Page 1 OWNER’S / OPERATOR’S MANUAL...
Page 2 INTRODUCTION You are now the owner of a Brown CONGRATULATIONS! EdgeMaster READ THIS MANUAL CAREFULLY! This manual will help you learn how to operate and service your EdgeMaster correctly. Fail- ure to read and follow the instructions of this manual could result in personal injury or equipment damage.
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY................OPERATION............... TROUBLESHOOTING............WARRANTY................ 8 SERVICE................11 PARTS LIST............... 12 ASSEMBLY INSTRUCTIONS..........16 All information, including illustrations and speci- ﬁ cations, contained in this manual are based on the latest information available at the time of publica- tion.
Page 4 PAGE LEFT BLANK INTENTIONALLY...
Page 5: Safety
Keep your EdgeMaster in proper repair. Safety decals, manuals and replacement parts are avail- able through your BROWN dealer. Unauthorized modiﬁ cations to the BROWN EdgeMaster not recommended. This could impair the func- tion, safety, and machine life. For any part of this manual that you do not understand, contact your BROWN dealer.
Page 6 Wear close-ﬁ tting clothing appropriate for the job. Wear a hearing protective device to protect from loud or uncomfortable noise. Wear proper eye protection. Safety goggles are supplied with each BROWN EdgeMaster Wear appropriate foot wear. Wear gloves when changing or replacing blades.
Page 7 PAGE 3 HANDLE FUEL SAFELY Fuel is highly ﬂ ammable. Handle with care. Stop engine before refueling. Do not refuel while smoking or near open ﬂ ames. Always ﬁ ll fuel tank outdoors. Keep edger clean of oil, grease, and dirt. Clean up spilled fuel immediately.
Page 8 PAGE 4 AVOID ROTATING BLADE Be sure blade guard is in place. Do not adjust curb depth while blade is turning. Do not put hands or feet near blade while engine is running. READ AND FOLLOW SAFETY SIGNS...
Page 9: Operating Instructions
WARNING: GASOLINE IS EXTREMELY FLAMMABLE AND IS EXPLOSIVE UNDER CERTAIN CONDITIONS. NOTE: FOR FURTHER INFORMATION CONCERNING THE SAFETY, OPERATING, MAINTENANCE, ETC. OF THE PARTICULAR ENGINE SUPPLIED WITH YOUR BROWN EdgeMaster , SEE THE EN- GINE OWNER’S MANUAL THAT IS SUPPLIED TO YOU WITH THE EdgeMaster BEFORE STARTING ENGINE 1.
Page 10 PAGE 6 3. START ENGINE A. Be sure belt tensioner is in disengaged position and that no tension is on the belt. B. Turn ignition to “ON” position. C. Close choke if engine is cold. D. Pull start cord rapidly. E.
Page 11: Troubleshooting
PAGE 7 TROUBLESHOOTING PROBLEM CAUSE SOLUTION A. Engine does not 1. Engine switch in 1. Switch to “ON” start. “OFF” position. position. 2. Engine ﬂ ooded. 2. Open choke completely. 3. Out of fuel. 3. Fill fuel tank. 4. Spark plug wire 4.
Page 12 PAGE LEFT BLANK INTENTIONALLY...
Page 13: Warranty
All parts, speciﬁ cally EXCLUDING expendable “wear” parts, that be- come unserviceable, due to defective material or workmanship, within one year / 12 months from date of the original retail purchase, shall, at Brown’s option, be repaired or replaced.
Page 14 PAGE 9 Brown is not responsible for and hereby disclaims any undertaking, representation, or warranty made by any dealer, distributor, or other person that is inconsistent with or in any way more expansive than the provisions of this limited warranty.
Page 15 PAGE 10...
Page 16 PAGE LEFT BLANK INTENTIONALLY...
Page 17: Service
PAGE 11 SERVICE 1. ENGINE SERVICE A. See owner’s manual for service, maintenance require- ments and procedures for engine. 2. EDGER SERVICE A. Check all nuts and bolts for proper tightness before initial operation and periodically thereafter. B. Check blade periodically. If worn excessively, replace. C.
Page 18: Parts List
PAGE 12 E-104H EdgeMaster PARTS LIST REF. PART NO. DESCRIPTION REQ. E-100-001 GUARD, BLADE 10” 12-32A TIRE AND WHEEL ASSY. E-100-003 HANDLE ASSY. E-200-002 BELT E-100-005 BLADE, EDGER, 10” E200-029-10 BLADE, EDGER, 10” STAR E200-029-09 BLADE, EDGER, 9” STAR 12-02 HANDLE GRIP E-100-007 LEVER, BELT TENSIONER...
Page 19 PAGE 13...
Page 20 PAGE 14...
Page 21 PAGE 15...
Page 22 PAGE LEFT BLANK INTENTIONALLY...
Page 23: Assembly Instructions
PAGE 16 A S S E M B L Y I N S T R U C T I O N S E D G E M A S T E R M O D E L E – 1 0 4 Refer to references and drawing on pages 11 and 12.
Page 24 PAGE 17 STEP 6 : (cont.) Adjust the control rod ends as necessary to maintain the bottom of the front belt guard to be no less than 3/8” above the ground. (Be sure the idler pul- ley is still not touching the belts.) After adjustment, tighten the lock nuts on the rod ends and the bolts securing the rod ends to the machine.
Page 25 PAGE LEFT BLANK INTENTIONALLY...
