Summary of Contents for WerkMaster Stealth
- Page 1 OPERATOR’S MANUAL IMPORTANT: Read before using your new WerkMaster Burnisher WerkMaster Grinders and Sanders Inc. 6932 Greenwood Street, Burnaby, BC V5A 1X8 tel: 604.629.8700 | toll free: 1.866.373.WERK | fax: 604.444.4231 www.werkmaster.com | email: support@werkmaster.com...
- Page 2 WerkMaster will not in any event be liable to the user, any successors in interest or any beneficiary or assignee relating to this sale for any...
-
Page 3: Table Of Contents
Changing the Engine Dust Filter................29 Maintaining the Cooling Fin.................29 Inspecting and Changing the Pad and Pad Holders..........30 Maintaining the Belt.....................30 Maintaining the Battery..................31 Adjusting the Wheels...................32 Cleaning the Dust Bag STEALTH ONLY..............32 Maintenance Schedule..................33 Troubleshooting....................34 Limited Warranty....................36 Warranty.......................37 Safety Awareness Form for Propane Machines..........39... -
Page 4: Introduction
This manual is provided to assist you in the operation and maintenance of your WerkMaster machine. WerkMaster is dedicated to our customers, their safety, and to providing information, services, and products that meet their needs. IMPORTANT Read this manual and all safety precautions before attempting to operate or perform service on your WerkMaster machine. -
Page 5: Machine Descriptions
MACHINE DESCRIPTIONS WerkMaster Propane Burnishers include the Stealth and the Spectre models. The WerkMaster family of machines include the Scarab, Termite XT, Viper XT, Raptor XT, TITAN XT and the COLOSSOS XT models. To see the complete family of WerkMaster machines, informational videos, tooling guide, chemicals and accessories visit our website at www.werkmaster.com. -
Page 6: Safety Precautions
This machine is manufactured for commercial use only. This machine is designed and manufactured for indoor use in burnishing hard floor surfaces. WerkMaster does not recommend use of this machine in any environment other than an indoor environment. The machine is... - Page 7 ‣ Prolonged or high exposure to CO may result in vomiting, confusion, and collapse in addition to loss of consciousness and muscle weakness. If such symptoms occur, call 911 for emergency medical attention. If you have experienced these symptoms DO NOT operate this machine or any other propane machine until cleared by a physician.
-
Page 8: Warning
DO NOT tamper with the original emission related parts. Tampering with the Emission Control System is prohibited and will VOID THE WARRANTY. WARNING WARNING indicates injury may occur to you or other persons if safety precautions are ignored or are not adhered to. Read and observe all WARNING statements found in the Operator’s manual and on the machine. -
Page 9: Operator Responsibilities
Wear eye and ear protection when using pressurized air or water. Disconnect battery connections before servicing machine. Only use replacement parts supplied by WerkMaster or a WerkMaster Authorized Distributor or Service Center. DO NOT operate this machine before carefully reading and understanding Operator the operation manual. -
Page 10: Propane Safety Information
DO NOT tamper with the tank gauges or safety relief valves. NEVER use a tank not intended for use with a propane burnisher. DO NOT substitute tanks that are used with a barbecue grill, etc. WerkMaster recommends having propane tanks tested once a year by an authorized National LP Gas Association propane dealer. -
Page 11: Filling Propane Tanks
UL. In addition, the steel cylinder meets meets European TPED specifications and is CE compliant. The engine and the fuel system on your WerkMaster machine are designed to run on vapor propane NOT liquid propane. Liquid propane and vapor propane are NOT interchangeable. Interchanging the fuel will VOID THE WARRANTY. -
Page 12: Storing Propane Tanks
Propane tanks should NOT be stores in buildings used by employees, the Storing Propane public or frequented by anyone passing through. Tanks When not in use tanks should always be stored outside in an upright position in a secure, tamper-proof, steel mesh storage cabinet. The cabinet may be located next to the building, but with at least five (5) feet (1.5 m) of space between the cabinet and the nearest building opening (door or window). -
Page 13: Engine Emissions And Carbon Monoxide Safety
ENGINE EMISSIONS AND CARBON MONOXIDE SAFETY DANGER All engines powered by by LPG (Liquid Propane Gas), including this engine, Carbon Monoxide (CO). it is a FATAL POSION gas that is colorless, odorless, tasteless, and non-irritating. It is produced by incomplete combustion of carbonaceous material such as LPG. -
Page 14: Machine Components
CO Safety Equipment Available WerkMaster propane machines are equipped with a catalytic muffler and an ACCU-Sense monitoring system on the Stealth and an AUTO-Sense monitoring system on the Spectre to reduce the CO emissions and promote a safer work environment. -
Page 15: Engine Ignition Switch
The STEALTH and SPECTRE feature a key switch ignition. Engine Ignition Switch For the STEALTH: START: Turn the key clockwise to START to engage the engine starter • motor. Once the engine starts release the key. ALWAYS start the machine with the bail throttle in the SLOW IDLE position. -
Page 16: Stealth Accu-Sense Emissions Monitoring System
The engine throttle controls the engine speed. To increase the engine speed, move the hand lever forward. For the idle position pull the lever back. The Stealth ACCU-Sense is an emissions monitoring device that monitors STEALTH the exhaust emissions and will shut the engine down if the emission levels ACCU-Sense are too low or too high. - Page 17 OIL: The light will come on when there is low oil pressure. If the engine looses oil pressure, the engine shuts down until the condition is corrected. The light comes on each time the engine is stopped. TILT/IDLE: The light will come on when the machine is tilted to the pad change position and the engine shuts down.
-
Page 18: Spectre Auto-Sense Emissions Monitoring System
Engines tend to go to a lean burn if allowed to idle for even short periods. Even at high idle speeds most engines will continue to lean downward. it is always best to shut the engine off when it is not being used to do work. Remember, the engine is always creating emissions as long as it is running. -
Page 19: Hour Meter/Tachometer
ON. The hour meter reading is used to mark the Tachometer recommended maintenance intervals. It also displays the engine speed. The meter displays hours when the machine is turned OFF and the engine speed when the machine is turned ON. STEALTH SPECTRE OPERATOR’S MANUAL... -
Page 20: Ez Bak Tilt Operation
The handle on both the STEALTH and the SPECTRE is designed to be EZ Bak Tilt positioned upright to allow for the machine to be tilted back. Operation STEALTH SPECTRE For the STEALTH: 1. Close the valve on the propane tank. Allow the engine to stop and turn the machine OFF. -
Page 21: Fuses
The machine’s electrical circuit is protected by fuses Fuses ‣ STEALTH: a 20A and a 7.5A, ‣ SPECTRE: a 20A which stop the flow of current in the event of a circuit overload. Once a fuse blows, it must be replaced. If the overload that caused the fuse to fail is still present, the new fuse will fail. -
Page 22: Machine Operation
Before using any type of power equipment, proper safety dictates that you should check the machine. Checklist 1. Adjust the handle of the STEALTH to a comfortable height by turning the knobs, positioning the handle and tightening the bolts. Adjust the handle of the SPECTRE by loosening the handle adjustment lever on the side of the handle, positioning and tightening the lever. -
Page 23: Starting The Machine
Opening quickly may cause the flow check valve to engage, limiting fuel flow. For the STEALTH: 1. Allow machine to tilt backward (pad off floor). 2. With the bail throttle in the IDLE position, engage the starter by turning the ignition key switch to the starting position for approximately 5 seconds. -
Page 24: Burnishing
30 seconds. If the engine refuses to start see the Troubleshooting Guide page 34.ƒ For both the STEALTH and SPECTRE: It is recommended to start burnishing on the right side of the aisle, turn and come back down the aisle in the opposite direction, overlapping the previous path slightly. -
Page 25: Idling And Stopping The Machine
For the SPECTRE: 1. After the engine has started, allow approximately 30 seconds for the engine to warm up. Once the engine has started the pads begin to spin. 2. Advance the engine throttle to operating speed. 3. Lower the burnishing head to the floor, gently squeeze either clutch lever. -
Page 26: Changing The Oil
3. Turn off the propane tank and and remove it. 4. Clean the area around the oil gauge before removing it. Remove the oil gauge and wipe it with a clean cloth. STEALTH SPECTRE 5. Insert the oil gauge into the tube. DO NOT tighten the oil gauge. -
Page 27: Replacing The Oil Filter
STEALTH SPECTRE 4. Place a suitable container under the end of the oil drain hose. 5. Slowly turn the valve counter-clockwise until the oil starts to drain. In order for the oil to drain, it may be necessary to loosen the oil fill cap. -
Page 28: Inspecting And Replacing The Spark Plug
Inspecting and 1. Push the machine to level surface. Replacing the Air 2. Turn off the propane tank and remove it. Filter For the STEALTH ONLY: 3. Remove the hood to allow the filter cover to be removed. OPERATOR’S MANUAL... -
Page 29: Inspecting And Replacing The Fuel Hose
For both the STEALTH and SPECTRE: 4. Turn the two knobs a 1/4 turn counter-clockwise and remove the filter cover. 5. Loosen the clamp that retains the filter and remove the air filter. STEALTH SPECTRE 6. Inspect both primary and secondary air filters. If necessary, clean primary filter by lightly tapping and wiping seal ends with a clean cloth. -
Page 30: Changing The Engine Dust Filter
Engine Dust Filter can also be vacuumed with a wet/dry vacuum. 2. Squeeze out the excess water. DO NOT wring. Allow the filter to air dry. STEALTH SPECTRE CAUTION Failure to maintain a clean engine filter will cause the engine to overheat. -
Page 31: Inspecting And Changing The Pad And Pad Holders
5. Inspect the pad holder for cracks or damage. If the pad holder does not have any damage proceed to Step 9. For both the STEALTH and SPECTRE: 6. If the pad holder needs to be removed, a 3/4 in wrench will be required. -
Page 32: Maintaining The Battery
6. To check for the proper tightness, squeeze the belt together. The belt should depress between 1/4 in (6 mm) and 1/2 in (13 mm). To change the belt: 1. Remove the pad holder by holding the end of the shaft on the top of the machine with a 3/4 in wrench and turn the pad holder counter- clockwise. -
Page 33: Adjusting The Wheels
Cleaning the 1. Remove the dust bag cover by lifting upward on the back of the cover. Dust Bag STEALTH ONLY 2. Pull dust bag downward off the dust tube by holding at the front pulling down and to the rear to remove. -
Page 34: Maintenance Schedule
As required As required As required As required * Check FS481V Service Manual. Contact WerkMaster at * Check FS481V Service Manual. Contact WerkMaster at * Check FS481V Service Manual. Contact WerkMaster at * Check FS481V Service Manual. Contact WerkMaster at * Check FS481V Service Manual. -
Page 35: Troubleshooting
TROUBLESHOOTING POSSIBLE CAUSE SOLUTION PROBLEM Propane tank is not properly connected. Check connection and open service valve slowly. Engine is hard to start Engine is hard to start Engine is hard to start Engine is hard to start Engine is hard to start Engine is hard to start Engine is hard to start Battery is weak. - Page 36 POSSIBLE CAUSE SOLUTION PROBLEM Smell of burned Belt out of adjustment. Check the automatic tensioner. rubber. Machine vibrates. Machine vibrates. Machine vibrates. Loose fasteners. Check the engine, tensioner, spindle and pad holder fasteners. Tighten any fasteners that are loose. Pad is not centered on the pad holder. Remove pad and re-center on pad holder.
-
Page 37: Limited Warranty
2) The valve trail is warranted by WerkMaster for one (1) year. 3) The Stealth 21” and 28” and Spectre 21” and 28” models will be warranted to be free from defects in material and workmanship for a period of one (1) year from the date of purchase by the original owners. -
Page 38: Warranty
Kawasaki motor, shall carry the accessory manufacturer’s own warranty. WerkMaster will, at its option, repair or replace, at the WerkMaster or a Terms & Conditions point designated by WerkMaster, any part which shall appear to the satisfaction of WerkMaster inspection to have been defective in material or workmanship. - Page 39 Seller’s delayed performance in shipment and delivery. Shipping of goods and/or products to and/or from WerkMaster or a WerkMaster representative is the sole responsibility of the Purchaser and is not covered under the terms of this warranty.
-
Page 40: Safety Awareness Form For Propane Machines
C. Clean air filter Cautions: A. Allow only qualified, trained personnel to operate this machine. B. Use only DOT approved propane tanks supplied by WerkMaster or an Authorized WerkMaster Distributor. C. ALWAYS store propane tanks outside in a proper enclosure.
