Page 1: Wireless Router R8 Series User Manual
User Manual M1 Series Wireless Modem 2/24/2010 Forwell Wireless Co., Ltd. Shandy Feng...
Page 2 User Manual M1 Series Wireless Modem User Manual Power by Forwell Wireless [Type text] Page 2...
Page 3: Important Notice
Do not operate the Forwell Wireless device in any aircraft, whether the aircraft is on the ground or in flight. In aircraft, the Forwell Wireless device MUST BE POWERED OFF. When operating, the Forwell Wireless device can transmit signals that could interfere with various onboard systems.
Page 4: Copyright
LIMITED TO, LOSS OF PROFITS OR REVENUE OR ANTICIPATED PROFITS OR REVENUE ARISING OUT OF THE USE OR INABILITY TO USE ANY FORWELL WIRELESS PRODUCT, EVEN IF FORWELL WIRELESS AND/OR ITS AFFILIATES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR THEY ARE FORESEEABLE OR FOR CLAIMS BY ANY THIRD PARTY.
Page 5: Table Of Contents
User Manual Contents Wireless Router R8 Series User Manual .................... 1 Important Notice ..........................3 Safety and Hazards ..........................3 Limitations of Liability ........................3 Copyright ............................4 Trademarks ............................4 Contact Information .......................... 4 Document History ..........................7 Overview ......................错误！未定义书签。 Introduction ............................
Page 6 User Manual System Management ..............错误！未定义书签。 Upgrade Firmware................错误！未定义书签。 Settings Management ..............错误！未定义书签。 Access Point Status ................错误！未定义书签。 Statistic .................... 错误！未定义书签。 System Log..................错误！未定义书签。 Product Parts List .................... 错误！未定义书签。 [Type text] Page 6...
Page 7: Document History
User Manual Introduction This user guide describes the M1 series wireless modem. The aim of the manual is to ease the test, install and disposition. Note: Though all features are documented in this manual, new features may still be in beta stage at publication and therefore may not yet be validated.
Page 8: Abbreviations
User Manual Abbreviations Access Point Name Digital Analog Converter GGSN Gateway GPRS Support Node GPRS General Packet Radio Service Internet Protocol Kilobyte Mobile Country Code Mobile Network Codes Mobile Station Protocol Data Unit PLMN Public Land Mobile Network RSSI Received Signal Strength Indication Small Adapter Short Message Services Produclist...
Page 9 Introduction With the development of wireless communication technologies, wireless products are being adopted in numerous industrial and civilian fields. Shenzhen Forwell Wireless Co., Ltd. a leader of wireless communication equipment manufacturer releases the M1 Series Wireless Modems, which support various frequency bands of GSM/GPRS/CDMA 1X, and provide industrial terminal solutions for 2.5G/2.75G communication.
Page 10 User Manual PCS 1900Mhz Class 1 (1W) M12AC111 GSM phase 2/2+ GPRS GSM 850 Mhz Class 4 (2W) EGSM 900 Mhz Class 4 (2W) DCS 1800 Mhz Class 1 (1W) PCS 1900Mhz Class 1 (1W) M12H111 GSM phase 2/2+ GPRS GSM 850 Mhz Class 4 (2W) EGSM 900 Mhz...
Page 11 User Manual Application Remote Data Monitor and Control Water, gas and oil flow metering AMR (automatic meter reading) Power station monitoring and control Remote POS (point of sale) terminals Traffic signals monitor and control Fleet management Power distribution network supervision Central heating system supervision Weather station data transmission Hydrologic data acquisition...
Page 12 User Manual Device Connection Description Power ON: boot FLASH: running Ring ON: boot FLASH: incoming call Data ON: boot FLASH: data transfer NOTE ：The indicator lamp of M12AZ1411 AND M12AC111 is different form above， as shown in the diagram below：描述...
Page 13 User Manual Assemble the antenna, connect to PC via RS-232, power on. Open the Hyperterminal Windows start menuall programsAccessoriesCommunicationsHyper Terminal Enter the name of the connection. [Type text] Page 13...
Page 14 User Manual Choose the communication port. Setting the port properties. Note: the ForwellWireless Modem port properties factory default is 115200/8/n/1/0, as above picture. [Type text] Page 14...
Page 15 User Manual Call Disconnect Propertie Port parameters If the port parameters is different to your setting, click disconnect, then click properties. Click the Configure. [Type text] Page 15...
Page 16 User Manual Comfirm the parameters again. Port parameters After setting, the Hyper Terminal window as above. Click call buttom, the Hyper Terminal is ready for operate. [Type text] Page 16...
Page 17: At Command Rule
User Manual AT Command AT Command Rule AT<cr> // return Ok AT+XXX=YYY<cr> // setting parameter AT+XXX <cr> // query parameter ？ AT&F<cr> // restore Modem parameters to factory default AT&W<cr> // save parameters Note: the AT command not case-sensitive, prefix by at and terminate by <cr>...
Page 18 // query the SMS center number which auto get from network +CSCA : “+8613800755500” , 145 M11/M12 ASCII Message AT+CMGF=1<cr> // setting ASCII mode AT+CMGS=”13691978232”<cr> // destination number >Hello Forwell // message by ASCII sets, terminate character ” ” means Ctrl+Z(0X1A) ，！！！→ → +CMGS // message stamp ：...
Page 19 +CSCA : “+8613800755500” , 145 M12Z1411/M12AZ1411/M12Z1511/M12AZ1511 ASCII Message AT+CMGF=1<cr> // setting ASCII mode AT+CMGS=”13691978232”<OXOD> // destination number >Hello Forwell // message by ASCII sets, terminate character ” ” means Ctrl+Z(0X1A) ，！！！→ → +CMGS // message stamp ：...
Page 20: Relate Command
User Manual M12Z1411/M12AZ1411/M12Z1511/M12AZ1511 Message Relate Command AT+CMGF=1<cr> // setting ASCII mode AT+CMGL=”ALL”<cr> // query the SMS list AT+CMGR=n<cr> // read the SMS, location value is n AT+CMGD=n<cr> // delete the SMS, location value is n M12Z1411/M12AZ1411/M12Z1511/M12AZ1511 Receive SMS AT+CPMS=MT,MT,MT<cr> // Preferred SMS message storage AT+CSMS=1<cr>...
Page 21 User Manual M13Z311/M13Z811 SMS M13Z311/M13Z811 Send SMS at+zmsgl=1,2<cr> // ASCII mode at+cmgs="13691978232"<cr> // destination mobile number Forwell Wireless<ctrl+z> // SMS content +CMGS:1 +CDS: 2,1,"13691978232",129,"07/08/02,11:28:40","09/08/02,11:28:45",32768 M13Z311/M13Z811 Commonest SMS Command AT+CMGL=”ALL”<cr> // list SMS AT+CMGR=n<cr> // read SMS, location value is n AT+CMGD=n<cr>...
Page 22 User Manual <length> SMS content length <ack> No acknowledge Acknowledge <format> ASCII Unicode 8-bit <prt> Normal Interactive Urgent Emergency <prv> Normal Restricted Confidential Secret M13H211/M13H311 Send SMS AT$HSMSSD=13691978232, 11, 1,1, 1, 1 // destination mobile number: 13691978232 // SMS content length: 11 // acknowledge // ASCII // priority: interactive...
Page 23 User Manual $HMTI: ”MT”, n,m // SMS acknowledge: normal SMS, location n, storage media m $HDSI: ”SR”, n, m // SMS acknowledge: statu report, location n, storage media m [Type text] Page 23...
Page 24 User Manual Dial Up Follow is the dial up instance, use the Windows XP environment. Note: M11S111 GSM Modem do not support the dial up function. Phone and Modem Option My ComputerControl PanelPhone and Modem Options [Type text] Page 24...
Page 25 User Manual Modem tabAdd Select “Don’t detect my modem, I will select it from a list” [Type text] Page 25...
Page 26 User Manual Select Standard 19200 bps Modem Select port COM1 [Type text] Page 26...
Page 27: Setting The 19200 Modem
User Manual Finish. Setting the 19200 Modem Open the standard 19200 bps Modem properies [Type text] Page 27...
Page 28 User Manual Tab “Modem”, change the maximun port speed to 115200 Open tab “Diagnostics”, Query Modem for detect the modem statu. [Type text] Page 28...
Page 29 User Manual Open tab ”Advanced”, fill the extra initialization commands Type Extra initialization command M12S211 AT+CGDCONT=1,IP,CMNET M12Z111 AT+CGDCONT=1,”IP”,”CMNET” M12AZ1411 M12AC111 M12O111 M12N111 M12N211 M12G111 M12H111 M13Z311 AT&D2 M13Z811 M13H211 M13H311 [Type text] Page 29...
Page 30 （M12S211）（M13）（ M12Z111/M12O111/M12N111/M12N 211/M12G111/M12H111）...
Page 31: Add Connection
Add Connection Open the Network Connections...
Page 32 User Manual Create a new connection Click next [Type text] Page 32...
Page 33 User Manual Choose commect to the internet Set up my connection manually [Type text] Page 33...
Page 34 User Manual Connect using a dial-up modem Type the name of connection [Type text] Page 34...
Page 35 (M12) (M13) Input the ISP phone number, “*99***1#” for M12 and “#777” for M13 Select the account (M12) (M13) Type the ISP account name and password, “wap”/“wap” for M12 in the China Mobile and...
Page 36 User Manual “card”/”card” for M13 in the China Telecom Finish. (M12) (M13) Open the dial-up connection, click properties. [Type text] Page 36...
Page 37 (M12) (M13) Click configure Chang the maximun speed to 115200 Dial Up...
Page 38: Apn Setting
(M12) (M13) Click Dial, then the connection will establish automatically. APN/VPDN Setting APN Setting The APN is special parameter provide by ISP. Follow is a sample by China Mobile, which APN is “CMNET” AT+CGDCONT=1,IP,CMNET // M12S211 AT+CGDCONT=1,"IP","CMNET" M12Z111/M12O111/M12N111/M12N211/M12G111/M12H111 （ M12Z111/M12O111/M12N111/M12N （M12S211）...
Page 39 VPDN Setting The VPDN have special user name and password, whick provice by the ISP. The follow sample is the provide by China Telecom...
Page 40 User Manual Relate Command Modem Initial Command AT&F0<cr> // restore parameters AT+IPR=115200<cr> // setting fixed baud rate AT&W<cr> // 保存参数 Note: n=0/300/600/1200/2400/4800/9600/14400/28800/38400/57600/115200 M12S211 factory defautl baud rate is 0(auto detect), other types （ factory default baud rate is 115200 ） Server Initial ATS0=2<cr>...
Page 41: Hardware Watchdog
User Manual Hardware Watchdog Disable Watchdog Open Open 15 mins Open Shortcut 30 mins Shortcut Open 5 mins Shortcut Shortcut Describe RG Shortcut Reserve GT Shortcut Monitor receive Empty Reserve NOTICE：M12AZ1411 does not have Hardware flow monitoring;M12AC111 is different from the figure above, hardwareware jumpper settings of M12AC111 are below：...
Page 42 User Manual The settings of K1、K2 and K3 is same to the table above ，it increase K4，setting method is below 说明 Normal working AB shortcut Upgrade BC shortcut [Type text] Page 42...
Page 43: Audio Interface
User Manual Audio Interface This interface is option base the order. Name Input/Output PIN Describe Memo Output Positive Vout=3.7V Green Output Negative Yellow MICP Input Positive Vimax=1.03Vpp at Ri=2Ω Vsupply=2.65V at Rsupply=4KΩ Black MICN Input Negative Blue STATUS O System Status Normal: 3.7V Reset: 0V Io>500mA...
Page 44 User Manual Product List Name Unit Quantity Describe Picture Item Device Garantee Card Piece 1 Standard Supply Power Adapter Item DC 9V1A RS-232 Cable Item Standard Supply Antenna Item Standard Supply Product CD Piece 1 Standard Supply [Type text] Page 44...
