Solar Heat Exchange SHEM40-80SDB-XG Installation And Owner's Manual

Simple drainback domestic hot water solar system with differential control

Advertisement

DOMESTIC HOT WATER SOLAR SYSTEM
WITH DIFFERENTIAL CONTROL
TWO TANK CONFIGURATION
INSTALLATION & OWNER'S MANUAL
The solar energy system described by this manual, when properly installed and maintained,
The solar energy system described by this manual, when properly installed and maintained,
meets the minimum standards established by the Florida Solar Energy Center, in accordance with
product by the Florida Solar Energy Center of the State of Florida.
SHEM-IOMSDB
4/16/13
SIMPLE DRAINBACK
GAS BACK-UP
SHEM40-80SDB-XG
SHEM64-80SDB-XG
80SDB-XG-Suntask 1
80SDB-XG-Suntask 2
80SDB-XG-TPP2-2
80SDB-XG-TPP2-3
80SDB-XG-TPP24-2
80SDB-XG-VHP30-1
80SDB-XG-VHP30-2
endorsement or warranty of this product by SRCC.
"SOLAR MADE SIMPLE"
TWO TANK CONFIGURATION
ELECTRIC BACK-UP
SHEM40-80SDB-XE
SHEM64-80SDB-XE
80SDB-XE-Suntask 1
80SDB-XE-Suntask 2
80SDB-XE-TPP2-2
80SDB-XE-TPP2-3
80SDB-XE-TPP24-2
80SDB-XE-VHP30-1
80SDB-XE-VHP30-2
Solar Heat Exchange Manufacturing
5009 Murray Rd. • Manhattan, KS 66503
www.solarheatexchangemanufacturing.com
(785) 320-5407

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SHEM40-80SDB-XG and is the answer not in the manual?

Questions and answers

Summary of Contents for Solar Heat Exchange SHEM40-80SDB-XG

  • Page 1 The solar energy system described by this manual, when properly installed and maintained, meets the minimum standards established by the Florida Solar Energy Center, in accordance with product by the Florida Solar Energy Center of the State of Florida. Solar Heat Exchange Manufacturing 5009 Murray Rd. • Manhattan, KS 66503 (785) 320-5407 SHEM-IOMSDB www.solarheatexchangemanufacturing.com...
  • Page 2: Table Of Contents

    SHEM Simple Drainback System CONGRATULATIONS! Congratulations on investing in one of the most advanced solar water heating systems available. Utilizing the free, environmentally friendly energy from the sun to heat water for your home makes so much sense. Solar energy is safe and reliable and your decision to use solar energy is helping to preserve our environment and to reduce our rapid depletion of non-renewable, fossil fuels.
  • Page 3: The Simple Drainback System

    SHEM Simple Drainback System TABLE OF CONTENTS CONT’D SYSTEM COMPONENTS SYSTEM COMPONENTS Solar Collectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Solar Collectors ......................
  • Page 4 SHEM Simple Drainback System OVERVIEW OF SYSTEM OPERATIONS pages 17, 18 and 20. 1. AURORA SOLAR COLLECTOR - tor is where the sun’s energy is harvested and is typically mounted on the top of your roof. Water is pumped through exceed temperature and pressure design ranges for the Simple Drainback Systems.
  • Page 5: Installation Instructions

    Safety SYSTEM SAFETY DEVICES Your system contains many protection devices. A pressure-temperature relief valve on the backup hot water tank ensures that the water in the Tank does not over heat or over pressurize. The Simple Drainback Tank enables all the water in the system from freezing even during power outage.
  • Page 6 Safety SAFETY PRECAUTIONS (CONT’D) • controller, or disconnect the power to the circulation pump, and then isolate the solar system utilizing the solar bypass valves. Call your dealer right away for service. Diagrams #1 & #2 detail how to enable and bypass the solar system. Diagram #1 Diagram #2...
  • Page 7: Sizing & Orientation

    The following table details a system sizing guide for a typical residential installation. System Tank Number Collector Model # Capacity (gal) of Collectors Type SHEM40-80SDB-XE SLAR-40 SHEM40-80SDB-XG SHEM64-80SDB-XE SLAR-32 SHEM64-80SDB-XG SHEM80-80SDB-XE SHEM80-80SDB-XG SLAR-40 4’x10’ SHEM120-80SDB-XE SLAR-40 4’x10’ SHEM120-80SDB-XG SHEM160-80SDB-XE SLAR-40 4’x10’...
  • Page 8 Installation Instructions COLLECTOR MOUNTING There are two basic roof-mounting methods: Flush Mount Installation - Parallel to the roof line, as illustrated below. Mounting Bracket Solar Collector Roof Truss Mounting Bracket Figure #1 Flush Mount Installations are recommended when the roof’s slope conforms to the orientation requirements as stated previously.
  • Page 9 Installation Instructions COLLECTOR MOUNTING (CONT’D) Verify a secure connection to the trusses. If lagging directly into the roof trusses is not possible, secure a 2’ x 4’ wood beam perpendicular to the trusses, inside the attic, and anchor the bolts to this member. Again, verify a secure connection into the new member.
  • Page 10 Installation Instructions COLLECTOR MOUNTING 1. Use the Angle Mounting kit SLAR-TM (Picture 5). Connect the U-channels to the roof just like in the Flush Mounting method. Assemble the mounting clips to both U-channels utilizing the provided bolts (Picture 6). Picture 5 Picture 6 2.
  • Page 11: Plumbing

    Installation Instructions COLLECTOR MOUNTING ONT’D 5. Lift the collector’s top with the assembled rod kits and anchor the U-channels to the roof, ensuring the proper angle to the collectors (Picture 10). Picture 10 sembly is not reduced. PLUMBING Penetrations of the building through which piping or wiring is passed shall not reduce or impair the function of the enclo- sure.
  • Page 12 Installation Instructions PLUMBING (CONT’D) Hard copper connections to the city cold water supply line and the home hot water feed lines are recommended. The gas- kets in standard water heater ex hose connectors can become brittle and compressed over time and begin leaking on the water heater.
  • Page 13: Checking For Leaks In The Solar Loop

    Installation Instructions PLUMBING (CONT’D) CHECKING FOR LEAKS IN THE SOLAR LOOP Checking for leaks in the solar loop utilizes ths same proce- dures used by plumbers when checking for leaks in new construction. The solar loop must be isolated. Using a compressor, pressurize the solar loop to 25 lbs.
  • Page 14: Thermometers

    Installation Instructions The T1 temperature sensor (black wire) should be securely fastened to the manifold outlet of the collector. A stainless steel screw clamp should be used (Figure #1). Sensor wire can be extended up to 165 feet with AWG #18 wire and up to 330 feet with AWG #14 wire. The collector wires should be fastened to the T1 wire location on the controller and secured with the wire strain reliever.
  • Page 15: System Start-Up

    Installation Instructions SYSTEM START-UP Throughout the installation procedures outlined above, emphasis has been placed on the correct procedures for plumb- ing and wiring the components and checking for plumbing leaks. Having completed these tasks it is time to start up your Simple Drainback solar water heating system.
  • Page 16: System Operation

    Installation Instructions SYSTEM OPERATION (TWO TANK CONFIGURATION) solar water heating system can (1) provide 100% solar operation during good weather, or (2) serve as a pre-heater to your electric or gas backup water heater adding solar energy when and as available, or (3) 100% on utility power during inclement weather.
  • Page 17 Installation COMPONENTS PARTS LIST AND FUNCTION (TWO TANK CONFIGURA- TION) See the schematics on pages 17 & 18 for the location of the following lists of components. All piping, 1. Solar Collectors - Solene Aurora Collectors SLAR40 4 x 10, or SLAR32 4 x 8 with all copper chrome plated absorber plate.
  • Page 18 1” SWEAT COUPLINGS OR UNIONS SOLAR COLLECTORS (1-5) ON/OFF BUTTON DIFFERENTIAL TEMPERATURE CONTROLLER 120V HOT WATER MG ANODE FLOWMETER PUMP ISOLATION VALVES SOLAR SIMPLE DRAINBACK TANK SENSOR (T2) TANK...
  • Page 19 1” SWEAT COUPLINGS OR UNIONS SOLAR COLLECTORS (1-5) ON/OFF BUTTON DIFFERENTIAL TEMPERATURE CONTROLLER 120V HOT WATER MG ANODE FLOWMETER PUMP ISOLATION VALVES SOLAR SIMPLE DRAINBACK TANK SENSOR (T2) TANK...
  • Page 20: Component Life Expectancy

    Valve life expectancy varies greatly depending on water quality and usage. CONTACT INFORMATION If you have any questions regarding the operation of your system, please contact your installing SHEM dealer. SHEM DEALER CONTACT INFORMATION Solar Heat Exchange Manufacturing 5009 Murray Road Manhattan, KS 66503 (785) 320-5407...
  • Page 21 Installation SIMPLE DRAINBACK OG-300 SYSTEM LABELS The following labels provide the system owner with important safety and operating information. Be sure to cut out the labels below and apply them to the proper system components as described below. Refer to the SHEM DHW System Schematic in this manual for reference numbers.
  • Page 22 SOLAR ENABLED OPEN LOSED Place these labels on Solar Bypass Valves, #18 on system schematic, as detailed in Diagrams #1 and #2 on page 5. 5X7 FREEZE PROTECTION LABEL SOLAR HEAT EXCHANGE MANUFACTURING FREEZE PROTECTION INSTRUCTIONS for models: 120SDB-XE-TPP2-5 80SDB-XG-TPP2-2...
  • Page 23: System Components

    SOLAR HEAT EXCHANGE SIMPLE DRAINBACK TANK All Simple Drainback systems come with an 80 to 120 gallon Simple Drainback Tank. These tanks are a tank within a tank.
  • Page 24: Valves In The System

    System Components VALVES IN THE SYSTEM COLD WATER INLET VALVE – This valve is a conventional gate valve located on the cold inlet to the solar storage tank that allows you to shut o all the water in the tank. This is an EMERGENCY SHUTOFF VALVE — in the event that there happens to be a leak in the tank or the associated hot water plumbing in your house.
  • Page 25: Automatic Differential Control

    System Components AUTOMATIC DIFFERENTIAL CONTROL SHEM32 FOR TWO TANK CONFIGURATIONS – Power to the Solar Pump is controlled by an Automatic Di erential Control that has two temperature sensors. One sensor is located on the outlet of the Solar Collector and the other sensor is located on the Simple Drainback Tank.
  • Page 26: Owner's Information

    Owner’s Information OPERATING SUGGESTIONS A properly designed solar hot water system provides solar energy for approximately 70-90% of your yearly hot water needs. Listed below are some suggestions that you can follow to maximize the bene ts of your solar hot water system. 1.
  • Page 27: Routine Maintenance

    Owner’s Information ROUTINE MAINENANCE There is very little maintenance that your solar system requires. Collectors will usually wash themselves in the rain. If rainfall DO NOT USE ACID OR HARD BRISTLE BRUSHES AND DO NOT POUR COLD WATER ON HOT GLASS. OPERATING PROCEDURES START-UP PROCEDURES The Simple Drainback Installation Instructions give detailed instructions for plumb-...
  • Page 28: Indicators Of Proper Operation

    Owner’s Information OPERATING PROCEDURES (CONT’D) If your Simple Drainback Tank should develop a leak, the whole solar system can be isolated from your home’s water supply by positioning the solar bypass valves as described in diagram #2 on page 5. If your conventional backup hot water tank should develop a leak, the cold-water inlet valve (#13) can be closed.
  • Page 29: Solar Bypass

    Owner’s Information (CONT’D) INDICATORS OF PROPER OPERATION a long cold winter spell, tank temperature (T2) can be as low as the tap water entering the tank (40-55° F). During the summer, T2 could reach 180° F. Collector temperatures (T1) can similarly vary. During T1 can reach 235°...
  • Page 30: Freeze Protection

    Owner’s Information FREEZE PROTECTION Your system is designed to be protected against freeze damage to temperatures as low as -10º F as long as temperatures where the Simple Drainback Tank is located remain above freezing. Freeze tolerance limits are based upon an assumed set of environmental conditions.
  • Page 31 Solar Heat Exchange Manufacturing (the warrantor) will furnish • used in a non-corrosive atmosphere; the ORIGINAL OWNER 1) a replacement SHEM Solar Tank of equivalent size and current model if the porcelain enamel lined •...
  • Page 32 , or with any other dealer handling the warrantor’s products. If this is not practical, the owner should contact: Solar Heat Exchange Manufacturing, 5009 Murray Rd, Manhattan, KS 66503. Phone: 1-888-786-4426 or visit our Model Number ______________________________ website: www.solarheatexchangemanufacturing.com...
  • Page 33 Warranty EAR WARRANTY, PLUS LIFETIME LIMITED WARRANTY Warranty This warranty is issued by SOLENE LLC, 927 Fern Street, Suite1500, Altamonte Springs, Florida 32701, and applies to all new AURORA collectors when purchased for use on residential or commercial water heating applications. SOLENE LLC, war- rants to the original purchaser only that the AURORA collector will be free from defect in materials and workmanship in the manufacturing process under normal use and service for a period of ten (10) years from the date of initial installation when purchased from and properly installed by an AUTHORIZED DEALER within that dealer’s authorized territory.
