5910 Ethernet Gateway
Hardware Manual
CONTROL
MICROSYSTEMS
SCADA products... for the distance
48 Steacie Drive
Kanata, Ontario
K2K 2A9
Canada
Telephone:
613-591-1943
Facsimile:
613-591-1022
Technical Support:
888-2CONTROL
888-226-6876

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5910 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Control Microsystems 5910

  • Page 1 5910 Ethernet Gateway Hardware Manual CONTROL MICROSYSTEMS SCADA products... for the distance 48 Steacie Drive Telephone: 613-591-1943 Kanata, Ontario Facsimile: 613-591-1022 K2K 2A9 Technical Support: 888-226-6876 Canada 888-2CONTROL...
  • Page 2 Printed in Canada. Trademarks TeleSAFE, TelePACE, SmartWIRE, SCADAPack, TeleSAFE Micro16 and TeleBUS are registered trademarks of Control Microsystems Inc. All other product names are copyright and registered trademarks or trade names of their respective owners. Material used in the User and Reference manual section titled SCADAServer OLE Automation Reference is distributed under license from the OPC Foundation.
  • Page 3: Table Of Contents

    OPERATION ....................9 MAINTENANCE ................... 10 Troubleshooting ................... 10 SPECIFICATIONS ..................11 APPROVALS AND CERTIFICATIONS ............12 Index of Figures Figure1: 5910 Module Layout ....................5 Figure 2: 5905 Ethernet RJ-45 Connection ................. 6 5910 Ethernet Gateway Hardware Manual October 19, 2007...
  • Page 4: Overview

    5910 will begin to operate. The 5910 mounts on a DIN rail and is powered from the 5V available in SCADAPack controllers and other 5000 series systems. The 5910 can also be powered from 11-30Vdc sources such as 12Vdc batteries, 24Vdc power supplies or AC adapters.
  • Page 5: Important Safety Information

    EXPLOSION HAZARD – WHEN IN HAZARDOUS LOCATIONS, TURN OFF POWER BEFORE REPLACING OR WIRING MODULES. WARNING ! EXPLOSION HAZARD - DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE NONHAZARDOUS. 5910 Ethernet Gateway Hardware Manual October 19, 2007...
  • Page 6: Installation

    I/O Bus as an integrated part of a Control Microsystems system. The model 5910SA is a stand-alone version of the 5910 and is used with other devices such as personal computers. Both versions of the modem are identical in every respect except that the 5910SA has rubber feet for desktop mounting.
  • Page 7: Ethernet Connection

    The 5910 module is normally powered through the connection to the system I/O Bus. The 5910 module is connected to the system I/O Bus using a cable connected to P1 or P2. Refer to the System Configuration Guide, at the beginning of this manual, for complete information on the system I/O Bus cabling.
  • Page 8: External Power Connection Using An External Power Source

     Ensure the AC adapter is not connected to the 120Vac supply.  Locate connector P8 on the 5910 module. Refer to Figure1: 5910 Module Layout for the location of P8.  The output cable end should be factory installed on a four position removable terminal block.
  • Page 9 Function connection) has been established. Flickers when data is being transmitted or received. Speed Off for 10 Mbps operation. On for 100 Mbps operation. 5910 Ethernet Gateway Hardware Manual October 19, 2007...
  • Page 10: Operation

    The 5910 is a layer 2, five port unmanaged switch. No programming or configuration is required to use the 5910. Once the Ethernet connections are made and the 5910 is powered it will begin to operate. Unlike an Ethernet hub that broadcasts all messages to all ports, the 5910 Ethernet Switch will route messages only out of the appropriate port.
  • Page 11: Maintenance

    Maintenance This module requires no routine maintenance. If the module is not functioning correctly, contact Control Microsystems Technical Support for more information and instructions for returning the module for repair. Troubleshooting Problem Solutions Power LED is not on. Check power source. If the input is 5V from the Bus on P1 or P2 then the J1 jumper should be in the bottom or “Bus power 5V”...
  • Page 12: Specifications

    Specifications Disclaimer: Control Microsystems reserves the right to change product specifications without notice. For more information visit www.controlmicrosystems.com 5 ports, unmanaged, store & forward, 10/100BaseT Ethernet switch type RJ45 ports (shielded) Ethernet Terminations Protocols IEEE 802.3, IEEE 802.3u (TBC), IEEE802.3x...
  • Page 13: Approvals And Certifications

    This product conforms to the above Emissions and Immunity Declaration Standards and therefore conforms with the requirements of Council Directive 89/336/EEC (as amended) relating to electromagnetic compatibility. The Low Voltage Directive is not applicable to this product. 5910 Ethernet Gateway Hardware Manual October 19, 2007...
