UCView RackMedia Xtreme Installation Manual

RackMedia Xtreme Installation Manual
Thank you for purchasing the UCView RackMedia Xtreme player. Please match the items on
the list below with the items in the box. If any item is missing or damaged, please contact your
UCView Media Networks sales representative immediately.

One (1) RackMedia Xtreme player

One (1) Power supply

One (1) Cable cord

One (1) or two (2) antenna(s)
Note: RackMedia Xtreme player will arrive with one (1) or two (2) antenna(s), depending on the
model.
Installing your RackMedia Xtreme Player:
1) Remove packaging - make sure box and plastic casings are stored away in case a
return is necessary.
2) Plug in the LAN/Ethernet cable into the RackMedia Xtreme player.
3) Plug in your video source, HDMI or DVI cable, into the RackMedia Xtreme player and
the monitor.
4) Plug in the Power cable into the RackMedia Xtreme player.
LAN/Ethernet
Note:
* A DVI to VGA converter will enable you to plug in a VGA screen.
* A DVI to HDMI converter will enable you to plug in more HDMI screens.
HDMI
transmitting high-definition video and high-resolution audio.
DVI (Digital Video Interface): A cable which is capable of providing digital video signal.
VGA (Video Graphics Array): An analog cable which enables connection from your
computer to a monitor.
LAN/Ethernet:
network, such as PCs and routers.
HDMI
(High-Definition Multimedia Interface): A single cable which is capable of
A LAN/Ethernet cable can connect to devices over a local area
18425 Napa St. Northridge, CA 91325
DVI
www.ucview.com
1-818-772-8255
Power
