Installation & Service Manual
5-Stage Reverse Osmosis Drinking Water System
WQA GOLD SEAL:
This System Conforms to (WQA S-300) for the reduction of TDS, Pen-
tavalent Arsenic, Barium, Cadmium, Chromium +6, Chromium +3, Cop-
per, Fluoride, Lead, Radium (226/228), Selenium and Turbidity as veri-
fied and substantiated by test data.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Proline Gold
Summary of Contents for Proline Gold
- Page 1 Installation & Service Manual 5-Stage Reverse Osmosis Drinking Water System WQA GOLD SEAL: This System Conforms to (WQA S-300) for the reduction of TDS, Pen- tavalent Arsenic, Barium, Cadmium, Chromium +6, Chromium +3, Cop- per, Fluoride, Lead, Radium (226/228), Selenium and Turbidity as veri-...
- Page 2 ® Congratulations on choosing the PROLINE ® 5-Stage Reverse Osmosis (RO) Drinking Water System This high quality unit has been designed to fit under most kitchen and wet-bar sinks. We suggest that you carefully review the following information booklet before you attempt to install the reverse osmosis system.
- Page 3 INSTALLATION DIAGRAM FOR PROLINE GOLD SYSTEM 3/8” red tubing to drain clamp (Fig. 1) 1/4” red tubing from flow restrict to air gap WARNING: CONNECT YOUR SYSTEM TO THE COLD WATER SUPPLY ONLY. DO NOT USE WATER SUPPLY THAT IS MICRO-BIOLOGICALLY UNSAFE, OR OF UNKNOWN SOURCE WITHOUT ADEQUATE DISINFECTION BEFORE OR AFTER THE SYSTEM.
- Page 4 ¼’’ Red Tubing (approximately 6 feet) 3/8’’ Yellow Tubing (approximately 6 feet) 3/8’’ Blue Tubing (approximately 6 feet) 3/8” Red Tubing (approximately 5 feet) Note: The color coded tubing matches the color coded plugs on the PROLINE RO unit. color tubing ® 2. SV-01:...
- Page 5 TAPPING INTO THE COLD WATER LINE A - (Using the water supply adaptor Part # AD-4BC-3W & BV-2BC) For flex metal or plastic line. NOTE: The Proline drinking water system must be connected to the COLD water ® supply only.
- Page 6 Valve handle Brass nut Brass insert NOTE: All local plumbing codes must be followed to ensure proper installation and use of your PROLINE system. ® NOTE: Use brass insert and plastic ferrule when connecting tubing to saddle valve. Cold Water Supply Valve (Figure #3)
- Page 7 DRILLING THE HOLE FOR THE FAUCET NOTE: SAFETY GLASSES SHOULD BE WORN TO PROTECT YOUR EYES WHILE DRILLING THE FAUCET WHOLE. 1) For best results, a 7/8” drill bit should be used to drill a hole into your sink for the auxiliary faucet.
-
Page 8: Mounting The Faucet
MOUNTING THE FAUCET Air Gap Faucet (Optional) 1) Drill a 7/8” hole in the sink or the counter top, or use an (Fig. 4 B) existing hole. 2) Slide chrome cover plate and rubber gasket on to stem of faucet and place faucet onto sink, with the stem going through the hole. -
Page 9: Positioning The System
See page 2 for connection diagram on color coded tubing. EZ FITTINGS- QUICK CONNECT Your PROLINE reverse osmosis system is equipped with EZ fittings. The quick connect fittings feature leak ® proof installations. EZ Fittings provide efficient quick connection and disconnection resulting in reduction of service time and labor cost. -
Page 10: Start-Up Procedure
This is normal as the contaminated water is being rejected by the reverse osmosis membrane. The Proline system comes with a manual flushing valve on the drain line. This must be closed during normal operation. WARNING: DO NOT DRINK WATER FROM THE FIRST TANK PRODUCED BY THE SYSTEM. - Page 11 HOW TO MANUALLY FLUSH THE MEMBRANE The Manual Flushing Device is located in between the Membrane Housing and the Post Carbon on top of the Proline RO unit, containing the Flow Restrictor (FR-450) and the straight ball valve in between the two “Y” fittings.
-
Page 12: Changing The Filters
Screw the fittings into the new cartridge paying close attention to the flow direction. Reinsert tubing. Instructions and Information Model: PROLINE-GOLD PRODUCTION: 43.5 LPD (11.5 GPD) Contact your local dealer for replacement filters, or you may call 281-933-5777 to locate a dealer in your area. - Page 13 Performance Data Sheet WQA S-300 Reverse Osmosis System Model Number: PROLINE GOLD Replacement treatment components: Stage: Item # 93023 & 3 Stages: Item # 32-250-125-975 Stage: TW30-1812-50 Stage: K2540-BB ➣ Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system.
-
Page 14: Arsenic Facts
It will not convert trivalent arsenic to pentava- PROLINE® lent arsenic. The system was tested in a lab. Under testing conditions, the system reduced 0.30 mg/L (ppm) pentavalent arsenic to 0.010 mg/L (ppm) (the USEPA standard for drinking water) or less. -
Page 15: Troubleshooting
TROUBLESHOOTING SYMPTOM CAUSE CORRECTION NOTES: 1) TURN WATER SUPPLY ON. 1) WATER SUPPLY IS TURNED OFF. 2) CHECK TO MAKE SURE FEED VALVE IS NOT CLOGGED. 2) NOT ENOUGH WATER PRESSURE TO SYS- 1) CHECK FEED WATER PRESSURE. MUST BE AT TEM. - Page 16 The PROLINE reverse osmosis system is warranted to be free from defects in materials and workmanship under normal ® use within the operating parameters listed below. For a period of five years from the date of purchase PROLINE will ®...
- Page 17 Serial #...
