  • Page 1 SIMADO GDT11 System Manual...
  • Page 3 SIMADO GDT11 GSM/CDMA Fixed Cellular Terminal for Data Applications System Manual...
  • Page 4 Documentation Disclaimer Matrix Comsec reserves the right to make changes in the design or components of the product as engineering and manufacturing may warrant. Specifications are subject to change without notice. This is a general documentation for all models of the product. The product may not support all the features and facilities described in the documentation.

  • Page 5: Table Of Contents

    Contents Section 1: Introduction ............................7 Welcome ................................. 9 Know your SIMADO GDT11 ......................... 10 Installing the System ............................. 11 Getting Started .............................. 14 Section 2: Features and Facilities ........................19 Data Services ............................... 21 GPRS (General Packet Radio Service) ......................31 Voice Services ..............................

  • Page 7: Section 1: Introduction

    Section 1: Introduction...

  • Page 9: Welcome

    Welcome Thank you for choosing the Matrix SIMADO GDT11. We hope you will make optimum use of this product. Please read this document carefully to get acquainted with the product before installing and operating it. This document provides detailed information and instructions for installing and operating the SIMADO GDT11.

  • Page 10: Know Your Simado Gdt11

    • Voice Services. You can connect the SIMADO GDT11 to a PC and use it efficiently for web browsing, sending and receiving SMS, data transfer and fax services. The SIMADO GDT11 is easy to install, and finds its application in enterprises and institutions of varying sizes.

  • Page 11: Installing The System

    Select an appropriate site for installing the product, taking into consideration the above listed safety instructions. • Make sure that the installation site you choose has good signal strength, from the network. • Unpack SIMADO GDT11 and verify its contents. SIMADO GDT11 System Manual...
  • Page 12 If any of the above listed items is missing or damaged, contact the source from where you have purchased the system. • Fix the system at the selected site. You may refer to the ‘SIMADO GDT11 Dimensions’ provided at the end of this topic. •...
  • Page 13 SIMADO GDT11 Dimensions 104.00 mm (4.09 Inch) SIMADO GDT11 System Manual...

  • Page 14: Getting Started

    If no SIM card is present then LED marked ‘NW’ remains continuously ‘ON’. • When SIM card is inserted, and the network is available this LED starts blinking. • The SIMADO GDT11 is now ready for use. • Now create Connection Type using HyperTerminal. Creating Connection Type using HyperTerminal 1.
  • Page 15 2. Double click Hypertrm Icon. 3. A New Connection Dialog Box with a text box for connection description appears. SIMADO GDT11 System Manual...
  • Page 16 4. Enter an appropriate name for the new connection in the text box (e.g. SIMADO GDT11), choose an Icon from the Icons listed. Click OK button. 5. In the response Window ‘Connect To’, go to ‘Connect Using’ and select the COM Port to which SIMADO GDT11 is connected.
  • Page 17 6. In the response Window make the following entries. Bits per seconds=115200, Data bits = 8, Parity = None, Stop bits = One, Flow control = Hardware. Click OK button. 7. In the ‘HyperTerminal’ Window, click the Call Menu, then click the Menu Item Disconnect. Relevant Topic: “Installing the System” SIMADO GDT11 System Manual...
  • Page 18 SIMADO GDT11 System Manual...

  • Page 19: Section 2: Features And Facilities

    Section 2: Features and Facilities...

  • Page 21: Data Services

    Make all settings same on both PCs. The receiving PC should be in 'Wait for Call', when user is in dialing state. • You can successfully send/receive data using the SIMADO GDT11. How to configure Data Services Set up the Modem 1.
  • Page 22 2. Control Panel window will open up as shown below. Double click the Phone and Modem Options icon. 3. 'Phone and Modem Options' window will open as shown below. Click Add button. SIMADO GDT11 System Manual...
  • Page 23 4. 'Add Hardware Wizard' window will open. Select Don't detect my modem; I will select from a list option in the window. Click Next button. 5. Select Standard 9600bps Modem from the available modem options in the window and click Next button. SIMADO GDT11 System Manual...
  • Page 24 6. Select COM1 port in the window and click Next button. 7. Click Finish button. SIMADO GDT11 System Manual...
  • Page 25 The Modem will be installed as shown below: 8. Click OK' button. Create Connection Type using HyperTerminal 1. Click Start  Programs  Accessories  Communications  HyperTerminal. SIMADO GDT11 System Manual...
  • Page 26 3. 'Connect To' window will appear on the screen. Enter area code and phone number as well as select country in Country/region field and modem in Connect using field as shown below. Click OK. 4. 'Connect' window will appear on the screen. 5. If phone number is to be modified, click Modify button. SIMADO GDT11 System Manual...
  • Page 27 If required, clear the checkbox Use country/region code and area code, clear the checkbox Redial on busy, and click OK. Sending Data Files 1. Click Call  Dial. 2. System will give the message ‘Connecting', followed by ‘Dialing’. SIMADO GDT11 System Manual...
  • Page 28 'Wait for a call' mode, when you click Call as shown below, else you will not be able to send or receive any file. 4. Click Transfer File Send File. SIMADO GDT11 System Manual...
  • Page 29 5. Browse and select the file to be sent. Select Zmodem as the setup protocol. Click Send. 6. Message 'Sending' will appear as shown below: Receiving Data Files 1. On HyperTerminal, click Call Wait for a call. SIMADO GDT11 System Manual...
  • Page 30 2. During 'Receive', Click Transfer Receive File. 3. Select the location to store received file. Select Zmodem as receiving protocol. Click Receive. 4. When a remote GDT11 unit or some other GSM terminal transmits data to your GDT11 unit, the following message will appear.

  • Page 31: Gprs (General Packet Radio Service)

    How to use GPRS To be able to use GPRS, you must do the following: 1. Get the GPRS service for the SIM used in the SIMADO GDT11 enabled by the service provider. 2. Set up a Modem. 3. Create a connection type.
  • Page 32 2. Control Panel window will open up as shown below. Double click the Phone and Modem Options icon. 3. 'Phone and Modem Options' window will open as shown below. Click Add button. SIMADO GDT11 System Manual...
  • Page 33 4. 'Add Hardware Wizard' window will open. Select the option Don't detect my modem; I will select from a list in the window. Click Next button. 5. Select 'Standard 33600bps Modem' from the available modem options in the window and click Next button. SIMADO GDT11 System Manual...
  • Page 34 6. Select 'COM1' port in the window and click Next button. 7. Click Finish button. SIMADO GDT11 System Manual...
  • Page 35 9. In Modem Properties window, click Advanced tab and enter the 'Extra Initialization Commands' as given by the service provider. For example enter: AT+CGDCONT=1, "IP", "airtelgprs.com". Click OK. 10. You return to the Phone and Modem Options window, click OK. SIMADO GDT11 System Manual...
  • Page 36 Establishing a GPRS Dial-Up Connection 1. Click Start  Control Panel. SIMADO GDT11 System Manual...
  • Page 37 2. Control Panel window will open up. Click Network Connections icon. 3. Click ‘Create a New Connection’ in the Network Connection window. SIMADO GDT11 System Manual...
  • Page 38 4. New Connection Wizard will open. Click Next button. 5. Select Connect to the Internet option and click Next button. SIMADO GDT11 System Manual...
  • Page 39 6. Select Set my connection manually and click Next button. 7. Select Connect using a dial up modem and click Next button. SIMADO GDT11 System Manual...
  • Page 40 8. Enter the name of your Internet Service Provider (ISP) in ISP Name field and click Next button. 9. Enter phone number in Type phone number below field and click Next button. SIMADO GDT11 System Manual...
  • Page 41 10. Select Anyone's Use radio button and click Next button. 11. Enter User Name and Password in the fields Username, Password and Confirm Password respectively. Select the other two check boxes given on the Internet Account Information page. Click Next button. SIMADO GDT11 System Manual...
  • Page 42 13. A shortcut to SIMADO GDT11_GPRS dial up will be created on your desktop. Sending/Receiving GPRS Data 1. Double click the shortcut SIMADO GDT11_GPRS on your desktop OR click Start  'My Network Places Setting' View Network Connections and double click Dial up SIMADO GDT11_GPRS.
  • Page 43 2. Connection process will be displayed as shown below. 3. Once the connection is established, you can access the Internet through GPRS connection. For example access: www.google.com in the Address Bar of the web browser. SIMADO GDT11 System Manual...

  • Page 44: Voice Services

    SIMADO GDT11 supports making and receiving voice calls. • User has to just connect Headphone to the jack provided at rear side of the GDT11 and use AT commands. User can also connect Handset for sending and receiving voice signal.
  • Page 45 +21.0 dB +22.5 dB By default, Channel is Main Microphone and gain level is 2. • Initiating Voice Call: • Initiate the voice call using the following command: ATD <string>; Dial the number by ATD <n>; Where, SIMADO GDT11 System Manual...
  • Page 46 = number to be dialed. Receiving a Voice Call: • Incoming call is identified by display ‘RING’ on the screen. • Answer the call by ‘ATA’ command. • Terminate the call by ‘ATH’ command. SIMADO GDT11 System Manual...

  • Page 47: Sms (Short Message Service)

    • It allows sending and receiving of messages using a computer. • Receipt of an SMS by the SIMADO GDT11 is indicated to the user on the computer. How to Send/Receive SMS through Computer? To send and receive SMS, •...
  • Page 48 Enter command AT+CMGF=1 to set text message format • Enter AT+CMGR=(Index) to read SMS Where, Index is the index number at which SMS is stored. (The index of the message is displayed when the SIMADO GDT11 indicates the arrival of a new message). SIMADO GDT11 System Manual...
  • Page 49 Now type the message. • When the message is completed, press CRTL+Z. • On successful transmission of the message, the confirmation OK will appear. Deleting the messages • Enter AT+ CMGD=(Index), on the HyperTerminal screen Where, SIMADO GDT11 System Manual...
  • Page 50 Index is the index number of the message to be deleted. SIMADO GDT11 System Manual...

  • Page 51: Fax Services

    How to send and receive FAX • The Fax Service for the SIM used in the SIMADO GDT11 must be enabled from the service provider. • A PC Fax application which is Fax Class 1 or Fax Class 2 compliant must be installed on the Computer.
  • Page 52 2. Control Panel window will open up as shown below. Double click the Phone and Modem Options icon. 3. 'Phone and Modem Options' window will open as shown below. Click Add button. SIMADO GDT11 System Manual...
  • Page 53 4. 'Add Hardware Wizard' window will open. Select Don't detect my modem; I will select from a list option in the window. Click Next button. 5. Select Standard 19200bps Modem from the available modem options in the window and click Next button. SIMADO GDT11 System Manual...
  • Page 54 6. Select COM1 port in the window and click Next button. 7. Click Finish button. Modem will be installed as shown below. Click Properties button. SIMADO GDT11 System Manual...
  • Page 55 8. Select Maximum port speed, as '19200' and click OK. Set up for Sending FAX 1. Click Start Program  Symantec WinFax PRO  WinFax PRO Message Manager. 2. Click Tools  Program Setup. SIMADO GDT11 System Manual...
  • Page 56 4. Modems and Communication Devices window will appear as shown below. Select Standard 19200 bps Modem and select the Active check box of the selected modem and click OK. 5. Following message will appear on the screen. Click Yes button. SIMADO GDT11 System Manual...
  • Page 57 6. Modem Configuration Wizard: Ready to Test window will appear on the screen. Click Next button. 7. Modem Configuration Wizard: Testing modem window will appear. Again click Next button. 8. Select 'Class 1 (Hardware Flow Control)' in the window that appears on the screen. Click Next. SIMADO GDT11 System Manual...
  • Page 58 9. Modem Configuration exit Wizard will appear on the screen. Click Finish button. 10. Now, select location for the standard modem and click OK. 11. Modems and Communication Devices Properties window will appear on the screen. Select Standard 19200 Modem and select Active checkbox. Click Properties button. SIMADO GDT11 System Manual...
  • Page 59 12. Select COM1 in communication port, initialize at 19200 bps and Modem Type: Class 1.0. Click FAX. 13. Enter Initializing string sequence: AT&C1&D2S7=55 and Reset=ATZ. Click Apply button and OK. SIMADO GDT11 System Manual...
  • Page 60 Device as Standard 19200 bps Modem and select the checkbox Active as shown below. Click Receive Setup button. 2. In 'Receive Properties', ensure that: When answering on = Standard 19200bps Modem, Answer after = 2 rings. Click Apply and OK. SIMADO GDT11 System Manual...
  • Page 61 1. Open WinFax PRO Message Manager screen. Click Send To: Matrix (or Name), Number: Enter the number where fax is to be sent. Enter the text content of the Fax message on the 'Cover Page'. Click 'Send'. SIMADO GDT11 System Manual...
  • Page 62 2. While sending the operation message is displayed as shown below: 3. Following screen shown that sending is in progress: SIMADO GDT11 System Manual...
  • Page 63 4. On successful transmitting, you can check the 'Send Log' as shown below: To Receive Fax: 1. On receiving Fax, you can check the 'Receive Log' as shown: SIMADO GDT11 System Manual...
  • Page 64 SIMADO GDT11 System Manual...

  • Page 65: Section 3: Appendices

    Section 3: Appendices...

  • Page 67: Appendix A: Technical Specifications

    : Wall Mounting or Table-Top Operational Conditions Temperature : -10 C to +55 C(14 to131 Fahrenheit) Humidity : 5-95% RH, non-condensing Storage Conditions Temperature : -40 C to +85 C(-40 to 185 Fahrenheit) Humidity : 0-95% RH, non-condensing SIMADO GDT11 System Manual...

  • Page 68: Appendix B: Regulatory Information

    Appendix B: Regulatory Information SIMADO GDT11 System Manual...
  • Page 69 SIMADO GDT11 System Manual...

  • Page 70: Warranty Statement

    Matrix has been advised of the possibility of such damages or losses or for any claim by any other party. SIMADO GDT11 System Manual...
  • Page 71 This warranty is not transferable and applies only to the original consumer purchaser of the Product. Warranty shall be void if the warranty card is not completed and registered with Matrix within 30 days of installation. All legal course of action subjected to Vadodara (Gujarat, India) Jurisdiction only. SIMADO GDT11 System Manual...
  • Page 72 MATRIX COMSEC PVT. LTD. Corporate Office: 394-GIDC, Makarpura, Vadodara - 390010, India. Tel.:+91 265 2630555, Fax: +91 265 2636598 E-mail: Info@MatrixComSec.com Factory: 39-GIDC, Waghodia - 391760, Dist. Vadodara, India. Tel.: +91 2668 262056/57 Technical Support: Tel.: +91 2668 263172/73, Fax: +91 2668 262631 E-mail: Support@MatrixComSec.com www.MatrixComSec.com...
