Hauppauge mySmarthome User Manual

mySmarthome
Control Starter Kit

What is mySmarthome?

What you will need to install
mySmarthome?
Hauppauge mySmarthome allows you to monitor
and control your home using the mySmarthome
1. Access to your home Internet router (wired
controller and mySmarthome devices (or
access), connected to the Internet
hundreds of other Z-Wave devices).
2. An e-mail address (for setting up your
mySmarthome connects to your home Internet
mySmarthome cloud service in Step 2)
router and uses our cloud based alert system to
3. A Windows PC or Mac, or Apple IOS or
let you know when something happens in your
Android mobile device
home.
mySmarthome is reliable and secure, and can 4. If you have an Apple or Android device,
save energy. download the Hauppauge mySmarthome
app from the Apple App Store or Google
What is in the mySmarthome
Play Store
Starter Kit?
Getting started with your Hauppauge
• mySmarthome Controller plus
mySmarthome only requires four
• RJ45 network cable
• Power Adapter steps:
• Serial number
1. Connecting mySmarthome controller to your
• 2 x mySmarthome Power Plug
router
• mySmarthome 4-in-1 Sensor (motion,
2. Signing up for the mySmarthome cloud
temperature, light level, door/window open
service
and close sensor)
3. Registering your mySmarthome controller
4. Adding mySmarthome devices such as the
provided power plugs, the 4-in-1 sensor plus
any other optional devices
mySmarthome Z-Wave Z-Wave Power
controller 4 in 1 Sensor plugs (2 pcs)
Step 2
WEB Signing up for the mySmarthome cloud service on your
Windows PC or Mac computer
Next, setup a User account on our mySmarthome Cloud Service.
1. Open your Internet browser (Chrome, Firefox, 5. You can now login to the mySmarthome
Internet Explorer, Safari) and in the address service using the email and password you
field type: used for the registration. The URL is:
www.hauppauge.com/mysmarthome www.hauppauge.com/mysmarthome
2. Start the Registration by selecting the 6. Once you are logged in, you will be at the
"Sign up" button (A). mySmarthome Main Menu (B).
3. Enter your e-mail address and choose a There are three parts of the Main menu (B):
password to sign up an account. Confirm
• the left side is the Device manager (C)
them by selecting Save.
• the center part lists Function Categories (D)
• the right side is where you create Rules (E)
4. After a few moments, you will receive an
email from the mySmarthome Cloud service
which will require you to verify your details.
Please click Verify.
B
C
A
Step 1
WEB Connecting mySmarthome Controller to your
Internet router
In the first step you will need to connect the mySmarthome Controller to your
Internet router.
1. Open the back plate (mount) on the back
of the mySmarthome Controller and make
a note of the Serial Number (A) of your
mySmarthome Controller.
2. Run the supplied network cable (B) through
the back plate and plug it into the RJ45
Network port of the mySmarthome Controller
(C). Connect the other end of the cable to
your router (D).
1
Step 3
WEB Registering your mySmarthome Controller
To register your mySmarthome Controller, you will need the Serial Number from the back
of you mySmarthome Controller (A).
On your smartphone:
1. Log into the mySmarthome App, and open
the Main Menu .
2. Select + Register mySmarthome (B) and
enter your mySmarthome serial number. Click
Save.
On a PC or Mac:
1. Log into your mySmarthome account. The
first time you log onto mySmarthome, you will
see the Add new box (C).
2. Enter your mySmarthome Serial Number and
click Save.
Your mySmarthome Controller will now be
assigned to your account.
D E
4
Step 2
Next, setup a User account on our mySmarthome Cloud Service.
1. Start the mySmarthome App (A) on your
Smartphone or Tablet.
2. Start the Registration by selecting the
"Register" button at the bottom right.
3. Enter your e-mail address and choose a
password to sign up for a mySmarthome
account. Confirm them by selecting
"Register" (B).
A
3. Connect the supplied power adapter (E) to
the mySmarthome Controller and add it to
your power socket.
The status LED on the left side of the
mySmarthome Controller will turn green to
indicate the unit is on.
During startup, your mySmarthome controller
will start flashing a white light quickly. This
indicates that your mySmarthome is connecting
to the cloud service. Once online the white light
will gradually glow. mySmarthome is now online
and is ready for use.
2
Step 4
The final step in the initial setup is to
wirelessly connect mySmarthome devices
to your mySmarthome Controller. During
this process, we recommend you position
B
mySmarthome devices within a few meters
of the mySmarthome Controller. Once the
device has been added, you can move it to
its final position in your home.
Note: these same steps can be used to add any
of the hundreds of third party Z-Wave devices.
Adding devices is done in two steps: Removing
or Exclusion and then Joining or Inclusion.
In this example we will use the mySmarthome
C
Power Plug. Plug the mySmarthome Power Plug
into a power socket.
A
A
5
Signing up for the mySmarthome cloud service using your
smartphone or tablet
4. After a few moments, you will receive an
email from mySmarthome Cloud service
which will require you to verify your details.
Please click "verify".
5. You can now login to the mySmarthome App
using the email and password you used for
the registration (C).
B C
WEB Adding mySmarthome devices or any other Z-Wave device
On a PC or Mac:
Once you have logged into your mySmarthome
account, in the mySmarthome browser, click
ADD NEW DEVICE (A).
On your smartphone:
Log into the mySmarthome App, and open the
Main Menu and choose "Add device"
On both types of devices:
1. In the next window, select Z-WAVE.
2. Removing/Exclusion:
Once you select Z-Wave, a countdown will
start (B). During this countdown, press the
button on the front of the mySmarthome plug
three times in quick succession.
B
3
.
6
