Summary of Contents for Solaric MIG-HMP50
- Page 1 MIG-HMP50 INSTRUCTION MANUAL...
- Page 2 The SOLARIC MIG-HMP50 solar power system consists of a 50W solar panel, a solar charge controller, battery, mod sine inverter and comes with 2 LED light bulbs, a multi-headed USB charger, and a DC fan. Solar power is converted into electricity;...
- Page 3 11. Do not exceed the load limit that the system can supply, or it may cause damage to the system. Remove the packaging: Please open the packaging and check whether the system is damaged during transportation; make sure there are all the accessories. Please contact the manufacturer or distributor immediately, if you find it is damaged or some accessories are missing.
- Page 4 Back panel show as below 1: AC Output ports 2：Battery main switch（Attention：switch must be in the ON position when charging) 3：Solar panel charge input port 4：AC fuse 5：AC switch 6：DC12V fuse 7：DC12V Output port...
-
Page 5: Installation
Installation Steps： 1. The solar panels should be installed in assigned places; Attention: when installing, the solar panel should face toward the sun, and the best angle of inclination is 15° (according to the local latitude) to assure the solar panel will work normally. Do not install the panel in shade or even partly shaded areas 2. -
Page 6: Battery Status Indicator
Solar power system control panel function introduction When system is harvesting sun，the charge indicator light is green. That means the system normal. When the battery is overvolted, the green indicator flashes quickly. Indicator state System state Steady on Normal charge Quick flashing Battery overvoltage Battery status indicator：... - Page 7 ○ ○ ○ ＜13.4V × ○ ○ ＜12.8V × × ○ ＜12.4V × × × “○” Light is on “×” Light is off Loading state indicator： When system is charging, the indicator light is on. When the loading voltage over 1.25 times rated load current for 60 seconds，or 1.5 times rated load current 5 seconds, it means it is overloaded, and the indicator light will flash slowly.
- Page 8 ○ ○ （Flooded） ○ AC Inverter Operation Mode Power output This system continued output：150W, with a small surge capacity of 300w. Do NOT plug in heavy loads like microwaves, refrigerators, pumps, electric kettles, etc. This is meant to run laptop and device chargers, small LCD TVs 19" and below.
-
Page 9: Specifications
Description Protection Outcome function LED light buzzing AC output Output low Green light “ buzzing” voltage When battery voltage normalizes, light will turn Input low green and system will voltage Red light on Auto shut OFF automatically go back on protection When battery voltage Input over... - Page 10 Output wave Modified sine wave ＞85% Max transfer efficiency ＜0.45A No-load current Input voltage shortage DC 10.2 – 10.8V Input under voltage DC 9.2 – 9.8V shut off Input over voltage shut DC 15 – 16V The best working environment 5 –...
- Page 11 ·Loading short out If a loading short out happens, the controller has automatic protection. After the controller automatically restores output, press the on/off button to reset. Explosion Danger! When replacing the battery, it must be an open type lead acid battery.
-
Page 12: Safety First
Overloading ： Please reduce electric equipment ， Press the Loading indicator low overloaded switch ，and in 3 seconds the flashing system will recovery output； First time: wait 10 seconds，it will reset itself. Or press switch for 3 seconds and it will go Loading indictor light Loading short out back to normal. -
Page 13: Claim Procedure
The system is warranted to be free from defects for a period of one year from the date of sale. Claim Procedure Before requesting warranty service, check the Manual to be certain that there is a problem with the system. If it cannot be solved, return the defective system to us with freight prepaid and provide proof of date and place of purchase. - Page 14 Warning Safety First Incorrect operation or installation may be dangerous or lead to unexpected damage. Please read the instruction carefully before operating. You should pay much attention to the messages of warning and attention. The messages of attention remind you that it may cause damage to the system or other equipment in certain condition or operating methods.
- Page 15 Attention Attention: This system has a modified sine wave inverter. Some chargers that charge nickel-cadmium battery are not suitable to connect the AC Output terminal, it may destroy the charger, such as small battery-driven appliances, rechargeable flashlight, electric shaver and searchlight, etc. So is the same with the battery chargers that are marked with some warning information that there exists dangerous voltage in the battery terminal.
-
Page 16: Product Specification
Above-mentioned information is critical to handle your warranty claim rapidly. Product specification Model No. MIG-HMP50 Mono solar panel Maintenance free lead acid battery 24AH Rated system voltage 12VDC Battery end max voltage Battery rated current ≤0.26V...
