Summary of Contents for MountzPro MountzProDT135
- Page 1 MountzPro Digital Flex Head Torque Wrench OWNER’S MANUAL Mountz, Inc. 1080 N. 11th Street San Jose, CA 95112 888-925-2763 www.mountzpro.com...
- Page 2 Wrench Components Digital LCD Display Push Button Handle Socket Release Ratchet Direction Battery Cap Switch Function Panel...
- Page 3 Wrench Torque Ranges & Specifications Torque Ranges Sq. Drive Length Model Item # lbf.ft lbf.in MountzProDT135 MP320000 11-99 132-1198 15 - 135 n. 3/8” 15 3/4” MountzProDT135 MP320000 11-99 132-1198 15 - 135 n. 1/2” 22 3/4”...
- Page 4 Battery 1. Remove screw that secures the 2. Position battery to the correct orientation by 3. Replace end-cap and secure the end-cap of the handle with PH2 following the Positive and Negative markings on screw. screwdriver and remove end-cap. the handle and insert battery. Attention: •...
- Page 5 Digital Display & Functional Panel Unit Selection Battery Indicator Tolerance Red LED Light Value Audible Alert Value Green LED Light Torque Value Set /Save Clear Digital LCD Power on: Press any key for 3 seconds Power off: Auto Shut off after 90 seconds or Hold CLR for 5 seconds...
- Page 6 Setting Torque Wrench : Selecting Units Press UNI to select the desired torque measurement unit Unit: Newton Meters - N.m Unit: Inch Pounds - lbf.in Unit: Foot Pounds - lbf.ft Unit: Kilogram Force Meters - kgf.m...
- Page 7 Setting Torque Wrench : Setting Torque Press SET to change the desired torque value Press the Up or Down arrows to change the target torque value When the desired torque value is reached, press SET to save the value...
- Page 8 Setting Torque Wrench : Setting Alarm Tolerance Press % to change the desired tolerance value Press the Up or Down arrows to change the target tolerance value When the desired tolerance value is reached, press % to save the value...
- Page 9 Tolerance Example If the torque wrench is set to 45 lbf.ft and the tolerance is set at 10%, then an alert tone will occur at 40.5 lbf.ft. There will be a rapid pulsing tone to indicate the torque value is closing to the target value of 45 lbf.ft. LBF.FT Tolerance 10% Rapid Pulsing Tone...
- Page 10 Operating Torque Wrench • Be sure not to apply torque when the wrench has not been powered on. To power on wrench, press and hold any button for 3 seconds. • Use correct size socket for the applied torque load. •...
- Page 11 Warnings • Low Battery -When battery capacity is 30% remaining, the battery icon on the display flashes. The wrench is still usable, however battery should be replaced soon. -When Battery capacity is 10% remaining, the display will only show the battery icon and the wrench will not function. Replace battery.
- Page 12 Mountz, Inc. 1080 N. 11th Street San Jose, CA 95112 888-925-2763 www.mountzpro.com...
