Summary of Contents for Anwell T360-269-GPS
- Page 1 Shenzhen Union Security industry Co., Ltd T360-269 User’s Manual Amwell GPS Tracking Unit Liven, Alex, Venessa 2011‐1‐18 Version 2.1 ...
-
Page 2: Table Of Contents
Shenzhen Union Security industry Co., Ltd Index 1. Product preface ........................ 3 2. Technician parameter ...................... 5 3. T360-269Packing list ...................... 6 3.1. Standard Accessories .................... 6 3.2. Optional accessories .................... 7 3.3. Packing View and Serial setting cable .............. 7 4. ... -
Page 3: Product Preface
Shenzhen Union Security industry Co., Ltd 1. Product preface Thank you for choosing our company's T360-269-GPS tracking anti-theft products, please carefully read the instructions before operating. T360-269 satellite positioning system combined with anti-theft, positioning, monitor and observe, alarm for help, advertising, vehicle scheduling, image capture and tracking functions, it’s easy to use, easy to operate, the... - Page 4 Shenzhen Union Security industry Co., Ltd T360-269 is not with waterproof capacity; select the dry location to install the device, also pay attention to moisture-proof and waterproof. Please correct installation of your use of T360-269 products, not in the non-compatible devices installed on T360-269 Products.
-
Page 5: Technician Parameter
Shenzhen Union Security industry Co., Ltd 2. Technician parameter Name Parameter Gift Box Dimension 245mm × 155mm × 51mm Color Black Working voltage 9V -- 30V DC 80 mA – 120 mA（12V/DC） Working current Back-up battery life time Up to 1 hour Tracker size 145mm X 104mm X 36mm Weight... -
Page 6: T360-269Packing List
Shenzhen Union Security industry Co., Ltd 3. T360-269Packing list 3.1. Standard Accessories Accessory QTY Image Function Packing 1PCS Gift box packing Main device 1PCS T360-269 main device 1PCS Receiving GSM network signal Antenna GPS Antenna 1PCS Receiving satellite locating signal data Implementation of the core components restoration Relay... -
Page 7: Optional Accessories
Shenzhen Union Security industry Co., Ltd 3.2. Optional accessories Name Image Function 1-Show the dispatching information from the monitoring center which is very convenient for dispatching management. Dispatching 2-Call conversation with screen monitoring centre by conencted to a earphone on side of the LCD 3-To programming the main device such as APN/IP/PORT LED Pixel：16*128... -
Page 8: T360-269Indicator Light Description
Shenzhen Union Security industry Co., Ltd 4. T360-269Indicator light description LED light Light on Light off Description Green 5 seconds 1 second GPS located Green 1 second 1second GPS unlocated Green 0.5Second 0.5Second Initialization 1 second 1second Searching for GSM network 0.5S GSM network normal Flashing quickly... -
Page 9: Functions Description
Shenzhen Union Security industry Co., Ltd 5. Functions Description 5.1. 6 channels signal detecting It can detect the following signal: ACC, engine, air conditioner, door, SOS, GPS antenna open, GPS antenna short circuit. Control center can check out this state any time and monitor the signal. -
Page 10: Real-Time Monitor Function
Shenzhen Union Security industry Co., Ltd 5.7. Real-time monitor function Uploading data about car state and position in preset time and preset times. 5.8. Supporting various external device Support devices Such as dispatch screen, Camera, RFID card reader, LED display, text broadcasting devices, fuel sensor. -
Page 11: T360-269 Main Device Installation
Shenzhen Union Security industry Co., Ltd 6. T360-269 Main device installation After you get T360-269 product, please familiar with it and test it before you install it in a Car, please check the packing list and make sure the packing and product quality well. - Page 12 Shenzhen Union Security industry Co., Ltd Step5.2 .Check communicate 3. Click to check if the serial communicate is ok Step5.3. Set center parameter and APN T360-269 User’s Manual 12 / 20 ...
-
Page 13: Install In A Car
Shenzhen Union Security industry Co., Ltd 6.3. Install in a car 6.3.1. Prepare for install This device using in 12V, 24V motor vehicles, will not conflict with the original car system, in order to facilitate fault diagnosis and unusual dispute after installation, please check the pre-installation inspection and truthfully inform the owner. -
Page 14: Main Device Installing
Shenzhen Union Security industry Co., Ltd 11. Installing cable derivative hole 12. GSM antenna 13. MIC set 14. GPS antenna 15. Handle setting 16. Voice speaker connector 269A9A Main device installing cable 269A6A Text broadcasting cable connector 269A4A LED Display board connector cable 269A4B Camera connecting cable 6.3.3. - Page 15 Shenzhen Union Security industry Co., Ltd 6.3.3.2. 269A9A cable installation diagram Power positive wire (red): power positive installation in general with the battery positive, or with the fuse box’s total power input regular wire (+12 V). During installation process must choose thick (+12 V) wires.
- Page 16 Shenzhen Union Security industry Co., Ltd Detect door-open wire (blue): Low trigger, for detecting the door-open signal; Customized trigger (orange, green): These two wires are for custom self-defined signal detection wire. (Custom orange negative trigger line should > 0.5V, which to trigger conduction; green line custom>...
- Page 17 Shenzhen Union Security industry Co., Ltd 6.3.3.5. 269A4B Installation Instructions (optional) Lines are installed 269A4B main camera cable connector; detailed installation and use please refer to the "camera installation instructions" and "platform operating instructions" related to the contents of the operation. 6.3.3.6.
-
Page 18: Extended Function
Shenzhen Union Security industry Co., Ltd 7. Extended function Photo taking function: The camera is infrared camera. It will automatically start the infrared function while in the dark enviorenment. The camera also works even using the backup battery while the main power is off. ... -
Page 19: Faq
Shenzhen Union Security industry Co., Ltd 8. FAQ Problem Reason Solution 1. power of positive and negative reversed installed Power installed 2. the power of the cathode not connected; incorrectly 3. the original car is controlled by main power Light off after switch (mostly in 24V vehicle.) device connected... - Page 20 Shenzhen Union Security industry Co., Ltd No alarm when Back-up battery Find a local dealer to open backup battery device power off failed to open switch Installation or 1- Due to operation mistake to cut the fuel Unable to power on operation pump.
