Summary of Contents for Erbauer ERB069PRW

  • Page 3 Congratulations on your purchase of a quality power tool from Erbauer. This product should give you reliable service but for your peace of mind this power tool does carry a 12-month guarantee, the terms of which are detailed below. If this product develops a fault within the guarantee period contact your retailer.
  • Page 4: Equipment Description

    We wish to thank you for choosing our machine. We are confident that the high quality of our machine will meet with your satisfaction and appreciation and that your pressure washer will give you long-lasting service. Before starting to use your machine, make sure to read with care this manual, which has been purposely drawn up to provide you with all the necessary information for proper use of the machine, in compliance with basic safety requirements.
  • Page 5 WARNING WARNING This warning symbol identifies specific instructions or procedures, which if not correctly followed could result in personal WARNING injury or death. CAUTION CAUTION This caution symbol identifies specific instructions or procedures, which, if not strictly observed, could result in damage to, or destruction of equipment.
  • Page 6 22. To prevent accidental discharge, the spray gun should be secured by locking the trigger when not in use. 23. Do not operate this product when fatigued or under the influence of alcohol or drugs. 24. To allow free air circulation, the pressure washer should NOT be covered during operation.
  • Page 7 Turbo nozzle head Spray gun with high-pressure hose Holder for power cable I/O switch High-pressure hose connector Threaded water inlet Wand with adjustable nozzle Holder for accessories Water plug 10. Screen filter 11. Garden hose inlet nipple...
  • Page 8: Technical Data

    TECHNICAL DATA TECHNICAL DATA Running Pressure 87bar Max. Pressure 130 bar Max. Flow Rate 300 litres per hour Rated Voltage/Frequency 230-240V/50Hz Max. Motor Capacity 1600W IP Degree IPX5 Siphon Pipe Use liquid detergent approved for pressure washers Shipping Weight 16 kg Guaranteed sound power level 94dB (A) KNOW YOUR PRESSURE WASHER...
  • Page 9: Water Connection

    ASSEMBLY ASSEMBLY HIGH-PRESSURE HOSE HIGH-PRESSURE HOSE Remove and discard the water plug (Fig.1). Attach the high-pressure hose by carefully inserting the fitting with the o-ring into the high-pressure outlet and tightening the threaded nut by hand (Fig.1). Fig.1 WATER CONNECTION WATER CONNECTION Before connecting,run water through the garden hose (not supplied) to flush out any foreign matter.
  • Page 10: Power Supply Connection

    POWER SUPPLY CONNECTION POWER SUPPLY CONNECTION The pressure washer is factory-equipped with an electrical cord. This cord should only be connected to an electrical outlet installed in accordance with local safety regulations. WARNING A. Connect only to a properly earthed outlet. ALWAYS use RCD adaptor with this product.
  • Page 11: Operation

    OPERATION OPERATION WARNING: WARNING: Risk of injection or injury. Do not direct discharge WARNING stream at persons or animals. START-UP PROCEDURE START-UP PROCEDURE 1. Make sure water supply is connected and turned on. 2. Make sure the unit is plugged in. 3.
  • Page 12 WARNING: WARNING: If the wand is not securely locked into place,it could be ejected under high pressure when operating the gun, possibly WARNING causing injury or damage. squeeze trigger on the spray gun. Now put on your safety goggles, then 8.
  • Page 13: Adjustable Spray Nozzle

    When low-pressure is required,grasp collar and slide collar and nozzle away from the gun. (Fig.7) ADJUSTABLE SPRAY NOZZLE ADJUSTABLE SPRAY NOZZLE The adjustable spray nozzle can adjust from fan to jet in the high-pressure position only. The spray is adjusted by turning the nozzle (Fig.8). CAUTION: CAUTION: The jet spray adjustment is very powerful, and potentially...
  • Page 14: High-Pressure/Turbo Spray

    HIGH-PRESSURE/TURBO SPRAY HIGH-PRESSURE/TURBO SPRAY CAUTION: CAUTION: CAUTION Do not try to adjust the turbo nozzle. The high-pressure turbo nozzle (Fig.9) is intended for maximum cleaning effect. Keep the spray wand 6-8'' away from the cleaning surface al all times. DETERGENT USE DETERGENT USE CAUTION: CAUTION:...
  • Page 15 CLEANING Techniques CLEANING Techniques When cleaning with the pressure washer, some cleaning tasks can be completed with water alone,but for most tasks it is advantageous to use a detergent. A detergent ensures a quick soaking of the dirt allowing the high-pressure water to penetrate and remove the dirt more effectively.
  • Page 16 1. Make sure that the pressure washer is turned off and that the power cord is unplugged. 2. Make sure that the water supply is turned off, and that the trigger is squeezed to depressurise the unit. 3. Separate the nozzle from the wand (Fig.12) 4.
  • Page 17: Cooling System

    CAUTION: CAUTION: Do not damage the screen while removing or cleaning. Any foreign particles entering the pump may cause damage. CAUTION COOLING SYSTEM COOLING SYSTEM The air vents, located in and around the pressure washer, must be kept clean and free of any obstructions to ensure proper air cooling of the motor during Never spray water directly onto the pressure washer for cleaning.
  • Page 18: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING PROBLEM PROBLEM POSSIBLE CAUSE POSSIBLE CAUSE C OMMON C OMMON SOLUTIONS SOLUTIONS Motor will not start or Extension cord length Use proper extension cord. See Operator's stops while operating. or gauge incorrect.Loose Manual section 2.0. or disconnected power Reconnect power plug.
