Xycom 1341 User Manual

Embedded node pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1341
Embedded Node PC
Printed in the United States of America
© © © © 2007 XYCOM AUTOMATION, L.L.C.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1341 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Xycom 1341

  • Page 1 1341 Embedded Node PC Printed in the United States of America © © © © 2007 XYCOM AUTOMATION, L.L.C.
  • Page 2 Trademark Information Xycom and Xycom Automation are trademarks of Xycom Automation, L.L.C. Xycom Automation, L.L.C. now is referred to as Pro-face through a D.B.A. The Pro-face name and logo will replace the Xycom name and logo on all documents where possible.

  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1 – INTRODUCTION ..........................1 ...............................1 ENERAL NFORMATION Standard Features ...............................1 .............................3 NPACKING THE YSTEM .................................3 UICK TARTUP CHAPTER 2 — INSTALLATION ..........................4 .............................4 NSTALLATION VERVIEW ..............................7 OUNTING PTIONS Wall Mounting ..............................7 PCI C .............................8 NSTALLATION ..............................10 UMPER ETTINGS JP6: C...

  • Page 4: Chapter 1 - Introduction

    Furthermore, the 1341 series can concurrently support three tiers of expansion interfaces: PCI, PCMCIA and mini-PCI. These interfaces are fully integrated within the 1341 and allow an upgrade to their usefulness.
  • Page 5 1341 Embedded Node PC Chapter 1 – Introduction The figures below show the internal and external components on the front and back panels of the unit to help you locate features relevant to installation. Front Side HDD LED Power LED...

  • Page 6: Unpacking The System

    1341 Embedded Node PC Chapter 1 – Introduction Unpacking the System When you remove the system from its shipping container, verify that you have the parts listed below. Save the box and inner wrapping in the event you need to reship the unit.

  • Page 7: Chapter 2 - Installation

    Chapter 2 — Installation Installation Overview The rugged design of the 1341 unit allows it to be installed in most industrial environments. The system is generally placed in a NEMA 4/4X/12 enclosure to protect against contaminants such as dust, and moisture. Metal enclosures also help minimize the effects of electromagnetic radiation that nearby equipment can generate.
  • Page 8 1341 Embedded Node PC Chapter 2 – Installation Install the unit in the rack or panel in such a way as to ensure that it does not • • • • cause a hazard from uneven mechanical loading Incorporate a readily-accessible disconnect device in the fixed wiring on •...
  • Page 9 1341 Embedded Node PC Chapter 2 – Installation Mechanical Dimensions Note: All dimensions in mm Figure 2-1. Unit Dimensions 144810(C)

  • Page 10: Mounting Options

    Mounting Options Wall Mounting The 1341 is suitable for wall mount using the included brackets and hardware. Secure the bracket to the unit with the 4 screws as shown below. Figure 2-2. Wall Mounting 144810(C)

  • Page 11: Pci Card Installation

    1341Embedded Node PC Chapter 3 – Award BIOS Setup PCI Card Installation Step 1: Unfasten the two screws on the rear panel. Step 2: Unfasten the three screws on the front panel. Step 3: Unfasten the six screws on the bottom lid. Step 4: Remove the screw with your finger (Figure 2-3) and get the PCI card ready to install.
  • Page 12 Figure 2-4 Figure 2-5 Step 7: Close the bottom lid of the 1341 and fasten six screws on the bottom lid. Step 8: Fasten the three screws on the front panel and the two screws on the rear panel. 144810(C)

  • Page 13: Jumper Settings

    1341Embedded Node PC Chapter 3 – Award BIOS Setup Jumper Settings The CPU board has a number of jumpers that allow you to configure your system to suit your application. The table below shows the function of each of the board’s jumpers: Jumper Function ATX Power to AT Function...

  • Page 14: Chapter 3 - Award Bios Setup

    The CMOS memory has lost power and the configuration information has been erased. The 1341 CMOS memory has an integral lithium battery backup for data retention. However, you will need to replace the complete unit when it finally runs down.
  • Page 15 1341Embedded Node PC Chapter 3 – Award BIOS Setup Use this menu for basic system configuration. (Date, time, IDE, etc.) Advanced BIOS Features Use this menu to set the advanced features available on your system. Advanced Chipset Features Use this menu to change the values in the chipset registers and optimize your system performance. Integrated Peripherals Use this menu to specify your settings for integrated peripherals.

  • Page 16: Chapter 4 - Driver Installation

    Chapter 4 – Driver Installation The 1341 comes with the Pro-face Documentation and Support Library CD that contains all drivers and utilities that meet your needs. Pro-face recommends connecting a parallel port or USB CD-ROM drive to the 1341 to install drivers or connecting the host computer to the 1341.

  • Page 17: Windows Xp Reinstallation

    Windows XP (shipped with systems preinstalled with Windows XP). This document is devoted to the reinstallation of your Windows XP operating system and drivers, utilizing the XP CD provided with your Pro-face/Xycom industrial computer. If you want to install a new operating system or reinstall a current operating system, refer to the Windows XP Professional CD-ROM (shipped with systems preinstalled with Windows XP Professional).

  • Page 18: Appendix A - I/O Information

    Appendix A – I/O Information A.1 I/O Address Map 144810(C)
  • Page 19 1341 Embedded Node PC Appendix A – I/O Information A.2 Memory Address Map 144810(C)
  • Page 20 1341 Embedded Node PC Appendix A – I/O Information A.3 IRQ Mapping Chart A.4 DMA Channel Assignments 144810(C)

  • Page 21: Appendix B Technical Specifications

    Appendix B Technical Specifications This section contains the hardware and environmental specifications for the 1341. Hardware Specifications The following table lists the hardware specifications for the 1341. Table B - 1. Hardware Specifications Characteristic Specification Mechanical Height 3.73” (94.75 mm) Width 8.43"...

  • Page 22: Environmental Specifications

    Appendix C – Watchdog Timer C.1 Programming The 1341 utilizes the ITE 8712 chipset as its watchdog timer controller. Below are the procedures to complete its configuration and the AAEON initial watchdog timer program is also attached with which you can develop a customized program to fit your application.
  • Page 23 1341 Embedded Node PC Appendix B – Technical Specifications There are three steps to complete the configuration setup: (1) Enter the MB PnP Mode; (2) Modify the data of configuration registers; (3) Exit the MB PnP Mode. Undesired result may occur if the MB PnP Mode is not exited normally.
  • Page 24 1341 Embedded Node PC Appendix B – Technical Specifications WatchDog Timer Configuration Registers Configure Control (Index=02h) This register is write only. Its values are not sticky; that is to say, a hardware reset will automatically clear the bits, and does not require the software to clear them.
  • Page 25 1341 Embedded Node PC Appendix B – Technical Specifications WatchDog Timer Control Register (Index=71h, Default=00h) WatchDog Timer Configuration Register (Index=72h, Default=00h) WatchDog Timer Time-out Value Register (Index=73h, Default=00h)
  • Page 26 1341 Embedded Node PC Appendix B – Technical Specifications B.2 IT8712 Watchdog Timer Initial Program .MODEL SMALL .CODE Main: CALL Enter_Configuration_mode CALL Check_Chip mov cl, 7 call Set_Logic_Device ;time setting mov cl, 10 ; 10 Sec dec al Watch_Dog_Setting: ;Timer setting...
  • Page 27 1341 Embedded Node PC Appendix B – Technical Specifications MOV CX,04h Init_1: MOV AL,BYTE PTR CS:[SI] OUT DX,AL INC SI LOOP Init_1 Enter_Configuration_Mode ENDP Exit_Configuration_Mode PROC NEAR MOV AX,0202h CALL Write_Configuration_Data Exit_Configuration_Mode ENDP Check_Chip PROC NEAR MOV AL,20h CALL Read_Configuration_Data...
  • Page 28 1341 Embedded Node PC Appendix B – Technical Specifications MOV DX,WORD PTR CS:[Cfg_Port+06h] IN AL,DX Read_Configuration_Data ENDP Write_Configuration_Data PROC NEAR MOV DX,WORD PTR CS:[Cfg_Port+04h] OUT DX,AL XCHG AL,AH MOV DX,WORD PTR CS:[Cfg_Port+06h] OUT DX,AL Write_Configuration_Data ENDP Superio_Set_Reg proc near push ax...
  • Page 29 1341 Embedded Node PC Appendix B – Technical Specifications DW 02Eh,02Fh END Main Note: Interrupt level mapping 0Fh-Dh: not valid 0Ch: IRQ12 03h: IRQ3 02h: not valid 01h: IRQ1 00h: no interrupt selected...
  • Page 30 1341 Embedded Node PC Appendix B – Technical Specifications Index Arm mounting............8 Product specifications Award BIOS setup..........11 environmental ............ 20 BIOS setup............. 11 Reverse side of unit Dimensions system setup............2 mechanical............6 Side view of unit Documentation kit ............ 3 system setup............
  • Page 31 144810(C) Xycom Automation, LLC Customer Support Hotline: 734-994-0482 Phone: 734-429-4971 Web support: http://support.profaceamerica.com Fax: 734-429-1010 Email: support@profaceamerica.com http://www.profaceamerica.com...
