Please read this user manual thoroughly before first using this device
*The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by HMM Diag-
nostics is under license. Other trademarks and trade names are those of their respective owners.
Heart rate monitor with data transfer
User Manual
HMM Diagnostics GmbH
D-69221 Dossenheim, Germany
www.hmm.info
15
Advertisement
Table of Contents
Summary of Contents for SmartLab hBeat B
-
Page 1: User Manual
Heart rate monitor with data transfer User Manual Please read this user manual thoroughly before first using this device HMM Diagnostics GmbH D-69221 Dossenheim, Germany www.hmm.info *The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by HMM Diag- nostics is under license. -
Page 2: Table Of Contents
Content I. Introduction II. Device Overview Heart rate monitor Adjustable elastic belt III. Setup & Functions Unpacking the product How to wear chest strap Maintenance Insert Batteries Important Supported Devices Regularity and Safety Notice Warranty... -
Page 3: Introduction
I. Introduction Thank you for using the smartLAB hBeat B heart rate monitor. This product is a sensor ® type heart rate monitor that will detect heart rate and send your data to a Bluetooth® Smart receiver, such as PC, Tablet or Smartphone. -
Page 4: Device Overview
II. Device Overview A. Heart rate monitor a. Front View pict. 1 b. Rear View 1. Left & Right wearing directions 2. Battery Door pict. 2... -
Page 5: Adjustable Elastic Belt
B. Adjustable elastic belt pict. 3 3. Electrodes 4. Fastening buttons... -
Page 6: Setup & Functions
III. Setup and Functions 1. Unpacking the product In this box, you will find: a. smartLAB® hBeat B heart rate monitor (transmitter) b. Adjustable elastic belt c. CR2032 battery – already installed d. User manual 2. To wear chest strap a. - Page 7 b. Attach the transmitter to the strap pict. 5 c. Strap the heart rate chest belt across your chest. To ensure an accurate heart rate signal, adjust the strap until the belt fits snugly below your (chest) pectoral muscles. pict. 6 C.
-
Page 8: Maintenance
Maintenance • Cleaning of transmitter and strap in a washing machine or dryer is strongly prohibited • Before hand washing the device, detach the transmitter of Heart Rate Monitor where electrodes are located. This part is not washable • While washing the straps, make sure water is no higher than 30°C •... -
Page 9: Insert Batteries
Insert Batteries The transmitter needs one CR2032 3V battery. The battery is already installed when bought. The battery typically lasts up to one year. To replace the chest belt battery: - First twist the compartment lid using a coin counter-clockwise until it clicks out of place. -
Page 10: Important
Important 1. Non-rechargeable and rechargeable batteries must be disposed of properly. Heart Rate Monitor and batteries need to be disposed of according to local regulations. 2. Batteries are extremely dangerous when swallowed! Therefore, keep batteries and small articles away from children. If a battery has been swallowed seek immediate medical advice. -
Page 11: Regularity And Safety Notice
Regularity and Safety Notice Declaration of Conformity This product is compliant with the EC Directives: -1999/5/EC Safety Statement This product has been verified to conform to the safety certification in accordance with the specification of EN Standards: EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 WEEE note The WEEE (Waste Electrical and Electronic Equipment) Directive, that came into effect as... - Page 12 The WEEE logo on the product and the packaging indicates that it is not allowed to dispose of the product in the ordinary household waste. It is your responsibility to deliver all the disused electri- cal and electronic equipment to the respective collection points. A separate collection and proper recycling of electronic waste helps dealing economically with natural resources.
-
Page 13: Warranty
Warranty HMM Diagnostics GmbH products need to fulfill high quality requirements. Because of this reason, HMM Diagnostics GmbH gives a 2-year warranty by purchasing this smartLAB product. You can even extend the warranty from 3 to 5 years without ®... - Page 14 Hersteller/Manufacturer: HMM Diagnostics GmbH Friedrichstr. 89 D-69221 Dossenheim, Germany E-mail: info@hmm.info www.hmm.info Weitere Informationen zu den smartLAB Produkten / ® More information on our smartLAB products: ® www.smartlab.org...
