Summary of Contents for MARSH SOUND DESIGN HT 4000
- Page 1 High Resolution Audio-Video Processor HT 4000 Marsh Sound Design...
- Page 3 Marsh Sound Design n your acquisition of your new HT 4000 product by Marsh Sound Design. This product is a fully integrated, high resolution, Audio/Video control center. It incorporates the most exacting and accurate surround sound technology available for home theater. As such, this product...
- Page 4 Marsh Sound Design Your new product was diligently handcrafted, thoroughly tested and carefully packed at our factory in California, USA In the unlikely event that this product is damaged during shipment, be sure to save the carton as evidence for the freight carrier's inspection and call your local dealer immediately.
- Page 5 Marsh Sound Design Be sure to complete and return your Product Warranty registration card immediately. This will entitle you to our extended warranty as outlined in the section titled “Warranty”. he model number and serial number of this product can be found on either the back or the bottom of the unit.
-
Page 6: Table Of Contents
Marsh Sound Design RECOMMENDATIONS GENERAL RECOMMENDATION SETUP RECOMMENDATIONS LISTENING RECOMMENDATION QUICK SET UP SPEAKER SIZE SPEAKER DISTANCE INPUT ASSIGNMENT BASS TRIM CALIBRATION COMPRESSION STATUS DISPLAY DVD AUDIO FULL RANGE REST TO DEFAULTS ADVANCE SET UP NAME CHANGE SET UP YOUR VIDEO MONITOR... -
Page 7: Recommendations
• Perform Quick Set Up ZONE 2 CD changer Listening Recommendation Please note that your new HT 4000 will improve sonically over the course of the first week. After the first week, you will notice that the sound of your new product has become... -
Page 8: Quick Set Up
Marsh Sound Design Quick Set Up Press menu on remote main menu will show 1. QUICK SET UP -SPEAKER SIZE on monitor 2. QUICK SET UP -SPEAKER DIST 3. INPUT ASSIGNMENT 4. TUNER/PAL/NTSC SETTING 5. BASS TRIM 6. CALIBRATION 7. COMPRESSION 8. -
Page 9: Input Assignment
Marsh Sound Design Input assignment 1. Press 3 input assignment you will change the defaults if they are not what you INPUT VIDEO require press the input you would like to 1. VCR1 ANALOG change and it will blink. 2. VCR2 ANALOG 2. -
Page 10: Compression
Marsh Sound Design Compression This is used to lower the dynamic so you can listen at low volume and still here the dialog. This doest give the best sound it is only meant for vary low volumes. 1, to turn on compression press 7 when in the main menu. -
Page 11: Advance Set Up Name Change
Marsh Sound Design Advanced set up. Input name change 1. Press menu 2. Press 3 input assignment 3. Press the input you want to rename, 4. Press guide on remote 5. The rename screen will come up at the top it will give you the default for that input, the current name and 5 X for the new name. -
Page 12: Set Up Your Vcr
Marsh Sound Design Set up your VCR We will use VCR1 input. 1. Connect a s- video cable from your VCR to the s-video input of VCR1 if your VCR does not have a s-video output use the composite Composite... -
Page 13: Set Up A Audio Video Source With Digital Out Put And Change Source Name
Marsh Sound Design Set up an audio video source with a digital output and change the default name DVD, DISH, SATELITE, GAME, CABLE BOX We will use the AUX input and a cable box for this instruction 1. Connect an s-video from the cable box s- video out to the s-video input of the aux input. -
Page 14: Controls And Functions
Marsh Sound Design Remote Control 1. POWER: This turns the unit off and into standby 2. Mute: This mutes the unit 3. TV: Toggles NTSC-PAL 4. Vol: Volume up 5. Vol: Volume down 6. CH: Seek up 7. CH: Seek down 8. -
Page 15: Remote Control Learning Mode
Marsh Sound Design Remote Control Learning MODE The remote allows you to transfer a command from a button on your source remote control (original equipment remote control) to a button on the remote control. New commands can be taught to any button in the CD, DVD, AUX, SAT, TVVCR and CBL device modes, except on the LIGHT button. -
Page 16: Front Panel Control
Marsh Sound Design Front Panel Controls Figure 1. HT 4000 Front Panel Controls. POWER SWITCH SEEK DOWN BUTTON Switches the unit into STANDBY mode. The When this button is pressed and the tuner LED turns on. Do not turn this switch off to Source is selected the tuner will advance to turn the system off press the off button. -
Page 17: Rear Panel Connections
TO PREVENT ELECTRICAL SHOCK OR HARM, DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. FOR CONTINUED PROTECTION AGAINST RISK OF FIRE OR DAMAGE REPLACE FUSES WITH THE TYPE AND CURRENT RATING SPECIFIED. Figure 2. HT 4000 Rear Panel. Digital Audio Inputs 13. -
Page 18: General Operation Of Unit
Marsh Sound Design 4.Mode button. This button toggles between General operation of unit Dolby Prologic logic2 music, Dolby Prologic Power up unit logic 2 movie, DTS neo6 music, and DTS 1. Press power button all the way in. this neo6 cinema as the default for 2chanel turns on the power and puts the unit in Sources with no flags. -
Page 19: General Zone 2 Operations
Marsh Sound Design General Zone 2 operations Inputs for zone 2 are 1. CD 2. TAPE 3. TUNE 4. ZONE 2 AUX To select a zone 2 input you press the zone 2 sift key and then the input you desire. The volume up down, seek up down, mute, work for zone 2. -
Page 20: General Precaution
Marsh Sound Design General precautions 1. Never install unit near heating outlets 2. Make sure there is ventilation around unit 3. Unit must be installed in a dry place free from any rain water. 4. Do not stack unit on top of any heat source 5. -
Page 21: Replacing The Ac Power Fuse
Marsh Sound Design Replacing the AC Power Fuse 1. Turn the unit off. 2. Disconnect the AC power cord. 3. Slide open the fuse drawer completely. 4. Remove and replace the fuse in the rear compartment. Use fuse type 5 x 20 mm 1.0 Amp. -
Page 22: Trouble Shooting Guide
Marsh Sound Design Trouble Shooting the Basics Problems Solutions NO sound, Status indicator and display are Check if AC power cord is securely plugged in. Check AC power fuse, replace if necessary. NO sound, Status indicator and display are Check all RCA cables for proper connections. -
Page 23: Specifications
Marsh Sound Design AUDIO/VIDEO SECTION Input Level 200 mVrms Output Level (Pre-amp) 3.5 Vrms Input Impedance 15K ohms Total Harmonic Distortion less than 0.03 % Frequency Response 20 Hz to 20 kHz ( 3 dB) © © Stereo Bypass mode... - Page 26 M a r s h MARSH SOUND DESIGN Email: sales@marshsounddesign.com www.marshsounddesign.com Tel: (415) 927-4672 Fax: (415) 924-6846 62 El Camino Drive, Corte Madera, CA 94925...
