Bavarian Soundwerks E46 Convertible Installation Instructions Manual

Stage 1 Audio Upgrade (BMW Speakers) Installation Instructions
for BMW 3 Series, M3 Convertible '00-'06 (E46)
Tools Required:
(All the below are readily available at your local auto
parts store)
•
Phillips Head Screwdriver
•
Panel Removal Tools
•
Torx bit set
•
Small, Straight Pick Tool
•
8mm Socket Wrench
•
13mm Socket Wrench
•
Hot Glue Gun w/Glue Sticks

Before you Begin

•
Please review and familiarize yourself completely with these instructions
before starting work on your vehicle!
•
Insure that your bass and treble settings are set to their default middle positions before
installing your new speaker upgrade. Once you've installed your Stage 1, you can reset the
bass and treble settings to taste. Keep in mind that we generally recommend keeping them both
very close to center as large adjustments introduce distortion into the audio signal and will lower
performance of your system.
•
Perform the installation one door at a time. Since there are many small parts that you'll remove
when completing the project, limiting the work you're doing to one door will prevent you from
confusing which parts go with what door. Take a quick listen to confirm that the speakers are
functional, but wait until all of the speakers are installed for a complete audition. Installing the
speakers into one door and comparing them to the rest of the factory speakers will not yield the
desired results of the upgrade.
•
The Process
As each customer's installation is unique, it is important to remember that installation is essentially the
reverse of the removal process outlined below, though you will need a certain level of personal ingenuity and
certain tools outlined above. Variations occasionally occur, so if anything seems out of line with what is
contained in the pages that follow, don't hesitate to contact us.
If you experience any issues with your installation, please consult the troubleshooting guide located
at the rear of this installation packet.
We're going to proceed as follows:
1. Front Doors
2. Rear Side Panels
Any reproduction, distribution, modification, or dissemination of these instructions without written permission from Bavarian Soundwerks is
expressly forbidden and a violation of international copyright law. Any violation will result in prosecution to the full extent available under
•
1 of 10
the law!
© 2006 Bavarian Soundwerks, LLC.
2195 Defoor Hills Rd., Suite D, Atlanta, GA 30318
P: 404.963.8857 | www.bavsound.com
