big enough, latency is less than 500ms  Network Support max 20 connections at the same time. ...
  • Page 15 Video H.264/MJPEG Compression Encode For H.264, it max supports 8-channel D1, 4-channel 720P, 2-channel 1080P. Capacity Audio G.711a Compression Video Output 1-channel VGA analog video output. Video Input 4/8-ch network video input HDMI 1-ch HDMI output. HDMI version is 1.3. Audio Input Audio Output Window Split...

  • Page 16: Nvr21H Series

    10℅－90℅ Working Humidity Air pressure 86kpa－106kpa Dimension 205mm×205mm×52mm Weight 0.5~1KG（Exclude HDD） Installation Desk installation 1.3.2 NVR21H Series Parameter Specifications 210XH Series 210XH-P Series System Max support 8-ch standard definition with the transmission rate of 2Mbps for each Resources channel; 4-channel 720P, with the transmission rate of 4Mbps for each channel; 2-channel 1080P, with the transmission rate of 8Mbps for each channel;...

  • Page 17: Nvr22 Series

    RS485 port USB2.0 Port 2 peripheral USB2.0 ports. One at the front panel and one at the rear panel. Network RJ45 10/100Mbps self-adaptive 4 PoE ports. Built-in Switch. Support PoE Connection Ethernet port. function. Power Port One power port, power adapter. Input DC Two power ports, power adapter.
  • Page 18 Video H.264/MJPEG Compression Encode It max supports 16-channel D1, 8-channel 720P, 4-channel 1080P. Capacity Audio G.711a Compression Video Output 1-channel VGA analog video output. Video Input 4/8/16-ch network compression video input HDMI 1-ch HDMI output. HDMI version is 1.3. Audio Input Audio Output Window Split 4/8/9/16-window...

  • Page 19: Nvr24 Series

    ＜12W(Exclude HDD) Power Consumption ﹣10℃～﹢55℃ Working Temperature 10℅－90℅ Working Humidity Air pressure 86kpa－106kpa Dimension 375mm×287mm×52mm Weight 1.5~2.5KG（Exclude HDD） Installation Desk installation 1.3.4 NVR24 Series Parameter Specifications 2408 Series 2416 Series System Max support 16-ch standard definition with the transmission rate of 2Mbps for each Resources channel;...

  • Page 20: Nvr31H Series

    Relay output. Relay （DC 30V 1A，AC 125V 0.5A（Activation output） ） Including one controllable DC +12V output. Storage 4 built-in SATA ports. 1 eSATA port. RS232 Port One RS232 port to debug transparent COM data. (RS-422) RS485 port One RS485 A/B port to control PTZ. Support various protocols. (Rs-485) USB2.0 Port 2 peripheral USB2.0 ports.
  • Page 21 The image delay time of each channel is under 500ms. Operation Embedded Linux real-time operation system System Operation WEB/Local GUI Interface Video H.264/MJPEG Compression Encode For H.264, it max supports 8-channel D1, 4-channel 720P, 2-channel 1080P. Capacity Audio G.711a Compression Video Output 1-channel VGA analog video output.

  • Page 22: Nvr31/31-W/31-S/31-P Series

    ＜12W(Exclude HDD) Power Consumption ﹣10℃～﹢55℃ Working Temperature 10℅－90℅ Working Humidity Air pressure 86kpa－106kpa Dimension 325mm×242mm×55mm Weight 1.25KG（Exclude HDD） Installation Desk installation 1.3.6 NVR31/31-W/31-S/31-P Series Specifications Parameter 31 Series 31-W Series 31-S Series 31-P Series Max support 16-ch standard definition with the transmission rate of 2Mbps for each channel;...

  • Page 23: Nvr32/32-P/32-8P Series

    Alarm Output Storage One built-in SATA port. RS232 Port RS485 port USB2.0 Port One peripheral USB2.0 port. Network One RJ45 10/100Mbps self-adaptive Ethernet port. Connection One power port, power adapter. Input DC 12V. Two power ports, power adapter. Power Port Input DC 12V or DC 48V.
  • Page 24 Operation Embedded Linux real-time operation system System Operation WEB/Local GUI Interface Video H.264/MPEG4 Compression Encode For H.264, it max supports 16-channel D1, 8-channel 720, 4-channel 1080P. Capacity Audio G.711a Compression Video Output 1-channel VGA analog video output. Video Input 4/8/16-ch network compression video input HDMI 1-ch HDMI output.

  • Page 25: Nvr32V/32V-P Series

    Clock Built-in clock.  16 record status indication lights  One power status indication light.  Indication Light One alarm status indication light.  One network status indication light.  One HDD status indication light. Power ＜12W(Exclude HDD) Consumption Working ﹣10℃～﹢55℃...

  • Page 26: Nvr34V/34V-P Series

    Multiple-chann Max 16-channel D1/8-channel 720P/4-channel 1080P playback. el Playback Alarm Input 4/8/16-ch series product support 4/8/16-ch alarm input respectively. 3-ch alarm output Alarm Output Relay output. Relay （DC 30V 1A，AC 125V 0.5A（Activation output） ） Including one controllable DC +12V output. 2 built-in SATA ports Storage 1 peripheral eSATA port...
  • Page 27 Operation Embedded Linux real-time operation system System Operation WEB/Local GUI Interface Video H.264/MPEG4 Compression Encode For H.264, it max supports 16-channel D1, 8-channel 720, 4-channel 1080P. Capacity Audio G.711a Compression Video Output 1-channel VGA analog video output. Video Input 4/8/16-ch network compression video input HDMI 1-ch HDMI output.

  • Page 28: Nvr38 Series

    Power ＜12W(Exclude HDD) Consumption Working ﹣10℃～﹢55℃ Temperature Working 10℅－90℅ Humidity Air pressure 86kpa－106kpa Dimension 157.5mm×220mm×172mm Weight 1.5～2.5KG（Exclude HDD） Installation Desk installation 1.3.10 NVR38 Series Specifications Parameter 38 Series Max support 16-ch standard definition with the transmission rate of 2Mbps for each channel;...

  • Page 29: Nvr50 Series

    6-ch alarm output Alarm Output Relay output. Relay （DC 30V 1A，AC 125V 0.5A（Activation output） ） Including one controllable DC +12V output. 8 built-in SATA ports Storage 1 peripheral eSATA port RS232 Port One RS232 port to debug transparent COM data. RS485 port One RS485 port to control PTZ.
  • Page 30 Support 20 online users at the same time, The image delay time of each channel is under 500ms. Operation Embedded Linux real-time operation system System Operation WEB/Local GUI Interface Video H.264/MPEG4 Compression Encode For H.264, it max supports 32*D1,16*720,8*1080P Capacity Audio G.711a Compression...

  • Page 31: Nvr52/52-P Series

     No record status indication light.  One system working disk indication light. Indication Light  One alarm status indication light.  One network status indication light. Power ＜40W(Exclude HDD) Consumption Working ﹣10℃～﹢55℃ Temperature Working 10℅－90℅ Humidity Air pressure 86kpa－106kpa Dimension 3U case: 448mm×490mm×133.2mm Weight...

  • Page 32: Nvr54/54-8P/54-16P Series

    Relay output. Relay （DC 30V 1A，AC 125V 0.5A（Activation output） ） Including one controllable DC +12V output. Storage 2 built-in SATA ports. RS232 Port One RS232 port to debug transparent COM data. (RS-422) RS485 port One RS485 port to control PTZ. Support various protocols. (RS-485) USB2.0 Port 2 peripheral USB2.0 ports.
  • Page 33 Operation Embedded Linux real-time operation system System Operation WEB/Local GUI Interface Video H.264/MPEG4 Compression Encode For H.264, it max supports 32-channel D1,16-channel 720P,8-channel 1080P Capacity Audio G.711a Compression Video Output 1-channel VGA analog video output. Video Input 8/16/32-ch network compression video input HDMI 1-ch HDMI output.

  • Page 34: Nvr58 Series

    Receiver Clock Built-in clock.  16 record status indication lights  Indication Light One system running status indication light.  One remote control button indication light. Power ＜40W(Exclude HDD) Consumption Working ﹣10℃～﹢55℃ Temperature Working 10℅－90℅ Humidity Air pressure 86kpa－106kpa Dimension 440mm ×...
  • Page 35 Multiple-chann Max 16-channel playback. el Playback Alarm Input 16-ch alarm input 6-ch alarm output Alarm Output Relay output. Relay （DC 30V 1A，AC 125V 0.5A（Activation output） ） Including one controllable DC +12V output. 8 built-in SATA ports. Storage 1 peripheral eSATA port RS232 Port One RS232 port to debug transparent COM data.

  • Page 36: Front Panel And Rear Panel

    2 Front Panel and Rear Panel 2.1 Front Panel 2.1.1 NVR21/21-P/21-S/31/31-W/31-P/31-S Series The NVR21/21-P/21-S front panel is shown as in Figure 2-1. Figure 2-1 The NVR31/31-W/31-P/31-S front panel is shown as in Figure 2-2. Figure 2-2 Please refer to the following sheet for detailed information. Icon Name Function...
  • Page 37 Figure 2-3 Please refer to the following sheet for detailed information. Name Icon Function Power button, press this button for three seconds to boot up Power button or shut down NVR. Activate current control, modify setup, and then move up and down.

  • Page 38: Nvr31H Series

    Network abnormal Network error occurs or there is no network connection, the light becomes red to alert you. indication light abnormal HDD error occurs or HDD capacity is below specified indication threshold value, the light becomes red to alert you. light It is to receive the signal from the remote control.

  • Page 39: Nvr32/32-P Series

    Go to menu Slow play Multiple slow play speeds or normal playback. One-window monitor mode, click this button to display assistant function: PTZ control and image color. Backspace function: in numeral control or text control, press it for 1.5seconds to delete the previous character before the cursor.
  • Page 40   Shift In textbox, click this button to switch between numeral, English (Small/Capitalized), donation and etc.  Enable or disable tour.  Fast play Various fast speeds and normal playback. Slow play Multiple slow play speeds or normal playback. ...

  • Page 41: Nvr50 Series

    Record Manually stop/start recording, working with direction keys or numeral keys to select the recording channel. Window switch Mult Click it to switch one-window/multiple-window. USB2.0 port To connect USB2.0 storage device, USB2.0 mouse, burner and etc. Record light 1-16 For 4/8/16 channel device: indication light on means that the channel is in recording.

  • Page 42: Nvr22/32-8P/52/52-P Series

    Network indication The network alarm indication light is blue when the light device Is offline or network is abnormal. USB2.0 port Connect to USB2.0 storage device,mouse, burner and etc. 16-HDD slots After you remove the front panel, you can see there are 16 HDDs. From the left to the right and from the top to the bottom, it ranges from 1~4, 5~8, 9~12, 13~16.

  • Page 43: Nvr24/54/54-8P/54-16P Series

    Left/2 Shift current activated control, move left or right. ,  Right/3 When playback, click these buttons to control playback bar. In normal playback click this button to start/pause playback.  Play/Pause /5 In normal playback or pause mode, click this button to Reverse/Pause ...
  • Page 44 The front panel is shown as in Figure 2-9. Figure 2-9 Please refer to the following sheet for front panel button information. Name Icon Function Power button, press this button for three seconds to boot up Power button or shut down NVR. In textbox, click this button to switch between numeral, Shift Shift...

  • Page 45: Nvr32V/32V-P Series

    In motion detection setup, working with Fn and direction keys to realize setup. In text mode, click it to switch between numeral, English character(small/capitalized) and etc. Realize other special functions. Various fast speeds and normal playback.  Fast play/7 In text mode, input number 7 (English character P/Q/R/S). ...
  • Page 46 Figure 2-10 Please refer to the following sheet for front panel button information. Name Icon Function Power button Power button, press this button for three seconds to boot up or shut down NVR.  One-window monitor mode, click this button to display assistant function: PTZ control and image color.

  • Page 47: Nvr34V/34V-P Series

    Network Network error occurs or there is no network connection, the light abnormal becomes red to alert you. indication light Alarm indicator The light becomes on when an alarm occurred. light 2.1.9 NVR34V/34V-P Series The front panel is shown as in Figure 2-11. Figure 2-11 Please refer to the following sheet for front panel button information.

  • Page 48: Nvr38/58 Series

     In HDD management interface, you can click it to switch HDD record information and other information (Menu prompt)  Realize other special functions. To connect USB2.0 storage device, USB2.0 mouse, burner and USB2.0 port etc. Power Power indication light. indication light HDD abnormal HDD error occurs or HDD capacity is below specified threshold...
  • Page 49  In normal playback click this button to pause playback  Play/Pause  In pause mode, click this button to resume playback.  In normal playback or pause mode, click this button to  reverse Reverse/Pause  playback  In reverse playback, click this button to pause playback. │...

  • Page 50: Rear Panel

    If there is Fn indication light, current status indication light is null. light Power indication Power indication light light 2.2 Rear Panel 2.2.1 NVR21/21-P/21-S Series The NVR21 series rear panel is shown as below. See Figure 2-13. Figure 2-13 The NVR21-P series rear panel is shown as below. See Figure 2-14.
  • Page 51 Figure 2-14 The NVR21-S series rear panel is shown as below. See Figure 2-15. Figure 2-15 Please refer to the following sheet for detailed information. Port Name Function 10M/100Mbps self-adaptive Ethernet port. Connect Network port to the network cable. High definition audio and video signal output port. It transmits uncompressed high definition video and High Definition multiple-channel data to the HDMI port of the...

  • Page 52: Nvr21H/21H-P/31H/31H-P Series

    2.2.2 NVR21H/21H-P/31H/31H-P Series The NVR210XH/310XH series rear panel is shown as below. See Figure 2-16. Figure 2-16 The NVR210XH-P/310XH-P series rear panel is shown as below. See Figure 2-17. Figure 2-17 Please refer to the following sheet for detailed information. Port Name Function Power input port...

  • Page 53: Nvr22 Series

    Port Name Function  Alarm input port. Alarm input port  When your alarm input device is using external 1～2 power, please make sure the device and the NVR have the same ground. Alarm input port Alarm input ground end. ground end ...

  • Page 54: Nvr24 Series

    Port Name Function communication RS485_B.It is the cable B. You can connect to the control devices such as speed dome port PTZ. Power input Input DC 12V/4A. port Power button Power on/off button. Alarm input ground end. 2.2.4 NVR24 Series The NVR24 series rear panel is shown as below.

  • Page 55: Nvr31/31-W /31-P/31-S Series

    Icon Port Name Function Power button Power on/off button. Alarm input port Alarm input ground end. ground end  There are two groups. The first group is from port 1 to port 4; the second group is from port 5 to port 8. They are to receive the signal from the external alarm source.
  • Page 56 Figure 2-21 The NVR31-P series rear panel is shown as below. See Figure 2-22. Figure 2-22 The NVR31-S series rear panel is shown as below. See Figure 2-23. Figure 2-23 Please refer to the following sheet for detailed information. Port Name Function Network port 10M/100Mbps...

  • Page 57: Nvr32 Series

    Port Name Function HDMI High Definition High definition audio and video signal output Media port. It transmits uncompressed high definition Interface video and multiple-channel data to the HDMI port of the display device. HDMI version is 1.4. video VGA video output port. Output analog video output port signal.

  • Page 58: Nvr32-P/32-8P Series

    Port Name Function HDMI High Definition Media High definition audio and video signal Interface output port. It transmits uncompressed high definition video and multiple-channel data to the HDMI port of the display device. HDMI version is 1.4. VGA video output port VGA video output port.
  • Page 59 Figure 2-25 The rear panel of the NVR32-8P series is shown as below. See Figure 2-26. Figure 2-26 Please refer to the following sheet for detailed information. Port Name Function USB2.0 port. Connect to USB2.0 mouse. Network port 10M/100M/1000Mbps self-adaptive Ethernet port.

  • Page 60: Nvr32V/32V-P Series

    Port Name Function NO1 to NO3 3-ch alarm 3 groups of alarm output ports. (Group 1：  output port port NO1～C1,Group 2:port NO2～ C2,Group 3:port NO3～C3）).Output C1 to C3 alarm signal to the alarm device. Please make sure there is power to the external alarm device.
  • Page 61 Figure 2-27 The NVR32V-P rear panel is shown as below. See Figure 2-28. Figure 2-28 Please refer to the following sheet for detailed information.
  • Page 62 Port Name Function USB2.0 USB2.0 port. Connect to USB2.0 mouse. Network port 10M/100M/1000Mbps self-adaptive Ethernet port. Connect to the network cable. HDMI High Definition High definition audio and video signal output Media port. It transmits uncompressed high Interface definition video and multiple-channel data to the HDMI port of the display device.

  • Page 63: Nvr34V/34V-P Series

    Port Name Function Power input Switch power port. Input DC 48V/1.0.4A. port Please note the 32V series product does not have this port. MIC IN Audio input Bidirectional talk input port. It is to receive the port analog audio signal output from the devices such as mike phone, pickup.
  • Page 64 Figure 2-30 Please refer to the following sheet for detailed information. Port Name Function USB2.0 USB2.0 port. Connect to USB2.0 mouse. Network port 10M/100M/1000Mbps self-adaptive Ethernet port. Connect to the network cable. HDMI High Definition High definition audio and video signal output Media port.

  • Page 65: Nvr38 Series

    Port Name Function there is power to the external alarm device. NO：Normal open alarm output port.  C：Alarm output public end.  RS485 RS485_A port. It is the cable A. You can (RS-485) connect to the control devices such as speed communication dome PTZ.
  • Page 66 Port Name Function Power button Power on/off button. Power input Input AC 220V power. port MIC IN Audio input Bidirectional talk input port. It is to receive the port analog audio signal output from the devices such as mike phone, pickup. MIC OUT Audio output Audio output port.

  • Page 67: Nvr50 Series

    Port Name Function CTRL 12V Controller 12V power output. It is to control the on-off alarm relay output. It can be used to control the device alarm output. At the same time, it can also be used as the power input source of some devices such as the alarm detector.
  • Page 68 Port Name Function MIC IN Audio input port Bidirectional talk input port. It is to receive the analog audio signal output from the devices such as mike phone, pickup. MIC OUT Audio output port Audio output port. It is to output the analog audio signal to the devices such as the sound box.

  • Page 69: Nvr52 Series

    Port Name Function eSATA eSATA port External SATA port. It can connect to the device of the SATA port. Please jump the HDD when there is peripheral connected HDD. USB2.0 port Connect to USB mouse. RS232 RS232 debug It is for general COM debug to configure IP （RS-422）...

  • Page 70: Nvr52-P Series

    Port Name Function  There are two groups. The first group is Alarm input port 1-8. from port 1 to port 4; the second group is from port 5 to port 8. They are to receive the signal from the external alarm source.
  • Page 71 Figure 2-34 Please refer to the following sheet for detailed information. Port Name Function USB2.0 USB2.0 port. Connect to USB2.0 mouse. Network port 10M/100M/1000Mbps self-adaptive Ethernet port. Connect to the network cable. RS232 RS232 debug It is for general COM debug to configure IP COM.

  • Page 72: Nvr54/54-8P/54-16P

    Port Name Function RS485 RS485_A port. It is the cable A. You can (RS-485) connect to the control devices such as speed communication dome PTZ. port RS485_B.It is the cable B. You can connect to the control devices such as speed dome PTZ.
  • Page 73 Figure 2-36 The NVR54-16P series rear panel is shown as below. See Figure 2-37. Figure 2-37 Please refer to the following sheet for detailed information. Icon Port Name Function Power on-off button Power on-off button Power input port Input AC 220V. Built-in Switch supports PoE function.
  • Page 74 Icon Port Name Function  There are four groups. The first group is from 1～16 Alarm input port port 1 to port 4, the second group is from port 1～16 5 to port 8, the third group is from 9 to 12, and the fourth group is from 13 to 16.

  • Page 75: Nvr58 Series

    Icon Port Name Function USB2.0 port. Connect to USB2.0 storage device , mouse, burner and etc.. RS232 （RS-422） RS232 debug It is for general COM debug to configure IP COM. address or transfer transparent COM data. VGA video output port. Output analog video video signal.

  • Page 76: Alarm Connection

    Port Name Function NO1 to NO5 5-ch alarm 5 groups of alarm output ports. (Group 1：  output port port NO1～C1,Group 2:port NO2～ C2,Group 3:port NO3～C3, Group 4： port C1 to C5 NO4～C4, Group 5: port NO5, C5, NC5).Output alarm signal to the alarm device.

  • Page 77: Alarm Port

    2.3.1 Alarm Port The alarm port is shown as below. See Figure 2-39. The following figure is based on the NVR38 series. Figure 2-39 Icon Function 1～16 ALARM1～ALARM16. The alarm becomes activated in the low level. NO1 C1， NO2 C2， NO3 C3， NO4 Four NO activation output groups.

  • Page 78: Alarm Input And Output Port

    Figure 2-40 Note  There are two alarm input types: NO/NC.  When connect the ground port of the alarm device to the NVR, you can use any of the GND ports (  Connect the NC port of the alarm device to the alarm input port (ALARM) of the NVR. ...

  • Page 79: Bidirectional Talk

    Between touches with different 1000VAC 1minute polarity Between touch and winding 1000VAC 1minute Between touches with same Surge voltage 1500V (10×160us) polarity Length of open 3ms max time Length of close 3ms max time Longevity Mechanical 50×106 (3Hz) Electrical 200×103 (0.5Hz) Temperature -40℃...

  • Page 80: Mouse Operation

    Connect the speaker or the pickup to the audio output port in the PC and then connect the earphone or the sound box to the first audio input port in the device rear panel. Login the Web and then enable the corresponding channel real-time monitor. Please refer to the above interface (Figure 2-41) to enable bidirectional talk.
  • Page 81 Double left Implement special control operation such as double click one item in the file list click mouse to playback the video. In multiple-window mode, double left click one channel to view in full-window. Double left click current video again to go back to previous multiple-window mode.

  • Page 82: Hdd Installation

    3 HDD Installation Important： Please turn off the power before you replace the HDD. The pictures listed below for reference only. For the first time install, please be aware that whether the HDDs have been installed. You can refer to the Appendix for recommended HDD brand. Please use HDD of 7200rpm or higher.

  • Page 83: Nvr22/32/32-P/32-8P/52/52-P Series

    3.2 NVR22/32/32-P/32-8P/52/52-P Series 1. Loosen the screws of the 2. Fix four screws in the HDD 3. Place the HDD in accordance with upper cover and side panel. (Turn just three rounds). the four holes in the bottom. 4. Turn the device upside down 6.

  • Page 84: Nvr50 Series

    ③Pull the HDD knob up when you put the HDD ④Put the knob back after you insert the HDD to the SATA board. into the box in case the knob buckle may strike the front panel. 3.4 NVR50 Series ① Use four screws to secure the HDD. ②...

  • Page 85: Nvr24/38 /54/58 Series

    3.5 NVR24/38 /54/58 Series ① Use the screwdriver to loose the screws of the rear panel and then remove the front cover. ② Put the HDD to the HDD bracket in the chassis and then line up the four screws to the four holes in the HDD.

  • Page 86: Network Connection

    4 Network Connection Please refer to Figure 4-1 for connection sample. The following figure is based on the NVR38 series product. Figure 4-1...

  • Page 87: Local Basic Operation

    5 Local Basic Operation 5.1 Boot up and Shutdown 5.1.1 Boot up Before the boot up, please make sure:  The rated input voltage matches the device power on-off button. Please make sure the power wire connection is OK. Then click the power on-off button. ...
  • Page 88 Figure 5-1 Click Cancel button or Next Step button, system goes to login interface. See Figure 5-2. System consists of four accounts:  Username: admin. Password: admin. (administrator, local and network)  Username: 888888. Password: 888888. (administrator, local only)  Username: 666666.
  • Page 89 Figure 5-3 Click Next button, you can go to network interface. See Figure 5-4 For detailed information, please refer to chapter 5.10.2. Figure 5-4 Click Next button, you can go to remote device interface. See Figure 5-5 For detailed information, please refer to chapter 5.3.
  • Page 90 Figure 5-5 Click Next button, you can go to Schedule interface. See Figure 5-6. For detailed information, please refer to chapter 5.6.2. Figure 5-6 Click Finish button, system pops up a dialogue box. Click the OK button, the startup wizard is complete.

  • Page 91: Remote Device

    Figure 5-7 5.3 Remote Device 5.3.1 Remote Device Connection From Mani menu->Remote device or right click mouse on the preview interface and then select remote device item, you can see the following interface. See Figure 5-8. Figure 5-8 Click IP search button, you can view the searched IP addresses at the top pane of the interface. Double click an IP address or check one IP address and then click Add button, you can add current device to the bottom pane of the interface.
  • Page 92 Figure 5-9 Set remote device corresponding information (For some series product only).  IP search: Click it to search IP address.  Add: Click it to connect to the selected device and add it to the Added device list. Support Batch add.
  • Page 93  Contrast: It is to adjust monitor window contrast. The value ranges from 0 to 100. The default value is 50. The larger the number, the higher the contrast is. You can use this function when the whole video bright is OK but the contrast is not proper. Please note the video may become hazy if the value is too low.

  • Page 94: Short-Cut Menu

    Figure 5-10 Tips For some series product, on the preview interface and then right click mouse, click IPC config item, you can go to Figure 5-10. See Figure 5-11. Figure 5-11 5.3.2 Short-Cut Menu In the preview interface, for the channel of no IPC connection, you can click the icon “+” in the centre of the interface to quickly go to the Remote Device interface.

  • Page 95: Upnp

    Figure 5-12 5.3.3 UPNP Important Do not connect the switch to the PoE port, otherwise the connection may fail! Please connect the IPC to the PoE port of the device rear panel (Figure 5-13), system can auto connect to the network camera. Please note the following figure is for reference only. Figure 5-13 5.3.4 Built-in Switch Setup The built-in switch function is for product of PoE port.

  • Page 96: Preview Interface

    After device booted up, the system is in multiple-channel display mode. See Figure 5-15.Please note the displayed window amount may vary. The following figure is for reference only. Figure 5-15 5.4.1 Preview Interface You can overlay the corresponding date, time and channel name on each screen. You can refer to the following sheet for channel record or alarm status information.
  • Page 97 up the preview control interface. See Figure 5-16. If your mouse stays in this area for more than 6 seconds and has no operation, the control bar automatically hides. Figure 5-16 You can refer to the following sheet for detailed information. Name Function It is to playback the previous 5-60 minutes...

  • Page 98: Right Click Menu

     During the preview playback process, you can not see the channel title and record status of current channel. It will display the channel title and the record status once you exit the preview playback.  During the preview playback, you can not switch the displayed channel or change current window-display mode.

  • Page 99: Preview Parameter

    Figure 5-18 Now you can set corresponding information.  Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255.  Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series).

  • Page 100: Ptz

    window switch function. Stands for opening switch function, stands for closing switch function.  Monitor tour type: System support 1/8-window tour.  Alarm tour type: System support 1/8-window tour. Figure 5-19 In tour mode, you can see the following interface. On the right corner, right click mouse or click shift button, you can control the tour.
  • Page 101  Channel: Select the current camera channel.  PTZ type: There are two types: local/remote. Please select local mode if you are connect RS485 cable to connect to the Speed dome (PTZ). Please select remote mode if you are connecting to the network PTZ camera. ...
  • Page 102 Figure 5-23 Select Pan/Tilt/Zoom, the PTZ setup is shown as in Figure 5-24. Please note the commend name is grey once device does not support this function. Double click the title to hide the PTZ menu interface. Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light and wiper, rotation and etc.
  • Page 103 Focus Near Iris close Open Preset/ Patrol/Pattern/Scan In Figure 5-24, please click the “set” button. The interface is shown as below. See Figure 5-26. Here you can set the following items:  Preset  Tour  Pattern  Border Figure 5-26 Figure 5-24, click page switch button, the interface is shown as in Figure 5-27.
  • Page 104  You need to refer to your speed dome user’s manual for Aux definition. In some cases, it can be used for special process.  The following setups are usually operated in the Figure 5-24, Figure 5-26 and Figure 5-27. Preset Setup In Figure 5-24, use eight direction arrows to adjust camera to the proper position.
  • Page 105 Figure 5-30 Activate Pattern Function In Figure 5-27, input mode value in the No. blank, and click pattern button. Auto Scan Setup In Figure 5-28, click border button. The interface is shown as in Figure 5-31. Please go to Figure 5-24, use direction arrows to select camera left limit Then please go to Figure 5-31 and click left limit button Repeat the above procedures to set right limit.

  • Page 106: Record And Snapshot

    Figure 5-32 5.6 Record and Snapshot 5.6.1 Encode Encode setting is to set IPC encode mode, resolution, bit stream type and etc From Main menu->Setting->Encode, you can see the following interface. See Figure 5-33.  Channel: Select the channel you want. ...

  • Page 107: Schedule

    box ALL. Please click the OK button in Figure 5-35 and Figure 5-34 respectively to complete the setup. Please note, once you check the All box, you set same encode setup for all channels. Audio/video enable box, overlay button and the copy button is shield. Please highlight icon to select the corresponding function.
  • Page 108  Channel: Please select the channel number first. You can select “all” if you want to set for the whole channels.  Week day: There are eight options: ranges from Saturday to Sunday and all.  Pre-record: System can pre-record the video before the event occurs into the file. The value ranges from 1 to 30 seconds depending on the bit stream .

  • Page 109: Schedule Record/Snapshot

    succeeded. Please note, if you select ALL in Figure 5-37, the record setup of all channels are the same and the Copy button becomes hidden. Figure 5-37 Click OK button to save current setup. 5.6.3 Schedule Record/Snapshot 5.6.3.1 Schedule Record From Main menu->Setting->Schedule, go to the Schedule interface.

  • Page 110: Motion Detect Record/Snapshot

    enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot. Only the activation snapshot supports this function. The schedule snapshot function can not send out picture via the email. But you can upload the picture to a FTP. 5.6.4 Motion detect record/snapshot 5.6.4.1 Motion detect record From Main menu->Setting->Detect, you can go to the following interface.

  • Page 111: Alarm Record/Snapshot

    From Main menu->Setting->Encode, you can go to encode interface. See Figure 5-33. Select the motion detect snapshot channel and then click Snapshot button. See Figure 5-38. In Figure 5-38, select activation snapshot from the dropdown list and then set picture size, quality and snapshot frequency.

  • Page 112: Alarm Snapshot

    From Mani menu->Setting->Schedule, you can go to Figure 5-36. Select alarm channel, period and the record type shall be alarm. Please refer to chapter 5.6.2. Click Copy button to copy current setup to other channel(s). Click OK button to save alarm record information. 5.6.5.2 Alarm Snapshot Please refer to Step a) to step c) of chapter 5.6.4.2 to enable timing snapshot.

  • Page 113: Manual Snapshot

    5.6.6.2 Manual Snapshot Click button at the preview control bar (Chapter 0), you can snapshot one picture. You can go to chapter 0 to view snapshot picture. 5.6.7 Holiday Record/Snapshot It is for you to set holiday record or snapshot plan. Please note the holiday record/snapshot setup has the higher priority than the ordinary date record/snapshot setup.

  • Page 114: Holiday Snapshot

    Figure 5-43 Click OK button to complete holiday setup. From Main menu->setting->schedule, you can go to schedule interface. Check the box here to enable holiday function and the period shall be set as Holiday. Now you can set period and record type of holiday time. Click OK button to set holiday record setup.
  • Page 115 Figure 5-44 Please refer to the following sheet for more information. Name Function  Display Here is to display the searched picture or file.  window Support 1/4/9/16-window playback.  Here you can select to search the picture or the recorded file. ...
  • Page 116  selection In 9-window playback mode, you can switch between 1-8 and 9-16 channels.  pane. In 16-window playback mode, you can switch between1-16 and 17-32 channels.  The time bar will change once you modify the playback mode or the channel option.
  • Page 117 │ to begin frame by frame playback. In frame by frame playback mode, click ►/ to restore normal playback. ► Slow play In playback mode, click it to realize various slow play modes such as slow play 1, slow play 2, and etc. Fast forward ...

  • Page 118: Accurate Playback By Time

    type  When system is playing, you can select a zone in the window to begin motion detect. Click the motion detect button to begin play.  Current button is null once the motion detect play has begun.  Smart The system will take the whole play zone as the motion detect region by search default.

  • Page 119: Smart Search

    Figure 5-45 5.7.4 Smart Search During the multiple-channel playback mode, double click one channel and then click the button, system begins smart search. System supports 396(22*18 PAL) and 330(22*15 NTSC) zones. Please left click mouse to select smart search zones. See Figure 5-46. Figure 5-46 Click the , you can go to the smart search playback.

  • Page 120: Picture Playback

     Smart search function is for one-channel playback mode only . 5.7.5 Picture Playback From Main menu->Search, or on the preview interface right click mouse, you can go to Figure 5-44. At the top right pane, you can check the box to select picture and then select playback interval.

  • Page 121: Config Backup

    Figure 5-48 Click backup button, system begins burning. At the same time, the backup button becomes stop button. You can view the remaining time and process bar at the left bottom. 5.8.2 Config Backup This function allows you to copy current system configuration to other devices. It also supports import, create new folder, and delete folder and etc function.

  • Page 122: Alarm

    folder if you are selecting a file. System pops up a dialogue box if there is no configuration file under current folder. After successfully import, system needs to reboot to activate new setup.  Format: Click Format button, system pops up a dialogue box for you to confirm current operation.
  • Page 123  Alarm upload: System can upload the alarm signal to the network (including alarm centre) if you enabled current function.  Send email: System can send out email to alert you when an alarm occurs.  Record channel: Select the channel to activate recording function once an alarm occurred. Please make sure you have set MD record in encode interface(Main Menu->Setting->Schedule) and schedule record in manual record interface(Main Menu->Advanced->Manual Record)

  • Page 124: Video Loss

    Figure 5-51 Figure 5-52 Figure 5-53 Figure 5-54 5.9.1.2 Video Loss In Figure 5-50, select video loss from the type list. You can see the interface is shown as in...

  • Page 125: Camera Masking

    Figure 5-55. This function allows you to be informed when video loss phenomenon occurred. You can enable alarm output channel and then enable show message function. You can refer to chapter 5.9.1.1Motion detect for detailed information. Tips: You can enable preset/tour/pattern activation operation when video loss occurs. Figure 5-55 5.9.1.3 Camera Masking When someone viciously masks the lens, or the output video is in one-color due to the...

  • Page 126: Alarm Output

    Figure 5-56 5.9.2 Alarm output Here is for you to set proper alarm output (Auto/manual/stop). From Main menu->Advanced->Alarm output, you can see an interface shown as in Figure 5-57 Figure 5-57 Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu.
  • Page 127  Enable: Please you need to highlight this button to enable current function.  Type: normal open or normal close.  Period: It is to set local alarm period. System only enables local alarm in the specified period. Click the Set button; you can select the business day and the non-business day. Please note for the work day/free day setup and the specific work day setup, system just saves the latest setup.
  • Page 128  You need to set alarm record mode as Schedule in Record interface (Main Menu->Advanced->Record). Please note the manual record has the highest priority. System record all the time no matter there is an alarm or not if you select Manual mode. ...

  • Page 129: Abnormality

    Figure 5-59 Figure 5-60 Figure 5-61 Please highlight icon to select the corresponding function. After setting all the setups please click save button, system goes back to the previous menu. 5.9.4 Abnormality Abnormality interface is shown as in Figure 5-62. ...

  • Page 130: Network

     Alarm upload: System can upload the alarm signal to the network (including alarm centre) if you enabled current function.  Send email: System can send out email to alert you when an alarm occurs.  Buzzer: Highlight the icon to enable this function. The buzzer beeps when an alarm occurs. Figure 5-62 5.10 Network 5.10.1 Basic Setup...

  • Page 131: Network Setting

    four ports. Please make sure the port values here do not conflict.  Max connection: system support maximal 20 users. 0 means there is no connection limit.  MTU: It is to set MTU value of the network adapter. The value ranges from 1280-7200 bytes. The default setup is 1500 bytes.

  • Page 132: Ip Filter

    Figure 5-64 5.10.2.1 IP Filter IP filter interface is shown as in Figure 5-65. You can add IP in the following list. The list supports max 64 IP addresses. System supports valid address of IPv4 and IPv6. Please note system needs to check the validity of all IPv6 addresses.

  • Page 133: Ntp Setup

    Figure 5-65 5.10.2.2 NTP Setup This function is to enable NTP server to synchronize time with the NVR to guarantee the system time accuracy. You need to install SNTP server (Such as Absolute Time Server) in your PC first. In Windows XP OS, you can use command “net start w32time”...

  • Page 134: Multicast

    Atlantic Time GMT-4 Brazil GMT-3 Middle Atlantic Time GMT-2 Figure 5-66 5.10.2.3 Multicast Multicast is a communication between a single sender and multiple receivers on a network. Multicast can transfer one message to multiple destinations simultaneously. Multiple-cast setup interface is shown as in Figure 5-67. Figure 5-67 Here you can set a multiple cast group.

  • Page 135: Pppoe

     Like the single broadcast address of RFC1918  Can not be used in Internet transmission  Used for multiple cast broadcast in limited space. Except the above mentioned addresses of special meaning, you can use other addresses. For example: Multiple cast IP: 235.8.8.36 Multiple cast PORT: 3666.
  • Page 136 Figure 5-69 Please note NNDS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS, and Dyndns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. Quick DDNS function shall work with special DDNS server and special Professional Surveillance Software (PSS).

  • Page 137: Upnp

     Do not register frequently. The interval between two registrations shall be more than 60 seconds. Too many registration requests may result in server attack.  System may take back the domain name that is idle for one year. You can get a notification email before the cancel operation if your email address setup is OK.

  • Page 138: 126

    Figure 5-70 Figure 5-71 5.10.2.7 3G 3G setup interface is shown as below. See Figure 5-72. There are total three panes.  Pane 1: Display 3G signal intensity after you enabled 3G function.  Pane 2: Display 3G module configuration information after you enabled 3G function. ...

  • Page 139: Wifi

    connection period is 5 seconds. The device automatically disconnect when time is up. If there is no extra stream, 3G network connection is valid all the time. If the alive time is 0, then the 3G network connection is valid all the time. ...
  • Page 140 You can view the WIFI connection status in the Network Setting interface. See Figure 5-74. You can view current connection status and IP address if there is a connection. Figure 5-74 The WIFI interface is shown as below. See Figure 5-75. ...
  • Page 141 Figure 5-76 After successfully connection, you can see the following interface. You can see it is connected now. See Figure 5-77. Figure 5-77  WIFI working status: Here you can view current connection status. Please note:  After successful connection, you can see WIFI connection icon at the top right corner of the preview interface.

  • Page 142: Email

    Figure 5-78 5.10.2.9 Email The email interface is shown as below. See Figure 5-79.  SMTP server: Please input your email SMTP server IP here.  Port: Please input corresponding port value here.  User name: Please input the user name to login the sender email box. ...

  • Page 143: Ftp

    Figure 5-79 Figure 5-80 5.10.2.10 FTP Here you can set backup record or file address, remote directory, interval and etc. You need to download or buy FTP service tool (such as Ser-U FTP SERVER) to establish FTP service. Please install Ser-U FTP SERVER first. From “start” -> “program” -> Serv-U FTP Server -> Serv-U Administator.
  • Page 144 Figure 5-81 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to FTP://10.10.7.7 and then test it can modify or delete H140H140H140H TU folder or not. See Figure 5-82. Figure 5-82 System also supports upload multiple NVRs to one FTP server.

  • Page 145: Alarm Center

    Figure 5-83 Figure 5-84 5.10.2.11 Alarm center Interface is pre-reserved for the users to develop this function. 5.10.2.12 SNMP SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network management frame of the network management system. The SNMP widely used in many environments.

  • Page 146: Auto Register

    Please enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB Browser. You still need two MIB file: BASE-SNMP-MIB, NVR-SNMP-MIB) to connect to the device. You can get the device corresponding configuration information after successfully connection. Please follow the steps listed below to configure.

  • Page 147: Wifi Ap

    4) Now you can boot up the proxy server. When you see the network status is Y, it means your registration is OK. You can view the proxy server when the device is online. Important The server IP address can also be domain. But you need to register a domain name before you run proxy device server.
  • Page 148 WIFI AP in Figure 5-87 to go to the following interface, it means the restart is still in process. Please wait. Figure 5-88 Tips On the preview interface and then right click mouse, you can see an interface shown as below. Here you can click WPS button too.
  • Page 149 Figure 5-90 Client show interface is for you to view devices (such as network camera, smart phone) connected to the WIFI AP. See Figure 5-91. Figure 5-91 Filter interface is shown as below. See Figure 5-92.  Max IPC No.: It is the max network camera amount the NVR can connect to via WIFI AP by default.
  • Page 150 this mode, only the network camera in the following list can access the NVR. Please make sure the Mac State is valid.  Forbid MAC in the list to access NVR: Check the box here to enable black list function. In this mode, the network camera in the following list can not access the NVR.

  • Page 151: Network Test

    Please note:  NVR wire IP and the WIFI can be in the same IP segment. But these two values can not be the same.  The WIFI AP reboot process may be slow. Sometimes it may result in wait time out. ...

  • Page 152: Network Load

    After Sniffer began, you can exit to implement corresponding network operation such as login WEB, monitor. Please go back to Sniffer interface to click stop Sniffer. System can save the packets to the specified path. The file is named after “Network adapter name+time”. You can use software such as Wireshark to open the packets on the PC for the professional engineer to solve complicated problems.

  • Page 153: Hdd Setup

    5.11 HDD Setup Here you can view HDD information such as type, status, total capacity, record time and etc. The operation includes format, resume from error, change HDD property (Read write, Read-only). Here you can also set alarm and HDD storage position. 5.11.1 Format From Mani-menu->Advanced->HDD Management, you can go to HDD management interface.
  • Page 154 Figure 5-98 In Figure 5-98, click view record d time button, HDD record time information interface is shown as in Figure 5-99. Figure 5-99 Parameter Function SATA 1-4 here means there are 4 HDDS. For different series product, the max HDD amount may vary, When HDD is working properly, system is shown as O.

  • Page 155: Hdd Management

    Status HDD can work properly or not. Bad track Display there is bad track or not. Page up Click it to view previous page. Page down Click it to view the next page. View Click it to view HDD record information (file start time and end time). recording time View Click it to view HDD property, status and etc,...
  • Page 156 Figure 5-101 HDD Setting Click the button “HDD Settings” at the top right corner of the Figure 5-100, system will pop up an interface as below. See Figure 5-102. The number of hard disk from 1 to 2 is shown in the “HDD No.” column (It is to show the max HDD amount you can install).

  • Page 157: Esata

    Channels Setting Click the button named with “Channels Settings” at the top right corner of the Figure 5-100, system will pop up an interface shown as in Figure 5-103. You can set HDDs for main stream, extra stream and snap pictures respectively. The main stream and extra stream of one channel can be saved to different groups.

  • Page 158: Basic Setups

    5.12 Basic Setups Set NVR basic setup, device setup and other setups. 5.12.1 General From Main menu->Setting->General, you can go to the general interface. See Figure 5-104.  System time: Here is for you to set system time  Date format: There are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY. ...

  • Page 159: Device Setup

    Figure 5-106 5.12.2 Device Setup From Main menu->Setting->General, you can go to the general interface. See Figure 5-104.  Language: System supports various languages: Chinese (simplified), Chinese (Traditional), English, Italian, Japanese, French, Spanish (All languages listed here are optional. Slight difference maybe found in various series.) ...

  • Page 160: Device Maintenance And Manager

     IPC Time Sync: You can input an interval here to synchronize the NVR time and IPC time.  Snap times: Here you can set snap picture amount of one click. Figure 5-107 Figure 5-108 5.13 Device Maintenance and Manager 5.13.1 System Info 5.13.1.1 Version Here is for you to view some version information.

  • Page 161: Bps

    Figure 5-109 5.13.1.2 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). See Figure 5-110. Figure 5-110 For the 32-channel series product, the interface is shown as below. See Figure 5-111. Figure 5-111...

  • Page 162: Online User

    5.13.1.3 Online User Here is for you manage online users connected to the local device. See Figure 5-112. You can disconnect one user or block one user if you have proper system right. Figure 5-112 5.13.1.4 Remote Device Information Here you can view the channel status of the remote device, connection log and etc. Channel status: Here you can view the IPC status of the corresponding channel such as motion detect, video loss, camera masking, alarm and etc.

  • Page 163: Log

    Connection log: In this interface, you can search the IPC log information of the corresponding channel. It includes IPC online, offline and etc. See Figure 5-114. Figure 5-114 5.13.2 Log 5.13.2.1 Search Log Info From Main menu->Info->Log, you can go to the following interface. See Figure 5-115. ...

  • Page 164: Upgrade

    Please select a folder you want to save; you can click the backup button to save the log files. After the backup, you can see there is a folder named Log_time on the backup path. Double click the folder, you can see the log file Figure 5-116 5.13.3 Upgrade From Mani menu->Info->Version, you can go to the following interface.

  • Page 165: Default

    5.13.4 Default You can restore factory default setup to fix some problems when the device is running slowly. Configuration error occurred. From Mani menu->Setting->Default, you can go to the following interface. See Figure 5-118. Click default icon, system pops up a dialogue box. You can highlight to restore factory default setup.

  • Page 166: Logout /Shutdown/Restart

    control the device via the special keyboard. Transparent COM (adapter) is to connect to the PC to transfer data directly. Protocol COM is for card overlay function. Network keyboard is for you to use the special keyboard to control the device. PTZ matrix is to connect to the peripheral matrix control.
  • Page 167 Figure 5-120...

  • Page 168: Quick Configuration Tool

    6 Quick Configuration Tool 6.1 Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. 6.2 Operation Double click the “ConfigTools.exe”...
  • Page 169 Select the “Open Device Web” item; you can go to the corresponding web login interface. See Figure 6-3. Figure 6-3 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set. In the configuration tool search interface (Figure 6-1), please select a device IP address and then double click it to open the login interface.
  • Page 170 Figure 6-5 For detailed information and operation instruction of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD.

  • Page 171: Web Operation

    7 Web Operation Slight difference may be found on the interface. Your purchased product may not support all the functions listed below. 7.1 General Introduction The device web provides channel monitor menu tree, search, alarm setup, system setup, PTZ control and monitor window. 7.1.1 Preparation Before log in, please make sure: ...

  • Page 172: Log In

    If it is your second time to insert the PoE, system can check the saved MAC address according to <Channel>---<IPC mac> map to make sure current IPC has connected or not. If system finds the previous information and the channel is idle, system can map it to the previously used channel.

  • Page 173: Lan Mode

    Figure 7-2 IE Safety Setup After installation, the interface is shown as below. See Figure 7-1. Figure 7-1 Please input your user name and password. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. 7.2 LAN Mode For the LAN mode, after you logged in, you can see the main window.
  • Page 174 Figure 7-2 This main window can be divided into the following sections.  Section 1: There are six function buttons: Preview（chapter 7.3）, setup (chapter 7.9), info (Chapter 7.10), playback (chapter 7.7), alarm (chapter 7.8), and logout (chapter 7.11).  Section 2: There are monitor channels successfully connected to the NVR. Please refer to Figure 7-3 for main stream and extra stream switch information.

  • Page 175: Real-Time Monitor

     Section 5: Local play button. The Web can playback the saved (Extension name is dav) files in the PC-end. Click local play button, system pops up the following interface for you to select local play file. See Figure 7-6. Figure 7-6 ...

  • Page 176: Ptz

     2: Local record. When you click local record button, the system begins recording and this button becomes highlighted. You can go to system folder RecordDownload to view the recorded file.  3: Snapshot picture. You can snapshoot important video. All images are memorized in system client folder PictureDownload (default).

  • Page 177: Image/Alarm-Out

    3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 7-9 7.5 Image/Alarm-out Select one monitor channel video and then click Image button in section 9, the interface is shown as Figure 7-10. 7.5.1 Image Here you can adjust its brightness, contrast, hue and saturation.

  • Page 178: Wan Login

    Here you can enable or disable the alarm signal of the corresponding port. See Figure 7-11. Figure 7-11 7.6 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 7-12. Figure 7-12 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default.

  • Page 179: Playback

    Figure 7-13 Important The window display mode and the channel number are by default. For example, for the 16-channel, the max window split mode is 16. 3) Multiple-channel monitor, system adopts extra stream to monitor by default. Double click one channel, system switches to single channel and system uses main stream to monitor.
  • Page 180 Figure 7-14 Then please click File list button, you can see the corresponding files in the list. See Figure 7-15. Figure 7-15 Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen.
  • Page 181 Figure 7-16 Select the file(s) you want to download and then click download button, you can see an interface shown as in Figure 7-17. The Download button becomes Stop button and there is a process bar for your reference. Please go to you default file saved path to view the files. Figure 7-17...
  • Page 182 Load more It is for you to search record or picture. You can select record channel, record type and record time to download. There are two download types. The download by file interface is shown as in Figure 7-18 and the download by time interface is shown as in Figure 7-19. Figure 7-18 Figure 7-19 Watermark...

  • Page 183: Alarm

    Figure 7-20 Alarm Click alarm function, you can see an interface is shown as Figure 7-21. Here you can set device alarm type and alarm sound setup (Please make sure you have enabled audio function of corresponding alarm events.). Figure 7-21 Please refer to the following sheet for detailed information.

  • Page 184: Setup

    Type Parameter Function external It refers to the on-off signal from the network alarm camera. It can activate the NVR local activation operation. No signal System can generate an alarm when the network camera and the NVR are disconnected. Operation Prompt Check the box here, system can automatically pops up an alarm icon on the Alarm button in the main interface when there is an alarm.
  • Page 185 Figure 7-23 Please refer to the following sheet for log parameter information. Parameter Function Click Device search button, you can view the searched device Device search information on the list. It includes device IP address, port, device name, manufacturer and type. Select a device in the list and then click Add button, system can connect the device automatically and add it to the Added device list.

  • Page 186: Conditions

    Parameter Function Click it, the interface is shown as in Figure 7-23. Here you can add Manual network camera manually. You can select a channel from the dropdown list (Here only shows disconnection channel.) Note:  System supports manufactures such as Panasonic, Sony, Dynacolor, Samsung, AXIS, Arecont, Dahua and Onvif standard protocol.
  • Page 187 function when the whole video is too dark or too bright. Please note the video may become hazy if the value is too high. The value ranges from 0 to 100.The recommended value ranges from 40 to 60. Contrast It is to adjust monitor window contrast. The value ranges from 0 to 100.

  • Page 188: Video/Audio

    color is proper.  Sunny: The threshold of the white balance is in the sunny mode.  Night: The threshold of the white balance is in the night mode.  Customized: You can set the gain of the red/blue channel. The value reneges from 0 to 100.

  • Page 189: Snapshot

    System supports active control frame function (ACF). It allows you to record in different frame rates. For example, you can use high frame rate to record important events, record scheduled event in lower frame rate and it allows you to set different frame rates for motion detection record and alarm record.

  • Page 190: Video Overlay

    Parameter Function There are two modes: Regular (schedule) and Trigger. Snapshot type  Regular snapshot is valid during the specified period you set.  Trigger snapshot only is valid when motion detect alarm, alarm or local activation alarm occurs. tampering Image size It is the same with the resolution of the main stream.

  • Page 191: Path

    You can enable this function so that system overlays channel Channel Title information in video window. You can use the mouse to drag the channel title position. You can view channel title on the live video of the WEB or the playback video.

  • Page 192: Network

    Figure 7-30 7.9.2 Network 7.9.2.1 TCP/IP The TCP/IP interface is shown as in Figure 7-31. Figure 7-31 Please refer to the following sheet for detailed information. Parameter Function Multiple-address eth0 and eth1 operate separately. You can use the services mode such as HTTP, RTP service via etho0 or the eth1.

  • Page 193: Connection

    fault-tolerance same time, you need to set one master card. Usually there is only one running card (master card).System can enable alternate card when the master card is malfunction. The system is shown as offline once these two cards are both offline. Please note these two cards shall be in the same LAN.

  • Page 194: Wifi

    Figure 7-32 Please refer to the following sheet for detailed information. Parameter Function Max connection It is the max Web connection for the same device. The value ranges from 1 to 120. The default setup is 120. TCP port The default value is 37777. You can input the actual port number if necessary.

  • Page 195: Wifi Ap

    Figure 7-33 Please check the box to enable WIFI function and then click the Search SSID button. Now you can view all the wireless network information in the following list. Double click a name to connect to it. Click Refresh button, you can view latest connection status. 7.9.2.4 WIFI AP The WIFI AP function is for NVR31-W series product only.
  • Page 196 Figure 7-35 Figure 7-36 Figure 7-37...

  • Page 197: 185

    7.9.2.5 3G 7.9.2.5.1 CDMA/GPRS The CDMA/GPRS interface is shown as in Figure 7-38. Figure 7-38 Please refer to the following sheet for detailed information. Parameter Function WLAN type Here you can select 3G network type to distinguish the 3G module from different ISP. The types include WCDMA， CDMA1x and etc.

  • Page 198: Pppoe

    to get alarm message. Figure 7-39 7.9.2.6 PPPoE The PPPoE interface is shown as in Figure 7-40. Input the PPPoE user name and password you get from the IPS (internet service provider) and enable PPPoE function. Please save current setup and then reboot the device to get the setup activated.

  • Page 199: Ddns

    7.9.2.7 DDNS The DDNS interface is shown as in Figure 7-41. The DDNS is to set to connect the various servers so that you can access the system via the server. Please go to the corresponding service website to apply a domain name and then access the system via the domain.

  • Page 200: Ip Filter

    name, password or the ID registration on the server. At the same time, each device has a default domain name (Generated by MAC address) for your option. You can also use customized valid domain name (has not registered.). 3) Operation Before you use Quick DDNS, you need to enable this service and set proper server address, port value and domain name.
  • Page 201 Figure 7-43 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25. You can modify it if necessary. Anonymity For the server supports the anonymity function.

  • Page 202: Upnp

    Parameter Function The send interval ranges from 0 to 3600 seconds. 0 means Interval there is no interval. Please note system will not send out the email immediately when the alarm occurs. When the alarm, motion detection or the abnormity event activates the email, system sends out the email according to the interval you specified here.

  • Page 203: Snmp

    7.9.2.11 SNMP The SNMP interface is shown as in Figure 7-45. The SNMP allows the communication between the network management work station software and the proxy of the managed device. It is reserved for the 3 party to develop. Figure 7-45 Please refer to the following sheet for detailed information.

  • Page 204: Multicast

    7.9.2.12 Multicast The multicast interface is shown as in Figure 7-46. Multicast is a transmission mode of data packet. When there is multiple-host to receive the same data packet, multiple-cast is the best option to reduce the broad width and the CPU load. The source host can just send out one data to transit.

  • Page 205: Https

    when local alarm occurs. Before you use alarm center, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data. Figure 7-48 7.9.2.15 HTTPS In this interface, you can set to make sure the PC can successfully login via the HTTPS.

  • Page 206: Download Root Certificate

    Figure 7-50 You can see the corresponding prompt. See Figure 7-51. Now the server certificate is successfully created. Figure 7-51 7.9.2.15.2 Download root certificate In Figure 7-49, click button, system pops up a dialogue box. See Figure 7-52. Figure 7-52 Click Open button, you can go to the following interface.
  • Page 207 Figure 7-53 Click Install certificate button, you can go to certificate wizard. See Figure 7-54. Figure 7-54 Click Next button to continue. Now you can select a location for the certificate. See Figure 7-55.
  • Page 208 Figure 7-55 Click Next button, you can see the certificate import process is complete. See Figure 7-56. Figure 7-56 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 7-57.

  • Page 209: View And Set Https Port

    Figure 7-57 Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 7-58. Figure 7-58 7.9.2.15.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface. See Figure 7-59. You can see HTTPS default value is 443.
  • Page 210 Figure 7-60 Figure 7-61...
  • Page 211 Figure 7-62 Figure 7-63...
  • Page 212 Figure 7-64 Figure 7-65 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list. Period Motion detection function becomes activated in the specified periods.

  • Page 213: Video Loss

    Parameter Function Record Delay System can delay the record for specified time after alarm ended. The value ranges from 10s to 300s. Alarm out Enable alarm activation function. You need to select alarm output port so that system can activate corresponding alarm device when an alarm occurs.

  • Page 214: Tampering

    Figure 7-66 7.9.3.1.3 Tampering The tampering interface is shown as in Figure 7-67. After analysis video, system can generate a tampering alarm when the detected moving signal reached the sensitivity you set here. For detailed setups, please refer to chapter 7.9.3.1.1 motion detect for detailed information. Figure 7-67...

  • Page 215: Alarm

    7.9.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm and network alarm. 7.9.3.2.1 Local Alarm The local alarm interface is shown as in Figure 7-68. It refers to alarm from the local device. Figure 7-68 Figure 7-69...
  • Page 216 Figure 7-70 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.

  • Page 217: Net Alarm

    Parameter Function System can delay the record for specified time after alarm Record Delay ended. The value ranges from 10s to 300s. Alarm out Enable alarm activation function. You need to select alarm output port so that system can activate corresponding alarm device when an alarm occurs.

  • Page 218: Ipc External Alarm

    Figure 7-71 7.9.3.2.3 IPC external alarm The IPC external alarm interface is shown as in Figure 7-72. Network alarm refers to the alarm signal from the network. System does not anti-dither and sensor type setup. For setup information, please refer to chapter 7.9.3.2.1. Figure 7-72...

  • Page 219: Ipc Offline Alarm

    7.9.3.2.4 IPC Offline Alarm The IPC offline alarm interface is shown as in Figure 7-73. System can generate an alarm once the network camera is offline. For setup information, please refer to chapter 7.9.3.2.1. Figure 7-73 7.9.3.3 Abnormality It includes six types: No disk, disk error, disks no space, disconnect, IP conflict, MAC conflict. See Figure 7-74 through Figure 7-79.
  • Page 220 Figure 7-76 Figure 7-77 Figure 7-78 Figure 7-79 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: No disk, disk error, no space, net Type disconnection, IP conflict and MAC conflict. You can set one or more items here. Less than: You can set the minimum percentage value here (For disk not space only).

  • Page 221: Storage

    Parameter Function Alarm Out Please select corresponding alarm output channel when an alarm occurs. You need to check the box to enable this function. Latch The alarm output can delay for the specified time after an alarm stops. The value ranges from 1s to 300s. Show System can pop up a message to alarm you in the local host screen if message...
  • Page 222 Figure 7-81 Figure 7-82 Please refer to the following sheet for detailed information.

  • Page 223: Hdd Manager

    Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30. Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD. Snapshot Check the box here to enable snapshot function.

  • Page 224: Ftp

    7.9.4.2.3 The FTP interface is to set FTP information. See Figure 7-85. Please set the FTP as your remote storage location. System can save record file or snapshot picture to the FTP once the network is offline or malfunction. Figure 7-85 7.9.4.3 Record Control The interface is shown as in Figure 7-86.

  • Page 225: Storage

    Please refer to the following sheet for detailed information. Parameter Function Here you can view channel number. Channel The number displayed here is the max channel amount of your device. Status There are three statuses: schedule, manual and stop. System enables auto record function as you set in record schedule Schedule setup (general, motion detect and alarm).

  • Page 226: Snapshot

    Figure 7-88 7.9.4.4.3 Snapshot The snapshot interface is shown as in Figure 7-89. Here you can set corresponding HDD group to save snapshot picture. Figure 7-89 7.9.5 Setting 7.9.5.1 General The general interface includes general, date/time and holiday setup. 7.9.5.1.1 General The general interface is shown as in Figure 7-90.

  • Page 227: Date And Time

    Please refer to the following sheet for detailed information. Parameter Function It is to set device name. Device ID Device No. It is device channel number. Language You can select the language from the dropdown list. Please note the device needs to reboot to get the modification activated.

  • Page 228: Holiday Setup

    Sync PC You can click this button to save the system time as your PC current time. Here you can set day night save time begin time and end time. You can set according to the date format or according to the week format. You can check the box to enable NTP function.

  • Page 229: User Name

    7.9.5.2.1 User name In this interface you can add/remove user and modify user name. See Figure 7-93. Figure 7-93 Add user: It is to add a name to group and set the user rights. See Figure 7-94. There are four default users: admin/888888/666666 and hidden user “default”. Except user 6666, other users have administrator right.

  • Page 230: Group

    Modify user It is to modify the user property, belonging group, password and rights. See Figure 7-95. Modify password It is to modify the user password. You need to input the old password and then input the new password twice to confirm the new setup. Please click the OK button to save. Please note, the password ranges from 1-digit to 6-digit.
  • Page 231 Please input the group name and then check the box to select the corresponding rights. It includes: shutdown/reboot device, live view, record control, PTZ control and etc. Figure 7-97 Modify group Click the modify group button, you can see an interface is shown as in Figure 7-98. Here you can modify group information such as remarks and rights.

  • Page 232: Display

    7.9.5.3 Display Display interface includes GUI, TV adjust, Tour and zero-channel encoding. 7.9.5.3.1 Display Here you can set background color and transparency level. See Figure 7-99. Figure 7-99 Please refer to the following sheet for detailed information. Parameter Function There are four options: 1920× 1080,1280 × 1024(default),1280 × Resolution 720,1024×768.

  • Page 233: Alarm Out

    Figure 7-100 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function. Enable tour Here is for you to adjust transparency. The value ranges from 5 to Interval 120s. The default setup is 5s. Here you can set window mode and channel group.

  • Page 234: Default

    Figure 7-101 7.9.5.5 Default The default setup interface is shown as in Figure 7-102. Here you can select Network/Event/Storage/Setting/Camera. Or you can check the All box to select all items. Figure 7-102 7.9.5.6 Import/Export The interface is shown as in Figure 7-103. This interface is for you to export or import the configuration files.

  • Page 235: Auto Maintain

    Parameter Function Click to select import file. Browse It is to import the local setup files to the system. Import It is to export the corresponding WEB setup to your local PC. Export 7.9.5.7 Auto maintain The auto maintain interface is shown as in Figure 7-104. Here you can select auto reboot and auto delete old files interval from the dropdown list.

  • Page 236: Rs232

    7.9.5.9 RS232 The RS232 interface is shown as in Figure 7-106. Figure 7-106 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Default setup is console. Select the baud rate. Baud Rate Default setup is 115200.
  • Page 237 Figure 7-107 Figure 7-108 Please refer to the following sheet for detailed information. Parameter Function Select speed dome connected channel. Channel There are two options: local/remote. PTZ Type Please select remote type if you are connecting to the network PTZ. Select the corresponding dome protocol such as PELCOD.

  • Page 238: Preview Control

    Parameter Function Parity Default setup is none. Please set according to the speed dome dial switch setup. 7.9.5.11 Preview Control The preview control interface is shown as Figure 7-109. Please select split mode and preview channel from the dropdown list. Figure 7-109 7.10 Information 7.10.1 Version...

  • Page 239: Online User

    Figure 7-111 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear. Set the start time of the requested log. Start time Set the end time of the requested log.

  • Page 240: Log Out

    Figure 7-112 7.11 Log out Click log out button, system goes back to log in interface. See Figure 7-113. You need to input user name and password to login again. Figure 7-113 7.12 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un-installation might result in error.

  • Page 241: Faq

    8 FAQ 1. Device can not boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
  • Page 242  Device color or brightness setup is not correct. 6. Can not search local records. There are following possibilities:  HDD ribbon is damaged.  HDD is broken.  Upgraded program is not compatible.  The recorded file has been overwritten. ...
  • Page 243  PTZ decoder and device address is not compatible.  When there are several decoders, please add 120 Ohm between the PTZ decoder A/B cables furthest end to delete the reverberation or impedance matching. Otherwise the PTZ control is not stable. ...
  • Page 244  System uses too much CPU resources. Please stop record first and then begin backup.  Data amount exceeds backup device capacity. It may result in burner error.  Backup device is not compatible.  Backup device is damaged. 17. Keyboard can not control device. There are following possibilities: ...

  • Page 245: Daily Maintenance

     There is no DivX503Bundle.exe control when you play the file transformed to AVI via media player.  No DivX503Bundle.exe or ffdshow-2004 1012 .exe in Windows XP OS. 23. I forgot local menu operation password or network password Please contact your local service engineer or our sales engineer for help. We can guide you to solve this problem.

  • Page 246: Glossary

    Glossary  DHCP: DHCP (Dynamic Host Configuration Protocol) is a network protocol. It is one of the TCP/IP protocol cluster. It is principally used to assign temporary IP addresses to computers on a network.  DDNS: DDNS (Dynamic Domain Name Server) is a service that maps Internet domain names to IP addresses.

  • Page 247: Appendix A Hdd Capacity Calculation

    10 Appendix A HDD Capacity Calculation Calculate total capacity needed by each device according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte.

  • Page 248: Appendix B Compatible Network Camera

    11 Appendix B Compatible Network Camera Please note all the models in the following list are for reference only. For those products not included in the list, please contact your local retailer or technical supporting engineer for detailed information. Manufact Model Version Video Encode...
  • Page 249 √ FD-100A v1.0.3.3 H264 ONVIF － √ Cannon VB-M400 H264 Private √ MPix2.0DIR XNETM112011 H264 ONVIF 1229 √ VIPBL1.3MIR XNETM210011 H264 ONVIF 1229 √ IGC-2050F XNETM210011 H264 ONVIF 1229 √ CP PLUS CP-NC9-K 6.E.2.7776 H264 Private, ONVIF √ CP-NC9W-K 6.E.2.7776 H264 Private √...
  • Page 250 √ HIDC-1300V 2.0.0.21 H264 ONVIF √ HICC-1300W 2.0.1.7 H264 ONVIF √ HICC-2300 2.0.0.21 H264 ONVIF √ HDZ20HDX H20130114NS H264 ONVIF √ － LW342-FP H264 Private √ － LNB5100 H264 ONVIF √ － Imatek KNC-B5000 H264 Private √ － KNC-B5162 H264 Private √...
  • Page 251 .4657 √ DD4N-X 01.02.0015 MPEG4 Private √ DD423-X 01.02.0006 MPEG4 Private √ D5220 1.8.3-FC2-2012 H264 Private 0614-1.9320-A 1.8035 √ Samsung SNB-3000P 2.41 H264、MPEG4 Private, ONVIF √ SNP-3120 1.22_110120_1 H264、MPEG4 Private, ONVIF √ SNP-3370 1.21_110318 MPEG4 Private √ SNB-5000 2.10_111227 H264、MPEG4 Private, ONVIF √...

  • Page 252: Appendix C Compatible Backup Device List

    12 Appendix C Compatible Backup Device List Compatible USB drive list Manufacturer Model Capacity Sandisk Cruzer Micro 512M Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256M Sandisk Cruzer Freedom 512M Sandisk Cruzer Freedom Sandisk Cruzer Freedom DataTraveler Ⅱ Kingston DataTraveler Ⅱ...
  • Page 253 Manufacturer Model Capacity Kingston Data Traveler Locker+ 32GB Netac U228 Compatible SD Card List Please refer to the following sheet for compatible SD card brand. Brand Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Micro-SD Sandisk Micro-SD Compatible Portable HDD List...
  • Page 254 Manufacturer Model SONY AW-G170S Pioneer NVR-217CH Pioneer NVR-215CHG Compatible SATA HDD List Port Manufacturer Series Model Capacity Mode Seagate Seagate SV35.1 ST3250824SV 250G SATA Seagate Seagate SV35.1 ST3500641SV 500G SATA Seagate Seagate SV35.2 ST3250820SV 250G SATA Seagate Seagate SV35.2 ST3320620SV 320G SATA Seagate...
  • Page 255 Port Manufacturer Series Model Capacity Mode Seagate Seagate Pipeline ST3320311CS 250G SATA Seagate Seagate Pipeline ST3500414CS 500G SATA Seagate Seagate Pipeline ST3500312CS 500G SATA Seagate ST31000424CS SATA Seagate Pipeline Seagate ST31000322CS SATA Seagate Pipeline Seagate ST1000VM002 SATA Seagate Pipeline Seagate Seagate Pipeline ST1500VM002...
  • Page 256 Port Manufacturer Series Model Capacity Mode Constellation ES Seagate Seagate ST2000NM0051 SATA Constellation ES Seagate Seagate ST1000NM0051 SATA Constellation ES Seagate ST500NM0051 500G SATA Seagate Constellation ES Seagate Seagate ST33000650NS SATA Constellation ES.2 Seagate Seagate ST32000645NS SATA Constellation ES.2 Seagate ST33000651NS SATA Seagate...
  • Page 257 Port Manufacturer Series Model Capacity Mode Digital Westem WD Caviar RE16 WD3200YS-01PGB0 320G SATA Digital Westem WD Caviar RE2 WD5000YS-01MPB0 500G SATA Digital Westem WD AV—AVJS WD2500AVJS-63WDA0 500G SATA Digital WD AV—AVJS WD3200AVJS-63WDA0 320G SATA Westem Digital WD AV—AVJS WD5000AVJS-63YJA0 500G SATA Westem...
  • Page 258 Port Manufacturer Series Model Capacity Mode Digital Westem WDAV-GP—EVDS WD20EVDS-63T3B0 SATA Digital Westem WDAV-GP—AVDS WD5000AVDS-63U7B0 500G SATA Digital Westem WD AV-GP WD30EURS SATA Digital WD AV-GP WD25EURS 2.5T SATA Westem Digital WD AV-GP WD20EURS SATA Westem Digital WD AV-GP WD15EURS 1.5T SATA Westem...
  • Page 259 Port Manufacturer Series Model Capacity Mode HitachiCinemaStar™ Hitachi HCT721075SLA360 750G SATA 7K1000.B HitachiCinemaStar™ Hitachi HCT721010SLA360 SATA 7K1000.B Maxtor DiamondMax 20 STM3320820AS 320G SATA Maxtor DiamondMax 20 STM3250820AS 250G SATA...

  • Page 260: Appendix D Compatible Cd/Dvd

    13 Appendix D Compatible CD/DVD Manufacturer Model Port Mode Type Sony DRX-S50U DVD-RW Sony DRX-S70U DVD-RW Sony AW-G170S SATA DVD-RW Samsung TS-H653A SATA DVD-RW Panasonic SW-9588-C SATA DVD-RW Sony DRX-S50U DVD-RW BenQ 5232WI DVD-RW...

  • Page 261: Appendix E Compatible Displayer List

    14 Appendix E Compatible Displayer List Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch LENOVO（LCD） LXB-L17C 17-inch SANGSUNG（LCD） 225BW 22-inch (wide screen) LENOVO(CRT) LXB-FD17069HB 17-inch LENOVO(CRT) LXB-HF769A 17-inch LENOVO(CRT) LX-GJ556D 17-inch Samsung (LCD)

  • Page 262: Appendix F Toxic Or Hazardous Materials Or Elements

    15 Appendix F Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ （Panel） ○ ○ ○ ○...

This manual is also suitable for:

Nvr21-p seriesNvr24 seriesNvr31h seriesNvr21h seriesNvr21-s seriesNvr31series ... Show all

Table of Contents
