WASP is designed for the Park Flyer Pilot. This durable little plane is affordable, easy to assemble, lightweight, and fun to fly. And best of all, you
can set it up to match your flying skills and interests. The wing can be built with dihedral or flat, and can have ailerons for banking, or just rudder.
It's durable too. The fuselage boom is carbon fiber and the framework is all light-plywood. The wing and tail are lightweight foam that can take a lot
of abuse and are easily repaired if damaged on one of those unexpected meetings with terra-firma. The WASP is what fun park flying is all about:
affordable, low-effort planes that are durable and fun. It's unique, it's customizable, it's the WASP.
Check out our website for more information about other exciting sport flyers by Hobby people products!
ASSEMBLY INSTRUCTIONS
The Sport Flyers by Hobbypeople WASP EP
is sold exclusively in the USA by
Hobby People
8480 Bandilier Circle, Fountain Valley, CA 92708
All contents Copyright © 2006, Hobby People
Version .0 July 2006
Wing span: 42.9 Inches (090mm)
Weight rtf: 6 Ounces (454gr)
functions: Elevator, Rudder, Throttle and Ailerons (Optional)
Motor required: KMS 3/2 Brushless Outrunner
Made in China
WWW.HoBBYpeopLe.net
Full-Function, Four-Channel Electric-Powered Aircraft
●
Carbon Fuselage Boom with Laser-Cut, Factory-Assembled Wood Framework
●
Molded Foam Wing
●
Two-Piece Wing for Easy Transportation
●
Lightweight Foam and Carbon Construction
●
Flies on Many Affordable Power Systems
●
Can Be Setup for 3- or 4-Channel Control (For Training or Aerobatics)
●
Includes all Necessary Hardware
●
Fast and Easy Assembly - Over 75 High-Resolution Digital Photos to Guide You
●
Wing Area: 378 Square Inches (24.4dm
●
Wing Loading: 6. Ounces/Square Foot (9gr/dm
●
radio required: 3-4 Channel or More w/2-4 Micro Servos and Micro Rx
●
esC required: 8Amp Brushless
●

WAsp ep feAtures
2
)
Length: 33 Inches (838mm)
●
2
)
Battery required: 2 Cell 320mAH LiPO
●
Kit product number 160521
Continued

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WASP and is the answer not in the manual?

Questions and answers

Related Manuals for Hobby People WASP

Summary of Contents for Hobby People WASP

  • Page 1 WASP is designed for the Park Flyer Pilot. This durable little plane is affordable, easy to assemble, lightweight, and fun to fly. And best of all, you can set it up to match your flying skills and interests. The wing can be built with dihedral or flat, and can have ailerons for banking, or just rudder.

  • Page 2: Table Of Contents

    GuArAntee Hobby People guarantees this kit to be free from defects in both material and workmanship at the date of purchase. This does not cover any component parts damaged by use, misuse or modification. in no case shall Hobby people's liability exceed the original cost of the purchased kit.

  • Page 3: Customer Service Information

    ABout Your eMAiL Address Hobby People will not disclose the information it collects to outside parties. Hobby People does not sell, trade, or rent your personal information to others . Your privacy is important to us. our reCoMMendAtions This section describes our recommendations to help you in deciding which types of accessories to purchase for your new airplane.

  • Page 4: A Warning About Working With Foam

    The WASP EP comes with a single roll of colored tape. This roll provides enough tape to cover the entire airplane. To liven up your color scheme, you might want to apply a second or even third contrasting color to the airplane.

  • Page 5: Lithium Polymer Battery Warnings - Please Read

    LitHiuM poLYMer BAtterY WArninGs - pLeAse reAd WARNINGS AND SAFETY PRECAUTIONS FOR ALL BRANDS OF LITHIUM POLYMER BATTERIES Please read and understand the warnings listed in this section. Make sure to read any and all warnings included in the packaging with your battery, too. If used improperly, lithium polymer batteries can be very dangerous, so please follow these warnings and suggestions at all times.

  • Page 6: Tools And Supplies Required

    tooLs And suppLies reQuired ❑ 5 Minute Epoxy ❑ Pencil ❑ Foam-Friendly Thin and Thick C/A ❑ T-Pins ❑ # 0 and # Phillips Head Screwdrivers ❑ Builder's Triangle ❑ .5mm Hex Wrench ❑ 220 Grit Sandpaper with Sanding Block ❑...

  • Page 7: Tips From The Pros

    tips froM tHe pros Test-Fitting the Parts: Make sure to test-fit the parts together before applying glue. This will ensure that the parts fit properly before gluing them together. Storage and Transport: We do not suggest storing your airplane in an extremely hot environment (like the back of your car in direct sunlight) for any length of time.
  • Page 8 step 2: instALLinG tHe LAndinG GeAr Wire ❑ Slide the landing gear wire into the mounting slot in the bottom of the wing mounting crutch, making sure that the landing gear wire is straight when viewed from the front. PRO TIP Before gluing the landing gear wire into place in the next procedure, lightly sand the gluing surfaces of the wire to roughen it.

  • Page 9: Stabilizer Installation

    stABiLiZer instALLAtion You'LL need tHe foLLoWinG pArts froM tHe Kit: ❑ (d) Horizontal Stabilizer with Elevator -  ❑ (u) Hinges - 8 ❑ (e) Vertical Stabilizer with Rudder -  ❑ (v) Balsa Triangle Stock - 2 ❑ (i) Plywood Stabilizer Mount -  ❑...
  • Page 10 step 2: tApinG tHe vertiCAL stABiLiZer And tHe rudder ❑ Sand the edges of the vertical stabilizer and the rudder smooth and straight. ❑ Sand a 45º bevel into the right and left sides of the leading edge of the rudder, making sure that the bevels line up along the centerline. ❑...
  • Page 11 ❑ Apply a thin layer of 5 minute epoxy to one half of each hinge, then slide the hinges halfway into the elevator, making sure that the hinges are centered and straight. ☞ Allow the epoxy to set up before proceeding. ❑...
  • Page 12 ❑ When satisfied with the alignment, glue the stabilizer mount to the fuselage stick, using thin C/A. step 6: instALLinG tHe HoriZontAL stABiLiZer ❑ Cut away the colored tape from over the top and bottom of the precut mounting slots in the stabilizer. IMPORTANT Before you glue the stabilizer onto the stabilizer mounting crutch, make sure that you cut away the colored tape from the gluing surfaces.

  • Page 13: Motor Installation

    Motor instALLAtion You'LL need tHe foLLoWinG pArts froM tHe Kit: ❑ (H) Plywood Radio Tray -  ❑ (Z) Rubber Band -  ❑ (L) Plywood Motor Mount -  You'LL need tHe foLLoWinG tooLs And suppLies: ❑ Foam-Friendly Thin C/A ❑...

  • Page 14: Elevator And Rudder Control Systems Installation

    step 3A: instALLinG tHe Motor - KMs BrusHLess outrunner or siMiLAr ❑ Loosen the grub screw from the side of the motor mount, then carefully, but firmly, pull the motor mount off the motor. IMPORTANT Be careful not to damage the motor wires. ❑...
  • Page 15 step 1: instALLinG tHe eLevAtor And rudder servos ❑ Install your servos into the servo tray, making sure that the servo output shafts are toward the front of the airplane. IMPORTANT Depending on the size of your servos, you may need to enlarge the servo mounting holes and/or drill new pilot holes for the servo mounting screws.
  • Page 16 ❑ With both the elevator and the servo arm centered, cut off the pushrod wire 1/8" (3mm) in front of the control horn. ❑ Lightly sand the end of the pushrod wire to roughen the surface, so that the glue will stick to it when you install the clevis. ❑...

  • Page 17: Wing Assembly - Aileron Version

    WinG AsseMBLY - AiLeron version You'LL need tHe foLLoWinG pArts froM tHe Kit: ❑ (A) Right Wing Panel -  ❑ (r) Wood Screws - 6 ❑ (B) Left Wing Panel -  ❑ (s) Plastic Control Horns - 2 ❑...
  • Page 18 step 2: CuttinG out tHe AiLerons ❑ Using a straight edge and a sharp modeling knife, carefully cut out the aileron from each wing panel, using the molded outlines as a guide. ❑ Carefully sand the leading edge of both ailerons round, then sand the edges of the aileron cutouts in the wing panels smooth and straight.
  • Page 19 ❑ Cut away the colored tape from over the top of the aileron servo arms. ❑ Turn the wing panels over and apply colored tape to the top of the wing panels. ☞ Make sure to wrap the colored tape completely around the leading edge of the wing panels, so that it doesn't peel up during flight.

  • Page 20: Wing Assembly - Non-Aileron Version

    WinG AsseMBLY - non-AiLeron version You'LL need tHe foLLoWinG pArts froM tHe Kit: ❑ (A) Right Wing Panel -  ❑ (K) Plywood Wing Joiner (Dihedral) -  ❑ (B) Left Wing Panel -  ❑ (W) Colored Tape -  ❑...
  • Page 21 IMPORTANT When you install the wing joiner channel in the next procedure, make sure that the opening in the wing joiner channel is toward the back of the wing. Also, be careful not to get glue inside the wing channel. ❑...

  • Page 22: Wing Mounting

    WinG MountinG You'LL need tHe foLLoWinG pArts froM tHe Kit: ❑ (W) Colored Tape -  ❑ (Z) Rubber Bands - 4 ❑ (X) Plywood Wing Mounting Plates - 4 ❑ (ZZ) Foam Dihedral Wing Supports - 2 You'LL need tHe foLLoWinG tooLs And suppLies: ❑...

  • Page 23: Final Assembly

    IMPORTANT After installing the wing, look from the front of the fuselage at both the wing and the horizontal stabilizer. The wing should be level with the horizontal stabilizer. If it's not, install a thin shim between the bottom of the low side of the wing and the edge of the wing mounting crutch assembly, so that the wing and the horizontal stabilizer are level.
  • Page 24 IMPORTANT The positions of the airborne equipment shown may differ depending on the particular equipment you use. The final mounting locations will depend on how your model balances. You might want to loosely test-fit your airborne equipment and check the C/G (see next page) before installing your airborne equipment permanently. step 2: instALLinG tHe eLeCtroniC speed ControL ❑...

  • Page 25: Balance Point

    BALAnCe point BALANCE POINT: the Center of Gravity (C/G or Balance point) is 3-1/2" (89mm) back from the leading edge of the wing, measured at the sides of the wing mounting crutch assembly. Balance the airplane right side up with the battery installed. Move the battery forward or aft until the airplane sits level or slightly nose down when you lift it up at the balance point.
  • Page 26 THIS PAGE INTENTIONALLY LEFT BLANK Continued...

  • Page 27: Product Evaluation Sheet

    Do not use staples and make sure our address faces out. Hobby People will not disclose the information it collects to outside parties. Hobby People does not sell, trade, or rent your personal information to others. Your privacy is important to us.
  • Page 28 _______________________________ _______________________________ Post Office will not deliver _______________________________ without proper postage (Return Address Here) Hobby People Attn: Global services 8480 Bandilier Circle Fountain Valley CA 92728-860 fold along dotted line Continued...
