Summary of Contents for exturn RC-11XE
- Page 1 D O C K I T E A S Y Installation & User Manual Radio Remote RC-11XE w w w . m a r i n n o . c o m i n f o @ m a r i n n o . c o m...
-
Page 2: Table Of Contents
Programming additional transmitters ................... 7 Replacing the batteries ....................... 8 User precautions ........................9 How to use Exturn thrusters ...................... 10 Service Partners ........................12 Model range The radio remote control can control a single bow thruster or a bow and stern thruster combined. -
Page 3: Technical Specifications
When additional transmitters are to be used, the receiver must be programmed again for all transmitters (please see programming section on page 7). • If a Exturn automatic main switch is fitted, the “OFF” button on your transmitter will shut off the main switch providing no other control panels are “ON”. -
Page 4: Receiver Installation
Receiver installation Prior to installation, it is important that the responsible installer reads this guide to ensure necessary acquaintance with this product. Warning! • Remote receiver power supply negative lead must be connected to the thrusters`s negative lead. Caution! • Install the receiver minimum 1 meter (3ft) from high power cables and NMEA cables or other sources of electrical interference, i.e. - Page 5 Installation & User Manual, Radio Remote RC11E Page 5...
-
Page 6: Visual Wiring Diagram
Receiver installation If the receiver is mounted against a wall, us spacers Mount the receiver by using between the receiver and the the 2 screwholes. wall to avoid moisture in the receiver. Visual wiring diagram To bow thruster To bow thruster To bow thruster To bow thruster To bow thruster control panel... - Page 7 Programming additional receivers Push the Pair Button with a plastic stick The original transmitter and receiver have the same factory preset code so that no programming is necessary. When additional transmitters are to be used, the receiver must be programmed again for all transmitters.
-
Page 8: Replacing The Battery
Replacing the battery Battery WARNING: Before working on the transmitter, deactivate the transmitter and the receiver (push “OFF” on the transmitter(s)) and turn off the power to the receiver as well as the thruster mainswitch. 1. Open the transmitter. 2. Take out the battery by inserting a screwdriver or similar between battery and holder at point A, and gently flip the battery out, taking care not damaging the battery grips at point B 3. -
Page 9: User Precautions
(batteries) so that the thruster can be turned off in case of a malfunction. • If a Exturn automatic main switch is fitted, the “OFF” button on your transmitter will shut off the main switch providing no other control panels are “ON”. - Page 10 Windlass Remote control “ON” Turn boat to Port Down Turn boat to Starboard Remote control “OFF” Auto-OFF appr. 4 min. Hold for 2 seconds How to use a bowthruster 1. Turn the main power switch for the bow thruster on. Turn on the power to the receiver. 2.
- Page 11 Electric schematics 4-lead & 1-lead connector Bow Thruster Windlass Channel B Channel A External relays for windlass requiring signal output over Coil voltage depend of voltage supply. Output current of relay depend of load form winch last. At least 3 time normal current. Installation &...
- Page 12 SIDE-POWER SERVICE CENTRES Argentina Estonia/Latvia/Lithuania Japan Spain Trimer SA Miltec Systems OÜ Turtle Marine Inc. Imnasa Marine Products Buenos Aires Tallin Nagasaki Girona Tel:+54 11 4580 0444 Tel: +372 5013997 Tel:+81 95 840 7977 Tel:+34 902 300 214 Fax:+54 11 4580 0440 Fax: +372 6442211 Fax:+81 95 840 7978 Fax:+34 902 300 215...
