2-BAND PARAMETRIC EQ

The parametric EQ is useful for shaping the timbre of a sound. Two frequency bands can be attenuated
or amplified.

PARAMETRIC EQ MAIN

FRQ1 sets the center frequency the first band
of the EQ will affect.
GN1 attenuates or boosts the set frequency.
Q1 controls the width of the frequency range
the GN1 setting affects. The higher the value
the narrower the frequency curve.
FRQ2 sets the center frequency the second
band of the EQ will affect.
GN2 attenuates or boosts the set frequency.
Q2 controls the width of the frequency range
the GN2 setting affects. The higher the value
the narrower the frequency curve.
Appendix B: EFFECTS REFERENCE

PARAMETRIC EQ SETUP

TYP1 sets how the first band of the filter will
operate. It can act as a low shelf shelving filter,
a full parametric EQ or as a high shelf shelving
filter.
TYP2 sets how the second band of the filter
will operate. It can act as a low shelf shelving
filter, a full parametric EQ or as a high shelf
shelving filter.
A-3
