INSTALLATION AND OPERATION
Scope
This User Guide covers
2,048 kbits/s E1/PRI and DAB ETI applications.
Part Numbers:
R2D3-ASSY-0326
R2D3-ASSY-0426
R2D3-ASSY-0130
R2D3-ASSY-0431
Document Reference
R2D3-MAN-E102
Publication Date
5 October 2006
Published by
Somerdata Ltd.
Underwood Business Park
Wookey Hole Road, Wells, Somerset, BA5 1AF
UK
Sales & Customer Support
Phone:
Fax:
E-Mail:
Website:
Copyright © 2002 - 2006 Somerdata Ltd.
R
D
2
Data Capture Card
R2D3
Data Capture Card for
+44 (0)1749-671481
+44 (0)1749-671482
sales@somerdata.com
support@somerdata.com
www.somerdata.com
3
R2D3-ASSY-0327
R2D3-ASSY-0427
R2D3-ASSY-0131

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R2D3-ASSY-0326 and is the answer not in the manual?

Questions and answers

Summary of Contents for Somerdata R2D3-ASSY-0326

  • Page 1 Publication Date 5 October 2006 Published by Somerdata Ltd. Underwood Business Park Wookey Hole Road, Wells, Somerset, BA5 1AF Sales & Customer Support Phone: +44 (0)1749-671481 Fax: +44 (0)1749-671482 E-Mail: sales@somerdata.com support@somerdata.com Website: www.somerdata.com Copyright © 2002 - 2006 Somerdata Ltd.
  • Page 2 Data Capture Card This page intentionally blank...
  • Page 3 In no event will SomerData be liable for direct, indirect, special, exemplary, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages.
  • Page 4 Data Capture Card This page intentionally blank Installation and Operation...

  • Page 5: Declaration Of Conformity

    Data Capture Card DECLARATION OF CONFORMITY Name of Manufacturer: Somerdata Ltd. Address of Manufacturer: Somerdata Ltd Underwood Business Park Wells Somerset BA5 1AF United Kingdom Equipment description: PCI Input/Output Card Model: R2D3 Conforms to the following Product Specifications: Safety: IEC 950...
  • Page 6 Data Capture Card SOMERDATA AND THE ENVIRONMENT Introduction SomerData is committed to design and introduce products that conform to applicable environmental legislation and standards. One of our missions is to integrate environmental stewardship into the business of providing quality products, services, and customer support at the best value.
  • Page 7 Somerdata products may be recycled free of charge at any local authority recycling centre as long as the Somerdata logo...
  • Page 8 Data Capture Card This page intentionally blank Installation and Operation...

  • Page 9: Table Of Contents

    N THIS ECTION ’ S IN THIS UIDE UIDE VAILABILITY PRODUCT DESCRIPTION N THIS ECTION NTRODUCTION PPLICABLE ERSIONS E1/PRI C ARDS R2D3-ASSY-0426 R2D3-ASSY-0427 R2D3-ASSY-0326 R2D3-ASSY-0327 DAB/DMB C ARDS R2D3-ASSY-0431 R2D3-ASSY-0131 R2D3-ASSY-0130 ANDLING ARDWARE EATURES NTERFACE BOARD UFFER PPLICATIONS YSTEM EQUIREMENTS LOCK...
  • Page 10 Data Capture Card IGNAL ROUNDING INKS RJ-45 C ONNECTORS NTERFACE DAPTER PTION NTERFACE DAPTER ONFIGURATION NTERFACE DAPTER PECIFICATION E1DT - E1 S 3-10 PLITTER UFFER PTION E1DT S 3-10 IGNAL ONNECTIONS OPERATION N THIS ECTION NPUT UTPUT IGNAL ATHS IGNAL NPUT IGNAL UTPUT...

  • Page 11: Troubleshooting

    OFTWARE EVICE RIVER NSTALLATION REPARATION ROUNDING REPARATIONS ANDLING RECAUTIONS NSTALLATION OFTWARE NSTALLATION SPECIFICATIONS N THIS ECTION R2D3-ASSY-0326 (BNC C ONNECTORS R2D3-ASSY-0426 (BNC C ONNECTORS IGNAL NPUT IGNAL UTPUT R2D3-ASSY-0327 (RJ-45 C ONNECTORS R2D3-ASSY-0427 (RJ-45 C ONNECTORS IGNAL NPUT IGNAL UTPUT...
  • Page 12 Data Capture Card R2D3-ASSY-0130 (BNC C ONNECTORS R2D3-ASSY-0131 (BNC C ONNECTORS R2D3-ASSY-0431 (BNC C ONNECTORS IGNAL NPUT IGNAL UTPUT NPUT UTPUT ITTER TTENUATION PCI I NTERFACE BOARD UFFER HYSICAL YSTEM EQUIREMENTS PPROVALS SUPPORT N THIS ECTION HAT TO DO IF YOU HAVE A PROBLEM ERVICING AINTENANCE AND EPAIRS...

  • Page 13: Introduction

    What’s in this User Guide This User Guide covers the R2D3 PCI Data Capture Card - E1/PRI, Digital Audio Broadcast (DAB) and Digital Multimedia Broadcast (DMB) Ensemble Transport Interface (ETI). Applicable Part Numbers R2D3-ASSY-0326 R2D3-ASSY-0327 R2D3-ASSY-0130 R2D3-ASSY-0131 R2D3-ASSY-0426 R2D3-ASSY-0427 R2D3-ASSY-0431 Section 2 –...

  • Page 14: User Guide Availability

    Programmer’s Reference Guide can be supplied on request. Please contact your local supplier or SomerData for ordering details. Electronic copies (Adobe Acrobat files) are included on the SomerData CD-ROM that is supplied with the original products. The electronic User Guide library, which also includes product data sheets, can be accessed by browsing the \Documents\ folder for the required document.

  • Page 15: Product Description

    Data Capture Card PRODUCT DESCRIPTION In this Section NTRODUCTION PPLICABLE ERSIONS E1/PRI C ARDS R2D3-ASSY-0426 R2D3-ASSY-0427 R2D3-ASSY-0326 R2D3-ASSY-0327 DAB/DMB C ARDS R2D3-ASSY-0431 R2D3-ASSY-0131 R2D3-ASSY-0130 ANDLING ARDWARE EATURES NTERFACE BOARD UFFER PPLICATIONS YSTEM EQUIREMENTS LOCK IAGRAM Installation and Operation...

  • Page 16: Introduction

    Data Capture Card Introduction R2D3 Data Capture Card is designed to provide a real-time data input / output interface for Personal Computers and other compatible platforms. With the appropriate control and application software R2D3 can be used to record, replay and monitor HDB3 (G.703/G.704) 2,048 kbits/s telecommunications and Digital Audio Broadcast signals, with real-time data being transferred to or from disk or host memory.

  • Page 17: Applicable Versions

    Data Capture Card Applicable Versions E1/PRI Cards R2D3-ASSY-0426 • PCI-X compatible • E1/PRI applications • Supports framed (G.704) and unframed (G.703) • 2 x BNC input connectors • 2 x BNC output connectors • Operating Modes: - Single-stream input or single-stream output - Dual-stream input or dual-stream output (subject to software functionality) R2D3-ASSY-0427...

  • Page 18: R2D3-Assy-0326

    Data Capture Card R2D3-ASSY-0326 (replaced by R2D3-ASSY-0436 from September 2006) • PCI 2.1 compatible • E1/PRI applications • Supports framed (G.704) and unframed (G.703) • 2 x BNC input connectors • 2 x BNC output connectors • Operating Modes: - Single-stream input or single-stream output...

  • Page 19: Dab/Dmb Cards

    Data Capture Card DAB/DMB Cards R2D3-ASSY-0431 • PCI-X compatible • DAB/DMB-ETI applications • Supports ETI-NA (G.704) and ETI-NI (G.703) • 2 x BNC input connectors • 2 x BNC output connectors • Operating Modes: - Single-stream input and single-stream output - Two-stream input or two-stream output (subject to software functionality) R2D3-ASSY-0131...

  • Page 20: Data Handling

    Data Capture Card Data Handling For card inputs, R2D3 accepts 2,048 kbits/s HDB3 signals compatible with ITU specifications G.703 and G.704. In telecommunications applications, these signals are referred to as framed and unframed. In DAB applications, these signals are referred to as ETI-NI and ETI-NA. The HDB3 encoded input signals are decoded, buffered and made available to the user’s application software for transfer over the PCI bus.

  • Page 21: Data Interface

    Data Capture Card Data Interface Depending upon the card version, signal connections are via one pair of BNC connectors or one RJ-45 connector for each input/output bitstream. The data interface supports ITU (G.703/G.704) 2,048 kbits/s input and output data transfers. On-board Buffer The card uses on-board memory to buffer data to and from the PCI Bus, with 16 Mbits of SDRAM.

  • Page 22: Data-Flow Block Diagram

    Data Capture Card Data-Flow Block Diagram Installation and Operation...

  • Page 23: Signal Connections

    Data Capture Card SIGNAL CONNECTIONS In this Section IGNAL NTERFACE G.703 R ECOMMENDATION G.703 P ULSE NPUT AND UTPUT MPEDANCE IGNAL NPUT UTPUT ONNECTIONS BNC C ONNECTORS IGNAL ROUNDING INKS RJ-45 C ONNECTORS NTERFACE DAPTER PTION NTERFACE DAPTER ONFIGURATION NTERFACE DAPTER PECIFICATION E1DT - E1 S...

  • Page 24: Signal Interface

    Data Capture Card Signal Interface The signal Interface supports HDB3 encoded 2,048 kbits/s signals in accordance with ITU-T Recommendation G.703. G.703 Recommendation All marks of a valid signal must conform to the mask irrespective of the sign. Pulse shape (nominally rectangular) The value V corresponds to the nominal peak value.

  • Page 25: G.703 Pulse Mask

    Data Capture Card G.703 Pulse Mask Installation and Operation...

  • Page 26: Input And Output Impedance

    On E1 cards, input impedance is software selectable between 75 Ω, 120 Ω and high-impedance (40 kΩ). When using high-impedance (40 kΩ) connections, the recommended maximum cable length is 2 metres. For greater distances, SomerData recommends using a SomerData Splitter/Buffer. Signal Input/Output Connections R2D3...
  • Page 27 Data Capture Card BNC Connectors Connect your signal leads as shown below. The upper pair of connectors are used for Stream A and the lower pair of connectors are used for Stream B. Connections should be made with 75 Ohm coaxial cable. A recommended cable is RG179B/U.
  • Page 28 Data Capture Card Function Comments RJ-45 Stream A Stream B RTIP Card Input RRING Card Input TX Ground TTIP Card Output TRING Card Output RX Ground Not used Not used Installation and Operation...

  • Page 29: Interface Adapter Option

    Data Capture Card Interface Adapter Option In-line adapter connects 75Ω unbalanced BNC Input/Output connections with RJ-45 120Ω balanced circuits. The Interface Adapter requires no power for operation. R2D2-ASSY-0036 Function Comments RJ-45 RTIP RRING TX Ground TTIP TRING RX Ground Not used Not used Installation and Operation...

  • Page 30: Bnc Connectors

    Data Capture Card Interface Adapter Configuration The Interface Adapter is pre-set to work in most applications without additional configuration. The only user-configurable settings are shield connection links between the 75Ω and 120Ω interfaces as shown in the diagram below. 120Ω RJ-45 Connector Alternative Jumper Type JP1 / JP2...

  • Page 31: Interface Adapter Specification

    Data Capture Card To open (break) one or both of the shield connections, proceed as follows. Insert a small flat-bladed screwdriver into the slots on the side of the Interface Adapter and twist. The case will pop open to reveal the jumpers on the circuit board.

  • Page 32: E1Dt - E1 Splitter/Buffer Option

    Data Capture Card E1DT - E1 Splitter/Buffer Option E1DT provides a means of monitoring 2Mbits/s E1/PRI communications links with minimum loading of the line and without the cable-length restriction when using the card’s high- impedance input setting. Line signals are split and fed into a high-impedance buffer, which drives a low impedance output to the monitoring equipment.

  • Page 33: Operation

    Data Capture Card OPERATION In this Section NPUT UTPUT IGNAL ATHS IGNAL NPUT IGNAL UTPUT IGNAL UTPUT UTPUT EPLAY LOCK ELECTION LED S TATUS NDICATORS LED I NDICATOR UNCTIONS UFFER HRESHOLD RIGGER NPUT IGNAL ONNECTING TREAMS OINT OINT ONNECTIONS ERMINATED NPUTS ERMINATED NPUT AND...

  • Page 34: Input/Output Signal Paths

    Data Capture Card Input/Output Signal Paths Signal Input The input signals are routed to the output except when the card is set for output data transfers, or the input connection has been disabled in software. R2D3 card Input Output (Downstream Monitor) Output Input (Downstream Monitor)

  • Page 35: Output (Replay) Clock Selection

    Data Capture Card Signal Output Output (Replay) Clock Selection The data capture card requires a reference clock in order to output data stream(s), The use of an external 2,048kbits/s (E1 or DAB) signal will ensure that the output signal will be synchronised with the external source.

  • Page 36: Led Status Indicators

    Data Capture Card LED Status Indicators Six status LED indicators are located on the card’s input/output panel as shown below. LED Indicators R2D3-ASSY-0326 R2D3-ASSY-0327 R2D3-ASSY-0130 R2D3-ASSY-0427 R2D3-ASSY-0131 R2D3-ASSY-0426 R2D3-ASSY-0430 R2D3-ASSY-0431 Installation and Operation...

  • Page 37: Led Indicator Functions

    Data Capture Card LED Indicator Functions Card is powered and has passed self-test Stream A - Buffer threshold trigger Stream A - Input Signal Loss Stream B - Input Signal Loss Stream B - Buffer threshold trigger Not used Buffer Threshold Trigger The Buffer Threshold LEDs will light when the amount of data in the buffer is above (input data transfers) or below (output data transfers) the threshold point.

  • Page 38: Connecting Data Streams

    Data Capture Card Connecting Data Streams Connections with signal sources will vary according to the application. Some typical examples are shown below. Point-to-Point Connections Terminated Inputs 75 Ω unbalanced or 120 Ω balanced depending on R2D3 card version. must be used where there is an Interface Adapter impedance mismatch between the signal source and R2D3...

  • Page 39: Terminated Input And Output

    Data Capture Card Terminated Input and Output 75 Ω unbalanced or 120 Ω balanced depending on R2D3 card version. must be used where there is an Interface Adapter impedance mismatch between the signal source and R2D3 card terminations. Signal Source A Signal Source B E1 Exchange, E1 Exchange,...

  • Page 40: Non-Intrusive Connections

    Non-Intrusive Connections Tee Connection R2D3 card should be set to High Impedance (40 kΩ). The recommended maximum cable length is 2 metres. For greater distances, SomerData recommends using a SomerData Splitter/Buffer. E1 Exchange, Switch or DAB Multiplexer Stream B input...

  • Page 41: Monitor Connection

    R2D3 card to High Impedance for signal level compatibility. The recommended maximum cable length is 2 metres when using high-impedance connections. For greater distances, SomerData recommends using a SomerData Splitter/Buffer. Stream B input Exchange R2D3 Card...

  • Page 42: Signal Output Examples

    Data Capture Card Signal Output Examples “Off-Line” Data Analysis “Real-Time” Signal Source In addition to replaying previously captured data for off- line analysis, R2D3 can be used as a source of “real- time” signals to support product development and testing. The source signals can be previously recorded or generated data files.

  • Page 43: Frame Synchronisation

    Data Capture Card FRAME SYNCHRONISATION In this Section E1 (G.703/G.704) F RAME ECOGNITION LIGNMENT APTURING RAME RRORS DAB ETI-NI/ETI-NA F RAME RECOGNITION LIGNMENT G.704 F RAMED TRUCTURE Installation and Operation...

  • Page 44: E1 (G.703/G.704) Frame Recognition

    Data Capture Card E1 (G.703/G.704) Frame Recognition Card versions: R2D3-ASSY-0326 (BNC connectors) R2D3-ASSY-0327 (RJ-45 connectors) R2D3-ASSY-0426 (BNC connectors) R2D3-ASSY-0427 (RJ-45 connectors) R2D3 cards provide frame synchronisation support for ITU (G.703/G.704) signals as described below. When set to UNFRAMED, incoming data will be transferred to the buffer as soon as START has been commanded.

  • Page 45: Word Alignment

    Data Capture Card Word Alignment Word alignment is only implemented when the card is set for FRAMED data. The effect of this feature is to place the frame alignment word into the first Byte of the word that is passed to the processor.

  • Page 46: Dab Eti-Ni/Eti-Na Frame Recognition

    Data Capture Card DAB ETI-NI/ETI-NA Frame recognition Card versions: R2D3-ASSY-0130 (before September 2003) R2D3-ASSY-0131 (from September 2003) R2D3-ASSY-0431 For ETI-NI signals, incoming data will only be transferred to the buffer once three consecutive ETI-NI (G.703) frame sync words have been received (073AB6 For ETI-NA signals, incoming data will only be transferred to the buffer once three consecutive ITU (G.704) frame sync words have been received (S0011011...

  • Page 47: Word Alignment

    Data Capture Card Word Alignment The effect of word-alignment is to place the DAB G.703 frame sync word (ETI-NI) or ITU G.704 frame alignment word (ETI-NA) into the first Byte of the word that is passed to the processor. It is assumed that the little-endian format is used (this is typical for all Intel PCs).

  • Page 48: G.704 Framed Data Structure

    Data Capture Card G.704 Framed Data Structure All versions of the card synchronise to framed E1/PRI (ITU-T G.703/G.704) input signals with the following data structure. The bitstream should consist of 32 byte frames containing a Frame Alignment Synchronising Byte (FAS) in every other frame with an appropriate alternate (NFAS) Byte in other frames.

  • Page 49: Troubleshooting I N This Section

    (BNC C IGNAL ROUNDING PTIONS ROUNDING INKS Checking Input Signal Status and Card Operation Six status LED indicators are located on the card’s input/output panel as shown below. LED Indicators R2D3-ASSY-0326 R2D3-ASSY-0327 R2D3-ASSY-0130 R2D3-ASSY-0427 R2D3-ASSY-0131 R2D3-ASSY-0426 R2D3-ASSY-0430 R2D3-ASSY-0431 Installation and Operation...

  • Page 50: Buffer Threshold Trigger

    Data Capture Card Input Signal Loss The Signal Loss LEDs will light when the input signal contains more than 175 consecutive zeros. Stream A - Input Signal Loss Stream B - Input Signal Loss Buffer Threshold Trigger The Buffer Threshold LEDs will light when the amount of data in the buffer is above (input data transfers) or below (output data transfers) the threshold point.

  • Page 51: Programming Link

    Data Capture Card Programming Link The link is located at the centre of the main board as shown below. Programming link (PL3) Signal Grounding Options (BNC Card) Only applies to cards with BNC connectors. The card’s default settings are in accordance with ITU G.703. Input screens are not connected to ground (no links fitted).
  • Page 52 Data Capture Card This page intentionally blank Installation and Operation...

  • Page 53: Installation

    Data Capture Card INSTALLATION In this Section INIMUM YSTEM EQUIREMENTS HAT YOU RECEIVED ECORDER AND EPLAYER OFTWARE EVICE RIVER NSTALLATION REPARATION ROUNDING REPARATIONS ANDLING RECAUTIONS NSTALLATION OFTWARE NSTALLATION Installation and Operation...

  • Page 54: Minimum System Requirements

    Data Capture Card Minimum System Requirements Below are the minimum recommended host PC requirements for operating the R2D3 card with SomerData Recorder Replayer application software. Customer-developed application software may require alternative configurations. • Single-processor system • Pentium™ IV processor 2GHz •...

  • Page 55: What You Received

    Different card versions may have a similar appearance so it is very important to check the part number and input / output connector labelling before use. BNC Connectors RJ-45 Connectors R2D3-ASSY-0326 R2D3-ASSY-0327 R2D3-ASSY-0130 R2D3-ASSY-0427 R2D3-ASSY-0326 R2D3-ASSY-0426 R2D3-ASSY-0431...

  • Page 56: Recorder And Replayer Software

    E1DT-ASSY-0029 - E1 Splitter/Buffer option Ω Ω option option R2D2-ASSY-0036 - Interface Adapter (75 - 120 Recorder and Replayer Software If your order included SomerData Recorder and/or Replayer application software, please refer to the Software Installation User Guide. Installation and Operation...

  • Page 57: Device Driver Installation

    Data Capture Card Device Driver Installation If your order included SomerData Recorder, Replayer and/or Monitor application software, the R2D3 Device Driver installer should be run before installing the R2D3 card. Please refer to the Software Installation User Guide for the R2D3 Device Driver installation procedure.

  • Page 58: Handling Precautions

    Data Capture Card Handling Precautions • Never slide cards or other parts over any surface • Avoid static-causing surfaces, such as plastic and polystyrene, in your work area • Remove the R2D3 card from its anti-static packing only when you are ready to use it •...

  • Page 59: Software Installation

    Data Capture Card Software Installation If your order included SomerData Recorder, Replayer and/or Monitor application software, please refer to the Software Installation User Guide. Installation and Operation...
  • Page 60 Data Capture Card This page intentionally blank Installation and Operation...

  • Page 61: Specifications

    Data Capture Card SPECIFICATIONS In this Section R2D3-ASSY-0326 (BNC C ONNECTORS R2D3-ASSY-0426 (BNC C ONNECTORS IGNAL NPUT IGNAL UTPUT R2D3-ASSY-0327 (RJ-45 C ONNECTORS R2D3-ASSY-0427 (RJ-45 C ONNECTORS IGNAL NPUT IGNAL UTPUT R2D3-ASSY-0130 (BNC C ONNECTORS R2D3-ASSY-0131 (BNC C ONNECTORS R2D3-ASSY-0431 (BNC C...

  • Page 62: R2D3-Assy-0326 (Bnc Connectors )

    <100ns using internal clock and <32ns using clock recovered from an external E1/HDB3 signal When using high-impedance (40 kΩ ) connections, the recommended maximum cable length is 2 metres. For greater distances, SomerData recommends using a SomerData Splitter/Buffer. Installation and Operation...

  • Page 63: R2D3-Assy-0327 (Rj-45 Connectors)

    <100ns using internal clock and <32ns using clock recovered from an external 2,048kbits/s signal When using high-impedance (40 kΩ ) connections, the recommended maximum cable length is 2 metres. For greater distances, SomerData recommends using a SomerData Splitter/Buffer. Installation and Operation...

  • Page 64: R2D3-Assy-0130 (Bnc Connectors)

    Data Capture Card R2D3-ASSY-0130 (BNC Connectors) R2D3-ASSY-0131 (BNC Connectors) R2D3-ASSY-0431 (BNC Connectors) Signal Input Signal Interface: G.703, 2,048 kbits/s Pulse shape: As ITU-T G.703 pulse mask Line code: HDB3 Data type: ETI-NA (G.704) ETI-NI (G.703) 75 Ω unbalanced Input impedance 1: Input sensitivity: -13.6dB ±2.37 V into 75 Ω...

  • Page 65: Input/Output Jitter Attenuation

    PCI board designed to fit a standard PC slot. The card is 174 mm long, 106 mm high and all components fit within the 19 mm form width of the PC I/O panel BNC connectors (R2D3-ASSY-0326, R2D3-ASSY-0426, R2D3-ASSY-0130, R2D3-ASSY-0131 and R2D3-ASSY-0431) or RJ-45 connectors (R2D3-ASSY-0327 and R2D3-ASSY- 0427) are mounted on the card’s input/output panel.

  • Page 66: System Requirements

    Data Capture Card System Requirements Minimum recommended host PC requirements for operating the R2D3 card with SomerData Recorder Replayer application software. Customer-developed application software may require alternative configurations. • PCI 2.1 or PCI-X, depending on version (see above) • 1 Free PCI slot •...

  • Page 67: Support

    Also, check the Troubleshooting section (where appropriate) to eliminate common problems. Servicing, Maintenance and Repairs Please contact your supplier or SomerData for all questions relating to maintenance and repairs. Any unauthorised attempt to open, modify or otherwise repair the product will invalidate the SomerData warranty and may result in the product being left in an irreparable condition.

  • Page 68: If You Need Support

    SomerData product is covered by warranty, extended warranty or maintenance contract. At SomerData, we will make our best efforts to provide prompt and friendly support by phone, fax and e-mail. However, please do not expect us to be magicians or mind-...

  • Page 69: Support Requests

    Data Capture Card Support Requests When contacting SomerData for support, please provide as much information as possible about the problem or issue for which you require assistance. We will be able to deal with your request more efficiently if you...

  • Page 70: Returns

    Data Capture Card Returns Please do not return any products to SomerData without first contacting SomerData and obtaining a Return Merchandise Authorisation (RMA) Number. This will ensure that the processing of any repair or upgrade is handled efficiently and in accordance with any agreed action.

  • Page 71: End-Of-Life Disposal

    Data Capture Card End-of-Life Disposal Your SomerData product may be returned to SomerData at the end of its life at the customer's expense, under the EU regulations on waste from electrical and electronic equipment legislation; provided that the product is free from radiation or biological contaminants and that no other legislation forbids the return.
  • Page 72 Data Capture Card This page intentionally blank Installation and Operation...

  • Page 73: Index

    Data Capture Card INDEX Applicable Versions ................2-3 Applications ..................2-7 Approvals ..................... 8-6 Block Diagram ..................2-8 BNC Connectors................... 3-5 Buffer Threshold Trigger............... 6-2 Buffer Threshold Trigger Status............4-5 Checking Input Signal Status and Card Operation ....... 6-1 Connecting Data Streams High-Impedance ................
  • Page 74 Data Capture Card G.703....................3-2 G.703 Pulse Mask ................3-3 G.704 Framed Data Structure .............. 5-6 Grounding Links ................3-5, 6-3 Hardware Features................2-6 High-Impedance Connections .............. 4-8 Indicator LEDs ..................4-4 Input Signal Loss .................. 6-2 Input Signal Loss Status............... 4-5 Input/Output Connector Options E1DT - E1 Splitter/Buffer ..............
  • Page 75 Programming Link ................6-3 R2D2-ASSY-0036 Interface Adapter (75Ω - 120Ω) ......3-7 R2D3-ASSY-0130 ................. 2-5, 8-4 R2D3-ASSY-0131 ................. 2-5, 8-4 R2D3-ASSY-0326 ................. 2-4, 8-2 R2D3-ASSY-0327 ................. 2-4, 8-3 R2D3-ASSY-0426 ................. 2-3, 8-2 R2D3-ASSY-0427 ................. 2-3, 8-3 R2D3-ASSY-0431 ................. 2-5, 8-4 RJ-45 Connectors.................
  • Page 76 Input/Output Jitter Attenuation ............8-5 Jitter....................8-5 PCI Interface..................8-5 Physical .................... 8-5 R2D3-ASSY-0130 ................8-4 R2D3-ASSY-0131 ................8-4 R2D3-ASSY-0326 ................8-2 R2D3-ASSY-0327 ................8-3 R2D3-ASSY-0426 ................8-2 R2D3-ASSY-0427 ................8-3 R2D3-ASSY-0431 ................8-4 System Requirements ..............8-6 Status Indicator LEDs................4-4 Support ....................
