Summary of Contents for Aleph ES-Series
-
Page 2: Connecting The Device
I. CONNECTING THE DEVICE. Before powering up the system make sure to connect the video inputs/outputs, network cable and USB mouse. Refer below for basic connection. 1. ES series connection diagram. 2. PTZ, sensors and relays connection diagram for ES series. RS485 or the AB 3 Relay Connections Connecting Port... - Page 3 II. HOW TO CONNECT THE DVR TO THE NETWORK AND INTERNET. 1. Assigning Network IP Address. DVR must be assigned an IP address, subnet mask and gateway. To know what network settings to use, open Windows command prompt on a pc connected to the same network as the DVR and type ipconfig to get the network status of your existing computer.
- Page 4 2. Port forwarding. To access the DVR over the Internet, user must forward the HTTP port and TCP port. Each router has a unique way of port forwarding some routers call it pin holes or virtual server but all of them will always have a common requirement.
- Page 5 3. DDNS If the public IP address is dynamic meaning it changes from time to time, users would need a dynamic dns service provider, so that the DVR will still be accessible even when the external IP address of the DVR’s network changes.
- Page 6 4.2 64 Channel NVR Client Install the NVR Client Software and add the sites Click Example 1: By Direct IP address Server Name: Any Name IP Address: the direct IP address of the system Port: Service/TCP Port or default on system would be 4000 User Name: Use to login on DVR Password: Use to login on DVR Total Channel: number of cameras...
- Page 7 Click Ok then, click Save to save the sites. After adding the Site Click on ALL button to view the cameras. Click here to connect all cameras...
- Page 8 III. Setting the DVR Schedule Scheduled Recoding RecodingodingReco 1. Manual Record. rding To open the Manual Record menu and enable Scheduled Recording, on the Main Menu select Advance Setup and then click on Manual Record or on the front panel of the DVR press the REC button. On the Manual Record window Highlight “All”...
- Page 9 Then Copy and Paste to the Sunday field Click save and right click the mouse to go back to the main screen...
- Page 10 IV. DVR Search & Backup Procedures Before beginning any backup procedures, make sure to use blank media or a USB drive that is supported by the DVR. The DVR's drive tray will show what type of media it supports, if it shows only CD it mean will only support CD's but if it shows DVD and CD it can support both media.
- Page 11 WARNING: To Prevent Data corrupt and video data loss it is recommended to install the DVR system on UPS (battery backup). Failing to install the system on a battery backup may VOID Warranty Never unplug the AC power from DVR while it’s on and operating. To properly restart or power off the DVR please login as admin and click on Setup, select System Shutdown and on the drop menu select either shutdown or restart.
