Summary of Contents for Vertical Sports LK8000

Page 2: Table Of Contents
V2 Index. Overview 15. LK8000 Setting Accessories 16. Touch Calibration Adding Icons 17. Bluetooth Adding Icons 18. Bluetooth Moving Icons Deleting Icons Screen Rotation Power O Power O LK8000 10. Owner Information 11. BackLight 12. Clock and Regional Settings 13. Internal GPS...
Page 3: Overview
V2: Overview Power on/o : Press and hold for 2-3 sec Micro SD Mini USB The V2 runs on the operating system Windows Mobile v6.1 which is based on Windows CE 5 kernel.
Page 4: Accessories
V2: Accessories Mount Car Charger USB Cable for PC AC adapter 10 pin to 5 pin Cable for External device Serial COM 7 : Pin 7 and 9...
Page 5 V2: How to add Icon to the home screen. 1. Press where you want to add a icon 2. Tap “Image” and Select “ Add Icon” 3. Select “Icon” which you like 4. Tap “Execute”...
Page 6 V2: How to add Icon to the home screen. 5. Select “Storage Card” 6. Select “LK8000 - PNA” then, tap “ok” on top right 7. Tap “Yes” to save and close 8. New icon is added on the home screen...
Page 7 V2: How to move an Icon. 1. Press icon which you want to move 2. Select “Move Icon” for 2 - 3 seconds 7. Press where you want to move for 2 -3 seconds 8. Icon is moved then, Select “Move Here”...
Page 8 V2: How to delete an Icon. Press icon which you want delete 2. Tap “Yes” to con rm and close for 2 - 3 seconds the, select “Delete Icon” 3. Icon is deleted from the home screen...
Page 9 V2: How to rotate the screen. 1. Tap “Screen rotate icon” at the home screen 2. Portrait screen...
Page 10 V2: How to power off. 1. Press “Power button” for 2 -3 seconds 2. Tap “Yes” to Power o Note: A momentary press of the Power button will be put the unit into “Sleep mode”. Any applications running at this time will be maintained but power consumption Is radically reduced.
Page 11 Note that LK is idle as well while the V2 is o ! It will not log data! After the ight, exit LK8000 and go back to the desktop, form there siwtch o as normal (see previous page). Do not Power o before exiting LK8000 as the ight log will be lost.
Page 12: Owner Information
V2: Settings - Owner Information. 1. Tap “Start” and then Select “Settings” 2. Tap “Owner Information” 3. Use the on - screen keyboard to enter your details then, tap “ok” to save and close...
Page 13: Backlight
3. Select “External Power supply” tap Un- check the Tick Box, and Select Maximum brightness 4. Tap “ok” to save and close At full brightness, and constant running of LK8000 using the internal GPS, the V2 battery lasts about2,5 hours (150 minutes).
Page 14: Clock And Regional Settings
V2: Settings - Clock and Regional Settings. 1. Select “Clock & Alarms” 2. Adjust Time zone and Time 1. Select “Regional Settings” 2. Select your country...
Page 15: Internal Gps
V2: Settings - Internal GPS. 1. Select “External GPS” 2. Internal GPS is assigned to COM 4 Note: Do not change the COM port. When GPS is in use, the RED LED LIGHT on the PNA ashes. This means: LK has accessed the internal GPS port, and the GPS is now working.
Page 16: Lk8000 Settings
V2: Settings - Running LK8000. LK8000 setting for gps: Device name: Generic Port: COM4 Baudrate 19200 8bit On the V2 desktop, ip pages until you nd the GPS icon, and select it. A page open, named GPS Settings, saying "Choose the port that programs will use to obtain gps data. Any program that uses GPS will need to communicate with this port".
Page 17 V2: Settings - Running LK8000. BACKLIGHT SETTING AND AUDIO From the desktop, click on the upper left corner on the windows icon, where "Start" is printed. A menu appears Click on Settings In the Personal tab, select "Sounds and Noti cations"...
Page 18: Touch Calibration
V2: Settings -Touch Calibration. 1. Select “Screen” 2. Tap “Align Screen” 3. Use a touch pen, Tap “+” correctly...
Page 19: Bluetooth
V2: Settings -Bluetooth. 1. Select “ Bluetooth” on “Connections” tap 2. Select “Mode” tap, and Check “Turn on Bluetooth” and “Make this device visible to other devices 3. Select “Devices” tap , and 4. Searching for Bluetooth devices Tap “ Add new device”...
Page 20: Bluetooth
V2: Settings - Bluetooth. 4. Select a device to connect with and 5. Use the on -screen keyboard to enter Tap ”Next” a passcode, if not required, Tap “Next” 7. Device is connected, and 8. Connected Tap “Done” to close...
