Congatec X945 User Manual

Intel atom n270, intel core 2 duo, intel core duo and celeron m processors with an intel 945 chipset
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XTX™
conga-X945 and conga-XA945
Intel
®
Atom™ N270, Intel
®
Core™ 2 Duo, Intel
®
Core™ Duo
and Celeron M processors with an Intel
®
945 chipset
User's Guide
Revision 1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X945 and is the answer not in the manual?

Questions and answers

Summary of Contents for Congatec X945

  • Page 1 XTX™ conga-X945 and conga-XA945 Intel ® Atom™ N270, Intel ® Core™ 2 Duo, Intel ® Core™ Duo and Celeron M processors with an Intel ® 945 chipset User's Guide Revision 1.3...

  • Page 2: Revision History

    Supply Voltage. Added information to section 4.2.4 PCI Express about x4 mode. Added note about floppy cable to section 4.3.6 Parallel Port/Floppy Interface. Added section 5.7 'congatec Battery Management Interface'. Updated section 8 System Resources and section 9 BIOS Setup Description.

  • Page 3: Intended Audience

    AG assumes no liability for any damages incurred directly or indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user's guide. In no event shall congatec AG be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in connection with this user's guide or any other information contained herein or the use thereof.
  • Page 4 All text, pictures and graphics are protected by copyrights. No copying is permitted without written permission from American Megatrends, Inc. congatec AG has made every attempt to ensure that the information in this document is accurate yet the information contained within is supplied “as-is”.
  • Page 5 AG makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited warranty ("Limited Warranty"). congatec AG may in its sole discretion modify its Limited Warranty at any time and from time to time.

  • Page 6: Technical Support

    XTX™ offers the newest I/O technologies on this proven form factor. Now that the ISA bus is being used less and less in modern embedded applications congatec AG offers an array of different features on the X2 connector than those currently found on the ETX ®...
  • Page 7 AG. Check the table for the Part no./Order no. that applies to your product. This will tell you what options described in this user's guide are available on your particular module.

  • Page 8: Table Of Contents

    1.5 Power Consumption........................13 1.5.1 conga-XA945 Intel® Atom™ N270 1.6GHz 512kB cache............15 1.5.2 conga-X945 Intel® Core™ 2 Duo L7400 1.5GHz 4MB cache..........15 1.5.3 conga-X945 Intel® Core™ Duo L2400 1.66GHz 2MB cache..........15 1.5.4 conga-X945 Intel® Core™ 2 Duo U7500 1.06GHz 2MB cache...........16 1.5.5 conga-X945 Intel®...
  • Page 9 5.3.1 Simplified Overview of BIOS Setup Data Backup..............32 5.4 SDVO............................33 5.5 Security Features........................33 5.6 Suspend to RAM (S3)......................33 5.7 congatec Battery Management Interface.................33 6 conga Tech Notes........................34 6.1 Comparison of I/O APIC to 8259 PIC Interrupt mode..............34 6.2 Native vs. Compatible IDE mode.....................34 6.2.1 Compatible Mode.........................34...
  • Page 10 9.4.2.1 PCI IRQ Resource Exclusion Submenu................78 9.4.2.2 PCI Interrupt Routing Submenu..................78 9.4.3 Graphics Configuration Submenu..................79 9.4.4 CPU Configuration Submenu for conga-X945 variants only..........81 9.4.5 CPU Configuration Submenu for conga-XA945 variants only..........82 9.4.6 Chipset Configuration Submenu...................83 9.4.7 I/O Interface Configuration Submenu...................85 9.4.8 Clock Configuration......................86...

  • Page 11: Specifications

    • BIOS Based on AMIBIOS8 ® -1MByte Flash BIOS with congatec Embedded BIOS features ACPI 3.0 compliant with battery support. Also supports Suspend to RAM (S3). Power Management Note Some of the features mentioned in the Feature Summary are optional. Check the article number of your module and compare it to the option information list on page 7 of this user's guide to determine what options are available on your particular module.

  • Page 12: Supported Operating Systems

    1.2 Supported Operating Systems The conga-X945/XA945 supports the following operating systems. Microsoft ® Windows ® Vista • Microsoft ® Windows ® XP/2000 • Microsoft ® Windows ® XP Embedded • Microsoft ® Windows ® CE 5.0 / 6.0 • Linux •...

  • Page 13: Supply Voltage Ripple

    This ensures the value measured reflects the true power consumption of the module and only the module. A keyboard is used to configure the module and then it is Copyright © 2006 congatec AG X945m13 13/102...

  • Page 14: Processor Information

    LV 90nm Intel ® also describes the type of manufacturing process used for each processor. The following term is used: nm=nanometer The manufacturing process description is included in the power tables as well. See Copyright © 2006 congatec AG X945m13 14/102...

  • Page 15: Conga-Xa945 Intel® Atom™ N270 1.6Ghz 512Kb Cache

    Amperes/Watts) ® 1.5.2 conga-X945 Intel Core™ 2 Duo L7400 1.5GHz 4MB cache With 512MB memory installed conga-X945 Art. No. 055874 Intel ® Core™ 2 Duo L7400 1.5GHz 4MB L2 cache LV 65nm Layout Rev. X945B0 /BIOS Rev. X945R111 Memory Size...

  • Page 16: Conga-X945 Intel® Core™ 2 Duo U7500 1.06Ghz 2Mb Cache

    1.5.4 conga-X945 Intel ® Core™ 2 Duo U7500 1.06GHz 2MB cache With 512MB memory installed conga-X945 Art. No. 014781 Intel ® Core™ 2 Duo U7500 1.06GHz 2MB L2 cache ULV 65nm Layout Rev. X945C1 /BIOS Rev. X945R111 Memory Size 512MB...

  • Page 17: Supply Voltage Battery Power

    If for some reason it is not possible to use the appropriate congatec module heatspreader, then it is the responsibility of the operator to ensure that all components found on the module operate within the component manufacturer's specified temperature range.

  • Page 18: Block Diagram

    Block Diagram Copyright © 2006 congatec AG X945m13 18/102...

  • Page 19: Heatspreader

    Application Note AN14_ETX_XTX_Mounting_Solutions.pdf that can be found on the congatec website. Copyright © 2006 congatec AG X945m13 19/102...

  • Page 20: Heatspreader Dimensions

    3.1 Heatspreader Dimensions Note All measurements are in millimeters. Torque specification for heatspreader screws is 0.5 Nm. Copyright © 2006 congatec AG X945m13 20/102...

  • Page 21: Exploded View Of Threaded Xtx Heatspreader, Module And Carrier Board Assembly

    3.2 Exploded view of Threaded XTX Heatspreader, Module and Carrier Board Assembly Copyright © 2006 congatec AG X945m13 21/102...

  • Page 22: Connector Subsystems

    The implementation of the PCI bus complies with PCI specification Rev. 2.3 and ETX ® specification Rev. 2.7 4.1.2 The conga-X945/XA945 offers 4 USB ports, via the Intel ® 82801GBM (ICH7M), that are connected to the X1 connector. These ports are both USB 1.1 and 2.0 compliant. For more information about how the USB host controllers are routed see section 6.7.

  • Page 23: Audio

    4.1.3 Audio The conga-X945/XA945 is equipped with a Realtek ALC203 PCI audio controller. It is AC97 2.2 specification compliant and legacy audio SB16 compatible. Note The USB and Audio controllers are PCI bus devices. The BIOS allocates the necessary system resources when configuring the PCI devices.

  • Page 24: Connector X2 (Xtx™ Extension)

    The following subsystems can be found on connector X2. 4.2.1 As a part of the replacement to the no longer supported ISA bus, conga-X945/XA945 offers the LPC (Low Pin Count) bus through the use of Intel ®...

  • Page 25: Ac'97 / Hda (High Definition Audio) Digital Audio

    4.2.6 AC'97 / HDA (High Definition Audio) Digital Audio The conga-X945/XA945 provides an interface that supports the connection of AC'97 digital audio codecs as well as HDA audio codecs. For more information about this interface consult the XTX Design Guide.

  • Page 26: Connector X3

    82945GME chipset and is supported on both Display Pipe A and Pipe B. 4.3.4 Serial Ports (1 and 2) The conga-X945/XA945 offers two serial interfaces (TTL) that are provided by the Winbond W83627HG Super I/O controller located on the conga-X945/XA945. 4.3.5 Serial Infrared Interface Serial port 2 can be configured as a serial infrared interface.

  • Page 27: Keyboard/Mouse

    4.3.7 Keyboard/Mouse The implementation of these subsystems comply with ETX ® specification 2.7. Copyright © 2006 congatec AG X945m13 27/102...

  • Page 28: Connector X4

    The conga-X945/XA945 provides support for controlling ATX-style power supplies. In order to do this the power supply must provide a constant source of 5V power. When not using an ATX power supply then the conga-X945/XA945's pins PS_ON, 5V_SB, and PWRBTN# should be left unconnected.
  • Page 29 BIOS settings or by system software. Power Supply Implementation Guidelines 5 volt input power is the sole operational power source for the conga-X945/XA945. The remaining necessary voltages are internally generated on the module using onboard power supplies.

  • Page 30: Power Management

    25 figure 7 of the document “ATX12V Power Supply Design Guide V2.2”. 4.4.5 Power Management APM 1.2 compliant. ACPI 3.0 compliant with battery support. Also supports Suspend to RAM (S3). Copyright © 2006 congatec AG X945m13 30/102...

  • Page 31: Additional Features

    Additional Features 5.1 Watchdog The conga-X945/XA945 is equipped with a multi stage watchdog. This solution can be triggered by software and external OEM hardware (input pin is pin 48 on the X2 connector called WDTRG#). For more information about the Watchdog feature see the BIOS setup description section 9.4.13 of this document and application note...

  • Page 32: Simplified Overview Of Bios Setup Data Backup

    Simplified Overview of BIOS Setup Data Backup The above diagram provides an overview of how the BIOS Setup Data is backed up on congatec modules. OEM default values mentioned above refer to customer specific CMOS settings created using the congatec System Utility tool.

  • Page 33: Sdvo

    After the Automatic Reset has been triggered the congatec module can be powered off and if need be removed from the baseboard without losing the new CMOS settings.

  • Page 34: Conga Tech Notes

    Unlike the 8259 PIC, the I/O APIC interrupt priority is independent of the actual interrupt number. A major advantage of the I/O APIC found in the chipset of the conga-X945/XA945 is that it's able to provide more interrupts, a total of 24 to be exact. It must be mentioned that the APIC is not supported by all operating systems.

  • Page 35: Thermal Monitor And Catastrophic Thermal Protection

    (IRQs 14 and 15) and decreases the chance that there may be a shortage of interrupts when installing devices. Note If your operating system supports native mode then congatec AG recommends you enable it. 6.3 Thermal Monitor and Catastrophic Thermal Protection Intel Atom™, Core™...

  • Page 36: Processor Performance Control

    75% the clock is running 75% of the overall time and this leads to a performance decrease of approximately 25%. On the conga-X945 variant that is equipped with a Celeron M 440 1.86GHz CPU (article number 078965), the power consumption decreases approximately 3W when set to 75% duty cycle and 6W when set to 50% duty cycle.
  • Page 37 The following graphs provide examples of how each maximum frequency limitation setting, found in the 'BIOS Setup Program', affects power consumption of the Intel ® Core™ Duo processor variants. Copyright © 2006 congatec AG X945m13 37/102...
  • Page 38 Copyright © 2006 congatec AG X945m13 38/102...

  • Page 39: Thermal Management

    This results in the operating system having the ability to take control of the operating environment by implementing cooling decisions according to the demands put on the CPU by the application. The conga-X945/XA945 ACPI thermal solution offers three different cooling policies. Passive Cooling •...

  • Page 40: Acpi Suspend Modes And Resume Events

    See section 12 of the ACPI Specification 2.0 C for more information about passive cooling. 6.6 ACPI Suspend Modes and Resume Events conga-X945/XA945 supports the S1 (POS= Power On Suspend) state and S3 (STR= Suspend to Ram). For more information about S3 wake events see section 9.4.1 “ACPI Configuration Submenu”.
  • Page 41 When using Windows XP, Standby mode is either an S1 state or S3 state depending on what has been selected in the ACPI Configuration Menu in the BIOS setup program. For more information about this see section 9.4.1 of this document. Copyright © 2006 congatec AG X945m13 41/102...

  • Page 42: Usb 2.0 Ehci Host Controller Support

    Only 6 (USB ports 0-5) of the available 8 USB ports and only 3 (UHCI 0-2) of the available 4 UHCI host controllers are supported on the conga-X945. Within the EHC functionality there is a port-routing logic that executes the mixing between the two different types of host controllers (EHCI and UHCI).

  • Page 43: Signal Descriptions And Pinout Tables

    The “#” symbol at the end of the signal name indicates that the active or asserted state occurs when the signal is at a low voltage level.

  • Page 44: X1 Connector Signal Descriptions

    5V Tolerant Note Some signals have special functionality during the reset process. They may bootstrap some basic important functions of the module. For more information refer to section 7.9 of this user's guide. Copyright © 2006 congatec AG X945m13 44/102...
  • Page 45 Analog input (1 Vrms) AUXAR Auxiliary input A right 22k PD Analog input (1 Vrms) Microphone input 2k2 PU Analog input (1 Vrms) AudioVref ASGND Analog ground of sound controller ASVCC Analog supply of sound controller Copyright © 2006 congatec AG X945m13 45/102...

  • Page 46: Connector X1 Pinout

    AD21 AD23 USB1# CBE0# AD24 CBE3# AD25 AD26 AD10 AUXAL AD28 USB0 AD11 AD27 AD29 AD12 AUXAR AD30 USB1 AD13 ASVCC PCIRST# AD31 AD14 SNDL INTC# INTD# AD15 ASGND INTA# INTB# CBE1# SNDR Copyright © 2006 congatec AG X945m13 46/102...

  • Page 47: X2 Connector Signal Descriptions (Xtx™ Extension)

    (see note below) Note Some signals have special functionality during the reset process. They may bootstrap some basic important functions of the module. For more information refer to section 7.9 of this user's guide. Copyright © 2006 congatec AG X945m13 47/102...
  • Page 48 If both signals are each pulled-up (using 1k Ω resistors) to 3.3V at the rising edge of PWROK then x4 mode is enabled. x1 mode is used by default if these resistors are not populated. For more information refer to section 7.9 of this user's guide. Copyright © 2006 congatec AG X945m13 48/102...
  • Page 49 USB Port 5, data + or D+ I/O 3.3V USB 2.0 compliant and backwards compatible to USB 1.1 USBP5# USB Port 5, data - or D- I/O 3.3V USB 2.0 compliant and backwards compatible to USB 1.1 Copyright © 2006 congatec AG X945m13 49/102...
  • Page 50 Physical Presence to the TPM. Note Some signals have special functionality during the reset process. They may bootstrap some basic important functions of the module. For more information refer to section 7.9 of this user's guide. Copyright © 2006 congatec AG X945m13 50/102...

  • Page 51: X2 Connector Pinout

    SATA3_RX+(*) USBP4 SATA3_RX-(*) DACK2# USBP4# WDTRIG IRQ3 SLP_S3# SATALED# IRQ4 PCIE1_RX- SATA3_TX-(*) IRQ5 PCIE1_RX+ SATA3_TX+(*) IRQ6 IL_SATA# IRQ7 PCIE1_TX- PP_TPM SYSCLK PCIE1_TX+ SA10 RESERVED REFSH# PCE_WAKE# SA11 PCI_GNT#A(*) DREQ1 SLP_S5# SA12 PCI_REQ#A(*) DACK1# Copyright © 2006 congatec AG X945m13 51/102...
  • Page 52 SMEMW# AC_SDIN1 AC_SDIN2 AC_BIT_CLK FAN_TACHOIN NOWS# LPC_AD0 DREQ2 FAN_PWMOUT LPC_AD1 LPC_FRAME# IRQ9 LPC_AD2 LPC_DRQ0# LPC_AD3 IOCHK# LPC_DRQ1# RSTDRV Note The signals marked with an asterisk symbol (*) are not supported on the conga-X945/XA945. Copyright © 2006 congatec AG X945m13 52/102...

  • Page 53: X3 Connector Signal Descriptions

    Luminance for S-Video or Red for SCART PD 150R Analog output Chrominance for S-Video or Green for SCART PD 150R Analog output COMP Composite Video or Blue for SCART PD 150R Analog output Copyright © 2006 congatec AG X945m13 53/102...
  • Page 54 Keyboard Clock O 5V PU 8k2 5V MSDAT Mouse Data I/O 5V PU 8k2 5V MSCLK Mouse Clock O 5V PU 8k2 5V IRTX Infrared Transmit O 5V IRRX Infrared Receive I 5V Copyright © 2006 congatec AG X945m13 54/102...
  • Page 55 TX1OUT1- FPDDC_DAT LTGIO0 FPDDC_CLK BLON# BIASON (*) DIGON COMP SYNC(*) TX1= Channel 1 transmit TX2= Channel 2 transmit Note The signals marked with an asterisk symbol (*) are not supported on the conga-X945/XA945. Copyright © 2006 congatec AG X945m13 55/102...
  • Page 56 TXD2 TRK0# RI2# INDEX# RXD1 RTS1# DTR1# WDATA# DCD1# WGATE# DSR1# MSCLK CTS1# MSDAT TXD1 KBCLK RI1# KBDAT Note The signals marked with an asterisk symbol (*) are not supported on the conga-X945/XA945. Copyright © 2006 congatec AG X945m13 56/102...
  • Page 57 CTS2# TXD2 RI2# RXD1 ACK# RTS1# BUSY DTR1# DCD1# SLCT DSR1# MSCLK CTS1# MSDAT TXD1 KBCLK RI1# KBDAT Note The signals marked with an asterisk symbol (*) are not supported on the conga-X945/XA945. Copyright © 2006 congatec AG X945m13 57/102...

  • Page 58: X4 Connector Signal Descriptions

    Secondary IDE interrupt request N.C. DASP_S Secondary IDE Drive active N.C. PDIAG_S Secondary IDE Master/Slave negotiation N.C. HDRST# Hard Drive reset O 5V CBLID_P# Primary IDE 80 pin cable detect I 3.3V PD 10k Copyright © 2006 congatec AG X945m13 58/102...
  • Page 59 General purpose power management event I 3.3VSB PU 10k input 1 3.3VSB GPE2# General purpose power management event I 3.3VSB PU 10k input 2 3.3VSB EXTSMI# System management interrupt input I 3.3VSB PU 10k 3.3VSB Copyright © 2006 congatec AG X945m13 59/102...
  • Page 60 Not supported Note Some signals have special functionality during the reset process. They may bootstrap some basic important functions of the module. For more information refer to section 7.9 of this user's guide. Copyright © 2006 congatec AG X945m13 60/102...

  • Page 61: X4 Connector Pinout

    SIDE_INTRQ(*) PIDE_A1 GPE2# CBLID_P# BATLOW# GPE1# RXD# PIDE_D8 SIDE_AK#(*) PIDE_INTRQ SIDE_D7(*) SIDE_RDY(*) PIDE_AK# TXD# PIDE_D7 SIDE_IOR#(*) PIDE_RDY HDRST# Note The signals marked with an asterisk symbol (*) are not supported on the conga-X945/XA945. Copyright © 2006 congatec AG X945m13 61/102...

  • Page 62: Sdvo Connector X6

    7.8 SDVO Connector X6 Connector and flat foil cable information for the SDVO connector (X6) located on the bottom side of the conga-X945/XA945. Connector type Hirose 0.5mm Pitch Bottom Contact Type • Order no. FH12-45S-0.5SH (55) FFC type 45 positions, 30cm length, 0.5mm pitch both ends opposite sides •...
  • Page 63 SDAOUFP2 Custom Note Some signals have special functionality during the reset process. They may bootstrap some basic important functions of the module. For more information refer to section 7.9 of this user's guide. Copyright © 2006 congatec AG X945m13 63/102...

  • Page 64: Boot Strap Signals

    If it is necessary to drive a TTL input (or another input which sources or sinks significant current) that uses the TXD1 signal, a CMOS-input buffer can be inserted in the signal path so that this line is not pulled up or down by external circuitry during system reset. Copyright © 2006 congatec AG X945m13 64/102...

  • Page 65: System Resources

    Note T.O.M. = Top of memory = max. DRAM installed * VGA frame buffer can be reduced to 1MB in setup. ** Only if ACPI Aware OS is set to YES in setup. Copyright © 2006 congatec AG X945m13 65/102...

  • Page 66: I/O Address Assignment

    8.2 I/O Address Assignment The I/O address assignment of the conga-X945/XA945 module is functionally identical with a standard PC/AT. The most important addresses and the ones that differ from the standard PC/AT configuration are listed in the table below. Table 37...

  • Page 67: Lpc Bus

    8.2.1 LPC Bus On the conga-X945/XA945 the PCI Bus acts as the subtractive decoding agent. All I/O cycles that are not positively decoded are forwarded to the PCI Bus not the LPC Bus. Only specified I/O ranges are forwarded to the LPC Bus. In the congatec Embedded BIOS the following I/O address ranges are sent to the LPC Bus: 280 –...
  • Page 68 2. If the ATA/IDE configuration is set to enhanced mode in BIOS setup (serial ATA and parallel ATA native mode operation), IRQ14 and 15 are free for PCI/LPC bus. Copyright © 2006 congatec AG X945m13 68/102...

  • Page 69: Direct Memory Access (Dma) Channels

    1. If the corresponding device is disabled in BIOS setup then the DMA channel can be used by customers hardware. 2. Not available if Parallel Port is used in ECP mode (Enhanced Parallel Port). Copyright © 2006 congatec AG X945m13 69/102...

  • Page 70: Pci Configuration Space Map

    2 instead of bus number 3, Port 4 will be assigned bus number 3 and the onboard LAN controller as well as the standard PCI slots will be assigned bus number 4. Furthermore, the respective PCI Express Root Port is hidden if the Copyright © 2006 congatec AG X945m13 70/102...

  • Page 71: Pci Interrupt Routing Map

    ² Interrupt used by single function PCI Express devices (INTA). ³ Interrupt used by multifunction PCI Express devices (INTB). Interrupt used by multifunction PCI Express devices (INTC). Interrupt used by multifunction PCI Express devices (INTD). Copyright © 2006 congatec AG X945m13 71/102...

  • Page 72: Pci Bus Masters

    8.7 PCI Bus Masters The conga X945 supports 4 external PCI Bus Masters. There are no limitations in connecting bus master PCI devices. Note If there are two devices connected to the same PCI REQ/GNT pair and they are transferring data at the same time then the latency time of these shared PCI devices can not be guaranteed.

  • Page 73: Bios Setup Description

    See setup node in the “BIOS Setup Program” section 9.6.1 “Security Settings”. 9.2 Setup Menu and Navigation The congatec BIOS setup screen is composed of the menu bar and two main frames. The menu bar is shown below: Note Entries in the option column that are displayed in bold print indicate BIOS default values.

  • Page 74: Main Setup Screen

    Serial Number no option Displays the serial number of the board. BC Firmware Rev. no option Displays the revision of the congatec board controller. MAC Address no option Displays the MAC address of the onboard Ethernet controller. Boot Counter no option Displays the number of boot-ups.

  • Page 75: Advanced Setup

    Boot Security Power Exit ACPI Configuration PCI Configuration Graphics Configuration CPU Configuration Chipset Configuration I/O Interface Configuration Clock Configuration IDE Configuration USB Configuration Keyboard/Mouse Configuration Remote Access Configuration Hardware Health Configuration Watchdog Configuration Copyright © 2006 congatec AG X945m13 75/102...

  • Page 76: Acpi Configuration Submenu

    In ACPI mode it is not possible for a “Watchdog ACPI Event” handler to directly restart or shutdown the OS. For this reason the congatec BIOS will do one of the following: For Shutdown: An over temperature notification is executed. This causes the OS to shut down in an orderly fashion.
  • Page 77 Windows will remain at a blue-screen after a 'Watchdog ACPI Event” that has been configured for 'Restart' has been generated. Below is a Windows screen-shot showing the proper configuration. Win XP/2000 Watchdog ACPI Event restart configuration Copyright © 2006 congatec AG X945m13 77/102...

  • Page 78: Pci Configuration Submenu

    2nd Exclusive PCI IRQ None, [IRQs assigned The selected IRQ will only be assigned to the PIRQ line it has been set to manually. PIRQs set to AUTO will not be assigned this IRQ. manually above] Copyright © 2006 congatec AG X945m13 78/102...

  • Page 79: Graphics Configuration Submenu

    Auto detection is performed by reading an EDID data set via the VGA 1x18 (013h) video I²C bus. SVGA 1x18 (001Ah) The number in brackets specifies the congatec internal number of XGA 1x18 (006h) the respective panel data set. XGA 2x18 (007h) Note: Customized EDID™...
  • Page 80 Select TV standard that should be supported. TV connection type VBIOS-Default is automatically detected by the Video BIOS. NTSC SECAM SMPTE240M ITU-R television SMPTE295M SMPTE296M EIA-770.2 EIA-770.3 TV Sub-Type (Options depend on Select sub-type for selected TV standard. selected TV standard) Copyright © 2006 congatec AG X945m13 80/102...

  • Page 81: Cpu Configuration Submenu For Conga-X945 Variants Only

    Automatic or Maximum Speed. Used when the system is battery powered. Note: This option is not available for Celeron M CPUs. This node is only visible when the system is connected to a congatec battery system. On Demand Clock Allows a reduction of the performance of the processor by utilizing clock...

  • Page 82: Cpu Configuration Submenu For Conga-Xa945 Variants Only

    Set boot CPU speed when powered by battery. ACPI OS may still change Battery Maximum the speed if SpeedStep is enabled. Intel C-State tech. Enabled Enable support for standard C states. Disabled Enhanced C-States Enabled support for enhanced C states. Enabled Disabled Copyright © 2006 congatec AG X945m13 82/102...

  • Page 83: Chipset Configuration Submenu

    Reserve PCIE Hotplug Reserve I/O and memory resources for empty PCI Express slots. Resources Setting a PCI Express port to Enabled and reserving resources is required for ExpressCard hotplug support on the respective port. Copyright © 2006 congatec AG X945m13 83/102...
  • Page 84 Disabled Enable Enabled PCIE Port 0 IOxAPIC Enable support for IOAPIC behind PCI Express port. Disabled Enable Enabled PCIE Port 0 IOxAPIC Disabled Enable support for IOAPIC behind PCI Express port. Enable Enabled Copyright © 2006 congatec AG X945m13 84/102...

  • Page 85: I/O Interface Configuration Submenu

    IRQ5 Specifies the interrupt for the parallel port. IRQ7 Serial Port 3/4 Disabled Specifies the I/O base address and IRQ of serial port 3/4. Configuration 3F8/IRQ11, 2F8/IRQ10, 3E8/IRQ11, 2E8/IRQ10, 3F8/IRQ10, 2F8/IRQ11, 3E8/IRQ10, 2E8/IRQ11 Copyright © 2006 congatec AG X945m13 85/102...

  • Page 86: Clock Configuration

    Select the mechanism for detecting 80Pin ATA(PI) cable. Detection Note: The use of an 80-conductor ATA cable is mandatory for Host running UDMA66 and faster hard disk drives. The standard 40- Device conductor ATA cable cannot handle the higher speeds. Copyright © 2006 congatec AG X945m13 86/102...

  • Page 87: Primary/Secondary Ide Master/Slave Submenu

    ARMD, it is required that you emulate boot up from a floppy or hard disk drive. Hard disk drive This is essentially necessary when trying to boot to DOS. You can select the type of emulation used if you are booting such a device. Copyright © 2006 congatec AG X945m13 87/102...

  • Page 88: Usb Configuration Submenu

    Number of seconds the legacy USB support BIOS routine waits for the Reset Delay 20 Sec USB mass storage device after the start unit command. 30 Sec 40 Sec ►USB Mass Storage sub menu Opens sub menu. Device Configuration Copyright © 2006 congatec AG X945m13 88/102...

  • Page 89: Usb Mass Storage Device Configuration Submenu

    Use this setting if you always need PS/2 mouse support even when the mouse is not connected at boot-up time. Auto lets the BIOS check for a connected PS/2 mouse and enable support if one is connected. Copyright © 2006 congatec AG X945m13 89/102...

  • Page 90: Remote Access Configuration Submenu

    Set the delay in seconds to display memory information if serial Delay redirection is enabled. Delay 1 Sec Delay 2 Sec Delay 4 Sec Serial Port BIOS Enable or disable the serial port BIOS update feature. Disabling Disabled Update saves boot time. Enabled Copyright © 2006 congatec AG X945m13 90/102...

  • Page 91: Hardware Monitoring Submenu

    Current Core A reading. VcoreB no option Current Core B reading. +3.3Vin no option Current 3.3V reading. +5Vin no option Current 5V reading. +5VSB no option Current 5V standby reading. VRTC no option Current VRTC reading. Copyright © 2006 congatec AG X945m13 91/102...

  • Page 92: Watchdog Configuration Submenu

    5sec 10sec 30sec 1min 2min Timeout 2 see above Selects the timeout value for the second stage watchdog event. Timeout 3 see above Selects the timeout value for the third stage watchdog event. Copyright © 2006 congatec AG X945m13 92/102...

  • Page 93: Boot Setup

    USB CDROM 8 boot devices can be USB Removable Dev. prioritized.) Onboard LAN External LAN PCI Mass Storage PCI SCSI Card Any PCI BEV Device Third Master Third Slave PCI RAID Local BEV ROM Copyright © 2006 congatec AG X945m13 93/102...

  • Page 94: Boot Settings Configuration

    1. The term 'AC power loss' stands for the state when the module looses the standby voltage on the 5V_SB pins. On congatec modules, the standby voltage is continuously monitored after the system is turned off. If after 30 seconds the standby voltage is no longer detected, then this is considered an AC power loss condition.

  • Page 95: Security Setup

    BIOS flash ROM chip. END-Key Loads CMOS If set to Yes, the user can force the loading of CMOS defaults by Defaults pressing the END key during POST. Copyright © 2006 congatec AG X945m13 95/102...

  • Page 96: Hard Disk Security

    Set or clear the master password for the hard disk. Master/Slave HDD Note: This option will be shaded if the hard drive does support the Master Password Security Mode Feature set but user failed to unlock the drive during BIOS POST. Copyright © 2006 congatec AG X945m13 96/102...

  • Page 97: Power Setup

    System Time Hour:Minute:Second Select the system time when the event should be generated. Power Button Mode Specifies if the system enters suspend or soft off mode when the On/Off power button is pressed. Suspend Copyright © 2006 congatec AG X945m13 97/102...

  • Page 98: Exit Menu

    Exit setup without saving any changes made in the BIOS setup program. Discard Changes Discard changes without exiting setup. The option values presented when the computer was turned on are used. Load CMOS Defaults Load the CMOS defaults of all the setup options. Copyright © 2006 congatec AG X945m13 98/102...

  • Page 99: Additional Bios Features

    The conga-X945/XA945 uses a congatec/AMIBIOS that is stored in an onboard Flash Rom chip and can be updated using the congatec System Utility, which is available in a DOS based command line, Win32 command line, Win32 GUI, and Linux version.

  • Page 100: Bios Recovery Via Serial Port

    Serial Redirection allows video and keyboard redirection via a standard RS-232 serial port. For more information about “Serial Port and Console Redirection” refer to application note AN2_Remote_Control.pdf, which can be found on the congatec AG website at www.congatec.com. 10.4 BIOS Security Features The BIOS provides both a supervisor and user password.

  • Page 101: Hard Disk Security Features

    POST to prevent their misuse. Without this protection it would be possible for viruses or malicious programs to set a password on a drive thereby blocking the user from accessing the data. Copyright © 2006 congatec AG X945m13 101/102...

  • Page 102: Industry Specifications

    11 Industry Specifications The list below provides links to industry specifications that apply to congatec AG modules. Specification Link Audio Codec ‘97 Component Specification, Version 2.3 http://www.intel.com/design/chipsets/audio/ (AC ’97) Low Pin Count Interface Specification, Revision 1.0 (LPC) http://developer.intel.com/design/chipsets/industry/lpc.htm Universal Serial Bus (USB) Specification, Revision 2.0 http://www.usb.org/home...
