Western Technology 9610A Operating Instructions

Operating Instructions: 9610A - Brick LED Light, Rev.A
Western Technology, Inc.
3517 Arsenal Way,
Bremerton, WA 98312
Tel: 800-654-5483
www.westerntechnologylights.com
READ CAREFULLY AND COMPLETELY

Description:

1. The 9610A Brick LED Light is one of a family of similar Lights (9610A, B, C, and D)
manufactured by Western Technology, Inc. The 9610A is UL and CSA Certified
Explosion Proof compliant for use in:
Class I Division 1 & 2, Zone 1 & 2, Groups C, D
Class II Division 1 & 2, Zone 20, 21 & 22, Groups F, G
Suitable for Wet Locations
2. The 9610A Brick LED Light is equipped with 96 High Bright White LEDs with a
Color Temperature of 6000°K +/- 200°K. Altogether the 96 LEDSs generate 50,000
Lux at 1-foot with a spectral range of 410 to 700 nm having no UV emission.
3. The 9610A Brick LED Light, with a variable T4/T5 temperature rating (see product
label) utilizes integrated Temperature Control Safety Technology
operating temperature so that a safe T4 Thermal Rating is never exceeded. If
automatically engaged by working and ambient conditions, the processor will
temporarily reduce the light (and thus heat) output, which ensures safety in field
Operation.
4. The standard 9610A Brick LED Light model features a fixed 60° Beam Angle
reflector optic.
6. The 9610A Brick LED Light is designed to allow in the field addition of beam
diffusion and filter materials as well as polycarbonate lens protectors.
7. The 9610A Brick LED Light is fitted with Steel Discs on four sides of the light body
to facilitate versatile magnetic and mechanical mounting and connecting options
specifically engineered for this light.
Western Technology, Inc., 3517 Arsenal Way, Bremerton, WA 98312
Telephone: 800-654-5483; www.westerntechnologylights.com
9610A Brick LED Light
Operating Instructions
Page: 1 of 4
TM
to monitor
