SERVICE
TFT-LCD MONITOR
GG15L*/GG15V*/GG15E*
GG15AS/GG15AS(R)
TFT-LCD MONITOR
GG15AS/GG15AS(R)
GG15L*/GG15L*(R)
GG15V*/GG15V*(R)
GG15E*/GG15E*(R)
Manual
10. Panel Description
CONFIDENTIAL
CONTENTS

Advertisement

Table of Contents
loading

Related Manuals for Samsung GG15AS

Summary of Contents for Samsung GG15AS

  • Page 1: Table Of Contents

    CONFIDENTIAL TFT-LCD MONITOR GG15AS/GG15AS(R) GG15L*/GG15L*(R) GG15V*/GG15V*(R) GG15E*/GG15E*(R) SERVICE Manual TFT-LCD MONITOR CONTENTS 1. Precautions 2. Product Specifications 3. Disassembly & Reassembly 4. Troubleshooting 5. Exploded View & Parts List GG15L*/GG15V*/GG15E* 6. Electrical Parts List GG15L*(R)/GG15V*(R)/GG15E*(R) 7. Block Diagram 8. Wiring Diagram 9.

  • Page 2: Precautions

    Appliances), and Underwriters Laboratories (UL characteristics as the recommended replacement part Publication UL1410, 59.7). might create shock, fire and/or other hazards. Product safety is under review continuously and new instructions are issued whenever appropriate. GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)

  • Page 3: Servicing Precautions

    ESDs. Motions such as solder removal devices not classified as “anti-static” brushing clothes together, or lifting your foot from can generate electrical charges sufficient to damage a carpeted floor can generate enough static ESDs. electricity to damage an ESD. GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)

  • Page 4: Product Specifications

    Storage Temperature : 13 °F ~ 113 °F (-25 °C ~ 45 °C) Storage Humidity : 5 % ~ 95 % •GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/GG15V*/GG15V*(R)/GG15E*/GG15E*(R) complies with SWEDAC (MPR II) recommendations for reduced electromagnetic fields. •Designs and specifications are subject to change without prior notice.

  • Page 5: Pin Assignments

    GND-G GND-G GND-B GND-B GND-B No Connection No Connection Not Used GND-Sync./Self Test GND-Sync./Self Test GND-Sync./Self Test DDC Data DDC Data DDC Data H-Sync. H/V-Sync. Not Used V-Sync. Not Used Not Used DDC Clock DDC Clock DDC Clock GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)

  • Page 6: Timing Chart

    B : Horizontal sync width O : Frame time total P : Vertical sync width C : Back porch D : Active time Q : Back porch R : Active time E : Front porch S : Front porch GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 7 B : Horizontal sync width O : Frame time total P : Vertical sync width C : Back porch D : Active time Q : Back porch R : Active time E : Front porch S : Front porch GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)

  • Page 8: Disassembly & Reassembly

    CONFIDENTIAL 3 Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/GG15V*/GG15V*(R)/GG15E*/GG15E*(R) monitor. WARNING: This monitor contains electrostatically sensitive devices. Use with caution when handling these components. 3-1 Disassembly Cautions:1. Disconnect the monitor from the power source before disassembly.
  • Page 9 CONFIDENTIAL 3 Disassembly and Reassembly 3. Disconnect the video cable and power cord. 4. Remove 4 screws from the rear cover. 5. Open the rear cover using the jig. GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 10 CONFIDENTIAL 3 Disassembly and Reassembly 6. Pull the rear cover. 7. Remove 4 screws of the panel. 8. Disconnect the function cable. GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 11 CONFIDENTIAL 3 Disassembly and Reassembly 9. Disconnect the inverter cable. 10. Disconnect the LVDS cable. 3-1-2 GG15AS/GG15AS(R) 1. Disconnect the video cable. GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 12 CONFIDENTIAL 3 Disassembly and Reassembly 2. Remove 4 screws of the stand. 3. Remove the stand from LCD monitor. 4. Turn the monitor over as the figure above. GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 13 CONFIDENTIAL 3 Disassembly and Reassembly 5. Open up the top part of front cover. 6. Open the rear cover using the hands. 3-2 Reassembly Reassembly procedures are in the reverse order of disassembly procedures. GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)

  • Page 14: Troubleshooting

    • 12V does not develop: Audio PCB, SMPS PCB 4. If you push and hold the “EXIT” button for more than 5 seconds, the monitor automatically turns back to the factory preset. 4-1 No Power [GG15AS/GG15L*/GG15V*/GG15E*] Does proper DC 12 V Check SMPS or CN120.
  • Page 15 CONFIDENTIAL 4 Troubleshooting 4-2 No Video [GG15AS/GG15L*/GG15V*/GG15E*] Does the H-sync pulse Check CN190. appear at Pin 43 of IC300? Does the H-sync pulse Replace IC300 or appear at Pin 34 of IC300? check its related circuit. Does the V-sync pulse check CN190.
  • Page 16 CONFIDENTIAL 4 Troubleshooting 4-2-1 No Video [GG15AS(R)/GG15L*(R)/GG15V*(R)/GG15E*(R)] Does the H-sync pulse Check CN190. appear at Pin 43 of IC102? Does the H-sync pulse Replace IC102 or appear at Pin 34 of IC102? check its related circuit. Does the V-sync pulse Check CN190.
  • Page 17 CONFIDENTIAL 4 Troubleshooting WAVEFORMS GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 18 CONFIDENTIAL 4 Troubleshooting 4-3 User Controls Don’t Work [GG15AS/GG15L*/GG15V*/GG15E*] Does the DC level change at Check the buttons. Pin 16 and 17 of IC300 when you (SW1~SW6) push the front panel button? Refer to 4-4 No OSD Display. 4-3-1 User Controls Don’t Work [GG15AS(R)/GG15L*(R)/GG15V*(R)/GG15E*(R)] Does the DC level change at Check the buttons.
  • Page 19 CONFIDENTIAL 4 Troubleshooting 4-4 No OSD [GG15AS/GG15L*/GG15V*/GG15E*] There is video but no OSD. While pushing a front control button does any pulse Replace IC102 or appear at Pin 121, 124~131 and check its related circuit. 135~137 of IC200? Replace IC200.
  • Page 20 CONFIDENTIAL 5 Exploded View and Parts List 5-1 GG15L*/GG15V*/GG15E* GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)

  • Page 21: Exploded View & Parts List

    CONFIDENTIAL 5 Exploded View & Parts List 5-2 GG15L*(R)/GG15V*(R)/GG15E*(R) GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 22 CONFIDENTIAL 5 Exploded View & Parts List 5-3 GG15AS/GG15AS(R) GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 23 CONFIDENTIAL 5 Exploded View & Parts List Memo GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)

  • Page 24: Electrical Parts List

    CONFIDENTIAL 6 Electrical Parts List 6-1-1 GG15AS/GG15AS(R) Main PCB Parts Loc. No. Code No. Description Specification Remarks BN94-00407A ASSY PCB MAIN GG15AS BN83-00081A CKD-BN44-00056A BN44-00056A,2203-000206 BN83-00086A CKD-BN44-00056A BN44-00056A,2203-002793 BN83-00086A CKD-BN44-00056A BN44-00056A,2203-002793 BN83-00082A CKD-BN44-00056A BN44-00056A,2203-001458 BN83-00083A CKD-BN44-00056A BN44-00056A,2203-000455 BN83-00079A CKD-BN44-00056A BN44-00056A,2301-001336...
  • Page 25 BN83-00249A CKD-0202-001203 GG15 BN83-00250A CKD-ML68-00573B GG15 BN83-00251A CKD-ML68-00516D GG15 BN83-00252A CKD-ML68-00516C GG15 BN83-00137A CKD-BN44-00056A BN44-00056A,2007-000091 CIS01 0202-001044 SOLDER-WIRE. S63S-W3.0,S63S,D3,63Sn/37Pb,- CIS02 0202-001046 SOLDER-WIRE FLUX CF-110VH-2A,-,-,-,- CIS03 0202-001222 SOLDER-WIRE FLUX RS-107,RS60-1.2AA,D1.2,SN60/PB40,- CIS04 0204-001095 THINNER #4520,-,-,- CIS05 BN39-00161A CBF HARNESS GH15LS,UL/CSA,UL1061#28,12P/12P,160MM,WHT,AWG28,51021-1200,51021-1200,-,-,1.25MM GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 26 Loc. No. Code No. Description Specification Remarks CIS06 BN39-00234A LEAD CONNECTOR-ASSY GG15LS,UL1571#30,UL/CSA,20P,#30,12507HS-20,12507HS-20,BK,170MM,1571#30,SJ01-01-3 CIS07 BN67-00049A CAP-POWER LM15PO,ABS PC,-,-,-,BK10,- CIS08 BN63-00507A SHIELD-D-SUB GG15AS,PBS,T0.15 CIS10 BN44-00053D ADAPTOR LCD-PSU15(NR,SW),15’ NARROW,100-240VAC,47-63HZ,+14VDC/3.3VDC,2A/2A,35W,-10 ~ +40 CIS13 BN44-00056A INVERTER GOGH,SIC1542,48KHZ,12VDC,1.5MARMS,5.6MARMS,48KHZ,37*140*16.0,4LAMP,40~56KV,-,SIC CIS14 BH68-40352A LABEL-BARCODE ALL,ART-PAPER,90G,WHT,BLK,W50* BN83-00110A CKD-BN44-00056A BN44-00056A,3711-000556 CN120...
  • Page 27 CKD-BN44-00056A BN44-00056A,2007-000122 BN83-00095A CKD-BN44-00056A BN44-00056A,2007-000122 BN83-00094A CKD-BN44-00056A BN44-00056A,2007-000102 BN83-00094A CKD-BN44-00056A BN44-00056A,2007-000102 BN83-00097A CKD-BN44-00056A BN44-00056A,2007-001114 BN83-00092A CKD-BN44-00056A BN44-00056A,2007-000872 BN83-00103A CKD-BN44-00056A BN44-00056A,2007-000070 BN83-00104A CKD-BN44-00056A BN44-00056A,2007-002422 BN83-00104A CKD-BN44-00056A BN44-00056A,2007-002422 BN83-00103A CKD-BN44-00056A BN44-00056A,2007-000070 BN83-00094A CKD-BN44-00056A BN44-00056A,2007-000102 BN83-00094A CKD-BN44-00056A BN44-00056A,2007-000102 BN83-00105A CKD-BN44-00056A BN44-00056A,2007-000691 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 28 BN44-00056A,1201-000471 BN83-00067A CKD-BN44-00056A BN44-00056A,1202-000104 BN83-00067A CKD-BN44-00056A BN44-00056A,1202-000104 BN83-00065A CKD-BN44-00056A BN44-00056A,1203-000560 BN83-00067A CKD-BN44-00056A BN44-00056A,1202-000104 CIS11 BN96-00210A ASSY MISC P-SHIELD-PCB GG15AS,SECC/SPTE T0.5 BN97-00185A ASSY SMD GG15AS BD01 3301-000314 CORE-FERRITE BEAD AB,120ohm,1.6x0.8x0.8mm,150mA,TP,FERRITE,0.2ohm BD02 3301-000314 CORE-FERRITE BEAD AB,120ohm,1.6x0.8x0.8mm,150mA,TP,FERRITE,0.2ohm BD03 3301-000314 CORE-FERRITE BEAD AB,120ohm,1.6x0.8x0.8mm,150mA,TP,FERRITE,0.2ohm BD04...
  • Page 29 CORE-FERRITE BEAD AB,4.5x1.6x1.6mm,-,- FT130 3301-001145 CORE-FERRITE BEAD AB,4.5x1.6x1.6mm,-,- FT150 3301-001145 CORE-FERRITE BEAD AB,4.5x1.6x1.6mm,-,- FT160 3301-001145 CORE-FERRITE BEAD AB,4.5x1.6x1.6mm,-,- IC110 1203-001488 IC-POSI.FIXED REG. 7805,T0-252,3P,-,PLASTIC,4.8/5 IC150 1203-002450 IC-VOLTAGE REGULATOR MC33375ST-2.5T3,SOT-223,4P,137MIL,PLASTIC,2.475/2.525V,-,-40TO+125C,300MA,-,TP IC160 1203-002450 IC-VOLTAGE REGULATOR MC33375ST-2.5T3,SOT-223,4P,137MIL,PLASTIC,2.475/2.525V,-,-40TO+125C,300MA,-,TP IC200 1003-001466 IC-LCD CONTROLLER S9001,PQFP,144P,28X28MM,-,-,TR,PLASTIC,3.3V,0TO+70C,-,-,S9001 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 30 Loc. No. Code No. Description Specification Remarks IC300 0903-001266 IC-MICROCONTROLLER NT68F63,8BIT,PLCC,44P,653MIL,12MHZ,ST,CMOS,PLASTIC,5V,-,-0TO+70C,256B,4KB,-,-,MC IC301 1103-001023 IC-EEPROM 524C80D81,1028x8Bit,SOP,8P,150MIL,10mS,5V,10%,PLASTIC,0to+70C,110uA,CMOS,TP MP1.0 BN41-00239A PCB MAIN GG15AS, FR4,4,1.6,110*72*1.6 Q130 0501-002080 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270 Q131 0501-002080 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270 Q132 0505-001170 FET-SILICON SI9933ADY-T1,P,-20V,3.4A,0.06ohm,2W,SO-8 Q140 0501-002080 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270...
  • Page 31 R-CHIP 820ohm,5%,1/16W,DA,TP,1608 R901 2007-000121 R-CHIP 820ohm,5%,1/16W,DA,TP,1608 R902 2007-000121 R-CHIP 820ohm,5%,1/16W,DA,TP,1608 X200 2801-003667 CRYSTAL-SMD 14.3182MHZ,50PPM,28-AAN,16,50OHM,TP X300 2801-003773 CRYSTAL-SMD 12MHZ,30PPM,28-AAN,20PF,50OHM,TP ZD190 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD191 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD192 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD193 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD194 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 32 GG15AS,ABS HB BK07 BN70-00176A BRACKET VESA RB15AS,SECC,1 BN90-00460B ASSY COVER FRONT GG15LS C/F+PAN 6003-000276 SCREW-TAPTITE BH,+,B,M3,L10,ZPC(YEL),SWCH10 BN96-00209B ASSY COVER P-FRONT GG15AS(S/M 151N),ABS HB IV16,SILVER BN59-00229A BOARD -,FUNCTION ASSY,-,-,-,-,- BN61-00067A SUPPORT-FUNCTION GH19PS,ABS+PC 5V,-,-,-,IV16,- BN63-00503A COVER-FRONT GG15AS,ABS HB BK07 BN64-00038D KNOB-FUNCTION GG15AS,ABS HB,IV16,SILVER...
  • Page 33 BN44-00056A,0505-001160 BN83-00073A CKD-BN44-00056A BN44-00056A,0501-002186 BN83-00074A CKD-BN44-00056A BN44-00056A,0407-000114 BN83-00075A CKD-BN44-00056A BN44-00056A,0402-001110 BN83-00076A CKD-BN44-00056A BN44-00056A,0407-000122 BN83-00077A CKD-BN44-00056A BN44-00056A,0407-000116 BN83-00078A CKD-BN44-00056A BN44-00056A,2401-003400 BN83-00079A CKD-BN44-00056A BN44-00056A,2301-001336 BN83-00080A CKD-BN44-00056A BN44-00056A,2201-002122 BN83-00081A CKD-BN44-00056A BN44-00056A,2203-000206 BN83-00082A CKD-BN44-00056A BN44-00056A,2203-001458 BN83-00083A CKD-BN44-00056A BN44-00056A,2203-000455 BN83-00084A CKD-BN44-00056A BN44-00056A,2203-000590 6-10 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 34 BN44-00053A,BH27-00050A BN83-00051A CKD-BN44-00053A BN44-00053A,BH27-00050A 6003-000117 SCREW-TAPTITE BH,+,B,M3,L6,ZPC(YEL),SWRCH18A LVDS+SH/COV 6003-000117 SCREW-TAPTITE BH,+,B,M3,L6,ZPC(YEL),SWRCH18A M/PCB+SH/COV 6003-000117 SCREW-TAPTITE BH,+,B,M3,L6,ZPC(YEL),SWRCH18A P/PCB+SH/COV BN83-00063A CKD-BN44-00053A BN44-00053A,PCB BN83-00052A CKD-BN44-00053A BN44-00053A,MTP2955V BN83-00053A CKD-BN44-00053A BN44-00053A,0501-000303 BN83-00054A CKD-BN44-00053A BN44-00053A,0501-000586 BN83-00011A CKD-BN44-00053A BN44-00053A,2001-001129 BN83-00018A CKD-BN44-00053A BN44-00053A,2001-000449 BN83-00018A CKD-BN44-00053A BN44-00053A,2001-000449 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ 6-11 GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 35 100nF,10%,16V,X7R,TP,1608 C215 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C216 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C217 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C218 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C219 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C220 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C221 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C222 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C223 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 6-12 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 36 CORE-FERRITE BEAD AB,4.5x1.6x1.6mm,-,- FT160 1203-001488 IC-POSI.FIXED REG. 7805,T0-252,3P,-,PLASTIC,4.8/5 IC110 1203-002450 IC-VOLTAGE REGULATOR MC33375ST-2.5T3,SOT-223,4P,137MIL,PLASTIC,2.475/2.525V,-,-40TO+125C,300MA,-,TP IC150 1203-002450 IC-VOLTAGE REGULATOR MC33375ST-2.5T3,SOT-223,4P,137MIL,PLASTIC,2.475/2.525V,-,-40TO+125C,300MA,-,TP IC160 1003-001466 IC-LCD CONTROLLER S9001,PQFP,144P,28X28MM,-,-,TR,PLASTIC,3.3V,0TO+70C,-,-,S9001 IC200 1103-001023 IC-EEPROM 524C80D81,1028x8Bit,SOP,8P,150MIL,10mS,5V,10%,PLASTIC,0to+70C,110uA,CMOS,TP IC301 1204-000292 IC-VIDEO SYSTEM LM1881M,SOP,8P,150MIL,PLASTIC, IC402 BN41-00149A PCB MAIN GH15LS, FR4,4,-,1.6,245*158,-,4,-,- GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ 6-13 GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 37 100ohm,5%,1/16W,DA,TP,1608 R305 2007-000084 R-CHIP 4.7Kohm,5%,1/16W,DA,TP,1608 R306 2007-000084 R-CHIP 4.7Kohm,5%,1/16W,DA,TP,1608 R307 2007-000078 R-CHIP 1Kohm,5%,1/16W,DA,TP,1608 R308 2007-000078 R-CHIP 1Kohm,5%,1/16W,DA,TP,1608 R309 2007-000078 R-CHIP 1Kohm,5%,1/16W,DA,TP,1608 R310 2007-000077 R-CHIP 470ohm,5%,1/16W,DA,TP,1608 R311 2007-000120 R-CHIP 680ohm,5%,1/16W,DA,TP,1608 R312 2007-000078 R-CHIP 1Kohm,5%,1/16W,DA,TP,1608 R314 2007-000084 R-CHIP 4.7Kohm,5%,1/16W,DA,TP,1608 6-14 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 38 R900 2007-000121 R-CHIP 820ohm,5%,1/16W,DA,TP,1608 R901 2007-000121 R-CHIP 820ohm,5%,1/16W,DA,TP,1608 R902 2801-003667 CRYSTAL-SMD 14.3182MHZ,50PPM,28-AAN,16,50OHM,TP X200 2801-003773 CRYSTAL-SMD 12MHZ,30PPM,28-AAN,20PF,50OHM,TP X300 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD190 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD191 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD192 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD193 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD194 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ 6-15 GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 39 CONFIDENTIAL 6 Electrical Parts List 6-2-2 GG15L*/GG15V*/GG15E* Others Loc. No. Code No. Description Specification Remarks BN90-00174A ASSY COVER REAR GH15LS*N(DS/ES),WW,ABS HB,IV16,SAMSUNG BN75-00151A UNIT-COVER REAR GH15L/GH15E,WW,ABS HB,-,IV16,-,-,- BN70-00176A BRACKET VESA RB15AS,SECC,1 BN72-00197A COVER REAR GH15LS,ABS,HB,IV16 BN90-00175A ASSY STAND GH15-SN,WW,ABS/HB,IV16,WW BN75-00168A UNIT-STAND...
  • Page 40 LXA410TLMU,POLYESTER FILM,-,-,345*260*0.104,TFT_14’ BN68-00213A LABEL RATING GH15MS,W/W,PE,T0.05,90,30,SYNC,-,PE NATURE,-,- BN68-00219A LABEL RATING W/W,BARCODE,PE,T0.05,60,35,SYNC,-,PE NATURE,-,- BN92-00344G ASSY BOX GH15ESSN/XSH,SEHK,HONGKONG,- BH75-10529A UNIT-HANDLE PACKING LXA410TLMU,PE,-,WHITE,- BN72-60001A LEVER TOP LSD210TL,PE-LD,WHITE,TFT_LCD BN72-60002A LEVER BOTTOM LSD210TL,PE-LD,WHITE,TFT-LCD BN68-00134D LABEL BAR CODE -,ALL,TCO99,W/W,ART-PAPER 90G,-,WHT,BLACK,-,-,- BN69-00209A S/M151B,W/W,CB-SW4,YEL,A-1,-,-,-,L451*W445*H211,- CE-GG15ESSN/XSH M150X3-L01(ZPD) GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ 6-17 GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 41 10nF,10%,50V,X7R,TP,1608 C110 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C111 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C112 2203-005437 C-CERAMIC,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C113 2203-000384 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1608 C114 2203-005437 C-CERAMIC,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C115 2203-005005 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,1608 C116 2203-000384 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,1608 C117 2203-005437 C-CERAMIC,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C118 2203-000626 C-CERAMIC,CHIP 0.022nF,5%,50V,NP0,TP,1608 6-18 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 42 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1 FT103 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1 FT104 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1 FT105 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1 FT106 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1 FT107 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm FT108 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1 FT109 2901-001114 FILTER-EMI SMD 25VDC,2.0ADC,-,100nF,3.2x1.6x1 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ 6-19 GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 43 470ohm,5%,1/16W,DA,TP,1608 R145 2007-000109 R-CHIP 1Mohm,5%,1/16W,DA,TP,1608 R146 2007-000107 R-CHIP 470Kohm,5%,1/16W,DA,TP,1608 R147 2007-000070 R-CHIP 0ohm,5%,1/16W,DA,TP,1608 R148 2007-000074 R-CHIP 100ohm,5%,1/16W,DA,TP,1608 R149 2007-000074 R-CHIP 100ohm,5%,1/16W,DA,TP,1608 R150 2007-000074 R-CHIP 100ohm,5%,1/16W,DA,TP,1608 R151 2007-000074 R-CHIP 100ohm,5%,1/16W,DA,TP,1608 R153 2007-000074 R-CHIP 100ohm,5%,1/16W,DA,TP,1608 R154 2007-000074 R-CHIP 100ohm,5%,1/16W,DA,TP,1608 6-20 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 44 22ohm,5%,63mW,L,CHIP,8P,TP RA106 2011-000002 R-NETWORK 22ohm,5%,63mW,L,CHIP,8P,TP U104 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 X101 2801-003773 CRYSTAL-SMD 12MHZ,30PPM,28-AAN,20PF,50OHM,TP X102 2801-003667 CRYSTAL-SMD 14.3182MHZ,50PPM,28-AAN,16,50OHM,TP ZD101 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD102 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD103 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD104 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 ZD105 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ 6-21 GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 45 DPA30L-9O,GG15,90 TO 264 VAC,47 - 63 HZ,12V/3.3V,2A/2A,36W,AC-DC,-10~+40C BN83-00059A CKD-BN44-00053A BN44-00053A,HEATSINK—TR1 BN83-00060A CKD-BN44-00053A BN44-00053A,HEATSINK—TR2 BN83-00138A CKD-BUSHING BN44-00053A,SK-BU-0002 BN83-00139A CKD-LABEL BN44-00053A,4M00-2552 BN83-00140A CKD-NUT BN44-00053A,HT1-M3(ZN) BN83-00141A CKD-POLYESTER TAPE BN44-00053A,YL20-680 BN83-00142A CKD-RUBBER BN44-00053A,4M80-2556 BN83-00143A CKD-SCREW BN44-00053A,BHTB-M3X6(ZN) BN83-00144A CKD-SCREW BN44-00053A,PH-M3X8(ZN) BN83-00149A CKD-BN39-00142B BN44-00053B,HARNESS(90MM),BN39-00142B BN44-00056B INVERTER GH15IS,SIC1542T,48KHZ,11.5~14.5,3.6MARMS,6.8MARMS,48KHZ,140*37.0*17.0,4LAMP,48KH 6-22 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 46 BN83-00040A CKD-BN44-00053A BN44-00053A,0402-000103 BN83-00041A CKD-BN44-00053A BN44-00053A,0401-000005 BN83-00042A CKD-BN44-00053A BN44-00053A,0402-000012 BN83-00043A CKD-BN44-00053A BN44-00053A,0402-000546 BN83-00044A CKD-BN44-00053A BN44-00053A,UZ27BSD BN83-00045A CKD-BN44-00053A BN44-00053A,MBR16100CT BN83-00046A CKD-BN44-00053A BN44-00053A,MBR745 BN83-00047A CKD-BN44-00053A BN44-00053A,UZ4.7BSB FUSE BN83-00058A CKD-BN44-00053A BN44-00053A,SR-5032H BN83-00048A CKD-BN44-00053A BN44-00053A,1203-002276 BN83-00049A CKD-BN44-00053A BN44-00053A,0604-001018 BN83-00050A CKD-BN44-00053A BN44-00053A,1203-000002 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ 6-23 GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 47 BN69-00212A CUSHION-L/R GH15LT,EPS 50M,-,-,-,-,-,-,- BN92-00670G ASSY ACCESSORY 51S-SS3,DOMESTIC,KOREA BN96-00288G ASSY ACCESSORY 51S-SS3,DOMESTIC,KOREA 0203-000214 TAPE-OPP MASKING OPP/W50/CLR,T0.05,W50,L400000, BH68-00511A MANUAL DOM-REGISTRATION,SAMSUNG,KOREAN,DOMESTIC,MOJO250G,148,210 BH69-30348D BAG-PE LDPE,T0.05,W240*L356,Y,-,CMG73 BN39-00165A CBF POWER CORD GH15L,SP-022/IS-034,VCTF 3G,250V,7A/2.5A,1830MM,CP3/YES,BLACK,¿‹,¿‹,-,-,-,DOMEST BN59-00212G S/W DRIVER SAMTRON 71S,IB/DRIVER,WW,E/F/S/G/P/I/SW/R/ BN68-00226F MANUAL-00 LCD W/CARD,SAMSUNG,KOREAN,DOMESTIC,MOJO100G,-,148,210,-,-,-,- 6-24 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)

  • Page 48: Block Diagram

    CONFIDENTIAL 7 Block Diagram GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 49 CONFIDENTIAL 7 Block Diagrams Memo GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)

  • Page 50: Wiring Diagram

    CONFIDENTIAL 8 Wiring Diagram 8-1 GG15AS/GG15L*/GG15V*/GG15E* CN170 CN120 CN190 CN190 CN180 CN102 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 51 CONFIDENTIAL 8 Wiring Diagram 8-2 GG15AS(R)/GG15L*(R)/GG15V*(R)/GG15E*(R) CN103 5V_PC 5V_PC CN104 SELF_R SELF_R DDC_SDA DDC_SDA HSYNC_IN HSYNC_IN CN105 CN190 VSYNC_IN VSYNC_IN DDC_SCL DDC_SCL CN102 CN101 GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)

  • Page 52: Schematic Diagrams

    CONFIDENTIAL 9 Schematic Diagrams 9-1 GG15AS Part Schematic diagram DELETE_MP10 22pF C390 +3.3V_PANEL R210 TP201 TP200 SOG/DDC OPTION 1/16W SOG_CSYNC C443 TP954 R421 100pF X200 HC-49/S-SMD(14.31818MHZ) 1/16W C210 C211 C201 10000nF 100nF IC402 C200 33pF LM1881M 33pF C440 C441 R420...
  • Page 53 CONFIDENTIAL 9 Schematic Diagrams GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 54 CONFIDENTIAL 9 Schematic Diagrams 9-2 GG15AS(R) Part Schematic diagram CN101 +3.3V_PANEL slcon22p_1 power C101 C102 100nF 10000nF FT101 SGM32F1E104-2A +3.3V_S R101 +12V_IN FT102 SGM32F1E104-2A power 1/16W LVDS_EN +3.3V_S DCLK C103 C104 CN107 10000nF FT103 slcon5p SGM32F1E104-2A BL_EN AUDIO_EN 1/16W C105...
  • Page 55 CONFIDENTIAL 9 Schematic Diagrams GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 56 C169 C168 U109 R196 100pF 100pF 100pF 100nF 680K For Touch Screen BD105 1/16W C109 C110 C111 1.5uH 10nF 10nF 10nF BD120 1.5uH ZD104 ZD105 ZD101 ZD103 ZD102 CN402 BD121 slcon2p BD114 1.5uH 5V_PC 1.5uH TP953 CN105 d_sub15p GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 57 CONFIDENTIAL 9 Schematic Diagrams GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 58 100uF 10nF SW_REG_EN Q140 BD181 1.5uH KEY2 BLUEN 100uF 2SC2412K-Q R141 IC160 TP130 MC33375ST-2.5T3 D180 D181 TP129 ZD190 ZD191 ZD192 ZD193 ZD194 VOUT C191 C190 SW_REG_EN 100pF ON_OFF C161 100pF C180 C181 C182 10nF 10nF 10nF TP131 LED_R GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 59 CONFIDENTIAL 9 Schematic Diagrams GG15AS/GG15AS(R)/GG15L*/GG15L*(R)/ GG15V*/GG15V*(R)/GG15E*/GG15E*(R)
  • Page 60 Samsung Electronics Co.,Ltd. 416, Maetan-3Dong, Paldal-Gu, Suwon City, Kyungki-Do, Korea. Printed in Korea P/N : BN81-00031A-01 http://www.samsungmonitor.com (SyncMaster Worldwide) http://www.samsung-monitor.com (SyncMaster USA) http://www.sec.co.kr/monitor (Korea)
