- Page 1 BURRINGTON SOLID FUEL ROOM HEATER 13.3 kW USER AND INSTALLATION INSTRUCTIONS To be retained by the householder...
- Page 2 HEALTH AND SAFETY INFORMATION FOR THE INSTALLER AND SERVICE ENGINEERS Under the Consumer Protection Act 1987 and the Health And Safety At Work Act 1974, it is a requirement to provide information on substances hazardous to health (COSHH Regulations 1988). Eurostove ltd takes every reasonable care to ensure that these products are designed and constructed to meet these general requirements, when properly used and installed.
-
Page 3: Table Of Contents
CONTENTS Page 1. USER INSTRUCTIONS Fuels to Use Operating Tool Lighting Control Settings Refuelling Ash Removal Overnight Burning To Revive the Fire 2. CLEANING Enamelled Parts Chimney Sweeping Grate Removal Shaker Rod Removal 3. MAINTENANCE Shutting Down Assembly 4. INSTALLATION INSTRUCTIONS General Description Specification Installation... -
Page 4: User Instructions
USER INSTRUCTIONS Refuelling Fuels to use: 1. Do not allow the fire to burn too low before refuelling. 2. With the door closed, clear ash from the grate by inserting Registered smokeless fuel (see SFA website) tool in end of shaker bar and operate sharply up and down. Anthracite Stove 3. -
Page 5: Cleaning
CLEANING Grate Removal The glass in the fire door has special heat resisting qualities This appliance is fitted with a reciprocating shaker grate and will adequately withstand the operating temperatures having ten individual bars fitted alternately on two rods, five reached by the appliance. -
Page 6: Assembly
WARNING Open doors and windows to ventilate the room and then leave the premises. Before re-lighting the appliance and in particular at the start Let the fire go out. of the heating session it is important to check the flue outlet has not become blocked by a fall of deposits from the Check for flue or chimney blockage and clean if chimney. - Page 7 AIR CONTROL ASSEMBLY Item Part Description Item Part Description 32750 AIR CONTROL ASSEMBLY 32753 Air Control Flap W.U. 32751 Thermostat, Rathgebar or Teddington 32756 Flap Gasket 32752 Thermostat Fixing Bracket 32775 Control Knob 91184 MX5X10 Pan Hd Pozi Setscrew 32776 Shroud 91321 M5X50 Pan Hd Pozi Setscrew...
-
Page 8: Assembly
SPARES BOILER BODY ASSEMBLY SURROUND ASSEMBLY Item Part No Description Item Part No Description No Off 30500 COMPLETE BOILER BODY 32470 COVER PLATE 30510 ASSY,TRH45 32463 EXTENSION TUBE 30525 BODY BOILER W.U. TRH45 Mk 3 32649 IDLING AIR DISC 32512 THROAT PLATE (MK 3) 32690 ASHPAN... -
Page 9: Installation Instructions
The room heater can be connected to any normal type of heating and indirect hot water system but as they are The Burrington boiler stove is only suitable for open continuously burning appliances it is essential that the domestic hot water is arranged for gravity circulation. -
Page 10: Domestic Hot Water System
Fig. 4 RECOMMENDED METHOD FOR FLUE CONNECTION Fig. 5 Domestic Hot Water System It is essential that a double feed indirect cylinder complying there is always adequate supply of air to the room from with BS. 1566:Part 1 is used for a domestic hot water adjacent rooms or passages. -
Page 11: Flue Connections
The chimney should not be subject to downdraught nor be kerb on front edge must not be more than 25mm. (1”) to fitted with a capping which could impede the discharge of allow the appliance door to open fully. AIR DAMPER SETTING AIR DAMPER SETTING flue gasses. -
Page 12: Boiler Dimensions
THE BURRINGTON ROOMHEATER... - Page 13 Eurostove’s policy is one of continuous research and development. This may necessitate alterations to this specification. Instructions correct at time of going to print. NOV 2012 Item No. burrington .ver3.2012...
